Emerson HD8110 User manual

PERSONALCD,CD-R/RWPLAYER
with40 SECOND ELECTRONIC
ANTI-SKIPPROTECTION,
and FMDIGITALTUNER
HD8110
OWNER’SMANUAL
Visitourweb siteatwww.emersonradio.com
HD8110_052404.p65 25/5/2004, 12:2122

1
Thankyou.........
Forpurchasing thisEmerson PersonalCD PlayerwithFMdigitaltuner.
The CD playerhasa20 track programmablememorysoyou can listen to
the songson yourfavoriteCD'sinanyorderyou choose.Oryou can use
the Randomplayback featureand letthe playerselectthe playback order
foryou.Usethe 3-wayRepeatfeaturetorepeatasingletrack,the entire
disc,oraprogrammed sequenceoftracks,indefinitely.We'vealsoincluded
40 second ElectronicSkipProtection whichmakesthisplayervirtuallyskip-
free during mostactiveuses.
Pleaseread thisinstruction manualcompletelyand carefullytomakesure
you understand the properoperation ofthisproduct, and getthe maximum
enjoymentoutofall the featuresofthisstate-of-the-artCD player.
Onceagain,thanks forpurchasing thisEmerson product.
The serialnumberofyourCD playercan be found on the bottomcabinet.
Wesuggestthatyou recordthe serialnumberofyourunitinthe space
belowforfuturereference.
ModelNumber:HD8110
SerialNumber:
HD8110_052404.p65 25/5/2004, 12:211

2
WARNING: TOPREVENTFIREORSHOCKHAZARD,
DONOTEXPOSETHISUNITTORAINORMOISTURE.
Thisdevicecomplieswithpart15 ofthe FCC rules.Operation issubjecttothe
condition thatthisdevicedoesnotcauseharmfulinterference.
CLASS 1LASERPRODUCT
CLASS 1LASERPRODUCT
APPAREILÁLASERDECLASSE 1
PRODUCTOLASERDECLASE 1
CAUTION
INVISIBLELASERRADIATION
WHENOPENAND INTERLOCKS
DEFEATED.
AVOIDEXPOSURETOBEAM
ThisproductcontainsalowpowerLaserDevice.
•Placesexposed todirectsunlightor
closetoheatradiatingappliancessuch
aselectricheaters.
Avoidinstalling theunitinlocationsdescribedbelow:
•Dustyplaces.
•Placessubjecttoconstant
vibration.
•Humidormoistplaces.
CAUTION
THISLASERCOMPACTDISCPLAYERFUNCTIONSBY HELPOFINVISIBLE
LASERLIGHTAND ISEQUIPPEDWITHSAFETYSWITCHES TOAVOID
EXPOSUREWHENDOORISOPENAND SAFETYINTERLOCKS ARE
DEFEATED.ITISDANGEROUSTODEFEATORBYPASS SAFETYSWITCHES.
IMPORTANTNOTES
DANGEROUSVOLTAGE
Uninsulated DangerousVoltage,thatmaybe ofsufficient
magnitude toconstitutearisk ofelectricshock topersonsis
presentwithinthisproduct'senclosure.
ATTENTION
The Owner'sManualcontainsimportantoperating and
maintenanceinstructions.
Foryoursafety,itisnecessarytorefertothe manual.
!
HD8110_052404.p65 25/5/2004, 12:212

3
PREPARATIONFORUSE
REMOVE THE TRANSIT CARD
This personal CD player is shipped with a dummy CD ‘transit card’ inside the CD
compartment. The purpose of this card is to prevent the laser from moving during
shipment of the product. This card must be removed before using the CD player.
Slide the OPEN switch to the right to unlock the CD door. Remove the ‘transit card’
from the player and discard it.
POWER SOURCES
This personal CD player is designed to operate on two “AA” batteries, not included.
Use a well known brand of alkaline batteries for longest life and best performance.
This player can also be operated by an optional AC/DC converter/adapter, not
included. If you decide to purchase an optional AC/DC adapter the specification
must be as follows:
Input: 120V 60Hz AC
Output: 4.5V DC, 500 mA.
Plug: 1.7 mm Female Type with Positive Center, UL Listed.
You may also purchase a “Universal” type AC/DC adapter which allows you to
select the required output voltage and plug polarity, and normally includes multiple
plug sizes to fit most brands of equipment. Always look for the “UL” listing mark
when you purchase an adapter.
Positive(+)Negative(–)
HD8110_052404.p65 25/5/2004, 12:213

4
INSTALLING THE BATTERIES
Note: The battery compartment is located inside the CD compartment.
1.) Slide the OPEN switch to the right to open the CD door. If you have not already
done so, remove the dummy CD ‘transit card’ and discard it.
2.) Press down on the “Arrow” mark in the center of the battery door and slide the
door outward as shown until the door ‘pops’ open.
3.) Inserttwoalkaline“AA”batteriesin the battery compartment. Be suretoobserve
the polarity markings engraved in the battery compartment. If the batteries are
inserted incorrectly the unit will not work.
4.) Fold the battery removal ribbon over the top of the batteries, close the battery
door, and slide the door inward into it is fully locked again.
5.) Close the CD door.
REPLACING THE BATTERIES
When the battery symbol flashes in the display the batteries are becoming
weak and should be replaced.Always replace both batteries at the same time with
new fresh alkaline batteries. Do not mix old and new batteries or different types of
batteries together.
If the display remains blank when you press thePLAY/PAUSE button, the batteries
are completely dead. Replace them immediately. If dead batteries are left inside
the battery compartment for a long period of time they may leak and cause damage
to the unit, and such damage or corrosion from leaking batteries is not covered by
your warranty.
HD8110_052404.p65 25/5/2004, 12:214

5
CONNECTING THE OPTIONAL AC ADAPTER (NOT INCLUDED)
1.) Connect the small female plug of the optionalAC adapter to the “DC IN 4.5 V”
jack on the right side of the CD player.
2.) Connect the adapter housing to your 120V AC 60Hz outlet.
Notes:
• Never connect or disconnect the adapter from the AC outlet while your hands
are wet.
• The housing of the AC adapter may become warm during operation. This is
normal.
• The female plug of the AC adapter must be completely disconnected from the
CD player in order to operate the player on batteries.
PRESET MODE RADIO
PLAY/
PAUSE
STOP SKIP REV./
TUN. DOWN
SKIP FWD./
TUN. UP
DC 4.5V INPUT JACK
TO 120V/60Hz AC OUTLET
OPTIONAL AC/DC ADAPTER
BATTERYPRECAUTIONS
Followtheseprecautionswhen using batteriesinthisdevice:
1.Useonlythe sizeand type ofbatteriesspecified.
2.Besuretofollowthe correctpolaritywhen installing the batteriesasindicated inthe battery
compartment. Reversed batteriesmaycausedamage tothe device.
3.Donotmixdifferenttypesofbatteriestogether(e.g.Alkaline and Carbon-Zinc)oroldbatteries
withfreshones.
4. If the deviceisnottobe used foralong period oftime,removethe batteriestoprevent
damage orinjuryfrompossiblebatteryleakage.
5.Donottrytorecharge batteriesnotintended tobe recharged;theycan overheatand rupture
(Followbatterymanufacturer’s directions.)
HD8110_052404.p65 25/5/2004, 12:215

6
CONNECTING THE STEREO HEADPHONES
Connect the plug of the supplied stereo headphones to the green-coloredPHONES
jack on the left side of the cabinet.
NOTE: Make sure the headphone plug is inserted into the PHONES jack as
far as it will go. If the plug is not fully inserted, you may only hear sound from
one side of the headphones.
IMPORTANT!
Always set the VOLUME control to a low level before you put the headphones on
and begin playing a CD. Then start playback and gradually increase the volume to
a comfortable listening level. Do not play the CD at loud volume levels that might
prevent you from hearing warning sounds such as car horns, etc.
PRESET MODE MEMORY RADIO
PLAY/
PAUSE
STOP
SKIP REV./
TUN. DOWN
SKIP FWD./
TUN. UP
HD8110_052404.p65 25/5/2004, 12:216

7
PRESET MODE MEMORY RADIO
PLAY/
PAUSE
STOP
SKIP REV./
TUN. DOWN
SKIP FWD./
TUN. UP
LOCATIONOFCONTROLSAND INDICATORS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
HD8110_052404.p65 25/5/2004, 12:217

8
1.)OPENSwitch–Slide tothe righttounlock and open the CDdoor..
2.)VOLUMEControl–Raisesorlowersthe volume.
3.)PHONES Jack –Connectstereo headphones,included,tothisjack.
4.)HOLDSwitch.
5.)MEMORYButton.
6.)PRESETButton.
7.)MODEButton.
CD -Selectsthe playback mode:Repeat1/All,Shuffle,orIntro.
FMRadio-SelectFMSTEREO/MONO.
8.)RADIO Button.
9.)LCDDisplay–ShowsTrack number,Playing time,Anti-Skipstatus,
Program,Repeat, Shuffle,and Intromodes.
10.)PLAY/PAUSE Button.
11.)SKIPFWD./TUN.UPButton.
12.)DC IN4.5VInputJack –ConnectanACadapter(notincluded)tothis
jack touse120V60Hzhousecurrent.
13.)SKIPREV./TUN.DOWNButton.
14.)STOPButton.
15.)CDDoor.
16.)BatteryCompartment(Inside CD Compartment).
HD8110_052404.p65 25/5/2004, 12:218

9
1.)FMRadioIndicator.
2.)FMSTEREOIndicator.
3.)PROG (Program) Indicator–Appearswhen programming tracks /FM
presetstations,orplaying programmed tracks.
4.)INTROIndicator–Appearswhen Introplayback mode isselected.
5.)SHUFF (Shuffle)Indicator–Appearswhen Randomplayback mode
isselected.
6.)REPEAT1/ALL Indicators–Appearswhen theRepeatplayback mode
isselected.
7.)BatteryStatusIndicator–Flasheswhen batterylevelbecomeslow.
8.)FMMONOIndicator.
9.)HOLDIndicator–Appearswhen HOLDswitchissetto‘On’position.
10.)Anti-Shock BarIndicator–IndicatesESP Protection isactivated.
11.)CD Elapsed Time/FMFrequency Display.
12.)CDTrack Number/FMpresetstation numberindicator.
LCD DISPLAYINDICATORS
10
1
2
3 4 5 6 7
12 11
8
9
HD8110_052404.p65 25/5/2004, 12:219

10
OPERATINGINSTRUCTIONS
SPECIAL FUNCTIONS
HOLD Switch
The HOLD switch (on the left side cabinet) must be in the ‘Off’ (left) position to
start the CD player. If you plan to carry the CD player in a handbag, briefcase,
school bag, back pack, etc, slide the HOLD switch to the ‘On’ (right) position.
While the HOLD switch is ‘On’ all of the controls on the CD door are disabled. This
prevents the player from starting accidentally by something pressing against the
PLAY/PAUSE or RADIO button.
After you begin CD playback you may also slide the HOLD switch to the ‘On’ (right)
position to disable all the controls on the CD door. You can then place the player in
a handbag, backpack, etc, and do not have to worry that the player will be
accidentally turned off by something pressing against the STOP button or Track
Skip buttons.
(On)
(Off)
HD8110_052404.p65 25/5/2004, 12:2110

11
Electronic Skip Protection (ESP)
This CD player includes an Electronic Skip Protection circuit that continuously
stores 40 seconds of CD music in an electronic memory. If the player is bumped
or shaken you will not hear any skipping because the player is reading from the
memory, not directly from the disc. Of course if the shaking continues for more
than 40 seconds, the ESP memory will be depleted and the player may then skip
or stop if the shaking continues.
ESP memory function is automatically activated during CD playback. The display
will show the ESP meter and begin to fill up with bars.
Each bar represents approximately 8 seconds of music in the memory. When all 5
bars appear the memory contains 40 seconds of music.
If the player is bumped or shaken one or more of the bars may disappear as the
memory is depleted .
When the shaking stops the memory will fill up again.
HD8110_052404.p65 25/5/2004, 12:2111

12
NORMAL CD PLAYBACK
• Make sure you have installed the batteries.
• Make sure the HOLD switch is set to the ‘Off’ (left) position.
• Make sure to set the VOLUME control to a low setting before you put on
the headphones.
IMPORTANT:
This CD player can play normal CDs plus CD Recordable (CD-R) and CD
Rewriteable (CD-RW) discs. However the playability of CD-R/RW discs may be
affected by the type of software that was used in ‘ripping’ the tracks from the
original discs and ‘burning’ the tracks onto the blank media. Playability may also
be affected by the quality and condition of the blank media you use for recording.
100% compatibility cannot be guaranteed. This is not an indication of any problems
with your player.
1.) Slide the CD door OPEN switch to the right to unlock
and open the CD door.
2.) Place your CD on the center spindle with the printed
label side facing up. Press downward on the disc near
the center hole until the disc is fully seated on the
spindle.
3.) Close the CD door and connect the headphones to the PHONES jack (green
color) by pushing the headphone plug into the PHONES jack until a ‘click’
sound is heard.
4.) Press the PLAY/PAUSE button to begin
playback. The display will briefly show “– –”
flashes while the player reads the disc. The
total tracks and playing time will appear briefly in the display and then the
playback will begin on track 1. The display will show the elapsed playing time
of the track being played.
5.) Adjust the VOLUME control as desired.
OPEN
HD8110_052404.p65 25/5/2004, 12:2112

13
6.) Playback will continue until the end of the disc, then the player will stop
automatically and the display will again show the total tracks and playing time
on the disc. After approximately 30 seconds the power switches ‘Off’
automatically to conserve the batteries and the display goes blank. To stop
playback before the disc ends press the STOP button at any time. Press the
STOP button after the disc has stopped to shut the power ‘Off’ completely.
PAUSE CONTROL
To pause momentarily during playback press the
PLAY/PAUSE button again. The elapsed time
display flashes. The sound stops but the disc
continues to spin.
Press the PLAY/PAUSE button once more to cancel Pause mode and resume
normal playback. The elapsed time display stops flashing.
SKIP/SEARCH CONTROLS
Press the SKIP FWD or SKIP REV buttons repeatedly during playback to skip to
higher or lower numbered tracks. Playback will begin on the selected track.
To search within a track at high speed to locate a specific musical passage depress
and hold either the SKIP FWD or SKIP REV controls. The player will search rapidly
forward or backward as long as the buttons are depressed. The volume is
automatically muted during high speed search. Watch the elapsed time display.
When the time display reaches the desired point, release the buttons. Normal
playback will resume at that point and the volume returns to normal level.
HD8110_052404.p65 25/5/2004, 12:2113

14
MODE BUTTON
Pressing the MODE button during CD playback cycles the player through the
following four special playback modes:
REPEAT 1 REPEAT ALL INTRO SHUFF (Shuffle) Playback.
REPEAT PLAYBACK
The player can be programmed to continuously repeat a single track or the entire
disc automatically.
One Track Repeat
During playback press the SKIP FWD or SKIP REV buttons to select the track to
be repeated, then press the MODE button once.
The REPEAT 1 indicator appears in the display
and the selected track will be repeated
continuously.
Press the STOP button to cancel Repeat 1 playback.
All Tracks Repeat
Press the PLAY/PAUSE button to begin playback, then press the MODE button
twice.
The REPEAT ALL indicator will appear in the
display and the entire disc will be repeated
continuously.
Press the STOP button to cancelAll Track Repeat playback.
HD8110_052404.p65 25/5/2004, 12:2114

15
INTRO (Intro Scan) PLAYBACK
The Intro Scan feature plays only the first 10 seconds of each track on the disc.
This feature is useful when you are trying to find a particular song but you cannot
remember the title.
1.) Load your disc in the player as usual and press the PLAY/PAUSE button to
begin playback.
2.) When playback begins press the MODE
button 3 times. TheINTRO indicator flashes.
3.) Press the PLAY/PAUSE button once more.
The INTRO indicator stops flashing and
remains ‘On’.
The player backs up to the beginning of track 1, plays the first 10 seconds of
each track on the disc, and then stops.
To cancel Intro Scan playback press the STOP button.
SHUFFLE (Random) PLAYBACK
When Shuffle playback is selected all the tracks on the disc will be played back in
random order.
1.) Load your disc in the player as usual and press the PLAY/PAUSE button to
begin playback.
2.) When playback begins press the MODE
button 4 times. TheSHUFF indicator flashes.
3.) Press the PLAY/PAUSE button once more.
The SHUFF indicator stops flashing and
remains ‘On’. The player randomly selects a
track for playback. After each track has
played once the player stops.
To cancel Shuffle playback press the STOP button.
HD8110_052404.p65 25/5/2004, 12:2115

16
PROGRAMMED PLAYBACK
You can program up to 20 tracks on a disc to play in any desired order.
NOTE: You can program a disc either during Playback or in Stop mode.
1.) Press the MEMORY button once. The
Program Number ‘01’ appears. The PROG
indicator and the the track number ‘00’ flash.
2.) Press the SKIP FWD or SKIP REV button to
select the first track to be programmed.
Example: Track 02.
3.) When the desired track number is flashing
in the display, press the MEMORY button
again to enter the desired track number in
Program Number 01.
The track number returns to “00” and the Program Number advances to “02”.
4.) Repeat Steps 2 and 3 to program additional tracks up to a maximum of 20.
5.) Press the PLAY/PAUSE button to begin
programmed playback. The PROG indicator
remains in the display and the track display
stops flashing.
• Playback begins with the first track you programmed and continues until all
programmed tracks have been played, and then the player stops.
The programmed sequence will remain in the memory until the power shuts
off (approximately 30 seconds) or until the CD door is opened.
• If you press the MEMORY and PLAY/PAUSE buttons again before the power
shuts off, the programmed sequence will play again.
HD8110_052404.p65 25/5/2004, 12:2116

17
LISTENINGTOTHERADIO
1.)Press the RADIObutton,the FMradio
frequency appearsinthe display.
2.)Tune tothe desired station bypressing the TUN.UPorTUN.DOWNbutton.
Eachtimethe button ispressed,the frequency changes.
3.)Tosearchforastation quickly(automatictuning),keep the TUN.UPorTUN.
DOWNbutton pressed until the frequencystartstochange rapidlythen release
the buttons.The tunerwill stop on the firststrong station.Repeatuntil you find
the desired station.
4.)If you tune intoaFMstereo station,the STEREOindicatorwill showinthe
Display.
If the FMreception isnoisy,press the MODEbutton tochange toMono mode.
The MONOindicatorappearsinthe display.
5.)Adjustthe VOLUMEcontroltoyourlistening preference.
6.)Toturnoff the radio,press STOPbutton toshutpower‘Off’.
AntennaInformation
The stereo headphone cableservesasthe FMantenna when listening toFM
stations.Makesurethatthe headphone cableisunwound completelyinorderto
provide the bestreception.
HD8110_052404.p65 25/5/2004, 12:2117

18
PRESETTINGSTATIONSINMEMORY
Upto20 FMstationscan be stored intothe Presetmemories.Theywill remainin
memoryaslong asthe batteriesareinstalled.
1.)Press the RADIObutton toturnthe radion ‘On’.
2.)Press the TUN.UPorTUN.DOWNbutton totune astation.
3.)Press the MEMORYbutton –the display
blinks.
4.)Whilethe the displayisblinking,press the
PRESETbutton toselectthe Presetchannel
tostore.Example:04.
5.)PresstheMEMORYbuttonagaintostorethat
station intoPresetnumber04.
6.)Repeatsteps2-5selecting adifferentpresetchannelnumbereachtimeto
storeup to20 presetchannels.
TORECALL PRESETSTATIONS
1.)Press the RADIObutton toturnthe radion ‘On’.
2.) Press the PRESET button to select the preset station as desired.
3.) To change a preset station, enter a new station into the memory you wish to
change. The previously memorized station is replaced by the new station.
HD8110_052404.p65 25/5/2004, 12:2118

19
CLEANINGTHECABINET
Wipe withasoft cloth.If the cabinetisverydirty,dampen the clothwithaweak
solution ofneutraldetergentand water,and then wipe clean.
CLEANINGTHELENS
Adirtylenswill causesound skipping and,ifthe lensisverydirty,the CD maynot
work.Open the disc coverand clean the lensasfollows:
DUSTORDRYPARTICLES
Using acameralensbrush/blower,blowon the lens
severaltimes,then wipe itlightlywiththe brushtoremove
dust. Then,blowon the lensoncemore.
FINGERPRINTS
Toremovefingerprintsfromthe lens,useacotton swab
starting inthe middleand working tothe outside edge.
Useonlyverylightpressureon the lenstoavoidforcing
itoutofalignment.
CLEANINGTHEDISC
When adisc becomesdirty,clean itwithacleaning cloth.Wipe the disc fromthe
centerout.
NOTE:
Donotusesolventssuchasbenzine,thinner,commerciallyavailablecleanersor
anti-staticsprayintended foranalog discs.
CAREAND MAINTENANCE
HD8110_052404.p65 25/5/2004, 12:2119
