Elkay LFAE8S1Z User manual

SPECIFICATIONS
Elkay Cooler Floor Mount Filtered Refrigerated 8 GPH Stainless
Model LFAE8S1Z
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com for
the most current version of Elkay product specification sheets. This specification describes an Elkay product with design,quality, and functional benefits to the user.
When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 09102021 1333 Butterfield Road, Suite 200 © 2021 Page 1
LFAE8S1Z Downers Grove, IL 60515 LFAE8S1Z_spec.pdf
PRODUCT SPECIFICATIONS
Elkay Cooler Floor Mount Filtered Refrigerated 8 GPH Stainless.
Chilling Capacity of 8.0 GPH (gallons per hour) of 50F drinking water,
based on 80F inlet water and 90F ambient, per ASHRAE 18 testing.
Features shall include Filtered. Furnished with Flexi-Guard ® Safety
Bubbler. Mechanical Top Bubbler Button activation. Product shall be
Floor Mount/Freestanding, for Indoor applications, serving 1 station(s).
Unit shall be certified to UL 399 and CAN/CSA C22.2 No. 120. Unit
shall be lead-free design which is certified to NSF/ANSI 61 & 372 (lead
free) and meets Federal and State low-lead requirements.
Special Features:
Filtered
Finish:
Stainless Steel
Power:
115V/60Hz
Bubbler Style:
Flexi-Guard ® Safety Bubbler
Activation by:
Mechanical Top Bubbler Button
Mounting Type:
Floor Mount/Freestanding
Chilling Capacity*:
8.0 GPH
Full Load Amps
5
Rated Watts:
370
Dimensions (L x W x H):
18" x 14-1/2" x 41-1/2"
Approx. Shipping Weight:
83 lbs.
Installation Location:
Indoor
No. of Stations Served:
1
*Based on 80° F inlet water & 90° F ambient air temp for 50° F chilled
drinking water.
Mechanically-Activated bubbler continues to supply water in
event of service disruptions.
Filter is certified to NSF 42 and 53 for lead, particulate,
chlorine, taste and odor reduction. 1,500 gal. capacity.
COOLING SYSTEM
Compressor: Hermetically-sealed, reciprocating type,
single phase. Sealed-in lifetime lubrication.
Condenser: Fan cooled, copper tube with aluminum
fins. Fan motor is permanently lubricated.
Cooling Unit: Combination tube-tank type. Continuous
copper tubing with is fully insulated with EPS foam that
meets UL requirements for self-extinguishing material.
Refrigerant Control: Refrigerant R-134a is controlled by
accurately calibrated capillary tube.
Temperature Control: Easily accessible enclosed
adjustable thermostat is factory preset. Requires no
adjustment other than for altitude requirements.
Included with Product:
Water Cooler,
Filter
Ships in one box.
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that
endure. For almost a century, Elkay has been a family-owned and
operated company, providing thousands of jobs that support our
families and communities.
PRODUCT COMPLIANCE
ASME A112.19.3/CSA B45.4
Buy American Act
CAN/CSA C22.2 No. 120
NSF/ANSI 42, 53, 61, & 372 (lead free)
UL 399
Installation Instructions (PDF)
5 Year Limited Warranty on the refrigeration system of the unit.
Electrical components and water system are warranted for 12 months
from date of installation. Warranty pertains to drinking water
applications only. Non-drinking water applications are not
covered under warranty.
Warranty (PDF)
Optional Accessories
PART:________________________________QTY: _____________
PROJECT:______________________________________________
CONTACT:______________________________________________
DATE:__________________________________________________
NOTES:_________________________________________________
APPROVAL:_____________________________________________

SPECIFICATIONS
Elkay Cooler Floor Mount Filtered Refrigerated 8 GPH Stainless
Model LFAE8S1Z
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com for
the most current version of Elkay product specification sheets. This specification describes an Elkay product with design,quality, and functional benefits to the user.
When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 09102021 1333 Butterfield Road, Suite 200 © 2021 Page 2
LFAE8S1Z Downers Grove, IL 60515 LFAE8S1Z_spec.pdf
51299C
Elkay WaterSentry VII Replacement Filter (Coolers + Fountains)
Spec Sheet (PDF)
LK1110
Elkay Glass Filler
Spec Sheet (PDF)
97446C
Accessory - Bubbler Kit Vandal-Resistant
Spec Sheet (PDF)
