Elpine 31110c User manual

31110c
• Super silent
• Compact and
lightweight design
• Carrying handle
• Portable fan heater
• Adjustable
thermostat control
• Fan only setting
• Cool blow
• Indicator light
• Cord storage
• Over heat protection
• Safety thermal cut-out
• Dual heat settings
• 1000W/2000w
• 230V - 50hz 2000w
1000/2000w Electric
Fan Heater

USER INSTRUCTIONS
Read all the instruction carefully before you use the appliance
and keep it for future use.
DO NOT TURN RADIATORS UPSIDE-DOWN DURING OPERATION
PreParation before oPerating
1. Check if the electrical voltage of the main supply and the load of the socket match the
rated voltage and power marked on the rating label of the appliance.
2. Check if the socket and the plug are undamaged and put the plug well in the socket.
3. Put the appliance on a stable and flat surface for no risk of falling down.
4. Be sure that there is enough space for the fan heater while operating, at least 50 cm
around the appliance, and right before the air outlet, the distance should be at least
120 cm.
Safety PrecautionS
1. Don’t cover the fan heater at any time when operating.
2. Don’t hung it on the wall.
3. Don’t use it on the carpet with long fluff.
4. Don’t use the heater in the immediate surrounding of a bath, a shower or a swimming
pool.
5. Don’t insert sticks or any other objects to either the air inlet or the outlet of the
appliance.
6. Don’t put the appliance immediately below a electrical socket.
7. Don’t put the appliance near a fire.
8. Keep children away from the heater.
9. Keep flammable and explosive objects away from the heater.
10. In case of malfunction or abnormal operation, don’t attempt to open or repair the
appliance at home, send the heater to appointed service agent for inspection and
repair.
11. If the power cord is damaged, it must be replaced by the appointed service agent or a
similarly qualified person.
oPeration inStructionS
1. Turn the thermostat switch to the minimal value, at the same time turn the heat select
switch to the “O” position (see picture).
2. Plug in the appliance, and turn the thermostat switch to the maximum position. Then
turn the heat select switch to choose air or warm air and the temperature of warm air
as below. While working the indicator light will be on.
2.1 Turn the heat select switch to “ “ position, the heater blows cool air.
2.2 Turn the heat select switch to “I” position, the heater blows warm air, working at 1000W.

2.3 Turn the heat select switch to “II” position, the heater blows warm air, working at
2000W.
2.4 Turn the heat select switch to “O” position, the heater stops working, the indicator
light will be off.
3. Adjust the thermostat switch to suitable position for desired temperature setting.
3.1 Check if the thermostat switch is on the maximum position.
3.2 When you feel the room temperature comfortable, turn the thermostat switch anti-
clockwise slowly to the minimal position until the appliance stops working.
3.3 Then the thermostat switch will keep the room temperature at the desired
temperature automatically.
3.4 You can also turn the thermostat switch anti-clockwise to the minimum position or
turn the thermostat switch clockwise to maximum position to make the temperature
lower or higher.
Security SyStem
1. To avoid risk to human being or damage to internal components, the fan heater has a
security system which will automatically switch off the appliance if the heat reaches
the safety limit. If overheating occurs:
1.1 Turn the heat select switch to “O” position, turn the thermostat switch to the minimal
position and remove the plug from the socket.
1.2 Check if the air flows smoothly before the outlet and inlet, and if the appliance is put
in right position. If so, get it in order before restart the appliance.
1.3 Let the fan heater cool down for 8 to 10 minutes before you start it again.
1.4 Plug in the appliance and switch it on. If the appliance can’t operate normally,
remove the plug immediately from the socket and have the fan heater serviced by an
appointed service only.

maintenance and cleaning
1. Before you turn off the appliance, turn the heat select switch to the “ “ position.
After operating for 3 to 5 minutes to lower the internal temperature of appliance, then
turn the heat select switch to “O” position.
2. Clean the air inlet and air outlet of the appliance regularly (at least twice a year
normally).
3. Before you clean the appliance, turn off the heater first, then remove the plug from
the socket, and wait until the appliance cools down.
4. Use a damp cloth to clean the surface of appliance, avoid water going inside the
appliance, dry the appliance before use or store.
This appliance is not intended for use by persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for
their safety.
ElEctric Fan HEatEr 1000/2000w
correct diSPoSal of thiS Product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the
return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.

UK plUg rewiring
Your appliance operates on 220-240V-SOHz AC Mains and comes fitted with a 3-pin
BSI Approved plug, so that it is ready for use by simply plugging into AC Mains.
Should you need to change or refit a plug, proceed as follows:
imPortant:
The wires in the mains lead are coloured in
accordance with the following code:
BLUE : NEUTRAL (N)
BROWN : LIVE (L)
GREEN &YELLOW : EARTH (E)
As the colours of the wires in the mains lead
of this appliance may not correspond with the
coloured markings identifying the terminals in
you plug, proceed as follows:
The wire which is coloured BLUE must be
connected to the terminal which is marked with the letter “N” or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is
marked with the letter “L or coloured RED.
The wire which is coloured GREEN & YELLOW must be connected to the terminal
which is marked with the letter “E” or or coloured GREEN.
Always ensure that the Mains Cord is located into the Plug through the Cord Guard
or Cable Clamp, and that the Cord Guard screws are lightened to clamp the Cord
(outer sheath and inner coloured wires) in position in the Plug. Make sure the Plug
top is also fitted securely.
This appliance must be protected by a 13-amp fuse in a 13-amp type (BS1363) plug.
Should you need to replace lhe fuse, use only an ASTA approved BS 1362 fuse.
