Eminent EM7100 User manual

EM7100 - Wireless HD sender and receiver

2 | ENGLISH
EM7100 - Wireless HD sender and receiver
Warnings and points of attention
Due to laws, directives and regulations set out by the European Parliament, this
device could be subject to limitations concerning its use in certain European member
states. In certain European member states the use of this product could be prohibited.
More information regarding this warning can be found in the Declaration of Conformity
on the last page of this document!
Inhoudsopgave
1.0 Introduction ...........................................................................................................2
1.1 Functions and features ......................................................................................2
1.2 Packing contents ...............................................................................................3
1.3 Explanation of the EM7100...............................................................................3
2.0 Installing the EM7100 wireless sender unit ............................................................5
2.1.1 Installing the sender unit using HDMI..............................................................5
2.1.2 Installing the sender unit using component .....................................................5
2.1.3 Installing the sender using SCART or composite ............................................5
3.0 Installing the receiver unit ......................................................................................5
3.1 Installing the receiver unit using HDMI...............................................................6
3.2 Installing the receiver unit using component ......................................................6
3.3 Installing the receiver unit using SCART or composite.......................................6
4.0 Using the EM7100.................................................................................................6
5.0 Connecting a digital receiver (HDMI only)..............................................................7
6.0 Frequently asked questions...................................................................................7
7.0 Service and support...............................................................................................8
8.0 Warranty conditions...............................................................................................9
9.0 Declaration of Conformity ......................................................................................9
1.0 Introduction
Congratulations with the purchase of this high-quality Eminent product! This product
has undergone extensive testing by Eminent’s technical experts. Should you
experience any problems with this product, you are covered by a five-year Eminent
warranty. Please keep this manual and the receipt in a safe place.
Register your product now on www.eminent-online.com and receive product updates!
1.1 Functions and features
The EM7100 is a wireless HD sender which allows you to stream your HD content
wirelessly from your media player or media device such as the Eminent EM7080
hdMEDIA RT or the EM7075 hdMEDIA STREAM DTS to your television. For example,

3 | ENGLISH
this is ideal when your media player is located in your living room, while you want to
watch your Full HD movies on your LCD or Plasma television in your bedroom.
Thanks to the great wireless performance of the EM7100, the movies will be shown in
full HD (HDMI only) without any delay. Just install the EM7100 and start enjoying your
media!
1.2 Packing contents
The following parts need to be present in the packing:
•EM7100 (wireless sender and wireless receiver unit)
•Two standards
•Two power supplies
•IR Flasher
•Component adapter
•Remote control
•Manual
1.3 Explanation of the EM7100
Both the sender and receiver have several connections at the back. We will explain
these connections in the following chapter. Also, the remote control will be explained.
Although the EM7100 will have a black color, the images below are in a lighter color
for clarity and highlighting the connections.
Wireless sender unit:
1. HDMI 1 IN: Used to connect the first
HDMI device.
2. HDMI 2 IN: Used to connect a
second HDMI device.
3. AV-IN: Used to connect a SCART
device.
4. IR-OUT: Use to connect the IR
Flasher.
5. PC AUDIO IN: Used to connect a
3.5 “ jack from the media device.
6. PC-IN: Used to connect the
component converter.
7. LAN: For professional use only.
8. DC: Used to connect the power
supply.
Image 1: Sender unit

4 | ENGLISH
Wireless receiver unit:
1. HDMI OUT: Used to connect a HDMI
television, monitor or HDMI receiver.
2. AV-OUT: Used to connect your television
or monitor using a SCART cable.
3. IR-IN: Not used
4. AUDIO-OUT: Used to connect stereo
speakers or a 2.0 receiver.
5. COMPONENT-OUT: Used to connect
your television or monitor using composite
cables.
6. USB: Used for firmware upgrades or
maintenance usage.
7. LAN: For professional use only.
8. DC: Used to connect the power supply.
Image 2: Receiver unit
Remote control:
1. Power button: Used to turn the EM7100
on or off.
2. Info button: Used to display information
about the wireless signal etc.
3. Receiver video source: Used to select
the video output of the receiver unit.
4. Sender video source: Used to select the
video source of the sender unit.
5. Sender audio source: Used to select the
audio source of the sender unit.
6. LAN button: Select the LAN interface.
7. WiFi channel 1: Used to select wireless
channel 1.
8. WiFi channel2: Used to select wireless
channel 2.
Image 3: remote control

5 | ENGLISH
2.0 Installing the EM7100 wireless sender unit
The EM7100 sender can be connected using different types of video cables: Using
HDMI, using component or by using SCART (composite to SCART). Use the following
steps to connect the EM7100.
2.1.1 Installing the sender unit using HDMI
1. Take the EM7100 (Sender and receiver unit) and accessories out of the
packaging.
2. Place the sender unit near your media player or media device.
3. Connect the IR flasher (IR cable) to the ‘IR-OUT’ connection on the sender unit.
4. Connect the HDMI cable to the ‘HDMI 1’ connection of the sender unit.
5. Connect the other side of the HDMI cable to your media player or media device.
6. Place the IR flasher near or in front of the media player or media device.
7. Place the sender unit in the supplied standard for optimal stability.
2.1.2 Installing the sender unit using component
1. Place the sender near your media player or media device.
2. Connect the IR flasher (IR cable) to the ‘IR-OUT’ connection on the sender unit.
3. Connect the component cables to the corresponding colors of the component
adapter.
4. Connect the other side of the component cables to the corresponding ports of
your media player or media device.
5. Then connect the component adapter to the ‘PC-IN’ connection of the sender
unit.
6. Place the IR flasher near or in front of the media player or media device.
7. Place the sender unit in the supplied standard for optimal stability.
2.1.3 Installing the sender using SCART or composite
1. Place the sender unit near your media player or media device.
2. Connect the IR flasher (IR cable) to the ‘IR-OUT’ connection of the sender unit.
3. Connect the SCART or composite to SCART to the ‘AV-IN’ connection of the
sender unit.
4. Place the IR flasher near or in front of the media player or media device.
5. Place the sender unit in the supplied standard for optimal stability.
3.0 Installing the receiver unit
The EM7100 receiver unit can be connected using different types of video cables:
Using HDMI, using component or by using SCART (composite to SCART). Use the
following steps to connect the EM7100 receiver unit:

6 | ENGLISH
3.1 Installing the receiver unit using HDMI
1. Place the receiver unit near your television.
2. Connect the HDMI cable to the ‘HDMI-OUT’ port of the receiver unit.
3. Connect the other side of the HDMI cable to the HDMI connection of your
television.
4. Place the receiver unit in the supplied standard for optimal stability.
5. Now connect the power supply of both the sender and receiver unit to a wall
outlet and to the ‘DC’ connection of the sender and receiver unit.
3.2 Installing the receiver unit using component
1. Place the receiver unit near your television.
2. Connect the component cables to the ‘COMPONENT-OUT’ connection of the
receiver unit. Make sure the colors of the component cables do match the colors
of the ‘COMPONENT-OUT’ connection of the receiver unit.
3. Connect the other side of the component cables to the corresponding component
connections of your television.
4. Place the receiver unit in the supplied standard for optimal stability.
5. Now connect the power supply of both the sender and receiver unit to a wall
outlet and to the ‘DC’ connection of the sender and receiver unit.
3.3 Installing the receiver unit using SCART or composite
1. Place the receiver unit near your television.
2. Connect the SCART cable (or composite to SCART) to the ‘AV-OUT’ connection
of the receiver unit.
3. Connect the other side of the SCART cable or composite cable to the
corresponding connection of your television.
4. Place the receiver unit in the supplied standard for optimal stability.
5. Now connect the power supply of both the sender and receiver unit to a wall
outlet and to the ‘DC’ connection of the sender and receiver unit.
4.0 Using the EM7100
The EM7100 has now been setup. You can now enjoy the full potential of wireless Full
HD streaming!
1. Make sure all devices have been started. Bear in mind that starting the EM7100
can take up to one and a halve minute.
2. Also, make sure you have chosen the right video channel on your television. If
correct, the screen or main menu of the media player or media device will be
shown.
3. If you do not see the screen or main menu of the media player or media device,
then use the supplied remote control to ‘switch’ to the correct video-mode.

7 | ENGLISH
4. Press ‘HDMI 2’ if you want to switch to the second HDMI device.
5. Press ‘Component’ if you are using component cables.
6. Press ‘AV’ if you are using SCART or composite to SCART cables.
5.0 Connecting a digital receiver (HDMI only)
Since the EM7100 receiver unit is equipped with a HDMI-OUT connection, it is also
possible to connect a digital receiver to the EM7100 receiver unit. This is ideal if the
digital receiver is equipped with a surround sound system.
1. Connect the HDMI cable to the ‘HDMI-OUT’ connection of the EM7100 receiver
unit.
2. Connect the other side of the HDMI cable to the HDMI input connection of your
digital receiver.
3. If correct, your digital receiver is also equipped with a HDMI output. Connect
another HDMI cable to the HDMI output connection of your digital receiver.
4. Connect the other side of this HDMI cable to the HDMI connection of your
television.
5. The television should now be able to display the main menu of your media player
or media device while your digital receiver can use the digital signals for the
(surround) sound system.
6.0 Frequently asked questions
Q: The EM7100 wireless receiver is equipped with a HDMI Out port. Which
sound formats are supported?
A: The EM7100 has HDMI 1.1 compliant HDMI ports. This means DTS 5.1 and
AC3 5.1 are supported streams. However, bear in mind that you need a
(certified) digital DTS receiver to playback DTS sound streams (if your
media player or media device cannot decode DTS to PCM sound). In some
cases you need to setup the media player or media device to use the DTS
or AC3 sound system. Refer to the manual of you media player or media
device.
Q: I do have other wireless N devices in my house. It seems the wireless signal
of the EM7100 is not sufficient enough to stream my HD content. Is it
possible to change the wireless signal of the EM7100 in order to prevent my
other wireless N devices interfering the wireless signal of the EM7100?
A: Yes. It is possible to change the wireless channel of the EM7100: Press the
‘WiFi CH 1/WiFi CH 2’ button on the remote control for approximately 5
seconds. The wireless channel will be changed and the EM7100 system
will be rebooted.
Q: How can I reset the EM7100?

8 | ENGLISH
A: You can reset the EM7100 using the following steps:
•Shut down the EM7100 wireless sender and receiver by unplugging the
power supply of both devices
•Press and keep pressing the button at the front of the wireless sender or
receiver
•Connect the power supply
•Keep the button pressed for another 3-5 seconds. The moment you stop
pressing the button, the device will be set back to factory settings
•Repeat these steps for the second device
Q: The EM7100 units do have LAN interfaces. For what purposes are these
interfaces?
A: The LAN interfaces are for professional usage only. These LAN connections
can be used to stream media content using your LAN network or to make
changes to the EM7100. However, network expertise is essential. Eminent
only supports the wireless interface. Using the LAN interface to change
settings is at own risk!
7.0 Service and support
This users manual has been carefully written by Eminent’s technical experts. If you
have problems installing or using the product, please fill out the support form at the
website www.eminent-online.com/support.
You can also contact us by phone. Below you will find a list with phone numbers for
each supported country.
Country
Phone number
Rate per minute*
Belgium (Dutch) 070 277 286 €0.30
Belgium (French) 070 277 286 €0.30
Denmark [phone] Local Costs
Finland [phone] Local Costs
Germany 1805 982 234 €0.14
Italy [phone] Local Costs
Norway [phone] Local Costs
Spain 807 080 042 €0.41
Sweden [phone] Local Costs
The Netherlands 0900-3646368 €0.45
UK 905 871 0013 £0.30
* Rates mentioned in this table do not include cell phone charges.

9 | ENGLISH
8.0 Warranty conditions
The five-year Eminent warranty applies to all Eminent products unless mentioned
otherwise before or during the moment of purchase. When having bought a second-
hand Eminent product the remaining period of warranty is measured from the moment
of purchase by the product’s first owner.
The Eminent warranty applies to all Eminent products and parts inextricably
connected to and/or mounted on the main product. Power supply adapters, batteries,
antennas and all other products not integrated in or directly connected to the main
product and/or products of which, without reasonable doubt, can be assumed that
wear and tear show a different pattern than the main product are not covered by the
Eminent warranty. Products are not covered by the Eminent warranty when subjected
to incorrect/improper use, external influences and/or when opened by parties other
than Eminent.
9.0 Declaration of Conformity
To ensure your safety and compliance of the product with the directives and laws
created by the European Commission you can obtain a copy of the Declaration of
Conformity concerning your product by sending an e-mail message to: info@eminent-
online.com. You can also send a letter to:
Eminent Computer Supplies
P.O. Box 276
6160 AG Geleen
The Netherlands
Clearly state ‘Declaration of Conformity’ and the article code of the product of which
you would like to obtain a copy of the Declaration of Conformity.

EM7100 | 03-2010
