Emblaze-VCON XPOINT User manual

E MBLAZE -VCON X P OINT R EMOTE C ONTROL
1 R EMOTE C ONTROL L AYOUT
The remote control device is used to control all aspects of the system. The system is equipped with highly
intuitive on screen graphical user interface which is used for navigation and operation.
The remote control is transmitting an infra-red light to the receiver connected to the main unit, and the
actions are reflected on the screen.
The remote control is divided to 3 logical parts: command buttons, keypad and Navigation joystick
Command buttons - The command buttons are used to send a specific command to the system such as
"Call Information", "Mute Microphone" etc.
Keypad - The keypad has 3 modes:

Number Mode: In number mode, the numbers 0-9 are used when pressing the digits 0-0 on
the keypad. In addition, the dot (.) sign is used when pressing the asterisk (*) sign on the
keypad

Text Mode: In letter mode, each letter sends 1 or more letters. The letters are printed on the
body of the remote control. For example, pressing once number 2 on the keypad in text mode
will produce the letter "A". Pressing twice on the number 2 will product the letter "B", etc.
Moving from upper case to lower case is done by pressing the volume up and down button
while in a text box.
- Special characters (located under the '*' button) are:
'.' (dot), ',' (comma), '@' (at sign), '^' (apostrophe), '* (star), '=' (equal), '$' (dollar), '_'
(underscore).

DTMF Mode: When in a call, the number on the keypad will send the corresponding DTMF
tone to the remote side (this is usually used for IVR systems input). The asterisk (*) and
pound (#) sign will send that DTMF tone accordingly.
Navigation Joystick – The navigation joystick has a four directional movement capability and a down
press capability. Use the arrows to navigate to either side and the press capability for "Menu" or "OK"
action where required by the graphical user interface

Figure 1: Remote Control Layout
1
Status Display the call status
2
Data Initiate data sharing
3
Address Book Open address book
4
Help Open the system help
5
Far End Control the position (PTZ) of
the camera at the far end
6
Camera Control Configure the camera
settings
7
Preset - Recall Recall a camera PTZ preset
position
8
Preset – Set Set a camera PTZ preset
position
Joystick (#17)
Back (#18)
Menu/
OK
(#19)
Make call
(#22) End call (#23)
9
PIP Toggle the position of the
PIP (5 positions)
10
Speed Dial Display the speed dial
screen
11
Call Log Display the current call log
12
Mute Mic. Mute the microphone
13
Display Toggle the local and remote
displays
14
Settings Open the settings menu
15
Mute Video Temporarily disable the
video camera
16
Mute Speaker Mute speaker
Up
Volume
Down
(#20)
In
Zoom
Out
(#21)
