Trotec IR 1500 SC User manual

TRT-BA-IR1500SC-IR1510SC-IR2000SC-TC2020-21-002-EN
IR 1500 SC / IR 1510 SC / IR 2000 SC
EN
OPERATING MANUAL
RADIANT HEATER

2 EN
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................2
Information about the device................................................5
Transport and storage...........................................................6
Assembly and installation.....................................................6
Operation ...............................................................................8
Errors and faults....................................................................9
Maintenance ..........................................................................9
Technical annex...................................................................10
Disposal ...............................................................................10
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning of hot surface
This symbol indicates dangers to the life and health of
persons due to hot surface.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
IR 1500 SC
https://hub.trotec.com/?id=44541
IR 1510 SC
https://hub.trotec.com/?id=44912
IR 2000 SC
https://hub.trotec.com/?id=44914
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.

EN 3
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
Warning
Children of less than 3years should be kept away from
the device unless continuously supervised.
Children aged from 3years and less than 8years shall
only switch on/off the appliance provided that it has
been placed or installed in its intended normal
operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Children aged from 3years and less than 8years shall
not plug in, regulate and clean the appliance or
perform user maintenance.
Warning
Do not use the device in small rooms if persons are
present who cannot leave the room independently and
who are not under constant supervision.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Parts of the device may become hot and may produce arcs
or sparks. Do not use this device in the vicinity of fuel,
solvents, varnishes or other easily inflammable and/or
explosive vapours or in rooms where these substances are
stored. Keep device away from open fire and hot surfaces
and do not store or operate it in their vicinity.
• Let the device dry out after a wet clean. Do not operate it
when wet.
• Do not use the device with wet or damp hands.
• Do not expose the device to directly squirting water.
• Never insert any objects or limbs into the device.
• Do not insert objects into the ventilation inlets. Failure to
comply may result in electric shock, fire or damage to the
device if this is not observed.
• Do not use the device as source of ignition.
• Do not cover or transport the device during operation.
• This appliance is not a toy! Keep away from children and
animals. Do not leave the device unattended during
operation.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The electrical connection must correspond to the
specifications in chapter Technical data.
• Insert the mains plug into a properly secured mains
socket.
• If possible, do not use extensions to the power cable as
they can overheat and cause a fire. If you need to use an
extension to the power cable, make sure its length is at
least1.5m.
• Observe the device's power input, cable length and
intended use when selecting extensions to the power
cable. Completely unroll extension cables. Avoid electrical
overload.
• Do not guide the power cable underneath carpets. Do not
cover the electric cable with carpets or similar fabrics. Lay
the electric cable away from walkways to avoid trip
hazards.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.
• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the power cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk!
• During the installation of the device observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
data chapter.
• Do not use the device in immediate proximity to curtains,
beds or sofas.
• Do not transport the device during operation.
• Allow the device to cool down before transport and/or
maintenance work.
• Do not use this device near bathtubs, shower trays,
swimming pools or other water containers. Risk of electric
shock!
• The device must not be installed directly beneath a socket.
• The device must be set up in a way that the switches and
controllers cannot be touched by a person in a bathtub or
shower.
• The device must not be used with a programming switch,
timer, separate remote control system or similar
equipment that switches the device on automatically, as
this could cause a fire hazard if the heater is covered or
positioned incorrectly.
• Make sure that the air inlet is not obstructed. Risk of fire!
Do not use the device on soft surfaces (e.g. on a bed) as
this may block the air inlet.
• Make sure that no inflammable material such as curtains,
roller shutters, flags, plastic sheeting etc. covers the
device due to wind or other weather conditions.

4 EN
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
• Never use the device after it has been dropped.
If the device has been dropped, it must be inspected and,
if necessary, repaired by the manufacturer, its customer
service or a similarly qualified person in order to avoid
hazards.
Intended use
Use the device for heating surfaces in indoor and roofed areas.
The device is only intended for ceiling installation.
Intended use comprises:
• heating surfaces
– in storage facilities,
– in construction areas,
– in containers,
– in the catering trade,
– at trade fairs and events,
– in roofed outdoor areas (e.g. covered terraces).
Foreseeable misuse
The device is not intended for industrial use.
• Do not place any objects, e.g. clothing, on the device.
• Do not use the device for heating in vehicles.
• Do not use this device in the vicinity of fuel, solvents,
varnishes or other easily inflammable vapours or in rooms
where these substances are stored.
• The device may not be used as a heating device for
babies / children or animals.
• The device may not be installed inside a shower or directly
above a bathtub.
• The device must not be used near swimming pools.
• Do not use this device in the immediate vicinity of sinks,
bathtubs or other water containers.
Never immerse the device in water.
• The device may not be exposed to moisture or weather
effects (rain, sunlight).
• Any other use than the one described in the chapter
"Intended use" is regarded as reasonably foreseeable
misuse.
Any unauthorised changes, modifications or alterations to the
device are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
electric devices in damp areas.
• have read and understood the operating manual, especially
the Safety chapter.
Maintenance tasks which require the housing to be opened
must only be carried out by specialist electrical companies or by
Trotec.
Symbols on the device
Symbols Meaning
This symbol located on the device indicates that it
is prohibited to place objects (such as towels,
clothes etc.) above or directly in front of the
device.
In order to avoid overheating and fire hazards, the
heater must not be covered.

EN 5
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
Residual risks
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of electrical voltage
Before any work on the device, remove the mains plug
from the mains socket!
Do not touch the mains plug with wet or damp hands.
Hold onto the mains plug while pulling the power cable
out of the mains socket.
Warning of hot surface
Some parts of this product can become very hot and
cause burns. Particular attention has to be given where
children and vulnerable people are present!
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
Improper installation or mounting entails a risk of fire.
Warning
Risk of injury due to infrared radiation!
Do not stay in the device's immediate vicinity for too
long. Do not look directly into the device for too long.
Observe the minimum distances.
Warning
In order to avoid overheating and fire hazards, the
device must not be covered!
Warning
Coarse dirt particles on the heating rods can cause the
device to overheat. Fire hazard!
Remove coarse dirt particles from the heating rods
according to the Maintenance chapter before switching
on the device.
Behaviour in the event of an emergency
1. Switch off the device.
2. In an emergency, disconnect the device from the mains
feed-in: Hold onto the mains plug while pulling the power
cable out of the mains socket.
3. Do not reconnect a defective device to the mains.
Information about the device
Device description
The device is used to quickly generate instant heat.
The device is based on the functional principle of heat
generation by infrared radiation. The infrared radiation is
generated by a carbon heating element and emitted to the
surrounding surfaces as heat radiation. Persons or objects are
heated directly.
The 3heating levels can be selected using the remote control.
• suitable for the application in roofed outdoor areas
• for ceiling installation
• silent operation
• no dust circulation (suitable for allergy sufferers)
The three devices differ in terms of their technical data and
design. Later in the operating manual, the device IR 1500 SC is
depicted as an example.

6 EN
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
Device depiction
1
1500W
1000W500W
3
2
4
5
6
No. Designation
1 Bracket for ceiling mounting
2 Heating coil
3 Operating light
4 On/off switch
5 Grille
6 Remote control
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
Before transporting the device, observe the following:
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not use the power cable to drag the device.
• Allow the device to cool down sufficiently.
Storage
Before storing the device, proceed as follows:
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down sufficiently.
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• in an upright position where it is protected from dust and
direct sunlight
• with a cover to protect it from invasive dust, if necessary
• Place no further devices or objects on top of the device to
prevent it from being damaged.
• Remove batteries from the remote control.
Assembly and installation
Scope of delivery
• 1x Device
• 2x Carabiner hooks
• 1x 50cm fastening chain
• 3x Cable tie
• 1 x Remote control
• 1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.

EN 7
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
Assembly
The device is intended for ceiling installation. Observe the
following requirements for the installation:
Warning
Risk of fire due to improper installation!
There is a risk of fire if the required minimum
distances are not observed.
Observe the Installation chapter and the technical data
in the Technical annex.
Warning
There is a risk of the device falling down if the required
minimum carrying capacity for the ceiling has not been
observed.
Select or mount a ceiling holder suitable for the weight
of the device (see technical data) and the structure of
the ceiling. The ceiling and the holder must be able to
hold a weight3 to4times heavier than the device. The
device must only be mounted to a solid ceiling surface.
1. Hook one carabiner to one end of the fastening chain and
to the bracket for ceiling mounting(1).
2. Connect the other carabiner hook with the mounting on the
ceiling.
3. Fasten the device on the ceiling by hooking one chain link
into the carabiner on the mounting on the ceiling. In doing
so, observe the minimum distances from the ceiling and to
the ground.
4. Check the clips of the carabiner hooks for closure.
5. Make sure that the on/off switch(4) is in position"0".
6. Guide the mains cable along the chain link and fasten the
mains cable with cable tie. Note that the mains cable must
not make contact with the device.
Installation
When installing the device, observe the minimum distances
from walls and other objects as described in the Technical data
chapter.
• Never install the device in a way that it radiates directly
onto walls or other objects. Observe the minimum
distances from walls or other objects according to the
Technical data chapter.
• Only install the device in a horizontal position.
A
B
CC

8 EN
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
Start-up
Info
Odours might arise upon initial start-up or after a
longer period of non-use.
• Before restarting the device, check the condition of the
power cable. If there are doubts as to the sound condition,
contact the customer service.
• Do not create tripping hazards when laying the power
cable or other electric cables, especially when positioning
the device in the middle of the room. Use cable bridges.
• Make sure that extension cables are completely unrolled.
• Make sure that there are no curtains or similar objects in
the immediate vicinity.
Prior to initial start-up, insert batteries in the remote control.
Connecting the power cable
• Insert the mains plug into a properly secured mains power
socket.
• Make sure that the power cable is guided along the back
of the device. Never guide the power cable along the front
of the device!
Operation
Operating elements
4
3
Remote control
P3
P2P1
7
8
9
10
No. Designation Meaning
3 Operating light Illuminated in red in standby mode
Illuminated in green during operation
4 On/off switch For switching the device on or off
7 Power button Switching the heating capacity on or off
8P1 button Selecting the low heating capacity
IR 1500 SC/IR 1510 SC: 500W
IR 200 SC: 650W
9P2 button Selecting medium heating capacity
IR 1500 SC/IR 1510 SC: 1000W
IR 200 SC: 1350W
10 P3 button Selecting a high heating capacity
IR 1500 SC/IR 1510 SC: 1500W
IR 200 SC: 2000W
Switching the device on
Once you have completely installed the device as described in
the Start-up chapter, you can switch it on.
1. Set the on/off switch(4) to"I".
ðThe operating light(3) is illuminated in red.
ðThe device is now in standby mode.
2. Press the on/off switch(7).
3. Press the corresponding button(8,9,10) to set the desired
heating level.
ðDuring operation the operating light(3) is permanently
illuminated in green.
ðThe device now starts heating at the selected heating
level.
Shutdown
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
Info
If you switch off the device via the remote control, the
device will be set to standby mode. If standby
operation is not required, you can switch the device off
using the mains switch.
• Switch off the device by pressing the on/off button(7) on
the remote control at first. Then set the on/off switch(4) on
the device to"0".
• Allow the device to cool down completely.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Clean the device according to the Maintenance chapter.
• Store the device according to the Storage chapter.

EN 9
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
Errors and faults
Warning of electrical voltage
Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The device does not start:
• Check the power connection.
• Check the power cable and mains plug for damages.
• Check the on-site fusing.
• Wait for 10minutes before restarting the device. If the
device is not starting, have the electrics checked by a
specialist company or by Trotec.
The device does not emit heat:
• The heating element may be defective. If the heating
element is defective, have it replaced by a specialist
electrical company.
• Check the on/off switch(4). If the switch is set to the"0"
position, the device is switched off. Switch the device on.
RCD or another fuse trips:
• Check the fuse. Switch off any other devices to reduce the
load on the line.
• Contact a specialist electrical company.
The device slightly vibrates during switch-on and then
stops vibrating:
• Slight vibrations during switch-on are a normal process.
No measures are required.
The device does not respond to the infrared remote control:
• Check whether the distance between remote control and
device is too large and reduce it if necessary.
• Make sure there are no obstacles, such as furniture or
walls, between the device and the remote control. Ensure
visual contact between device and remote control.
• Check the charging status of the batteries and change
them if required.
• If the batteries have just been changed, check them for
correct polarity.
Note
Wait for at least 3 minutes after maintenance and
repair work. Only then switch the device back on.
Your device still does not operate correctly after these
checks?
Please contact the customer service. If necessary, bring the
device to an authorised specialist electrical company or to
Trotec for repair.
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down completely.
Warning of electrical voltage
Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.
Cleaning the device
Warning of electrical voltage
Never immerse the device in water!
Warning of hot surface
Do not touch the reflector or the heating rods with bare
hands.
Clean the device with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Wipe the housing dry after cleaning.
Dirt on the heating rods should be removed with a long brush
with soft bristles.

10 EN
radiant heater IR 1500 SC / IR 1510 SC / IR 2000 SC
Technical annex
Technical data
Parameter Value
Model IR1500SC IR1510SC IR2000SC
Heating capacity 500 / 1000 /
1500W
500 / 1000 /
1500W
650 / 1350 /
2000W
Power supply 220-240V/
50-60Hz
220-240V/
50-60Hz
220-240V/
50-60Hz
Plug type CEE 7/7 CEE 7/7 CEE 7/7
Protection class IP34 IP34 IP34
Dimensions
(lengthx widthx
height)
420 x 420 x
240mm
425 x 425 x
300mm
605 x 605 x
300mm
Minimum distance
to walls and other
objects:
top (A):
bottom (B):
sides (C):
front:
30cm
180cm
100cm
100cm
50cm
180cm
100cm
100cm
50cm
180cm
100cm
100cm
Weight 1.5kg 2.5kg 3kg
Remote control
battery
type
CR2025/ 3V
type
CR2025/ 3V
type
CR2025/ 3V
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website https://de.trotec.com/shop/.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
In the European Union, batteries and accumulators must not be
treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2006/66/EC of the
European Parliament and of the Council of 6September 2006
on batteries and accumulators. Please dispose of batteries and
accumulators according to the relevant legal requirements.

Trotec GmbH
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
