Elpress PS710 Series Parts list manual

Technical description PS710
Doc.No. 5204-009000A Date: 171128 Approved by : AM
Change No. 19460
Page 1 ( 3 )
PS710D
PS710E
PS710R

Technical description PS710
Doc.No. 5204-009000A Date: 171128 Approved by : AM
Change No. 19460
Page 2 ( 3 )
HYDRAULIC PUMP
Pressure range 0-700 bar, default setting for PS710E and PS710R is 630
bar.
Oil ow at 20 bar 0.6 dm³/min. 1.0 dm³ for PS710D.
Oil volyme 1 dm³
Oil type Hydrex MV22 or similar
Dimensions 370x170x280 mm (lxwxh)
Weight 12,4 kg
Battery (PS710E) Panasonic EY9L82B32, 28.8 V 3,0 Ah Li-ion.
Battery charger (PS710E) Panasonic quick charger EY0L81 10.8-28.8 V.
Charging time: 65 min.
Mains power 85-276 V AC 50/60 Hz
Ambient temperature -15° C - +40° C
Protection IP54
No of crimps/charging 120 pcs of Cu terminals 150mm²
Sound level Max 73 db(A)
Control handle Attendance button/Start function
Reset button/Stop function (red colured)
Others Elpress PS710 Analyzer software for crimp process
control. USB connection to PC, cable included in software
kit. CAN bus system with PS710D and CS2500.
CE requirements met Machine safety 2006/42/EU
Electro magnetic compatibility 2014/30/EU
Low voltage directive 2014/35/EU
ROHS 2011/65/EU
WEEE 2012/19/EU

Technical description PS710
Doc.No. 5204-009000A Date: 171128 Approved by : AM
Change No. 19460
Page 3 ( 3 )
DESCRIPTION OF FUNCTIONS
When the pump has been switched on, the stop button on the handle or the foot pedal has to
be activated once before the pump is ready to be used. By pressing the start button the pump
motor starts and oil ows into the crimp tool cylinder.
The pump continues to work until it reaches 630 bar, the system will automatically unload and
tool will retract. A crimp cycle can be interrupted by releasing the start button and restarted
again by pushing the start button. A crimp cycle can be ended by pushing the stop button at
any time and the tools will retract.The stop button has functional priority to the start button.
In the electronic control system for PS710E and PS710D every crimp characteristic as well as
the crimp Id No is recorded and saved. All the crimps can be analyzed afterwards or on-line in
real time by using the Elpress Analyzer software.
Several error messages in the display can facilitate troubleshooting
Stop button stuck Signal cable not connected or damaged
Battery low Charge or change battery
Motor temp high Improve air ventilation around pump
Log memory full Use "Clear logs" in main menu
High motor current Contact Elpress
Time for service Time for preventive mainenance
PS710R is made without electronic control system but have the same functions regarding
start/stop buttons.
Turn the power on the pump and just press the start button to get the pump working.
ACCESSORIES
Hydraulic hose, with or without spiral cable 2.5m or 5m, ERGO or ERGOCOM
PS710EBP battery
PS710EBC charger (For Eu and China + USA)
PS710FCU foot control unit
PS710 Analyzer software
Strap
Mains cable (For EU, China, USA)
