Emulex LP952L Installation and operating manual

LP952L Installation and Reference Manual
Table of Contents
Installation
Compatability
Prerequisites
Install HBA
Attach Media
Apply Power
View LEDs
Reference
Specifications
FCC and Regulatory Notices
Declaration of
Conformity
Laser Safety
Emulex Drivers, Software and Manuals
1

Chapter 1 − Installation
Table of Contents
Compatability
Prerequisites
Install HBA
Attach Media
Apply Power
View LEDs
Emulex Drivers, Software and Manuals
2

Installation
Caution Emulex LightPulse ® Host Bus Adapters (HBAs) contain
electronic components that can be damaged by static
electricity through an electrostatic discharge (ESD) event. To
prevent ESD damage, maintain constant contact with any
grounded metal surface. A grounding wrist strap is useful for
this purpose. Handle the card carefully at all times and
preferably by the edges. Avoid touching electronic
components and keep the card in the original packaging until
you are ready for installation.
Compatibility
Software
Environments Windows Server 2003, Windows 2000, Windows NT, Linux, NetWare
Hardware
Environments x86 PCI hardware platforms
Prerequisites
The host computer must provide 3.3VDC bus power• The open 32−bit or 64−bit (64−bit recommended) PCI bus slot can be
either 3.3 VDC or 5.0 VDC signaling interface
•
PCI bus clock rate of 66 MHz is preferred• Multimode fiber optic cable (50/125 µ m or 62.5/125 µ m) with LC
connectors, used with short−wave lasers
•
Emulex Drivers, Software and Manuals
3

Install the Host Bus Adapter Board
Record IEEE and serial numbers.
Each host bus adapter port is shipped with a unique address identifier
called the IEEE address. Since this adapter has two ports, there are two
IEEE addresses. The IEEE address is used when configuring your
system. The serial number is used when communicating with Emulex.
All numbers are clearly marked on the board. We recommend that you
record these numbers before installing the adapter.
1.
Turn off and unplug the computer.2. Remove the computer case.3. Remove the blank panel from an empty 32 or 64−bit PCI bus slot.
Compare the removed panel to the bracket on the host bus adapter.
Follow steps 5−8 to change the bracket if they are different sizes.
4.
Note The host bus adapter comes with a standard PCI
bracket installed. The low profile mounting bracket is
shorter than the standard bracket; approximately
3.11 in. (7.9cm) compared to 4.75 in. (12.06 cm)
long.
Remove the mounting bracket screws from the top of the host bus
adapter.
5.
Remove the bracket and store it for future use.6. Align the new mounting bracket tabs with the holes in the HBA.7. Replace the screws that attach the HBA to the bracket.8. Insert the host bus adapter into the empty 32 or 64−bit PCI bus slot.
Press firmly until it is seated.
9.
Secure the host bus adapter's mounting bracket to the case with the panel
screw or clip.
10.
Replace the computer case and tighten case screws.11.
The host bus adapter is now installed in the PC and is ready for media
attachment.
Emulex Drivers, Software and Manuals
4

Attach Media
Note The host bus adapter will not allow normal data transmission
on an optical link unless it is connected to another similar or
compatible laser product (that is, multimode to multimode.)
Use multimode fiber optic cable used with short−wave lasers, that adhere to the
following specifications:
Fiber Optic Cable Maximum Length Minimum
Length Connector
62.5/125 µm
(multimode) 300 meters at 1.0625 Gb/s
150 meters at 2.125
Gb/s
2 meters LC
50/125 µm
(multimode) 500 meters at 1.0625 Gb/s
300 meters at 2.125
Gb/s
2 meters LC
Connect the fiber optic cable to the LC connector on the HBA.1.
Connect the other end of the cable to the Fibre Channel device.2.
After the media is connected to the host bus adapter, you are ready to apply
power to the computer.
Emulex Drivers, Software and Manuals
6

Apply Power
Verify that the host bus adapter is securely installed in the computer.1. Verify that the correct media is attached.2. Plug in and turn on the computer.3. Observe LEDs for Power On Self Test (POST) results.4.
View LEDs
Green and yellow display lights (LEDs) can be seen through openings in the host
bus adapter's mounting bracket. Green indicates power and yellow signifies port
activity.
POST conditions and results are summarized in this table.
Green
LED Yellow LED State
OFF OFF Wake−up failure (dead board)
OFF ON POST failure (dead board)
OFF Slow blink (1 Hz) Wake−up failure (dead board)
OFF Fast blink (4 Hz) Failure in POST (dead board)
OFF Flashing (irregular) POST processing in progress
ON OFF Failure while functioning
ON ON Failure while functioning
ON Slow blink (1 Hz) Normal − 1 Gb link rate
ON Fast blink (4 Hz) Normal − 2 Gb link rate
Blink (1 Hz) OFF Normal − link down or not yet started
Emulex Drivers, Software and Manuals
7

Chapter 2 − Reference
Table of Contents
Specifications
FCC and Regulatory Notices
Declaration of Conformity
Laser Safety
Emulex Drivers, Software and Manuals
8

Reference
Specifications
Parameter Range
Media Interface Dual LC connector
Physical Dimensions Low Profile PCI form factor 6.6" x 2.54"
Power Requirements 8.5 watts (typical) @ + 3.3 VDC, +/−5 % DC
Airflow 100 lf/min (minimum)
Temperature Operating:K2° to 113° F (0° to 45° C)
Storage:−40° to 158° F (−40° to 70° C)
Humidity 5% to 95% non−condensing
Agency Approvals for
LP952L−F2 Class 1 Laser Product per DHHS 21CFR (J) & EN60825 UL recognized to UL1950
CUR recognized to CSA22.2, No.950
TUV certified to EN60950
FCC Rules, Part 15, Class A
Industry Canada, ICES−003, Class A
EMC Directive 89/336/EEC (CE Mark)
EN55022, Class A
EN55024
Australian EMC Framework (C−Tick Mark)
AS/NZS 3548: Class A
VCCI, Class A
Emulex Drivers, Software and Manuals
9

FCC and Regulatory Notices
CLASS 1 LASER PRODUCT
LASER KLASSE 1
LUOKAN 1 LASERLAITE
APPAREIL A` LASER DE CLASSE 1
The above statement applies to products marketed in the European Union.
Model LP9002 / LP9002L / LP952L / LP9002S / LP9002DC / LP9002C /
LP9402DC (2x5 SFF Models)
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense. Shielded cables must be used between this
equipment and attached peripheral devices. The reader is cautioned that changes
or modifications made to the equipment not expressly approved by Emulex could
void the user's authority to operate this equipment. The above statement applies
to products marketed in the USA
This class A digital apparatus meets all requirements of the Industry Canada (IC)
Interference − Causing Equipment Standard (ICES−003). Cet appareil numerique
de la Classe A respecte toutes les exigences du reglement sur le materiel
brouilleur du Canada. This statement applies to products marketed in Canada.
Emulex Drivers, Software and Manuals
10

FCC Compliance Information Statement; Models LP9000−N1/L1/T1 (GBIC
Models):
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Responsible Party: Paul Folino, President & CEO, Emulex Corporation, 3535
Harbor Blvd., Costa Mesa, CA 92626, USA, (714) 662−5600
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.•
The reader is cautioned that any changes or modifications to the equipment not
expressly approved by Emulex could void the user’s authority to operate this
equipment.
This class B digital apparatus meets all requirements of the Canadian
Interference − Causing Equipment Regulations. Cet Appareil numerique de la
classe B respecte toutes les exigences du reglement sur le material brouilleur du
Canada.
The above statement applies to products marketed in Canada.
Emulex Drivers, Software and Manuals
11

VCCI Notices and Translations (Japan Only)
Note VCCI regulations provide that changes or
modifications not expressly approved by Emulex
Corporation could void your authority to operate this
equipment.
LP9000−N1/L1/T1 (GBIC Model):
Translation:
This is a Class B product based on the standard of the Voluntary Control Council
for Interference by Information Technology Equipment (VCCI). If this
equipment is used near a radio or television receiver in a domestic environment,
it may cause radio interference. Install and use the equipment according to the
instruction manual.
LP9002/LP9002L/LP952L/LP9002S/LP9002DC/LP9002C/LP9402DC (2x5
SFF models)
Translation:
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures. VCCI—A
Emulex Drivers, Software and Manuals
12

Manual Notice
Translation:
This is a Class A product based on the standard of the Voluntary Control Council
for Interference by Information Technology Equipment (VCCI). If this
equipment is used in a domestic environment, radio disturbance may arise. When
such trouble occurs, the user may be required to take corrective actions.
Emulex Drivers, Software and Manuals
13

Declaration of Conformity
LP9002 / LP9002L / LP952L / LP9002S / LP9002C / LP9002DC /
LP9402DC−F2 (2x5 SFF models)
Note Changes or modifications not expressly approved by Emulex
Corporation could void the user's authority to operate this
equipment. This equipment complies with CISPR22/EN55022
Class A.
Warning This is a class A product. In a domestic environment, this
product may cause radio interference requiring the user to
take adequate measures.
DECLARATION OF CONFORMITY
Manufacturer: Emulex Corporation
3535 Harbor Blvd., Costa Mesa, CA 92626 USA
declares under sole responsibility that the product:
Product
Name: LightPulse™ LP9000 Fibre Channel PCI Host Adapters
Models: LP9002−F2, LP9002L−F2/X2, LP952L−F2, LP9002S−F2,
LP9002DC−F2, LP9002C−F2/X2, LP9402DC−F2
Assembly
Number: FC1020033−XX (FC1010466−XX) − PCI, 2x5 SFF model FC1020034−XX (FC1010472−XX) − PCI, 2x5 SFF model
FC1020035−XX (FC1010474−XX) − PCI, Dual Channel, 2x5 SFF
model
FC1020036−XX (FC1010483−XX) − PCI−X, Dual Channel, 2x5 SFF
model
FC1020037−XX (FC1010475−XX) − SBUS, 2x5 SFF model
FC1020043−XX (FC1010488−XX) − cPCI, 2x5 SFF model
to which this declaration relates is in conformity with the following standards
or other documents for Information Technology Equipment (ITE):
Safety: UL Recognized to UL1950
CUR Recognized to CSA22.2, No. 950
IEC 950 (1991) + Amendments 1,2,3,4, and 11
EN60950 (1992)+ Amendments 1,2,3,4, and 11
EN60825−1 (1994) + Amendment 11
EN60825−2 (1994)
CFR Title 21, Laser AEL Class 1, FDA/CDRH
Emulex Drivers, Software and Manuals
14

EMC: FCC Rules, CFR Title 47, Part 15, Subpart B, Class A
Industry Canada, ICES−003, Class A
EN55022 (1998) / CISPR−22 (1997), Class A
EN55024 (1998)
AZ/NZS 3548: Class A and VCCI, Class A
Supplementary Information:
1. The product was tested in a typical configuration with shielded
cables.
2. The product complies with the requirements of the following directives:
− European Union Low Voltage Directive
− European Union EMC Directive 89/336/EEC (as amended by 92/31/EEC)
− CE−Marking Directive 93/68/EEC (Carries the CE−Mark accordingly)
− Australian EMC Framework (Carries the C−Tick mark accordingly)
February 22, 2002
Costa Mesa, CA
European
Contact: Emulex Corporation 7 & 8 Forrest Court, Oaklands Park, Fishponds Road
Wokingham, Berkshire, RG41 2FD, England
Telephone: 44−118−977−2929
Fax: 44−118−977−3237
Emulex Drivers, Software and Manuals
15

Laser Safety Notice
This laser safety information contains certification and product information
covering laser products known as optical Gigabaud Link Modules (GLMs),
Gigabit Interface Converters (GBICs), 1x9 and small form factor transceivers
sold as accessories to or incorporated in Emulex LightPulse host adapters. The
GLM, GBIC, 1x9 and small form factor transceiver are the primary cable
connection mechanisms for any optical port on the host adapter and hub. This
data is not intended to be a replacement for any safety regulations and standards;
relevant safety documents should always be consulted if necessary. Contact
Emulex Corporation with any questions or concerns about laser safety.
Certification and Classification
Labeling Requirements
Product Information
Usage Restrictions
System Level Certification
Certification and Classification
LP6000 and LP7000E PCI host adapters may contain a laser product known as
an optical Gigabaud Link Module (GLM). The optical GLM is attached to the
host adapter using an 80−pin connector and extends through the mounting
bracket. In turn, the host adapter can be inserted into any host system's PCI slot.
The LH5000 hub may contain a laser product known as a Gigabit Interface
Connector (GBIC). The GBIC provides the physical connector to the optical
cable. The GBIC can be inserted into any pluggable hub port.
The LP8000, LP850 and LP9000 PCI host adapter may contain a laser product
known as a Gigabit Interface Converter (GBIC) or an embedded 1x9 transceiver.
The GBIC and or 1x9 transceiver provide the physical connection to the optical
cable, and its SC−style connector extends through the mounting bracket. In turn,
the host adapter can be inserted into any host system’s PCI slot.
The LP9002, LP9002L, LP952L, LP9002S, LP9002DC, LP9002C, and
LP9402DC PCI host adapters may contain a laser product known as a small form
factor transceiver. This transceiver provides the physical connection to the
optical cable, and its LC−style connector extends through the mounting bracket.
In turn, the host adapter can be inserted into any host system's PCI/cPCI slot.
In the United States, all optical GLMs, GBICs, 1x9 and small form factor
transceivers sold by Emulex are certified as Class 1 laser products that conform
to the requirements contained in the Department of Health and Human Services
(DHHS) regulation 21 CFR subchapter J. The certification is indicated by a label
located on the optical GLM, GBIC, 1x9 or small form factor transceiver.
Emulex Drivers, Software and Manuals
16

In Europe, all optical GLMs, GBICs, 1x9 and small form factor transceivers sold
by Emulex are certified as Class 1 laser component assemblies that conform to
the requirements contained in the CENELEC (European Committee for
Electrotechnical Standardization) standard EN60825−1:1994 (including
amendment 11) and EN60825−2:1994. GLMs, GBICs, 1x9 and small form factor
transceivers are certified by a recognized European testing agency and have
appropriate markings on the assembly. The DHHS conformity label and
European conformity mark will not be visible externally once the optical GLM,
GBIC, 1x9 or small form factor transceiver is connected to or inserted in the host
adapter and the adapter is installed into a system.
Labeling Requirements
No caution or danger labels are required for use of the GLM, GBIC, 1x9 or small
form factor transceiver since they are Class 1 laser component assembly. In the
U.S., the only laser safety label required is the DHHS certification label that
already appears on the GLM, GBIC, 1x9 and small form factor transceiver. In
Europe, the EN60825−1/EN60825−2 standards require that the system−level
product has a Class 1 information label permanently attached and clearly visible
whenever access to the GLM, GBIC, 1x9 and small form factor transceiver
optical port is possible. Each Class 1 product shall have affixed an explanatory
label bearing the words:
Alternatively, at the discretion of the manufacturer, the same statement may be
included in user information. If a label is used, an example of the IEC Class 1
information label that is suitable for most European countries is shown below.
The label consists of black printing on a white background. Languages
represented on this label are English, German, Finnish and French, and they
represent the minimum set for acceptance of a Class 1 product in most European
countries.
Emulex Drivers, Software and Manuals
17

Product Information
GLM
GBIC
1 x 9 Transceiver
Small Form Factor Transceiver
GLM
The optical GLM is a single port communications card. Each
communication port consists of a transmitter and receiver optical
subassembly. The transmitter subassembly contains a semiconductor
laser diode of gallium aluminum arsenide (GaAlAs). This material emits
in the wavelength range of 770 to 860 nanometers for shortwave and
1270 to 1355 nanometers for long wave, and are commonly referred to
as short wavelength (SW) or long wavelength (LW) lasers. The discrete
laser diodes are classified as Class 3B laser products. Once they are
incorporated into the GLM, the product’s automatic power control
maintains the average power launched into a fiber at a value below the
Class 1 limit.
Note OFC GLMs are found only on the LP6000. Any reference to
OFC or non−OFC products applies only to the LP6000, and
not to the LP7000E, LP8000, LP850 or LP9000.
For OFC GLMs (Open Fiber Control) the optical fiber link between two
GLM ports is continuously monitored by the open fiber link detection
and laser safety control system (OFC). In the event of a break anywhere
in the path, this control system prevents laser emissions from exceeding
Class 1 levels. For non−OFC links, the optical power from the laser
transmitter is controlled and maintained at a lower power level. The
power emitted from either an open fiber or open laser transmitter is
guaranteed to be below the Class 1 limit. Class 1 laser products are not
considered hazardous. No user maintenance, service operations or
adjustments can be performed on any GLM accessory.
GBIC
The optical GBIC is an integrated duplex data link for bi−directional
communications over multimode or single mode optical fiber. Each
GBIC consists of a transmitter and receiver optical subassembly. The
transmitter subassembly contains a semiconductor laser emitting in the
wavelength range of 770 to 860 nanometers for shortwave length GBICs
and 1270 to 1355 nanometers for long wavelength GBICs. For non−OFC
links, the optical power from the laser transmitter is controlled and
maintained at a lower power level. The power emitted from either an
open fiber or open laser transmitter is guaranteed to be below the Class 1
limit. Class 1 laser products are not considered hazardous. No user
Emulex Drivers, Software and Manuals
18

maintenance, service operations or adjustments can be performed the
GBIC.
Small Form Factor Transceiver
The small form factor transceiver is an integrated duplex data link for
bi−directional communications over multimode or single mode optical
fiber. Each small form factor transceiver consists of a transmitter and
receiver optical subassembly. The transmitter subassembly contains a
semiconductor laser emitting in the wavelength range of 770 to 860
nanometers for shortwave length small form factor transceivers and 1270
to 1355 nanometers for long wavelength small form factor transceivers.
For non−OFC links, the optical power from the laser transmitter is
controlled and maintained at a lower power level. The power emitted
from either an open fiber or open laser transmitter is guaranteed to be
below the Class 1 limit. Class 1 laser products are not considered
hazardous. No user maintenance, service operations or adjustments can
be performed the small form factor transceiver.
1x9 Transceiver
The 1x9 transceivers is an integrated duplex data link for bi−directional
communications over multimode fiber. Each 1x9 consists of a transmitter
and receiver optical subassembly. The transmitter subassembly contains
a semiconductor laser emitting in the wavelength range of 770 to 860
nanometers for shortwave 1x9s. For non−OFC links, the optical power
from the laser transmitter is controlled and maintained at a lower power
level. The power emitted from either an open fiber or open laser
transmitter is guaranteed to be below the Class 1 limit. Class 1 laser
products are not considered hazardous. No user maintenance, service
operations or adjustments can be performed the 1x9 transceiver.
Usage Restrictions
Failure to comply with these usage restrictions may result in incorrect operation
of the system and could possible lead to points of access that may emit laser
radiation levels above the Class 1 limits established in the U. S. by the DHHS
and within Europe by EN60825−1/EN60825−2.
GLM
GBIC
1 x 9 Transceiver
Small Form Factor Transceiver
Emulex Drivers, Software and Manuals
19

GLM
The GLM is designed and certified for applications using point−to−point optical
fiber links only. Use of the product with multiple input or multiple output optical
links (for example, star couplers) is prohibited since it is incompatible with the
GLM’s certification.
The GLM will not allow normal data transmission on the optical link unless it is
connected to another similar GLM or compatible laser product. For OFC GLMs,
another manufacturer’s laser product is not considered compatible unless it
contains the open fiber link detection and laser safety control system (OFC) and
is properly certified as a Class 1 laser product. Similarly, for non−OFC GLMs, a
compatible laser device must be non−OFC.
Any system level product that incorporates the GLM must provide power supply
protection that guarantees a voltage of 6.0 volts or less at the GLM. The
functional power supply range of the GLM product is specified as 4.75 to 5.25
volts typically. Operation outside of this range may degrade the performance and
lifetime of the GLM. The GLM will remain operational with laser emissions
below Class 1 limits provided the power supply level at the adapter remains at or
below 6.0 volts. If the power supply level rises above 6.0 volts, the GLM cannot
be guaranteed to operate correctly and could result in laser emissions that may
exceed Class 1 limits.
GBIC
Short wavelength and long wavelength GBICs allow normal data transmission on
the optical link when they are connected to another compatible laser product.
Short wavelength and long wavelength GBICs sold by Emulex as accessories are
non−OFC devices. For non−OFC links, a compatible laser device must be
non−OFC and certified as a Class 1 laser product.
1 x 9 Transceiver
Short wavelength 1x9 transceivers allow normal data transmission on the optical
link when they are connected to another compatible laser product. Short
wavelength 1x9s embedded in Emulex host adapters are non−OFC. For
non−OFC links, a compatible laser device must be non−OFC and certified as a
Class 1 laser product.
Small Form Factor Transceiver
Short wavelength and long wavelength small form factor transceivers allow
normal data transmission on the optical link when they are connected to another
compatible laser product. Short wavelength and long wavelength small form
factor transceivers embedded in Emulex host adapter are non−OFC. For
non−OFC links, a compatible laser device must be non−OFC and certified as a
Emulex Drivers, Software and Manuals
20

Class 1 laser product.
Any system level product that incorporates the small form factor transceivers
must provide power supply protection that guarantees a voltage of 5.0 volts or
less at the small form factor transceivers. The functional power supply range of
the small form factor transceivers product is specified as 3.135 to 3.465V
typically. Operation outside of this range may degrade the performance and
lifetime of the transceiver. The transceiver will remain operational with laser
emissions below Class 1 limits provided the power supply level at the adapter
remains at or below 5.0 volts. If the power supply level rises above 5.0 volts, the
small form factor transceiver cannot be guaranteed to operate correctly and could
result in laser emissions that may exceed Class 1 limits.
Emulex Drivers, Software and Manuals
21
