emaux HP35A Service manual

A p p l i c a b l e M o d e l :
H P 3 5 A
H P 1 0 5 A
H P 5 0 A
H P 1 3 5 A
H P 9 0 A
EMHP20113001

1. PREFACE 1
2. SPECIFICATION 2
2.1 Parameter of swimming pool heat pump unit 2
2.2 Dimension of swimming pool heat pump unit 3
Swimming pool Heat Pump
SWIMMING POOL HEAT PUMP UNIT
Installation & Instruction Manual
Contents
4. GUIDELINES 9
4.1 Water chemistry 9
4.2 Winterizing 9
4.3 Spring startup 9
4.4 Owner Inspection 10
5. Operating Instructions 11
6. Unit status checking 14
7. Factory parameter 15
8. Fault code table 16
9. Wiring Diagram 17-20
3. INSTALLATION 5
3.1 Heat pump location
3.2 How to close to the pool
3.3 Distance from the pool
3.4 Installation of the check-valve
3.5 Pool system set up
3.6 Connecting the by-pass
3.7 Electrical wiring
3.8 Initial start-up
3.9 Condensation
5
5
6
6
7
7
8
8
8

1. Preface
* In order to provide our customers with quality, reliability and versatility, this product has
been made to strict producing standards. This manual includes all necessary information
about installation, debugging, discharging and maintenance. Please read this manual
carefully
before you open or maintain the unit. The manufacturer of this product will not be held
responsible if someone is injured or the uinit is damaged, as a result of improper installation,
debugging or unnecessary maintenanc. It is vital that the instructions within this manual are
adhere at all times. Only qualified person could install the unit.
* A qualified installer, centre, personnel or an authorized dealer, can only repair the unit.
* Maintenance and operation must be carried out according to the recommended time and
frequency, as stated in this manual.
* Use genuine standard spare parts only.
Failure to comply with these recommendations will void warranty.
* The swimming pool heat pump unit heats the swimming pool water and keeps the
temperature constant.
Our heat pump has following characteristics:
Durable
The heating exchanger is made of PVC & Titanium tube, which can withstand prolonged
exposure ot swimming pool water.
Easy operation
The unit is very easy to operate: switch it on and set the desired pool water temperatue.
Quiet operation
The unit comprises an efficient rotary compressor and a low-noise fan motor, which
guarantees its quiet operation. The unit can heat your swimming pool water when the air
temperature is 10.C or higher.
Low cost
The operational cost is very low due to its high performance
Swimming pool Heat Pump
1

2.1 Parameter of Swimming Pool Heat Pump Unit
3
2
2. Specifications
Swimming pool Heat Pump
Above parameters is only for reference exact details please as per nameplate.,
Model HP3.8B HP5.6B HP7.8B HP9.5B HP12.5B HP14B1
KW 3.8 5.6 7.8 9.5 12.5 14
K BTU 13 18 26.5 32.5 42.5 48
Heating Input Power KW 0.8 1 1.6 1.9 2.5 2.8
Heating Running Current A 3.6 5 7.5 8.8 11.7 13.3
KW 2.3 3.2 4.8 5.9 7.7 8.6
K BTU 7.8 11 16.5 20 26.5 29.5
Cooling Input Power KW 0.75 1 1.5 1.9 2.6 2.9
Cooling Running Current A 3.4 4.7 7.1 8.7 12.5 13.8
Power Supply V/Ph/Hz
Compressor Type
Controller
Codensor
Noise dB(A) 48 48 48 48 50 50
Water Connection mm 50 50 50 50 50 50
Water Flow Volume m³/h 2-4 3-5 3-5 4-7 4-7 5-8
Water Pressure Drop( Max) kpa 10 12 12 15 15 15
Unit Dimension L / W / H
mm 940 / 365 / 550 940 / 365 / 550 940 / 365 / 550 1010 / 374 / 610 1100/440/700 1100/440/700
Packing Size L / W / H
mm 1045 / 390 / 590 1045 / 390 / 590 1045 / 390 / 590 1120 / 395 / 655 1260/500/730 1260/500/730
Net / Gross Weight kg 37 / 40 53/ 56 54/ 57 63 /67 70/78 80/88
Model HP14A HP17A HP21A HP26A HP50A HP90A
KW 14 17 21 26 50 90
K BTU 48 60 73 89 170 306
Heating Input Power KW 2.88 3.5 4.25 5.2 10.3 17.5
Heating Running Current A 5.8 6.5 7.9 9.3 16.4 31.2
KW 8.6 10.3 13.5 14 36 58
K BTU 29.3 35 46 48 123 200
Cooling Input Power KW 2.98 3.6 4.65 6.2 12.1 18.8
Cooling Running Current A 6 6.8 8.3 11 19.3 33.5
Power Supply V/Ph/Hz
Compressor Type
Controller
Codensor
Noise dB(A) 52 54 58 58 61 62
Water Connection mm 50 50 50 50 63 75
Water Flow Volume m³/h 6-9 7-10 8-11 8-14 8-15 35-55
Water Pressure Drop( Max) kpa 15 16 16 16 18 28
Unit Dimension L / W / H
mm 660 / 660 / 850 660 / 660 / 950 660 / 660 / 950 660/660/950 1448/730/1260 2150/760/1330
Packing Size L / W / H
mm 750 / 700 / 860 750 / 700 / 960 750 / 700 / 960 750/700/960 1630/810/1380 2275/900/1500
Net / Gross Weight kg 98 /115 106 / 120 106 / 120 106/120 260/290 510/570
Scroll
Intelligent LCD Controller
PVC Titanium Heat Exchanger
220V/1Ph/50Hz
Rotary
Intelligent LCD Controller
PVC Titanium Heat Exchanger
380V/3Ph/50Hz
Cooling Capacity
Heating Capacity
Heating Capacity
Cooling Capacity

3
HP9.5A HP12.5A
HP14A HP17A
HP21A HP26A
660
660
A
GF
Swimming pool Heat Pump
2.2 Dimension of swimming pool heat pump unit
H
GF
HP3.8B HP5.6B HP7.8B
HP9.5B HP12.5B HP14B1
A
B
E
D C
B
A
C
D
E
Model
Size
340
650
300
370
1010
270
110
610
330
680
290
360
950
220
110
550
F
HP3.8B
HP5.3B
HP7.8B
G
H
HP9.5B
(mm)
HP9.5A
HP12.5A
HP14A
HP17A
HP21A
HP26A
850 955
110 110
320 450
Model
Size
(mm)
A
G
F
440
760
420
470
1110
320
110
670
HP12.5B
HP14B1

Swimming pool Heat Pump
HP35A HP45A HP50A HP90A
1480
770 704
730
755
90
1260
430 135
HP35A HP45A HP50A HP90A
mm 1448*730*1060 1448*730*1260 1448*730*1260 2150*760*1300
mm 1630*810*1180 1630*810*1380 1630*810*1380 2275*900*1500
mm 63 63 63 75
kg 240 / 270 250 / 280 260 / 290 510 /570
Dimension (L *w * H)
Packing Size (L *w * H)
Net Weight / Gross Weight
M odel
Water connection
HP105A HP135A
mm 2000*900*1820 2000*900*1920
mm 2150*1020*1980 2150*1020*2080
mm 110 110
kg 820 /880 850 /920
Dimension (L *w * H)
Packing Size (L *w * H)
Net Weight / Gross Weight
Model
Water connection
HP105A HP135A
3
4

Swimming pool Heat Pump
3.Installation
The factory only provides the heat pump unit; the other items including an eventual bypass, in the
are necessary parts for the water system, provided by users or the installers.
Attention:
Please follow these steps when installing the heat pump:
1. All feeding of chemicals to the pool water has to be done downstream of the heat pump.
2. Install a bypass when the flow of the pool pump is more than 20% above the rated flow of the heat
of the heat pump.
3. Install the heat pump above the level of the pool water.
4. Install the heat pump on a solid foundation and use the damping rubbers to eliminate vibrations and noise.
5. Always keep the unit straight up. If the unit has been tilted or put on his side, allow 24h before starting the unit.
The unit may be installed virtually anywhere outdoors. For indoor pools please consult your suppliers.
DO NOT put the unit in an enclosed area with a limited air volume where the unit discharge air will be re-circulated.
DO NOT put the unit next to shrubs, which can block the air inlet, Such locations deny a continuous source of fresh
air, which reduce its efficiency and may prevent adequate heat delivery.
The picture below give the minimum required distances from each side of the heat pump.
illustration
exchanger
3.1 Heat pump location
100 0 mm A b o ve 100 0 mm A b o ve
Top 2000mm Above
Inlet Inlet
Outlet
Heat
pump
100 0 mm A b o ve
100 0 mm A b o ve
Inlet Inlet
Inlet
100 0 mm A b o ve
Top 1000mm Above
3.2 How to close to the pool
Install the heat pump as close to the swimming pool as possible to minimize the loss of heat through the piping.
Put it on a solid base and place the rubber blocks under the heat pump to eliminate vibrations.
5

3.3 Distance from the pool
3.4 Installation of the check-valve
Normally, the pool heat pump is installed within a 7.5 meter radius of the pool. The greater the distance
from the pool, th e greater the heat l oss from th e piping. S ince the piping is b uried for the most part,
heat loss is minimal for distances of up to 30 meters (15 meters to and fr om th e pump= 30
meters total),unless the soil is wet or the water level is high. Heat loss per 30 meters could roughly be
estimated at 0.6kw-hour (2000 BTU) for every 5 temperature difference between the pool water
and the soil surrounding the pipe which translates to an operation time increase of
- When using automatic chlorine and PH dosage systems, it is of uttermost importance to
protect the heat pump from high concentrations of these chemicals that could corrode the heat exchanger.
Therefore, such systems should add the chemicals in the conduits located DOWNSTREAM of the heat
pump and it is recommended to install a ch eck-val ve in order to prevent backflow when there is no
water circulation . Damage to the heat pump caused by disregarding any of these recommendations will
invalidate the warranty.
℃
, .3-5％
Attention
P-trap
Check-valve
Filter
Chlorinator
Water Pump
Swimming Pool
Water Pump
P-trap
Check-valve
Filter Chlorinator
Check-valve
Swimming Pool
Swimming pool Heat Pump
3
6

3.5 Pool system set up
3.6 Connecting the by pass-
Valve 1
Valve 2
Valve 3
BY-PASS F
r
o
m
f
i
l
t
e
r
T
o
p
o
o
l
OUT IN
HEAT PUMP
Power cable inlet
Heat Pump
Inlet
Outlet
Condensed water draining pipe
Draining nozzle Discharge water to pool
Pool water inlet Water pump Filter
Water processor Side connection valve
VALVE1–
VALVE2–
VALVE3–
Slightly closed( water pressure increased
with just 100 to 200gr)
Completely open
Half way open
Setting the valve of the by-pass:
-Set all 3 valves entirely open
-Slightly close valve 1 ( see also 3.6)
-Close valve 3 about half way to adjust the refrigerant pressure
Swimming pool Heat Pump
3
7
HP35A HP45A HP50A HP90A HP105A
Power cable inlet
Heat Pump
Outlet
Inlet
Condensed water draining pipe
Draining nozzle Discharge water to pool
Pool water inlet Water pump Filter
Water processor Side connection valve
HP3.8B HP5.6B HP7.8B HP9.5B
HP12.5B HP14B1 HP17A HP21A
HP26A

3.7 Electrical wiring
1. Turn on the filter pump, check for leaks and verify flow to and from the pool.
2. Turn on the electrical power supply to the unit, then press the ON/ OFF key on the electronic control
panel. The unit should start when the time delay period has lapsed .
3. When the unit has been running for a couple of minutes, check if the air leaving the unit is cooler.
4. Check the performance of the flow switch as follows: with the unit running, turn the filter pump off.
The unit should also switch off automatically. If not, the flow switch must be readjusted.
5. All the unit and filter pump to run 24 hours a day until the desired pool water temperature is reached.
When the set temperature is reached, the unit switches itself off. The unit will now automatically
restart (as long as your filter pump is running) when the temperature of the pool water experiences a
drop of more than 1 below set temperature℃ .
Start up procedure- after the installation is completed, you should follow these steps:
3.8 Initial start-up
3.9 Condensation
When the swimming pool water is being heated by the heat pump, the incoming air is cooled down quite
a bit, which can cause condensation on the fins of the evaporator. Condensed volumes can attain severa
l litres per hour underhigh atmospheric humidity. Sometimes, this is wrongfully interpreted as a water leak.
Time delay— - -
.
- .
the unit is equipped with a built in 3 minute start delay included to protect electrical
components and contacts After this time delay, the unit will automatically be restarted. Even a
brief interruption of the power supply will activate the start delay and prevent the unit from starting
immediately. Additional interruptions of the power supply during the delay period will have no effect
on the 3 minute countdown
Water flow switch—
( .
).
the unit is equipped with a flow switch that is switched on when enough water has
flowed through the unit and that is switched off when the water flow becomes too low. e g. when
the filter pump is switched off
Depending on the starting temperature of the pool water and the air temperature, it can take several days
for the water to reach the desired temperature. Covering the pool can drastically reduced this period.
Note:-Verify the local power supply and the operating voltage of the heat pump. It is recommended to use
a separate circuit breaker(slow type-D curve)for the heat pump together with the proper wiring characteristics
(see table below). The current to the heat pump should only be applied when the filter pump is running. For
example a relay controlled by the filter pump could be used to activate the current to the heat pump. Further
connect the electrical supply to the junction box inside the unit. All PRO heat pumps require single-phase connection.
the heat pump is required to protect you against electrical shock caused by an eventual short circuit
inside the unit.
The heat pump is not equipped with a flow switch or any other kind of water flow detection. Therefore, the heat pump
has to be wired electrically together with the filter pump to ensure water flow while the heat pump is running.
Grounding
Swimming pool Heat Pump
3
8

4. Guidelines
4.1 Water chemistry
pH
Free chlorine(mg/1)
TAC(mg/1)
Salt(g/1)
Important: failure to comply with these limits will invalidate the warranty.
Note: exceeding one or several limits can damage the heat pump beyond repair. Always install water
treatment equipment past the heat pump s water outlet, especially if the chemicals are automatically
added to the water.
A check valve should also be installed between the outlet of the heat pump and this equipment in
order to prevent products from flowing back into the heat pump if the filter pump stops
'
-
.
Special attention should be paid to the chemical balance of the pool water. The pool water values should
always stay within the following limits:
4.2 Winterizing
Important: failure to winterizing could damage the heat pump and will void warranty
The heat pump, filter pump, filter and conduits must be protected in areas where the temperature can drop
below the freezing point, Evacuate all water from the heat pump as follows:
1. Turn off the electrical power supply to the heat pump
2. Close the water supply to the heat pump: completely close valves 2 and 3 of the by-pass
3. Disconnect the water inlet and outlet coupler fittings of the heat pump and let the water drain out of the
unit
Min
7.0
0.5
80
Max
7.4
1.2
120
3
4.3 Spring startup
If your heat pump has been winterized, perform the following steps when starting the system in the spring:
1. Inspect the system for any debris or structural poroblems.
2. Connect the water inlet and outlet unions firmly.
3. Turn on the filter pump to supply water to the heat pump. Adjust the by-pass to allow water flow through
the heat pump.
4. Turn on the electrical power to the heat pump at the main breaker panel.
Swimming pool Heat Pump
3
9

4.4 Owner inspection
The PRO heat pumps are designed and constructed to provide long performance life when installed and
properly under normal conditions. Periodic inspection are important to keep your heat pump running
The following basic guidelines are suggested for your inspection:
1. Make sure the front of the unit is accessible for future service.
2. Keep the surrounding areas of the heat pump clear of all debris.
3. Keep all plants and shrubs trimmed and away from the heat pump.
4. Keep lawn sprinkler heads from spraying on the heat pump to prevent corrosion and damage.
5. If the unit is installed under a very sharp roof pitch or under a roof without a gutter, a gutter or diverter should
be fitted to prevent excessive water from pouring down onto the unit.
6. Do not use the heat pump if any parts has been under water. Immediately call a qualified professional
technician to inspect the heat pump and replace any part of the control system, which has be submerged.
The heat pump will produce condensation(water) while in operation. The heat pump base is designed to allow
the condensation to exit through the bottom drain port. The condensation will increase as the outdoor air
humidity level increase. Check the following at regular intervals to ensure proper condensate drainage:
1. Visually inspect and clear the bottom drain port of any debris that could clog the port.
2. Keep the air intake area and discharge area clear of debris so the airflow through the heat pump is not
restricted. The cooler discharge air should not accumulate and be drawn into the side air intake coils.
During normal operation, the heat pump produces ten to twenty liters of condensate per hour. If condensate
drainage is above this range during operation or if water continues to drain from the base when the heat pump
is not in operation for more than an hour, a leak in the internal plumbing may have occurred. Call a qualified
heat pump technician to investigate the problem.
NOTE: A quick way to verify that the water running through the drain is condensation water is to shut off the
and keep the pool pump running. If the water stops running out of the base pan, it is condensation water.
AN EVEN QUICKER WAY TEST THE DRAIN WATER FOR CHLORINE--if there is no chlorine present, then
it’s condensation.
operated
safe and efficiently all the years.
unit
Swimming pool Heat Pump
3
10

Swimming pool Heat Pump
3
11
ON/OFF
Under unlock status,press it for one second to “ON/OFF”.
Under other setting status,press it can reture to home page
Under lock status,press it for 5 seconds to unlock.
Function key
In the home page,press it can enter to check the data.
electrical heating
supply water valve
return water valve
water pump
motor fan
fan speed
water level
r
5.Operating Instructions

3
12
Swimming pool Heat Pump
You can check and set the parameters with the function key
Press “+” and “-” can set the temperature when the unit is running.
Timer setting
Press it 5 seconds to enter time setting
Controller operation
Parameter setting and checking
Parameter checking and set(can setting under “ON/OFF” status)
In the home page,press “function” key 3 seconds to enter parameter checking page.press “+”
and “-” can check parameter.
In checking page,press “function” key can enter current parameter setting,press “+” and “-” to
change the parameter,press it again to exit.
It will exit to checking/setting page without press any key in 30 seconds.Press “ON/OFF” key
can exit to home page.
Factory parameter checking and setting
Under factory parameter checking page,press function key to enter current parameter setting,
press “+” or “-” to modification parameter ,press it again to exit.
It will exit to checking/setting page without press any key in 30 seconds,then reture to home
page.Press “ ON/OFF” can exit to home page.
Time setting
Under home page,press timer key 5secnds to enter time setting.
In time setting page,press “timer” key,the hour setting will flash,press “+” or “-” to set the parameter
data.
Finish the hour setting,press “timer” again,the minute setting will flash,press “+” or “-” to set the
parameter data.
When the minute setting is finished,press “timer” key again will confirm the time setting and exit
to home page.
Please note that no motion on display for 30 seconds, it will confirm the time setting and exit
to home page.
Under time setting status,press “ON/OFF” key will confirm time setting and exit to home page.
Page up and down,check and modify the parameters
Page up and Page down

3
13
Swimming pool Heat Pump
Note:The first timer setting is “ON/OFF” of the unit. The second third fourth timer setting
is “ON/OFF” of water refill.The fifth timer setting is “ON/OFF” of the water supply.
、 、
Lock /Unlock
Under lock status,press “ON/OFF” key for 5 seconds,you will hear a sound bee,then the
controller will unlock.No motion on the display for 30 seconds,the LCD will lock.
Cooling Mode
When It’s using in swimming pool model,Press “+” key for 5 seconds can change cooling/heating
model.
Forced defrost
Under running status,press “-” key for 5 seconds can enter forced defrost(every coil temp. must
lower than parameter H6)
Stop the unit can exit the forced defrost status,or when the defrosting time reach parameter H5
can exit.
press timer and “ ON/OFF” key for 3 seconds to start/stop electric heating
How to clear fault code history
Under fault code checking status,press “ON/OFF” key and function key for 5 seconds,can clear
fault code history.
Under the timer setting status,press “timer” key for 5 seconds to cancel the current timer setting.
Under timer setting status,no motion on the display for 30 seconds,it will confirm the timer
setting and exit to home page.(It has memory for setting when the power is cut off)
When the hour setting is finish,press timer key again to set the minute to open the unit.When
the minute setting is flashing,press “+” and “-” key to set the minute.
When the minute setting of first timer is finish,press timer key again to enter the hour setting
of shut off the unit of the first timer.
Under home page,press timer key can enter timer setting,you can setting 5 different timer.
When the first timer setting is flashing, press timer key to set hour to open the unit.When hour
setting is flashing,press “+” and “ key to set the hour.-”
The other timer setting is the same as the first timer setting.
Timer setting of “ON/OFF”

5
14
Swimming pool Heat Pump
Dispay Meaning dual system Dispay Meaning dual system( ) ( )
A1 coil 1 temperature B2
A2 B3
A3 B8 Compressor current of system 2
A4 Ambient temperature B9
expansion valve opening angle of
system
A5 Water outlet temperature E1 Fault code record
A6 Return water temperature E2 Fault code record
A7 E3 Fault code record
A8 Compressor current of system 1 E4 Fault code record
A9
expansion valve opening angle of
system E5 Fault code record
A10 reserve E6 Fault code record
B1 coil 2 temperature(daul system)
6.Unit status checking
return temp.of system1
Exhaust temp. of system 1
Ground source water outlet temperature
return temp.of system 2
Exhaust temp. of system 2(daul system)
(daul system)
Code Meaning Range Default
L2 Compressor start and return temp.setting 2℃～18℃3℃
L3 Temp. setting (Heating Model) 20℃～parameter F1 27℃
L4 Temp. setting (Cooling Model) 8℃～28℃12℃
L5 Ambient temperature of electric heating work 0℃～35℃0℃
L6 Temp. setting of return water 30℃～65℃30℃
L7 Temp.setting Of auto water supply 20℃～60℃48℃
L8 Running Current of compressor 0～40A 15
Parameter setting(can setting and change by user)

3
15
Swimming pool Heat Pump
Parameter meaning Range Default Remark
H2 Freezing protection temp.setting -30℃～0℃-10℃
H3 Total working time of compressor after frosting 20min～90min 45min
H4 Setting initialization temp. for defrosting -15℃～-1℃-3℃
H5 Defrosting time setting 5min～20min 8min
H6 Temp. of exit defrost 1℃～40℃20℃
H7
Entrance defrost Temp.setting of temp.different
between ambient and coil 0℃～15℃0℃
H8 Ambient temp.of entrance defrost 0℃～20℃20℃
P1 Cycle setting of electronic expansion valve 20S～90S 45S
P2 Overheat setting -5℃～10℃1℃
P3 expansion valve 80℃～110℃88℃
P4
Electronic expansion valve opening angle setting
when defrosting 2～45 40 Number of steps is the displayed value * 10
P5
Minimum opening setting of Electronic
expansion valve 5～20 12 Number of steps is the displayed value * 10
P6 Electronic expansion valve manual / automatic 0/1 00:manual/1:automatic
P7 Electronic expansion valve manual steps 2～45 reserved
F1 Water tank temp.setting 50℃～90℃55℃
F2 cycle water pump setting under electric heating 0/1 0 0:OFF 1:ON
F3
Temp. difference setting between water tank and LCD
display -5℃～15℃2℃
F4 water flow switch setting(online) 0～1 0 0:Single 1:online
F5 Water pump mode(swimming pool heat pump) 0/1 1 0:Ordinary / 1:Special
F6 By-pass valve setting （obligate）-30℃～45℃5℃
F7 Single/dual system 1/2 2
7.Factory parameter(Only setting by professional Technician)

5
16
Swimming pool Heat Pump
Fault code Meaning(Dual system) Fault code Meaning(Dual system)
Er01 Phase error Er23 Refrigeration overcooling protection
Er02 Default Phase
Er03 Water flow switch fault of indoor water
outler Er25 Level switch failure
Er04 Winter frost protection Er26 Antifreeze protection of outdoor water
inlet
Er05 High pressure protection of system 1 Er27 Water outlet sensor failure
Er06 Low pressure protection of system 1 Er28
Er07 High pressure protection of system 2 Er29 Return temp. sensor failure of system 1
Er08 Low pressure protection of system 2 Er30 Return temp. sensor failure of system 2
Er09 Communication fault Er31 Pressure switch failure
Er11 Time lock
Er12 Exhaust temperature protection of system 1
Er13 Exhaust temperature protection of system 2 Er35 Current protection of compressor1
Er36 Current protection of compressor2
Er15 Water tank/water inlet sensor failure Er37 temp. difference protection of water
indoor inlet/indoor outlet
Er16 Coil sensor failure of system 1 Er38 outdoor water outlet temp. overcooling
protection
Er17 Coil sensor failure of system 2 Er39 water flow switch failure of outdoor
water inlet
Er18 Exhaust sensor failure of system 1 Er40
Er19 Exhaust sensor failure of system 2 Er41
Er21 Ambient sensor failure Er43
Er22 Water return sensor failure Er44
8.Fault code table

3
17
9. Wiring Diagram
Swimming pool Heat Pump
Ambient temp.
Model: HP3.8B HP5.6B HP7.8B HP9.5B

Swimming pool Heat Pump
3
18
Model:HP12.5B HP14B1 HP17B
