Emerson HD7999C User manual

PERSONALCD,CD-R/RWPLAYER
withLIGHTWEIGHT
STEREOHEADPHONES
HD7999C
OWNER’SMANUAL
Visitourweb siteatwww.emersonelectronics.ca
HD7999_031004.p65 11/3/2004, 10:15

1
Thankyou.........
Forpurchasing thisEmerson PersonalCDPlayer.The CDplayerhasa20
track programmablememorysoyou can listen tothesongsonyourfavorite
CD'sinanyorderyouchoose.Oryoucan usethe Randomplayback feature
and letthe playerselectthe playback orderforyou.Usethe 3-wayRepeat
featuretorepeatasingletrack,the entiredisc,oraprogrammed sequence
oftracks,indefinitely.
Pleaseread thisinstruction manualcompletelyand carefullytomakesure
you understand the properoperation ofthisproduct, and getthe maximum
enjoymentoutofall the featuresofthisstate-of-the-artCD player.
Onceagain,thanks forpurchasing thisEmerson product.
The serialnumberofyourCD playercan be found on the bottomcabinet.
Wesuggestthatyou recordthe serialnumberofyourunitinthe space
belowforfuturereference.
ModelNumber:HD7999C
SerialNumber:
HD7999_031004.p65 11/3/2004, 10:15

2
WARNING: TOPREVENTFIREORSHOCKHAZARD,
DONOTEXPOSE THISUNITTORAINORMOISTURE.
CLASS 1LASERPRODUCT
CLASS 1LASERPRODUCT
APPAREILÁLASERDECLASSE 1
PRODUCTOLASERDECLASE 1
CAUTION
INVISIBLELASERRADIATION
WHENOPENAND INTERLOCKS
DEFEATED.
AVOIDEXPOSURETOBEAM
ThisproductcontainsalowpowerLaserDevice.
•Placesexposed todirectsunlightor
closetoheatradiatingappliancessuch
aselectricheaters.
Avoidinstalling theunitinlocationsdescribedbelow:
•Dustyplaces.
•Placessubjecttoconstant
vibration.
•Humidormoistplaces.
CAUTION
THISLASERCOMPACTDISCPLAYERFUNCTIONSBY HELPOFINVISIBLE
LASERLIGHTAND ISEQUIPPEDWITHSAFETYSWITCHES TOAVOID
EXPOSUREWHENDOORISOPENAND SAFETYINTERLOCKS ARE
DEFEATED.ITISDANGEROUSTODEFEATORBYPASS SAFETYSWITCHES.
IMPORTANTNOTES
DANGEROUSVOLTAGE
Uninsulated DangerousVoltage,thatmaybe ofsufficient
magnitude toconstitutearisk ofelectricshock topersonsis
presentwithinthisproduct'senclosure.
ATTENTION
The Owner'sManualcontainsimportantoperating and
maintenanceinstructions.
Foryoursafety,itisnecessarytorefertothe manual.
!
HD7999_031004.p65 11/3/2004, 10:15

IMPORTANT
Since CD circuitry may cause interference to other radio tuners nearby,
switch this unit off when not in use or move it away from the affected radio
tuner.
NOTE: This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus as set out in the Radio Interference
Regulations of Industry Canada. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television (which can be determined by turning the equipment off),
the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
3
HD7999_031004.p65 11/3/2004, 10:15

4
PREPARATIONFORUSE
REMOVE THE TRANSIT CARD
This personal CD player is shipped with a dummy CD ‘transit card ‘ inside the CD
compartment. The purpose of this card is to prevent the laser from moving during
shipment of the product. This card must be removed before using the CD player.
Slide the OPEN switch to the right to unlock the CD door. Remove the ‘transit card’
from the player and discard it.
POWER SOURCES
This personal CD player is designed to operate on two “AA” batteries, not included.
Use a well known brand of Alkaline batteries for longest life and best performance.
This player can also be operated with an optional AC/DC converter/adapter, not
included. If you decide to purchase an optional AC/DC adapter the specification
must be as follows:
Input: 120V 60Hz AC
Output: 4.5V DC, 500 mA.
Plug: Female Type with Positive Center,
You may also purchase a “Universal” type AC/DC adapter which allows you to
select the required output voltage and plug polarity, and normally includes multiple
plug sizes to fit most brands of equipment.
Positive(+)Negative(–)
HD7999_031004.p65 11/3/2004, 10:15

5
INSTALLING THE BATTERIES
Note: The battery compartment is located on bottom cabinet.
1.) Slide the battery door in the direction of the ‘Arrow’ to open the battery door
and lift it up as shown.
2.) Inserttwoalkaline“AA”batteries(not included) in the batterycompartment. Be
sure to observe the polarity markings engraved on the battery door. If the
batteries are inserted incorrectly the unit will not work.
3.) Close the battery door, and push the battery door inward until you hear a ‘click’
sound to lock the door again.
REPLACING THE BATTERIES
When the battery symbol flashes in the display the batteries are becoming
weak and should be replaced.Always replace both batteries at the same time with
new fresh alkaline batteries. Do not mix old and new batteries or different types of
batteries together.
If the display remains blank when you press the PLAY/PAUSE button, the
batteries are completely dead. Replace them immediately. If dead batteries are
left inside the battery compartment for a long period of time they may leak and
cause damage to the unit, and such damage or corrosion from leaking batteries is
not covered by your warranty.
HD7999_031004.p65 11/3/2004, 10:33

6
CONNECTING THE OPTIONAL AC ADAPTER (NOT INCLUDED)
1.) Connect the small female plug of the optionalAC adapter to the “DC IN 4.5 V”
jack on the right side of the CD player.
2.) Connect the adapter housing to your 120V 60HzAC outlet.
Notes:
• Never connect or disconnect the adapter from the AC outlet while your hands
are wet.
• The housing of the AC adapter may become warm during operation. This is
normal.
• The female plug of the AC adapter must be completely disconnected from the
CD player in order to operate the player on batteries.
BATTERYPRECAUTIONS
Followtheseprecautionswhen using batteriesinthisdevice:
1.Useonlythe sizeand type ofbatteriesspecified.
2.Besuretofollowthe correctpolaritywhen installing the batteriesasindicated inthe battery
compartment. Reversed batteriesmaycausedamage tothe device.
3.Donotmixdifferenttypesofbatteriestogether(e.g.Alkaline and Carbon-Zinc)oroldbatteries
withfreshones.
4. If the deviceisnottobe used foralong period oftime,removethe batteriestoprevent
damage orinjuryfrompossiblebatteryleakage.
5.Donottrytorecharge batteriesnotintended tobe recharged;theycan overheatand rupture
(Followbatterymanufacturer’s directions.)
DC 4.5V Input Jack.
To 120V/60Hz AC Outlet.
OptionalAC/DCAdapter
HD7999_031004.p65 11/3/2004, 10:15

7
CONNECTING THE STEREO HEADPHONES
Connect the plug of the supplied stereo headphones to the green-colored
headphone jack on the left side of the cabinet.
NOTE: Make sure the headphone plug is inserted into the headphone jack as
far as it will go. If the plug is not fully inserted, you may only hear sound from
one side of the headphones.
IMPORTANT!
Always set the VOLUME control to a low level before you put the headphones on
and begin playing a CD. Then start playback and gradually increase the volume to
a comfortable listening level. Do not play the CD at loud volume levels that might
prevent you from hearing warning sounds such as car horns, etc.
HD7999_031004.p65 11/3/2004, 10:15

8
1.)OPENSwitch–Slide tothe righttounlock and open the CD door.
2.)HOLDOn/Off Switch.
3.)CDDoor.
4.)MODEButton -Toselectthe playback mode:Repeat1/All orIntro.
5.)RANDOMButton.
6.)PROGRAMButton.
7.)SKIP/SEARCH ReverseButton.
8.)SKIP/SEARCH ForwardButton.
9.)LCDDisplay–ShowsTrack number,Program,Repeat, Random,and Intro
modes.
10.)PLAY/PAUSE Button.
11.)STOPButton.
12.)BatteryCompartment(BottomCabinet).
13.)DC IN4.5VInputJack –Connectan ACadapter(notincluded)tothisjack to
use120V60Hzhousecurrent.
14.)LINEOUTJack –Connecttoan externalaudioequipmentinput.
15.)PHONES Jack –Connectstereo headphones,included,tothisjack.
16.)VOLUMEControl–Raisesorlowersthe volume.
17.)BASS On/Off Switch.
LOCATIONOFCONTROLSAND INDICATORS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
HD7999_031004.p65 11/3/2004, 10:15

9
1.)HOLDIndicator–Appearswhen HOLDswitchissetto‘On’position.
2.)(Repeat1)/ALL Indicators–Appearswhen the Repeatplayback
mode isselected.
3.)Track NumberDisplay.
4.)BatteryStatusIndicator–Flasheswhen batterylevelbecomeslow.
5.)PROG (Program) Indicator–Appearswhen programming tracks or
playing programmed tracks.
6.)RANDOMIndicator–Appearswhen Randomplayback mode is
selected.
7.)INTROIndicator–Appearswhen Introplayback mode isselected.
LCD DISPLAYINDICATORS
HOLD
1 ALL RANDOM
INTRO
PROG
1
2
3
4
5
6
7
HD7999_031004.p65 11/3/2004, 10:15

10
OPERATINGINSTRUCTIONS
SPECIAL FUNCTIONS
HOLD Switch
The HOLD switch on the left side of the cabinet must be in the ‘Off’ (left) position
to start the CD player. If you plan to carry the CD player in a handbag, briefcase,
school bag, back pack, etc, slide the HOLD switch to the ‘On’ (right) position.
While the HOLD switch is ‘On’ all of the controls on the CD door are disabled. This
prevents the player from starting accidentally by something pressing against the
PLAY/PAUSE button.
After you begin CD playback you may also slide the HOLD switch to the ‘On’ (right)
position to disable all the controls on the CD door. You can then place the player in
a handbag, backpack, etc, and do not have to worry that the player will be
accidentally turned off by something pressing against the STOP button or Track
Skip buttons.
BASS Boost Switch
During CD playback you may slide the BASS switch to the ‘On’ position to activate
the Bass Boost function as desired.
HOLD
Off
HOLD
BASS
Off
HD7999_031004.p65 11/3/2004, 10:15

11
NORMAL CD PLAYBACK
• Make sure you have installed the batteries.
• Make sure the HOLD switch is set to the ‘Off’ (left) position.
• Make sure to set the VOLUME control to a low setting before you put on
the headphones.
IMPORTANT:
This CD player can play normal CDs plus CD Recordable (CD-R) and CD
Rewriteable (CD-RW) discs. However the playability of CD-R and CD-RW discs
may be affected by the type of software that was used in ‘ripping’ the tracks from
the original discs and ‘burning’ the tracks onto the blank media. Playability may
also be affected by the quality and condition of the blank media you use for
recording. 100% compatibility cannot be guaranteed. This is not an indication of
any problems with your player.
1.) Slide the CD door OPEN switch to the right to unlock
and open the CD door.
2.) Place your CD on the center spindle with the printed
label side facing up. Press downward on the disc near
the center hole until the disc is fully seated on the
spindle.
3.) Close the CD door and connect the headphones to the headphone jack (green
color) by pushing the headphone plug the into headphone jack until a ‘click’
sound is heard.
4.) Press the PLAY/PAUSE button to begin
playback. The “ – – “ flashes while the player
reads the disc. The total tracks will appear
briefly in the display and then the playback
will begin on track 1. The display will show the track being played.
5.) Adjust the VOLUME, and BASS controls as desired.
OPEN
HD7999_031004.p65 11/3/2004, 10:15

12
6.) Playback will continue until the end of the disc, then the player will stop
automatically and the display will again show the total tracks on the disc.After
approximately 30 seconds the power switches ‘Off’ automatically to conserve
the batteries and the display goes blank. To stop playback before the disc
ends press the STOP button at any time. Press the STOP button after
the disc has stopped to shut the power ‘Off’ completely.
PAUSE CONTROL
To pause momentarily during playback press the PLAY/PAUSE button again.
The track number display flashes. The sound stops but the disc continues to spin.
Press the PLAY/PAUSE button once more to cancel Pause mode and resume
normal playback. The track number display stops flashing.
SKIP/SEARCH CONTROLS
Press the or buttons repeatedly during playback to skip to higher or lower
numbered tracks. Playback will begin on the selected track.
To search within a track at high speed to locate a specific musical passage press
and hold either the or controls. The player will search rapidly forward or
backward as long as the buttons are pressed. The volume is automatically muted
during high speed search. Watch the elapsed time display. When the time display
reaches the desired point, release the buttons. Normal playback will resume at
that point and the volume returns to normal level.
HD7999_031004.p65 11/3/2004, 10:15

13
REPEAT PLAYBACK
The player can be programmed to continuously repeat a single track or the entire
disc automatically.
One Track Repeat
During playback press the or buttons to select the track to be repeated,
then press the MODE button once. The ‘1 ’indicator appears in the display and
the selected track will be repeated continuously.
Press the STOP button to cancel Repeat 1 playback.
All Tracks Repeat
Press the PLAY/PAUSE button to begin playback, then press the MODE button
twice. The ALL indicator will appear in the display and the entire disc will be
repeated continuously.
Press the STOP button to cancel All Track Repeat playback.
1
ALL
HD7999_031004.p65 11/3/2004, 10:15

14
INTRO (Intro Scan) PLAYBACK
The Intro Scan feature plays only the first 10 seconds of each track on the disc.
This feature is useful when you are trying to find a particular song but you cannot
remember the title.
1.) Load your disc in the player as usual and press thePLAY/PAUSE button to
begin playback.
2.) When playback begins press the MODE
button 3 times. The INTRO indicator flashes.
3.) Press the PLAY/PAUSE button once more. The INTRO indicator stops
flashing and remains ‘On’. The player backs up to the beginning of track 1,
plays the first 10 seconds of each track on the disc, and then stops.
To cancel Intro Scan playback press the STOP button.
RANDOM PLAYBACK
When Random playback is selected all the tracks on the disc will be played back
in random order.
1.) Load your disc in the player as usual and press thePLAY/PAUSE button to
begin playback.
2.) When playback begins press the RANDOM
button. The RANDOM indicator flashes.
3.) Press the PLAY/PAUSE button once more. The RANDOM indicator stops
flashing and remains ‘On’. The player randomly selects a track for playback.
After each track has played once the player stops.
To cancel Random playback press the STOP button.
INTRO
RANDOM
HD7999_031004.p65 11/3/2004, 10:15

15
PROGRAMMED PLAYBACK
You can program up to 20 tracks on a disc to play in any desired order.
NOTE: You can program a disc either during playback or in Stop mode.
1.) Press the PROGRAM button once. The
PROG indicator and the ‘0 0’ flashes in the
display.
2.) Press the or button to select the first
track to be programmed.
Example: Track # 02.
3.) When the desired track number is flashing in
the display press thePROGRAM button again
to enter the desired track number in Program
Number 1. The track number returns to “0 0”.
4.) Repeat Steps 2 and 3 to program additional tracks up to a maximum of 20.
5.) Press the PLAY/PAUSE button to begin
programmed playback. The PROG indicator
remains in the display and the track display
stops flashing.
• Playback begins with the first track you programmed and continues until all
programmed tracks have been played, and then the player stops. The
programmed sequence will remain in the memory until the power shuts off
(approximately 30 seconds) or until the CD door is opened.
• If you press the PROG and PLAY/PAUSE buttons again before the power
shuts off the programmed sequence will play again.
PROG
PROG
PROG
PROG
HD7999_031004.p65 11/3/2004, 10:15

16
LINEOUTJACK (CABLENOTINCLUDED)
The LINEOUTJack allowsyou toconnectthispersonalCDplayertothe Record
Inputjacks ofacassetterecorderorMiniDisc recorderfordirectrecordingsof
compactdiscs.You mayalsoconnectthispersonalCD playertothe Line Input,
AuxiliaryInput, orCD Inputjacks ofastereo receiver,homeaudiosystem,orcar
stereo sothatyou can listen toyourCDsthrough the speakersofthe othersystem.
Note:The connection cableisnotincluded.
TO:AUX(LINE)INPUT.
LINEOUTJACK.
HD7999_031004.p65 11/3/2004, 10:15

17
CLEANINGTHECABINET
Wipe withasoft cloth.If the cabinetisverydirty,dampen the clothwithaweak
solution ofneutraldetergentand water,and then wipe clean.
CLEANINGTHELENS
Adirtylenswill causesound skipping and,ifthe lensisverydirty,the CD maynot
work.Open the disc coverand clean the lensasfollows:
DUSTORDRYPARTICLES
Using acameralensbrush/blower,blowon the lens
severaltimes,then wipe itlightlywiththe brushtoremove
dust. Then,blowon the lensoncemore.
FINGERPRINTS
Toremovefingerprintsfromthe lens,useacotton swab
starting inthe middleand working tothe outside edge.
Useonlyverylightpressureon the lenstoavoidforcing
itoutofalignment.
CLEANINGTHEDISC
When adisc becomesdirty,clean itwithacleaning cloth.Wipe the disc fromthe
centerout.
NOTE:
Donotusesolventssuchasbenzine,thinner,commerciallyavailablecleanersor
anti-staticsprayintended foranalog discs.
CAREAND MAINTENANCE
HD7999_031004.p65 11/3/2004, 10:15

Lecteur CD, CD-R/CD-RW portatif avec
casque d’écoute stéréo léger
GUIDE D’UTILISATION
HD7999C
Visitez notre site Web, au : www.emersonelectronics.ca

Nous vous remercions……
D’avoir acheté ce lecteur CD portatif d’Emerson Le lecteur CD
possède également une mémoire de 20 pistes vous permettant
d’écouter les chansons de votre DC préféré, dans l’ordre que vous
désirez. Vous pouvez également utiliser la fonction de lecture
aléatoire et laisser le lecteur sélectionner l’ordre de lecture pour vous.
Utilisez la répétition à trois voies pour répéter indéfiniment une seule
piste, le disque en entier ou une séquence programmée ou laissez le
lecteur déterminer la séquence de pistes.
Pour vous permettre de profiter au maximum de toutes les fonctions
avancées de votre nouveau lecteur CD, veuillez lire ce guide
d’utilisation attentivement et en entier. Conservez-le pour toute
référence ultérieure.
Nous vous remercions encore une fois d’avoir fait l’acquisition de cet
appareil Emerson.
Vous trouverez le numéro de série de votre lecteur CD sous le boîtier
de celui-ci. Afin de pouvoir vous y référer ultérieurement, veuillez
l’inscrire dans l’espace ci-dessous :
No. de modèle : HD7999C
No. de série :_________________________
1
