Emdoor EM-I20U User manual

EM-I20U
USER MANUAL
Rugged Mobile Computing Solutions

March 2022
NOTE
The information in this manual is subject to change without notice.

Table of Contents
ⅰ
Chapter 1 Getting Started ..............................................................
Getting the Tablet Running .......................................................
Unpacking .............................................................................
Connecting to AC Power .......................................................
Turning On and Off the Tablet .............................................
Taking a Look at the Tablet .......................................................
Front Components ...............................................................
Rear Components .................................................................
Right-Side Components .......................................................
Left-Side Components .........................................................
Top Components .................................................................
Bottom Components ..........................................................
Chapter 2 Operating Your Tablet ...................................................
Using the Touchscreen ............................................................
Using Multi-touch Gestures ...............................................
Using Wireless Connections ....................................................
Using the WLAN ..................................................................
Using the Bluetooth Feature ..............................................
Chapter 3 Managing Power ..........................................................
AC Adapter ................................................................................
Battery Pack .............................................................................
Charging the Battery Pack .................................................
Checking the Battery Level ................................................
Low Battery ........................................................................
Replacing the Battery Pack ................................................
Power-Saving Tips ...................................................................
1
2
2
3
4
6
6
8
9
9
10
11
13
14
15
17
17
18
19
20
21
21
22
22
23
25

ⅱ
Chapter 4 Expanding Your Tablet ..................................................
Connecting Peripheral Devices ...............................................
Connecting a USB Device ...................................................
Connecting a USB Type-C Device ......................................
Connecting a Monitor .........................................................
Connecting an Audio Device ..............................................
Chapter 5 Using BIOS Setup .........................................................
When and How to Use ..............................................................
Menu Descriptions ...................................................................
Main Menu ..........................................................................
Security Menu ....................................................................
Boot Menu ..........................................................................
Save & Exit Menu ................................................................
Chapter 6 Care and Maintenance ..................................................
Protecting the Tablet ...............................................................
Using an Anti-Virus Strategy ..............................................
Taking Care of the Tablet .........................................................
Location Guidelines ...........................................................
General Guidelines .............................................................
Cleaning Guidelines ...........................................................
Battery Pack Guidelines ....................................................
Touchscreen Guidelines ....................................................
When Traveling ........................................................................
Chapter 7 Troubleshooting ..........................................................
Preliminary Checklist ..............................................................
Solving Common Problems ....................................................
Battery Problems ...............................................................
Bluetooth Problems ...........................................................
Display Problems ...............................................................
26
27
27
27
27
27
28
29
30
30
32
33
34
35
36
36
37
37
38
38
39
40
41
42
43
44
44
45
45

ⅲ
Hardware Device Problems ...............................................
Power Management Problems ..........................................
Software Problems .............................................................
Sound Problems .................................................................
Startup Problems ...............................................................
WLAN Problems ..................................................................
Restart the Tablet .....................................................................
46
46
47
47
47
48
49

Getting Started
Chapter 1
1
This chapter first tells you step by step how to get the tablet up and running.
Then, you will find a section briefly introducing the external components of
the tablet.

Unpacking
Getting the Tablet Running
2
After unpacking the shipping carton, you should find these standard items:
● I20U Rugged Tablet
● AC power cord ● Battery（Built-in）
● Carry handle ● Hand-strap
● AC adapter

3
Connecting to AC Power
CAUTION：Use only the AC adapter included with your Tablet. Using other AC
adapters may damage the Tablet.
NOTE：
● The battery pack is shipped to you in power saving mode that protects it from
charging/discharging. It will get out of the mode to be ready for use when you install
the battery pack and connect AC power to the Tablet for the very first time.
● When the AC adapter is connected, it also charges the battery pack. For
information on using battery power, see Chapter 3.
You must use AC power when starting up the Tablet for the very first time.
1. Open the DC port waterproof plug (Place the tablet flat on the desktop, left
position)
2. Plug the DC cord of the AC adapter to the power connector of the Tablet.
3. Plug the female end of the AC power cord to the AC adapter and the male end to an
electrical outlet.
4. Power is being supplied from the electrical outlet to the AC adapter and onto your
Tablet. Now, you are ready to turn on the Tablet.
DC port

4
Turning On and Off the Tablet
Turning On
2. Press the power button ( ) . The Windows operating system should start.

5
Turning Off
When you finish a working session, you can stop the system by turning off the power
or leaving it in Sleep or Hibernation mode:
* “Sleep” is the default result of the action. You can change what the action does
through Windows settings.
To... Do this...
Power off
(Shutdown) Click →[ Power]→[Shut down].
Sleep Use one of these methods:
● Press the power button.
● Click →[ Power]→[Sleep].
Hibernate By default, this option is not shown in the Start menu. If
you want to use the feature, set up accordingly in
Windows settings.

❶
❷❾
❸
❹
❺
❻
❼
❽
6
Taking a Look at the Tablet
NOTE：Depending on the specific model you purchased, the color and look of your
model may not exactly match the graphics shown in this document.
CAUTION：You need to open the protective covers to access the connectors. When
not using a connector, make sure to close the cover completely for water-, and
dust-proof integrity. (Engage the locking mechanism if existing.)
Front Components

7
Ref Component Description
Microphone
Stereo Speaker
Indicators
Receives sound and voice for the Tablet.
Sends out sound and voice from the Tablet.
Up：The power on is always on blue, and the
power off light is off. When switching the built-in
small battery power supply, it flashes blue.
Down：(red and green) charging red, full of green.
The low battery red light flashes, and the
discharge is not on.
❶
❷
❸
F Key 2D scan key (can be defined).
❹
Windows HOME Used to open windows shortcuts.
❺
Volume Button + Used to adjust and increase the volume.
❻
Volume Button - Used to adjust or reduce the volume.
❼
Power Button Used for sleep wake-up equipment and
switching equipment.
❽
LCD Screen Displays the output of the Tablet. Include
touchscreen feature.
❾

❶❻❸ ❷
❺
❾❽
❹
❼

8
Rear Components
Ref Component Description
Camera
Flash Lamp
Cooling Fan
Used to realize the camera function.
Fill light and lighting.
Used for radiating the flat plate (air inlet).
❶
❷
❸
Battery Cover Latch Lock the battery cover.
❹
Battery Location of large battery.
❺
Plastic Top Shell The scanning head needs to be replaced.
❻

❶
❽ ❼ ❻ ❺ ❾ ❹
❷
❸
Ref Component Description
Battery Cover Latch
Fingerprint
NFC
Lock the battery cover.
Fingerprint unlock.
NFC swipe card.
❼
❽
❾
SSD SSD interface location.

9
Right-Side Components
Left-Side Components

❶
❷
Ref Component Description
Cooling Fan
Interface
Protection Cover
DC Power Jack
Used for radiating the flat plate (air outlet).
Play the role of protective interface, slide to the
left to open the protective cover.
Connect the power adapter.
❶
❷
❸
3.5mm Earphone
Jack Connect the audio device.
❹
TF Card Installing the TF card，max：128G.
❺
SIM Card Install the SIM card.
❻
USB3.0 Port Connects a USB device.
❼
Type-C Port Connects a USB-C device.
❽
HDMI Connector Connects a HDMI monitor or TV set.
❾
10
Top Components
Ref Component Description
Module Port Network port (default), serial port, USB,
1D code and 2D code, One out of five.
❶
Handle Screw
Position
Install M4 handle screw to facilitate the
installation of handle.
❷

❶
❷
11
Schematic diagram of handle: (the picture is for
reference only)
Bottom Components
Ref Component Description
Pogo Pin Matched with the positioning hole to connect the
Vehicle Mount and Docking Charger for expanding
USB, RJ45 and RS232 communication interfaces.
❶
Locating Hole It plays a fixed role when connecting the
Vehicle Mount and Docking Charger.
❷

Schematic diagram of Docking Charger: (the picture is
for reference only)
（Front + Docking Charger） （Back + Docking Charger）
（Front + Vehicle Mount）
（Back + Vehicle Mount）
12
Schematic diagram of Vehicle Mount: (the picture is
for reference only)

Operating Your
Tablet
Chapter 2
13
This chapter provides information about the use of the Tablet.
If you are new to Tablets, reading this chapter will help you learn the operating
basics. If you are already a Tablet user, you may choose to read only the parts
containing information unique to your Tablet.
CAUTION：
● Do not expose your skin to the Tablet when operating it in a very hot or cold
environment.
● The Tablet can get uncomfortably warm when you use it in high temperatures. As
a safety precaution in such a circumstance, do not place the Tablet on your lap or
touch it with your bare hands for extended periods of time. Prolonged body contact
can cause discomfort and potentially a burn.

The following table shows how you use the touchscreen to obtain equivalent
mouse functions.
Term / Action Equivalent
Mouse Function
Tap：Touch the screen once. Click / Point
Double-tap：Touch the screen twice rapidly. Double-click
Tap and hold：Tap and hold until a popup menu appears. Right-click
Drag：Hold the finger on the screen and drag
across the screen until reaching your destination.
Drag
14
Using the Touchscreen
CAUTION：Do not use a sharp object such as a ballpoint pen or pencil on the
touchscreen. Doing so may damage the touchscreen surface. Use your finger or the
stylus.
Select models have a capacitive touchscreen. This type of touchscreen responds to
objects that have conductive properties, such as fingertips and a capacitive-tipped
stylus. You can navigate on the screen without using a keyboard, or mouse.

Using Multi-touch Gestures
Gestures Descriptions
Actions
( =finger down； =finger up)
Pan
(Scroll)
Use panning to see
another part of a page
that has scroll bars.
Zoom
(Pinch)
Use zooming to make an
item (a photo for example)
on the screen larger or
smaller. The gesture works
in applications that
support mouse wheel
zooming.
Rotate Use rotating to move a
picture or other item on
the screen in a circular
direction (clockwise or
counter- clockwise).
The gesture works in
applications that
support the specific
gesture.
15
You can interact with your Tablet by placing two fingers on the screen. The
movement of the fingers across the screen creates “gestures,” which send
commands to the Tablet.
Here are the multi-touch gestures that you can use:
Drag 1 or 2 fingers up or down.
or
Move two fingers apart / toward each other.
Move two fingers in opposing directions.
-or-
Use one finger to pivot around another.
or
