Emm labs Pre2 User manual

PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

001

Version 1.1

ank you for choosing EMM Labs...

Welcome 002

PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Warranty

Operational Features

PRE2 STEREO PREAMPLIFIER

Main Screen

Front Panel & Functions 008

008

Rear Panel & Functions

011

012

003

Table Of Contents

Welcome 002

005

007

009

006

PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Features & Specifications

012

013

Volume Knob and Signal Gain

Input Selectors

Product Power Up

Programming Menu

014

Display Contrast and Brightness

Appendix A - Serial Remote Control (RS232)

Infrared Remote Control

Input Naming Menu

Volume Display Units

System Maintenance

Input Preselect 017

008

Clear Settings

019

004

Table Of Contents

014

015

016

017

016

PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Set Volume Font

018

Warranty

EMM Labs warrants the PRE2 product against defects in material

and workmanship under normal use and service for a period of time

specied by the product’s serial number from the date of rst

delivery to the owner. e warranty time period is 5 years. Warranty

is limited to the original owner and is non-transferable.

EMM Labs will pay for return shipping charges back to the owner

when the product is sent to EMM Labs within the rst 90 days aer

purchase (US and Canada end-users only). Otherwise, owner will be

responsible for all shipping charges to and from EMM Labs.

For all warranty claims, a copy of the original invoice must

accompany the product.

Opening the product or modifying it in any way by the owner,

including but not limited to cryogenic treatment, will void any

warranty.

Please contact EMM Labs ([email protected]) for RMA number

and shipping instructions before shipping any product to EMM Labs.

EMM Labs products are sold worldwide through authorized dealers

with restricted territories. EMM Labs product purchased from

non-authorized dealers or from a dealer selling outside his / her

authorized territory will automatically void product warranty.

005 PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

006

PRE2 STEREO PREAMPLIFIER

Built on the heritage of the famous PA6i, the PRE2 preamplier

incorporates Ed’s latest preamplication designs coupled with ground

breaking technology.

e PRE2 STEREO PREAMPLIFIER features:

• 6 sets of stereo analog inputs and 1 stereo recording loop.

• 100% contactless dual-balanced discrete audio paths.

• Proprietary soware-based analog volume control.

• Exclusive aerospace-grade composite laminate circuit boards.

• Newly designed intuitive control system featuring

programmable input naming, settings recall and many

additional features.

• Proprietary High-isolation resonant mode power supply for

silent, green operation.

e PRE2 is the culmination of years of research and development

resulting in EMM Labs most sophisticated and transparent

preamplier to date.

PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

007

Features & Specifications

Features & Specications

S/N ratio: 110dB (A-weighted)

THD: 1kHz <0.01%; 20kHz <0.01%

Frequency range: 0Hz-100kHz

Gain control range: Better than 62dB

Maximum output level: +/- 11V p-p (+26 dBu)

Maximum input level: +/- 7V p-p (+22 dBu)

System Gain: +12dB

Analog Inputs:

• 2 Stereo sets of Balanced (XLR) - Input Impedance: 20kΩ

• 4 Stereo sets of Un-Balanced (RCA) - Input Impedance: 10kΩ

• 1 Stereo Loop Input Un-Balanced (RCA) - Input Impedance: 50kΩ

Analog Outputs:

• 1 Stereo set of Balanced (XLR) - Output Impedance: 150Ω

• 1 Stereo set of Un-Balanced (RCA) - Output Impedance: 75Ω

• 1 Stereo Loop Output Un-Balanced (RCA) - Output Impedance: 300Ω

System:

• System control via serial RS-232

• Soware upgradeable

Power Consumption Max: 40W

Dimensions W x D x H: 435 x 400 x 92mm, Weight: 12kg

PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

008

Front Panel and Functions PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Front Panel & Functions

1. Standby/Power-Save button:

Toggles the operation between on and power-save mode. In power save mode the

remote control and all front panel functions become inactive.

2. Program and Function buttons:

Front panel buttons used to access functions and program the PRE2.

3. PRE2 Display:

Display can be dimmed or turned o using the the remote DIM button.

4. Input Selection buttons.

5. PRE2 Volume Knob.

009

Back Panel and Functions PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Back Panel & Functions

1. Analog Inputs:

• Inputs 1 and 2 are balanced XLR inputs

• Inputs 3, 4, 5 and 6 are un-balanced RCA inputs

2. Loop Input and Output (un-balanced)

3. Analog Outputs:

• Le and Right Balanced (XLR) Connectors

• Le and Right Un-Balanced (RCA) Connectors

4. System:

• Remote RS232: RS232 control port

• USB: soware update port

010

Back Panel and Functions PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Back Panel & Functions

4. System (Cont’d):

• RESET: Used to access the backup BIOS.

5. Product model and serial number indicator:

Warranty void if model/serial number indicator is not attached to unit, missing or

damaged whereby serial number cannot be seen.

6. Main Power connector and Power Switch

7. Product VOLTAGE indicator:

Indicates working voltage of the PRE2. Only use with indicated line voltage.

011

Operational Features PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Main Screen

1. Mute Button

Pressing the mute button initiates a 2-stage, sequential Mute

function. So Mute (-20dB from the current level), Full Mute,

and nally Mute O. Mute is O/disabled as soon as the

Volume knob is rotated or the Volume buttons are depressed

on the remote. Once Mute is o the PRE2 will return the

signal path to its current volume setting. A short fade-in is

performed to avoid audible transient artifacts.

2. Loop Button

e Loop function allows for the insertion of an external

device (e.g. signal processor) into the main signal path. ere is no gain applied to loop return signal. e state of Loop path

is input-dependent. Each preamp input can engage the Loop as required.

3. PGM Button

e PGM (program) opens a pop-up menu with 4 main programming or conguration selections. New navigation buttons

will appear: Up, Down, Enter, and Exit. See “Programming Menu” section.

4. SAVE Button

e SAVE function immediately saves the state of the system in non-volatile memory. e following parameters are saved:

• Volume Step Number and Loop state - as set for each input

• Volume Display Units (steps or decibels)

• Volume Font: 7-Segment or a ‘Designer’ font

• LCD display Contrast and Brightness settings

• e default input to be selected upon power-up.

012

Operational Features PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Main Screen

4. SAVE Button (cont’d)

Notes:

• e Mute is a transient feature and its state is not saved. PRE2 product powers up with Mute O.

• Input names are saved from a dedicated, on-screen name editor; see the ‘Programming Menu’

e Volume Knob and Signal Gain

e Volume knob adjusts the signal gain from full attenuation (step 0) to maximum gain at step 100. e maximum gain

measured from any input to RCA output is +6dB. e maximum gain measured from any input to XLR output is +12dB.

From the top of the control range (Step 100) down to Step 10, a single step lowers the gain by 0.5dB. Below Step 10, the

changes are progressively coarser. Step 1 is at -64dB. Volume indicator on the main screen shows either the Volume Step or

Signal Gain in decibels (Please ‘Programming Menu’ to change Volume indicator). e gain is referenced to signal level at the

RCA outputs. Actual gain at XLR outputs is 6dB higher.

Input Selectors (1 to 6)

Input selection buttons connect one of six front-end input stages to main signal path. e system performs short fadeout/

fade-in operation on signals being switched. Please Note: e Mute is applied in the main (common) signal path; input

selection does not aect the state of Mute.

Product Power-up

Upon Power-Up Reset, the system controller restores the input and display settings as listed in section 1.1.4. In addition,

all input names (kept in separate les in non-volatile memory) are restored. File data integrity is checked. Should data

corruption occur, the system reformats aected set-up les and restores default conguration.

013

Operational Features PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Product Power-up (cont’d)

In a newly built product or when PRE2 is reset, default settings are as follows:

• Selected input : Input 1 (XLR)

• Volume : Step 0 (all inputs)

• Volume Units : Steps

• Loop : O (all inputs)

• Mute : O

• LCD Contrast/Brightness : Mid-point

• Input Names: : Blank, no characters (all inputs)

• Volume Font : ‘7-segment’ font

Programming Menu

In this release, the programming menu has 4 items, shown in a pop-up box on the LCD screen.

014

Operational Features PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Programming Menu (cont’d)

1. Display Contrast and Brightness

Contrast and Brightness both have a 9-step adjustment range, visualized on screen by horizontal indicator bar. e le

and right arrow so buttons operate the adjustment. Contrast and Brightness adjustments have separate screens, and the

so button ‘NEXT’ allows you to access both screens. Both settings are saved in non-volatile memory from the main

screen.

2. Input Naming Menu

Input names are edited using the Volume knob and the line editor with 3 so buttons: Cursor Le, Cursor Right, and

Backspace Erase. Rotating the Volume knob changes the character at the cursor position. e character set is as follows:

• capital letters A-Z

• SPACE character

Display Contrast and Brightness Input Naming Menu

015

Operational Features PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Programming Menu

2. Input Naming Menu (cont’d)

• DASH, PERIOD, and SLASH characters

• digits 0-9.

Rotating the Volume knob scrolls through the characters. Pressing one of Input Selector buttons shows the current name

of the input, and allows the name to be edited. e name being edited is stored only by pressing the ‘SAVE’ button on this

screen. Pressing another input button or selecting a dierent/same input discards the changes. Pressing the ‘Quit’ button

returns you to the ‘Programming Menu’ page, discarding any changes made.

3. Volume Display Units

e screen shows a sample value of the Volume display.

e ‘Change Units’ so button toggles the Volume

display units to the following two options:

• Volume Step

• Gain in [dB]

e Volume knob is active and you can change the

sample value. e actual Volume (signal gain) is not

aected. e Volume display unit selected is stored only

by pressing the ‘SAVE’ button. Upon ‘EXIT’ aer ‘SAVE’

the main screen will display the selected Volume display

unit. Pressing ‘EXIT’ without pressing ‘SAVE’ discards any changes.

016

Operational Features PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Programming Menu

4. System Maintenance

e System Maintenance screen shows the current rmware version and a list of maintenance tasks. e tasks are

selected by using the numbered input select buttons. In this release, there are 3 maintenance tasks:

• Set Volume Font (2 options):

a. 7-segment font

b. EMM font

In future updates EMM may update the Volume Font selection with many other fonts.

Font selection is saved only when you press the ‘SAVE’ button. Pressing ‘EXIT’ without pressing ‘SAVE’ discards any

changes.

System Maintenance Volume Font Selection

017

Operational Features PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

Programming Menu

4. System Maintenance (cont’d)

• Input Preselect

e power-on input can be changed by the user using the ‘Input Preselect’ feature. e current power-on input is

shown on-screen. At this point, any Input can be chosen either by pressing the associated numbered input button or

by using the ‘NEXT’ so button. Pressing the ‘SELECT’ so button saves the new setting.

• Clear Settings

All user settings will be reset to run the factory default programming. An alert box ‘Proceed?’ is shown rst

allowing the user to cancel the operation.

Input Preselect Clear Settings

018

Infrared Remote Control PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

DISPLAY

VOL

UNITS

1

4

LOOP

DIM

23

5 6

MUTE

INPUT

VOLUME

Infrared Remote Control

VOL UNITS : is button toggles volume display units between steps and dB

DIM : is butons toggles through the 3 display states:

• DIM (dim the display)

• OFF (display o)

• FULL (back to the current default setting)

INPUT (1 to 6) : ese buttons can be used to directly access any INPUT.

LOOP : Turns LOOP funtion on/o for the selected INPUT

MUTE : is buttons toggles through 3 MUTE states:

• SOFT MUTE

• MUTE

• MUTE OFF

VOLUME : Controls the volume/signal gain. Press the up arrow button to

increase volume/gain. Press the down arrow button to decrease

volume/gain

019

Appendix A - PRE2 Serial Remote Control (RS232)

PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

PRE2 Serial Remote Control (RS232)

Introduction

e PRE2 can be remotely controlled in one of the two (mutually exclusive) modes:

• Standard mode

• Slave Preamp mode.

In Standard mode the product receives and acts upon the RC-6 Infra Red Remote commands. Recognized IR codes are

translated into EMM Labs’ ASCII-based control commands that are sent out on the RS232 port. e Command Protocol is

dened in Section 2. e PRE2 also receives the control commands from RS232 port. Recognized commands are acted upon,

and, in addition, echoed (sent out) in the transmit path on the RS232 port.

All outgoing RS232 commands are destined for slave PRE2s, which are meant to act in sync with main unit. In Slave Preamp

mode, the IR Remote receiver is disabled, but the product still receives commands at its RS232 port. As before, the decoded

and recognized commands are echoed in the transmit path of the RS232. is will facilitate product daisy-chaining, where

multiple slave preamps can act in sync with the main (Standard) unit.

In either mode, all front panel controls and menus are fully operational. Standard/Slave modality determines only the

IR remote control capabilities of this product. e Standard controller mode is best used in the following scenarios:

• PRE2 is the only preamp in a system

• PRE2 is the main pre-amp in a multichannel set-up, typically running front-le and front-right channels; the main

preamp is receiving IR remote commands, while other preamps are slaved to it.

e Slave mode should be used when the PRE2 is in the signal path of any additional channels in a multichannel

set-up. e slave unit follows main preamp actions while the main unit receives IR Remote commands. Multiple

slave preamps can be connected in a daisy-chain conguration.

020

Appendix A - PRE2 Serial Remote Control (RS232)

PRE2 STEREO PREAMPLIFIER OWNER’S MANUAL

PRE2 Serial Remote Control (RS232)

Remote Control Protocol

e PRE2 Remote Control protocol is dened with the goal of structural simplicity and ease of implementation. Typical

implementation requires only a standard, asynchronous UART/RS232 port. At the Data Link level the following assumptions

are made:

• Short, xed-length data frames

• Data encoding uses only ascii (printable) characters

• Data frame has a checksum eld for error detection, but the checksum opt-out is possible at sender’s request - in such a

case, Sender’s frame has a standard blank checksum, and the Receiver side does not check against it.

At the Application level (i.e. remote control of a product) the message processing will be stateless:

• Each message is handled independently

• Each command acted upon immediately.

Frame Structure

e PRE2 frame structure is shown in the following diagram:

Frame preamble : < > Asterisk character.

Destination Product Class : P1, P0 two alphanumeric characters (a preamplier product will be denoted as "PR").

Command Message : M3, M2, M1, M0 typically 4 characters long, but it is product-dependent.

| Product Class

*P1 P0 M3 M2 M1 M0 C1 C0

| Command Message | Cheksum |

*

EMM Labs PRE2 User manual

Popular Amplifier manuals by other brands
