Embassy ELITE LF1400 Series User manual

LF1400 Series
USER
MANUAL

Installation
• Only operate this product from the type of power source indicated on the marking
label. If you are not sure of the type of power available, consult an electrician.
• Make sure the electrical outlet is easily accessible from the shredder.
• Shredder must be operated only in upright position.
• To make sure the shredder has proper ventilation, place it a minimum distance of
2 in. (5 cm) from the wall or furniture.
Safety Instructions
1. Read and follow all instructions before use. Save these instructions for later use.
2. Always turn off and unplug the machine before moving, servicing, cleaning, or
anything other than normal operation. Serious injury may result. Clean shredder
with a damp cloth, using a mild soap and water solution.
3. Do not use abrasives or petroleum-based cleaners.
4. Place this product as close as possible to power source for quick and easy
unplugging.
5. Turn off the power switch before removing waste bin. It is advisable to disconnect
the power cord before opening the shredder.
6. This product should never be placed near a radiator or other heat source.
7. Do not allow anything to rest on the power cord. Do not place the power cord
where people may walk on it.
8. If an extension cord is used with this product, make sure the total ampere (amps)
ratings on the products plugged into the extension cord do not exceed the
extension cord’s ampere rating.
9. The machine contains no serviceable parts. Do not attempt to service this product
yourself, as opening or removing covers may expose you to risk of injury. The
manufacturer disclaims all liability for injuries resulting from opening the machine.
Mechanical damage resulting from opening the machine may void the warranty.
10. Unplug this product and contact technical support when:
• The power cord or plug is damaged or frayed.
• Liquid has been spilled on the product.
• The product has been exposed to rain.
• The product does not operate normally, even when the operating instructions
are followed.
• The product has been dropped, or the casing has been damaged.
11. This shredder should be operated only with an operator in attendance.
12. Empty the waste bin regularly so that the waste output is not impeded.
13. This machine can shred normal paper and credit cards. However, you should shred
only one type of these items at a time to avoid causing an overload.

WARNING
CAUTION: KEEP THIS DEVICE AWAY FROM CHILDREN AND PETS! Place
the paper shredder in an area less accessible to children.
DO NOT PLACE FINGERS TOO CLOSE TO THE FEED SLOT, AS SERIOUS
INJURY MAY OCCUR. Paper shredders can pull children’s ngers into the
shredder mechanism.
AVOID GETTING LOOSE CLOTHING OR JEWELRY NEAR THE FEED SLOT.
AVOID GETTING HAIR NEAR THE FEED SLOT.
NEVER spray any aerosol-based products in or around the shredder.
NEVER dispose of ammable chemicals, or materials that have come into
contact with ammable chemicals (for example, nail polish, acetone, gasoline)
in the shredder basket. NEVER use any petroleum–based or ammable oils
or lubricants in or around the machine, as some oils can combust causing
serious injury. Lubricants specically designed for shredders are acceptable.
NEVER place the shredder near water or any heat source.
Avoid direct contact with water.
STOP USE IMMEDIATELY IF:
1. The shredder blades become jammed with paper.
2. The shredder motor makes loud and/or irregular noise during operation.
3. The shredder blades or paper guides become bent or compromised in any way.
Continuing to operate your shredder with any of the above conditions present
could be potentially dangerous.
! !

Shredder Diagram
Wastebasket
Safety Cover
Auto Feeding Tray Reverse/Off/On/Forward
slide switch
Manual Feed Entry
Casters
Power On
Overheat
Bin Full
Credit Card
Power Off Power On
Reverse
Button Forward
Button

Technical Specications
Model ...................................................................................................... LF1400 Series
Cutting Style.................................................................................................... Microcut
Shred Size .....................................................................................0.16” x 0.39” (4 x 10mm)
Sheet Capacity Manual Feed .......................................12 (letter size, 20lb, 75gsm paper)
Sheet Capacity Auto Feed .........................................140 (letter size, 20lb, 75gsm paper)
Shred Speed Auto Feed ............................................................... 11.15 ft/min (3.4 m/min)
Shred Speed Max. Sheet Capacity Manual Feed ......................... 5.58 ft/min (1.7 m/min)
Intake Throat Width ..................................................................................... 8.66” (220mm)
Dimensions (l x w x h) ................................. 13.58” x 9.45” x 21.89” (345 x 240 x 556mm)
Weight ...............................................................................................20.79 lbs (9.43 kg)
Basket Capacity .......................................................................... 6.0 gallons (23.0 liters)
Continuous Operation (min) ..............................2 minutes manual / 20 minutes auto feed
Cooldown Time (min) ..........................................................................................90 minutes
Noise Level (motor).....................................................................................................70 dB
Product / Cutter Warranty ............................................................................ 1 Year / 1 Year
140-SHEET MICROCUT
AUTOFEED PAPER SHREDDER

Assembly
NOTE: This shredder will operate only when used with the supplied basket.
The supplied basket has a built-in safety feature which prevents the shredder
from operating if used with any other basket or if improperly assembled.
This shredder contains sharp edges on the underside of the shredder head.
The plug on the power supply cord is intended to serve as the disconnect
device, so the socket-outlet should be installed near the equipment and should
be easily accessible.
Operation
Please read operating instructions before using shredder. Check machine for
damage or defect; remnants of paper particles found in the waste bin are
normal due to product testing.
Setup
1. Place the machine on level ground and plug the power cord into any easily
reached grounded electrical outlet.
2. Make sure the wastebasket is correctly positioned.
3. To power ON, slide the power switch to the Power On position.
4. The machine will be ready to operate when the Power On LED indicator is
illuminated green.
Paper Clips and Staples:
Although our shredders are safe to shred the occasional standard staple, you
should remove staples whenever possible to prolong the life of the unit. For
auto feeding any stapled papers, please put the stapled side showing on top.
Industrial or non-standard, large-size staples MUST be removed. DO NOT
shred paper clips at any time as this will cause damage to the blades.

Operation (cont’d)
Manual Feed:
1. To shred paper, insert up to 12 sheets straight into the manual feed entry.
2. To shred credit cards, insert 1 card at a time into the middle of the
paper feed entry.
Auto Feed:
1. Open the auto feed tray.
2. Insert up to 140 sheets of paper into the auto feed tray. Once you
insert papers into the auto feed tray, it will start shredding each sheet
automatically.
Please Note:
- Only paper should be used in the auto feed tray. Credit cards should be
shred through the manual paper feed slot.
- Do not insert additional paper into the auto feed tray when it is already in
use.
- Staples must be at the top of the paper (furthest away from the shredder
opening).
- Do not insert folded paper as it may cause the unit to jam.
- While shredding in auto feed mode, you can occasionally shred 2-3 sheets
of paper through manual feed in front, simultaneously.
3. It will take approximately 11 to 12 minutes to shred 140 sheets on
auto feed mode.
For the safety of children and pets, always Power Off the shredder and
unplug the unit when it is unattended or not in use.
OVERHEATING:
This shredder is equipped with a temperature sensor device that protects
the motor from heat damage. If the device senses the motor is too hot, it will
automatically turn off the shredder and the red Overheat LED indicator will
illuminate. This is normal. If this happens, you shredder will need approximately
60 minutes to cool. Once the Overhead LED indicator is no longer illuminated,
you can continue shredding as normal.
OVERLOAD:
If too much paper is inserted into either the manual feed or auto feed the unit
will automatically stop shredding. When this occurs, slide the switch to Manual
Reverse to dislodge the jammed paper. Remove the paper, recount the pages,
and continue with no more than the maximum stated capacity.
To clear a paper jam, see Troubleshooting section.

Operation (cont’d)
BIN FULL:
The Yellow Bin Full LED indicator will illuminate when waste bin is full.
1. Turn the unit OFF by sliding to the Power Off position.
2. Remove the bin and either dispose of the paper shreds or compress the
shreds down.
3. Re-insert the bin into the housing. NOTE: the Yellow Bin Full LED indicator
will be illuminated and the unit will not power on until the bin is properly
inserted.
4. Slide the power switch to Power On to resume normal operation.
MAINTENANCE:
Apply lubricant after 30 minutes of shredding or a minimum of twice per
month. Only shredder lubricant sheets or bottled lubricant designed specically
for shredders should be used. Follow the instructions provided with the
shredder lubricant. NEVER USE AN AEROSOL LUBRICANT, or any lubricant
that is ammable. Refer to the warnings provided in this shredder manual.
Shredder bag will t this model.

Troubleshooting
If you have a problem with your shredder, check the issues and resolutions
below. If you cannot solve the problem, contact our product support experts at
1-866-860-1151. Do not open the shredder head to attempt repair.
It could expose you to electric shock and sharp blades. Doing this will
void your warranty.
RESOLUTIONS
a. Make sure the shredder is plugged in.
b. Make sure the slide switch is in the Power On position.
c. Make sure the unit has not overheated. See the OVERHEATING section.
d. Make sure the bin is empty and properly inserted. The Yellow Bin Full LED
will be illuminated if the bin is full.
1. Reverse the jammed paper by sliding to Manual Reverse.
2. Flip the safety cover up and remove jammed paper.
3. Close the safety cover.
4. Insert paper into the auto feed tray to resume normal operation.
If a paper jam is detected in the manual slot the shredder will stop running.
Use the Manual Reverse position to dislodge the jammed paper.
a. Make sure the unit has not overheated. See the OVERHEATING section.
b. Make sure the bin is not full. See the BIN FULL section.
a. Check that all staples are at the top of the page, furthest away from the
shredder opening.
b. Check that the paper is not folded or unsupported materials are in the
auto feed tray.
c. Reduce the number of sheets in the tray.
ISSUE
Shredder will not
turn on.
Paper is jammed in
the auto feed tray.
Paper is jammed in
the manual entry.
Shredder suddenly
stops while
shredding.
Shredder does not
pull paper from the
auto feed tray.

One Year Limited Warranty* / Product Registration
The manufacturer warrants the machine for a period of one year to be free from defects
in material and workmanship; this warranty does NOT cover normal wear and tear. If any
part is found to be defective during the warranty period, your sole and exclusive remedy
will be repair or replacement, at the manufacturer’s option and expense, of the defective
part except for the shipping cost. It is the responsibility of the consumer to pay the
shipping costs to return the machine to the manufacturer.
*Parts and labor rst 90 days. After 90 days, parts only.
This warranty is valid for the original consumer only with original proof of purchase
and is not transferable. This warranty does not apply in cases of abuse, mishandling
or unauthorized repair. The machine contains no serviceable parts. Do not attempt to
service this product yourself, as opening or removing covers may expose you to risk
of injury. The manufacturer disclaims all liability for injuries resulting from opening the
machine. Mechanical damage resulting from opening the machine may void the warranty.
ANY IMPLIED WARRANTY, INCLUDING THAT OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO THE WARRANTY
PERIOD SET FORTH ABOVE. In no event shall the manufacturer be liable for any
consequential or incidental damages attributable to this product. This warranty gives you
specic legal rights. You may have other legal rights that vary according to the laws of
each territory.
Please retain original proof of purchase to ensure that your product is recorded and
warranty information received.
Return Instructions
1. Before you return your shredder, call 866-860-1151 for a Return Authorization Number
(RA#), shipping instructions, and the manufacturer’s address.
2. Make a photocopy of the proof of purchase (store receipt), showing original purchase
date, and tape it securely to the shredder (DO NOT send the original receipt).
3. Pack the shredder in its original carton, or equivalent, and write the RA# clearly on the
outside of the box.
4. Ship the shredder to the address provided. Save your shipping receipt.
Call us for a RA# before returning a defective product.
Product Registration
Please register your new product at www.shredcare.com, or call 866-860-1151.
Contact Us
For more information, please call 866-860-1151, or email us at [e-mail].
