EMT STX 5/10 User manual

Warranty
This unit is covered by EMT’s two-year warranty from the day of purchase (dealer’s invoice). It covers all
factory materials and processing errors. However this warranty does not cover the following: malfunction
caused by neglecting the instructions in user manual; normal wear. Unauthorized disassembly or modifi-
cations whatsoever of the cartridge will also avoid the warranty. In any case of warranty claims please
contact your dealer.
EMT and its Logo are registered trademarks.
Specifications, options, features and models subject to change without notice.
EMT Tontechnik
HiFiction AG
Tösstalstrasse 14
CH-8488 Turbenthal
Specifications
Wire: 99,99% Silver
Core: Very low loss alloy
Recommended specs.
of MM-input:
Gain: 35...45 dB
Load: 47 kOhm
Size: 200x160x80mm
Output Gain: +14 dB +20 dB
Transformer Ratio: 1:5 1:10
Effective load at Input
Option = EMT: 250 Ohm Always use Option = Open
Effective load at input
Option = Open: Load MM-input : 25 Load MM-input : 100
EMT STX 5/10 User Manual
Dear Client
Congratulations to your EMT MC step-up transformer. This unit has been carefully
designed and manufactured in Switzerland to satisfy highest demands for musicali-
ty. It is perfectly matched to EMT cartridges as a reference and offers a second out-
put for cartridges with lower output level.
The toroidal winding technology with purest silver wire and advanced magnetic ma-
terials bring this very traditional technology to a new level of ultra-low noise and high
resolution.

LEFT/RIGHT INPUT
Connect your MC-cartridge her. Use an EMT-
cartridge with an output-level of 1,05mV @
5cm/s.
Alternatively, you can use a cartridge with
lower output-level (ca. 0,5mV @ 5cm/s).
GROUND CONNECTOR
This terminal is to be connected with the
ground-socket of the MM
fication.
LEFT/RIGHT OUTPUT +20dB
Connect this output with the MM-input of
your amplification if an MC-cartridge with
lower output-level (0,5mV @ 5cm/s) is con-
nected to the input.
LEFT/RIGHT OUTPUT +14dB
Connect this output with the MM
your amplification if an EMT
output-level of 1,05mV @ 5cm/s) is connect-
ed to the input.
GROUND CONNECTOR
This terminal is to be connected with the
socket of the MM-input of your ampli-
GROUND OPTIONS
Here you can choose three ground-options.
Choose the option with the best result regard-
ing hum @ low noise floor.
LEFT/RIGHT OUTPUT +14dB
Connect this output with the MM-input of
your amplification if an EMT-cartridge with an
level of 1,05mV @ 5cm/s) is connect-
LOAD OPTIONS
If an EMT-cartridge is connected to the input,
choose “EMT”. For any other cartridge, or if
the load shall be set at the MM-input of your
amplification, choose “Open”.
