Thank you for purchasing ELVIRA Handheld Vacuum
Cleaner - CYCLONE
This appliance is intended only household use. Please read the instructions
carefully before rst usage and pay special attention to the safety warnings.
Follow all instructions in this manual. Place it where easy to access whenever
you need.
CONTENT
Safety Precautions 11
Parts Description 13
Specications 14
Operation 15
Cleaning & Storage 16
Warranty Conditions 17
Contact Us 18
11
SAFETY PRECAUTIONS
• Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,
sensoryormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeen
givensupervisionorinstructionconcerningtheuseoftheappliancebyapersonresponsible
fortheirsafety.Neverletchildrenplaywithit.
• Whentheapplianceisswitchedon,don’tleaveitrunningalone.
• Don’tleavetheappliancepluggedinwhenun-attended.Unplugwhenitisnotinusedand
beforeservicing.
• Don’timmersetheapplianceintowateroranyotherliquids.
• Nevervacuumammablesubstancesorcorrosiveliquidsanddon’tvacuumashesuntilthey
arecold.Useonlyondrysurfaces.
• Don’t attempttousetheappliancebeyondtherecommendedrangeofapplicationinthis
manual.
• Keephair,looseclothes,face,ngersandallpartsofbodyawayfromopeningandmoving
parts.
• Don’tusewethandtotouchplugorcable,oroperatetheappliance.
• Turnothehandheldvacuumcleaner’spowerswitchbeforeunplugorplugthepower.
• Whennishingusingtheappliance,holdtheplugtounplugsmoothlyandstraightly.
Don’tpullcable.
• Aseverevibrationwilldamagetheappliance.
• Don’tusetheappliancewithoutthedustcuplterinplace.
• Thisapplianceisprovidedwithdoubleinsulation.Useonlyidenticalreplacementpartsfrom
ELVIRAServiceCenter.
1. Inspect the Handheld Vacuum Cleaner Before Start:
• Inspecthandheldvacuumcleaner’sinputandoutputcableconnectionandplug.Checkifthe
inputpowersupplyisincompliancewiththerequirement.
• Don’tusetheproductwithadamagedpowercord.Ifthepowercordisdamaged,contact
ELVIRAservicecenterforrepairing,changingthequaliedsparepart.
2. After Usage:
• Topreventtheappliancefromanaccidentaloperation,alwaysunplugfrompowersupply.
• Don’tplacethehandheldvacuumcleanernearbyanyheatsourcesuchas,re,radiator,
heater,airblower,etc.
• Neverattempttocoverthehothandheldvacuumcleanerimmediatelyafteruse.Leaveitfor
cooldowninairowarea.
• Storetheapplianceindoorsinacool,dryarea.
12
3. Maintenance and Service:
• Alwaysunplugtheplugbeforemaintenanceorservice.
• Ifanyoffollowingproblemsisfound,pleasetakethehandheldvacuumcleanertoELVIRA
servicecenter.ReparationmustbedonebyELVIRAservicecenter,inordertoavoidahazard.
-Iftheapplianceoranypartoftheapplianceisdamaged.
-Ifsometroubleisfound.
-Ifthesupplycordisdamaged
• Neverattempttomaketechnicalamendmentoftheappliancesuchaselectricsystem,
anysparepartsortechnicalparameters,etc.
• Warrantywillbeterminatediftheapplianceismodiedorrepairedbyotherperson,
notELVIRAserviceagents.
13
Main Components and Accessories:
1.ON/OFFSwitchSlider
2.PowerCord
3.DustContainerReleaseButton
4.BottomLidReleaseButton
5.AluminumTelescopicTube
6.ECOFloorBrush
7.Multi-functionCurtainBrush
8.2in1CombinedNozzle
9.Filter
10.FilterHolder
11.DustContainer
12.DustCupFilter
14
SPECIFICATIONS:
RatedVoltage : AC220-240V
Frequency : 50/60Hz
RatedPower : 800W
DustCapacity : 0.8Liter
ProductNetWeight : 1.3kgs*
ProductDimension : 330x120x200mm*
*Onlyhandleunit
Precautionary Measures:
Important:Ifnozzle,brush,orthehoseisblocked,switchothevacuumcleanerandremovethe
blockingsubstancebeforeyoustarttheunitagain.
• Don’toperatethevacuumcleanertooclosetoheaters,radiatorsorcigarettebutts.
• Beforeinsertingthepowerplugintothewalloutlet,makesurethatyourhandsaredry.
• Beforeyoustartvacuuming,makesuretoremovelargeorsharpobjectsthatmightdamage
thedustcuplter.
• Whenpullingoutthepowerplugfromthewalloutlet,pulltheplugnotthepowercord.
• Don’tpickupanythingthatisburningorsmokingsuchascigarettes,matchesorhotashes.
• Don’tusewithoutdustcuplterinplace.
15
OPERATION
1.Removethepowerplugfromthewalloutletbeforeassemblingorremovingaccessories.
2. Insertingthealuminumtelescopictubesintothemainbody.Checkiftheconnectionisrmly.
3. Assemblenozzleorbrushthatappropriateswithusage.
4. Checkthepowercordandplugtomakesuretheyareingoodcondition.Insertthepluginto
themainspowersupply.
5. Switchonbyslidetheon/obutton(1);Pushuptoturn“ON”,pushdowntoturn“OFF”.
6. Afternishusingtheappliance,unplugfromthemainspowersocket.
7. Cleanthedustcupandlter.Keeptheapplianceinair-owcooldryplace.
Caution: Thesuctionholemustbeopenandfreeofanyobstructionsatalltimes.
Otherwise,themotorwilloverheatandcouldbecomedamaged.
The following are recommendations for accessory usage:
ECOFloorBrush(6)-Forallkindsofooring,includingcarpetedandtiledoors.
Multi-functionCurtainBrush(7)–ForCabinettop,highshelf,ceiling,curtain.
2in1CombinedNozzle(8)-Forradiators,crevices,corners,staircase,bed,base-boardsand
betweencushions.
Changing and Cleaning the Dust Cup Filter
• Inordertoachievethebestperformance,emptythedustcontainer(11)andcleanthelter(9)
aftereachuse.
16
CLEANING & STORAGE
• Releasedustcontainer(11)bypressingthereleasebutton(3)
• Afterdustcontainerisdisconnectedfromtheappliancebody,holdrmlythecoverofdust
container,thenturnitclockwisetounscrewthecoverandpullout.Youwillseethelter(9)
inside.
• Inthemiddleofthelter,thereislterholder(10).Holditrmlythenturnitcounter-clockwise
topulloutthelter(9).Cleanthelterwithcleanwater.
• Pullout&rinsethedustcuplter(12)incoldwater,andthenletitair-dryfor24hoursbefore
replacingitbackinthedustcontainer(11).
• Do notimmersetheappliancebodyintowater.Ifthereisanydirt,usedryclothtowipeout.
ImportantNote:DO NOTuseawashingmachinetocleanthedustcuplterorlter.Do not
useahairdryertodryit.NaturalAIR-DRYONLY.
• Replacethedustcuplter(12)carefullyintothedustcontainer(11).NEVERoperatethe
vacuumwithoutthedustcuplterinplace.
• Attachthedustcupcontainertothemainbodyoftheunit.
• Duringusageyoucansimplytrashdustfromdustcontainer(11)
byreleasingthebottomlid(4)afterswitcho.
Trouble Shooting:
PROBLEM REASON SOLUTION
TheVacuumNot
Operate
TheVacuumNot
Pick-uporSuction
PowerisWeak
TheDustEscaping
FromtheAppliance
• Nopowerinelectricaloutlet.
• Dustcupcontainerisfull.
• Dustcuplterneedsclean
• Dustcupcontainerisfull.
• Dustcuplterisnot
installedcorrectly.
• Dustcoverairduct.
• Checkfuseorbreaker.
Replacefuse/resetbreaker.
• Emptydustcupcontainer.
• Removedustcuplterandcheck
forobject(s)inairductandremove.
Cleanorreplacedustcuplter.
• Chargeunit.
• Emptydustcupcontainer.
• Reviewdustcuplterinstallation
instructions.
• Cleanorreplacedustcuplter.
17
WARRANTY CONDITIONS
Thishandheldvacuumcleanerhas1-yearwarrantysincethedayofpurchase.Theconditions
ofwarrantyareasfollowing:
• Thewarrantywillnotcoverforthepartsorsparepartsthatiswornduetonormalusage.
• ELVIRAacceptsnoliabilityforfaultsinyourapplianceintheeventofnoncompliancewiththe
specicationsofthewarrantyconditionsorfailuretofollowtheoperatingormaintenance
directionsincludedinthisinstructionmanual.
• Warrantywillbeterminatediftheapplianceismodiedorrepairedbyotherperson,
notELVIRAserviceagents.
• Thisapplianceisforhouseholdusage.Thewarrantywillbeterminatediftheapplianceisused
forcommercialpurpose.
• Thewarrantywillnotcoverfortheunitthatisnotfullypaidorthetermofpaymenthasnot
beencompleted.
• Thewarrantywillnotcoverforthedamagethatoccurredbyaccident,lostorstolen.
• Thewarrantywillcoveronlyfortheunitthatserialnumberindicatedonthewarrantycard
attached.
• Foryourrighttoclaimwarranty,customerhastoshowwarrantycardtoELVIRAserviceagents
beforeusingtheservice.
• Wheneverthereisanyproblemoccurred,pleasetakeyourappliancetoELVIRAservice
centernearby.
Thismarkingindicatesthatthisproductshouldnotbedisposedwithother
householdwastesthroughouttheEU.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,recycleit
responsiblytopromotethesustainablereuseofmaterial
resources.Toreturnyouruseddevice,pleaseusethereturnand
collectionsystemsorcontacttheretailerwheretheproductwas
purchased.Theycantakethisproductforenvironmentalsaferecycling.
CORRECT DISPOSAL OF THIS PRODUCT
