Energer ENB542BDS User manual

Original Instructions_MNL_ENB542BDS_GB_V01_130720
ENB542BDS
350W Band Saw
Barcode: 5052931253678
WARNING! Read the instructions before using the product!
350W BAND SAW

Thank you for choosing a product it will give you full satisfaction in your
craft in the work.
The band saw is a product easy to use, it comes with accessories. For best use,
you must read this noice. It will provide key information on the functions of the device
and the rules to follow for maintenance.
Please keep this manual for future reference later.

ENB542BDS by ENERGER
GB
IE
03
23
28
35
37
37
38
In more detail...
Product functions
Care and maintenance
Trouble shooting
Recycling and disposal
Guarantee
EC declaration of conformity
22
03
04
05
13
Getting started...
Your product
Technical and legal information
Before you start
These instructions are for your safety. Please read through them thoroughly
before use and retain them for future reference.
Let’s
get started…

15. Rip fence locking handle
16. Motor
17. Angle scale pointer
18. Fixing handle for table
19. Dial scale for tilt angle
20. Work table
21. Mitre guage
22. Fixing knob
23. Saw blade
24. Fixing screw for band guide
25. Push stick
26. Additional support
27. Mounting holes
ENB542BDS by ENERGER
Getting started...
GB
04
Your product
Your product
1. On/Off switch
2. Fixing knob
3. Side cover
4. Blade tension knob
5. Upper band pulley
6. Saw blade guide
7. Upper blade guide
8. Lower blade pulley
9. Base
10. Dust extraction port
11. Setting screw for upper band pulley
12. Setting knob for blade guide
13. Machine frame
14. Rip fence
IE
1
3
2
25 19
17
27
20
21
22
23
24
10
4
11
12
13
15
16
26
18
14
5
6
7
8
9

ENB542BDS by ENERGER
05
Getting started...
Technical and legal
information
Technical specifications
General
> Input Voltage
> Power Input
> No load speed
> Max. cutting depth
> Max. cutting width
> Table size
> Table tilting range
> Saw line speed
> Blade Length
> Width
Teeth
Thickness
> Net Weight
:
:
:
:
:
:
:
:
:
:
:
:
:
230-240V~50Hz
350W
1450min-1
80mm
190mm
300x300mm
0°~45°
14.7m/s
1425mm
6.35mm
6TPI
0.3mm
17kg
VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help
reduce hand arm vibration syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to provide indicative vibration test
results to enable users to make informed decisions as to the period of time a power
tool can be used safely on a daily basis and the choice of tool.
Further Advice can be found at www.hse.gov.uk
The declared vibration emission value should be used as a minimum level and
should be used with the current guidance on vibration.
Calculating the actual period of the actual period off use can be difficult and the HSE
website has further information.
Sound power level L WA : 99.3dB(A)
Sound level according to
EN 61029
Work mode description 1
(if required by the relevant Part 2)
Vibration total values (triax vector sum) determined according to EN 61029:
Wear ear protection when sound
pressure is over
Sound pressure level L pA : 86.3dB(A)
85dB(A)
Uncertainty K pA, K WA : 3dB(A)
Vibration emission value ah= 3.0m/s2
Uncertainty K = 1.5m/s2
GB
IE

ENB542BDS by ENERGER
Getting started...
GB
06
IE
Technical and legal
information
The declared vibration emission been measured in accordance with a standardised
test stated above and may be used to compare one tool with another.
The declared vibration emission value may also be used in a preliminary
assessment of exposure.
Warning! The vibration emission value during actual use of the power
tool can differ from the declared value depending on the ways in which
the tool is used dependant on the following examples and other variations
on how the tool is used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained.
The use the correct accessory for the tool and ensuring it is sharp and in good
condition.
The tightness of the grip on the handles.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not
adequately managed
Warning! identify safety measures to protect the operator that are based
on an estimation of exposure in the actual conditions of use (taking account
of all parts of the operating cycle such as the times when the tool is switched off
and when it is running idle in addition to the trigger time).Note The use of other
tools will reduce the users’ total working period on this tool.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and keep well lubricated
(where appropriate)
Avoid using tools in temperatures of 10ºC or less.
Plan your work schedule to spread any high vibration tool use across a number
of days.
Health Surveillance
All employees should be part of an employer’s health surveillance scheme to
help identity any vibration related diseases at an early stage, prevent disease
progression and help employees stay in work.
Important note
Remove the mains plug from socket before carrying out any adjustment
or servicing.
Ensure your mains supply voltage is the same as your tool rating plate voltage.

ENB542BDS by ENERGER Technical and legal
information
Symbols
07
Getting started...
GB
IE
On the product, the rating label and within these instructions you will find among
others the following symbols and abbreviations.
Familiarise yourself with them to reduce hazards like personal injuries and damage
to property.
V~
W
min-1
yyWxx
Volt
Input power
Per minute
Manufacturing date code; year of manufacturing (20yy) and week of
manufacturing (Wxx);
Hz
kg
dB(A)
Hertz
Kilogram
Decibel (A-rated)
Safety warnings
GENERAL SAFETY INSTRUCTIONS
WARNING! To ensure safe operation when using your Band Saw,
make sure you follow basic safety principles to reduce risk of
personal injury, electric shock and fire. Please read the following
instructions prior to operating this product and keep for future use.
Caution / Warning. Wear hearing protection.
Read the instruction
manual. Wear eye protection.
Wear respiratory protection.Wear gloves.
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
Switch the product off and disconnect it from the power supply before
assembly, cleaning, adjustments, maintenance, storage and transportation.
WEEE symbol. Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling advice.

ENB542BDS by ENERGER
Getting started...
GB
08
IE
Technical and legal
information
SAVE THESE INSTRUCTIONS
1. Keep work area clear
> Cluttered areas and benches invite injuries.
2. Consider work area environment
> Do not expose tools to rain.
> Do not use tools in damp or wet locations.
> Keep work area well lit.
> Do not use tools in the presence of flammable liquids or gases.
3. Guard against electric shock
> Avoid body contact with earthed or grounded surfaces (e.g. pipes, radiators,
ranges, refrigerators).
4. Keep other persons away
> Do not let persons, especially children, not involved in the work touch the tool
or the extension cord and keep them away from the work area.
5. Store idle tools
> When not in use, tools should be stored in a dry locked-up place, out of reach
of children.
6. Do not force the tool
> It will do the job better and safer at the rate for which it was intended.
7. Use the right tool
> Do not force small tools to do the job of a heavy duty tool.
> Do not use tools for purposes not intended; for example do not use circular
saws to cut tree limbs or logs.
8. Dress properly
> Do not wear loose clothing or jewellery, they can be caught in moving parts.
> Non-skid footwear is recommended when working outdoors.
> Wear protective hair covering to contain long hair.
9. Use protective equipment
> Use safety glasses.
> Use face or dust mask if working operations create dust.
10. Connect dust extraction equipment
> If the tool is provided for the connection of dust extraction and collecting
equipment, ensure these are connected and properly used.
11. Do not abuse the cord
> Never yank the cord to disconnect it from the socket. Keep the cord away from
heat, oil and sharp edges.
12. Secure work
> Where possible use clamps or a vice to hold the work. It is safer than using
your hand.
13. Do not overreach

> Keep proper footing and balance at all times.
14. Maintain tools with care
> Keep cutting tools sharp and clean for better and safer performance.
> Follow instruction for lubricating and changing accessories.
> Inspect tool cords periodically and if damaged have them repaired by an
authorised service facility.
> Inspect extension cords periodically and replace if damaged.
> Keep handles dry, clean and free from oil and grease.
15. Disconnect tools
> When not in use, before servicing and when changing accessories such
as blades, bits and cutters, disconnect tools from the power supply.
16. Remove adjusting keys and wrenches
> Form the habit of checking to see that keys and adjusting wrenches are removed
from the tool before turning it on.
17. Avoid unintentional starting
> Ensure switch is in "off" position when plugging in.
18. Use outdoor extension leads
> When the tool is used outdoors, use only extension cords intended for outdoor
use and so marked.
19. Stay alert
> Watch what you are doing, use common sense and do not operate the tool when
you are tired.
20. Check damaged parts
> Before further use of tool, it should be carefully checked to determine that it will
operate properly and perform its intended function.
> Check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its operation.
> A guard or other part that is damaged should be properly repaired or replaced
by an authorised service centre unless otherwise indicated in this instruction
manual.
> Have defective switches replaced by an authorised service centre.
> Do not use the tool if the switch does not turn it on and off.
21. Warning
> The use of any accessory or attachment other than one recommended in this
instruction manual may present a risk of personal injury.
22. Have your tool repaired by a qualified person
> This electric tool complies with the relevant safety rules. Repairs should only be
carried out by qualified persons using original spare parts, otherwise this may
result in considerable danger to the user.
23. If the replacement of the supply cord is necessary, this has to be done by
09
ENB542BDS by ENERGER Technical and legal
information
Getting started...
GB
IE

23. If the replacement of the supply cord is necessary, this has to be done by
the manufacturer or his agent in order to avoid a safety hazard.
24. For tools intended to be connected to a water supply.
> For tools provided with a PRCD: Never use the tool without the PRCD delivered
with the tool.
> For tools provided with an isolating transformer: Never use the tool without the
transformer delivered with the tool or of the type as specified in these
instructions.
> Replacement of the plug or the supply cord shall always be carried out by the
manufacturer of the tool or his service organisation.
> Keep water clear off the electrical parts of the tool and away from persons in
the working area.
HEALTH ADVICE
Warning! When drilling, sanding, sawing or grinding, dust particles will be
produced. In some instances, depending on the materials you are working
with, this dust can be particularly harmful to you (e.g. lead from old gloss paint).
You are advised to consider the risks associated with the materials you
are working with and to reduce the risk of exposure. You should:
- Work in a well-ventilated area.
- Work with approved safety equipment, such as those dust masks that are
specially designed to filter microscopic particles.
ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR BAND SAW
Warning! Some wood and wood type products especially MDF (Medium
Density Fibreboard) can produce dust that can be hazardous to your health.
We recommend the use of an approved face mask with replaceable filters when
using this machine in addition to using the dust extraction facility.
1. Safety precautions
> Do not use saw blade which are damaged or deformed;
> Replace the table insert when worn;
> Lock the work table firmly before operation;
> Tension the saw blade properly;
> Do not clean the saw band whilst it is in motion;
> Wear suitable personal protective equipment, when necessary, this could
include:
• Hearing protection to reduce the risk of induced hearing loss,
• Respiratory protection to reduce the risk of inhalation of harmful dust,
• Gloves for handling the saw band and rough material.
Note: It is not advisable to wear gloves when feeding material through the
machine.
ENB542BDS by ENERGER
Getting started...
GB
10
IE
Technical and legal
information

> Always ensure that the adjustable blade guard is as close to the work piece as
possible.
> Always ensure that all adjustments are correct and secure before starting the
band saw.
> Always ensure that the blade tension and tracking are set correctly.
> Avoid cutting nails. Inspect the workpiece and remove all nails and other foreign
objects before beginning sawing.
2. Safe operation
> When ever possible the band saw should be connected to a suitable
dust extraction system when cutting timber or timber based products such as
MDF.
> When straight cutting always use the push stick provided. This will prevent hands
from contacting the blade. Store the push stick on it’s holder after use.
> This saw must be attached to a solid secure work surface by means of the
fixing holes in the base.
> Never adjust or assemble the rip fence or mitre gauge when the machine is
working;
> When the workpiece is near to the saw blade, never use your hand to push it.
Always use the push stick provided (See 25 on main diagram)
> Never tension the saw blade when working;
> If need to adjust the blade guide, stop the machine first.
> Do Not Operate the bandsaw with the door or guard protecting the band saw
blade open, damaged or is missing. Always ensure that the bandsaw blade
selected and the operating speed is suitable for the material being cut.
> Always support long lengths of material and ensure that the material is held flat
against the table. This will help to reduce noise levels due to vibration.
> When bevel cutting with the table inclined place the guide fence on the lower
part of the table.
> When cutting round material, use a suitable holding device to prevent the material
from twisting.
> Never use your hands to remove sawdust, chips or waste close by the saw blade.
> Never reach over the blade to remove waste or off cuts.
> Do not attempt to free a jammed blade before first switching off the machine.
> Do not slow or stop a blade with a piece of wood. Let the blade come to rest
naturally.
> If you are interrupted when operating the saw, complete the process and switch
off before looking up.
3. Transportation
> During transportation ensure that the adjustable blade guard is in the fully down
position.
11
ENB542BDS by ENERGER Technical and legal
information
Getting started...
GB
IE

> Do not use any guard or protection device as a hand hold when carrying
or transporting the band saw. Lift and transport the band saw at position
indicated.
4. After use
> After use and before storage clean the machine thoroughly and release the blade
tension.
> Periodically check that all nuts, bolts and other fixings are properly tightened.
Technical and legal
information
ENB542BDS by ENERGER
Getting started...
GB
12
IE

Unpack
> Unpack all parts and lay them on a flat, stable surface.
> Remove all packing materials and shipping devices if applicable.
> Make sure the delivery contents are complete and free of any damage. If you
find that parts are missing or show damage do not use the product but contact
your dealer. Using an incomplete or damaged product represents a hazard to
people and property.
> Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
You will need
(items not supplied)
> Suitable personal
protective equipment
> Phillips screwdriver
> Combination square
> 10mm Spanner
(items supplied)
> 3, 4, 5mm Hex keys (3pcs)
Condition of use
> The saw should be placed in a covered and dry place. The ambient temperature
must be between-15°C to + 35°C. The humidity should be below 60%.
> Make sure the machine stands securely, i.e. bolt it to a workbench or solid base.
There are two holes for this purpose in the machine foot.
> All covers and safety devices have to be properly fixed before the machine is
switched on.
> It must be possible for the blade to run freely.
> The saw should only be used for cutting wood, Appropriate slides must be used
depending on the material to be cut.
13
ENB542BDS by ENERGER Before you start
Getting started...
GB
IE
WARNING! Before using your band saw, read the instruction
manual carefully.

WARNING! Do not connect to power supply until assembly
is complete. Failure to comply could result in accidental starting
and possible serious injury.
Before you start
Fitting the machine table
> Remove the bolt (28) and wing nut (29) from the hole located in the front edge
of the table. (Fig. 1)
> Carefully slide the work table (20) over the saw blade (23), through the slot in
the work table (20). Please note that the saw blade (23) is positioned in the
center of the table. (Fig. 2)
> When working with wood that has been processed before, watch out for foreign
bodies such as nails or screws etc.
> Before you actuate the On/Off switch, make sure that the saw blade is correctly
fitted and that the machine’s moving parts run smoothly.
> Before you connect the machine to the power supply, make sure the data on
the rating plate is the same as that for your mains.
> Wear safety glasses, gloves and a helmet for the job.
> Do not open the housing when the saw is running or when the saw is connected
to the mains. To cut right against the guide, use the push stick.
ENB542BDS by ENERGER
Getting started...
GB
14
IE
Fig. 1
28
29

> The dial scale (19) of the table (20) must be fitted in the guide on the machine
frame. (Fig. 3)
> The work table (20) is capable of adjustment. Locate the guide on the machine
frame and make sure the work table locates into the guide.
> The fixing handle (18) is spring loaded.
> Pull the fixing handle (18) outward from the thread. This disengages the fixing
handle (18) from the thread. Located the flat washer M10 (30), offer the thread
to the hole and tighten the thread with the 4mm hex key. (Fig. 4)
15
ENB542BDS by ENERGER Before you start
Getting started...
GB
IE
Fig. 3
0
10
20
30
40
45
20
Fig. 2
23
20
19
Fig. 4
45
40
35
30
25
30
18

Before you start
ENB542BDS by ENERGER
Getting started...
GB
16
IE
> Alternatively you can tighten the fixing handle (18) in a clockwise direction as
shown Fig. 5.
The fixing handle is spring loaded. Pull the fixing hanlde outward and rotate in
a counterclockwise direction. Release the fixing handle and allow it to engage
the thread. (Fig. 6)
Repeat the procedure until the working table is clamped.
> Insert and tighten the bolt (28) and wing nut (29) into the hole located in the
front edge of the work table.
> Unscrew the upper left hand hinge screw, attach the storage hook (31) and
resecure the screw with screwdriver. (Fig. 7)
> Always store the push stick (25) in position when not in use. (Fig. 8)
Fitting the push stick storage hook
Fig. 7 Fig. 8
Fig. 5 Fig. 6
0
10
20
18
1
0
10
20
40
45
2
18
31 25

> Put the additional support (26) on the base (9), and align four holes to the holes
(32) on the base, then put the flat washers M5 (33) and screws M5 x 20mm (34),
then tighten them with the screwdriver. (Fig. 9 & 10)
Fitting the additional support
17
ENB542BDS by ENERGER Before you start
Getting started...
GB
IE
Tensioning the saw blade
Note:
> Remove the tension from the saw blade if the band saw is not going to be used
for some time. Be sure to re-tension the saw blade before you start the machine.
Bench mounting
> The machine has four mounting holes (27) in its base. These can be used to
permanently secure the band saw to a workbench with suitable screws or bolts
(not supplied).
> Alternatively, if the machine needs to be moved frequently it can be secured to
a base of 19mm plywood to provide a more stable base.
NOTE: The metal support must be fitted on the base with four bolts
it the machine is not be bolted to a workbench.
Fig. 9 Fig. 10
CAUTION: Two person handling may be required.
32 34
33
26
34

> Turn the blade tension knob (4) for tightening the saw blade (23) in a clockwise
direction. (Fig. 11)
> The correct saw blade tension can be checked by applying pressure to the side
of the band with your finger, carry out this check at a point roughly between the
two band pulleys . You should only be able to bend the blade (23) very slightly
(approx. 1-2 mm). (Fig. 12)
Before you start
Getting started...
GB
IE
ENB542BDS by ENERGER
18
IMPORTANT! The saw blade may break if the tension is too high.
BEWARE OF INJURY! If the tension is too low, the powered band
pulley (8) will spin while the band does not move.
Fig. 11
Fig. 13
Fig. 12
Note:
> The saw blade tension has to be set correctly before you can adjust the saw
blade.
> Undo the fixing knobs (2) with the screwdriver and open the left side cover (3).
(Fig. 13)
Adjusting the saw blade
clockwise counterclockwise
1-2mm
4
23
3
23
350W BAND SAW
350W BAND SAW
2

> Undo the fixing handle.
> Undo the setting wheel (12) in a counterclockwise direction to lower the upper
band guide (7) as close as possible to the workpiece to be cut. The gap should
be approx. 2-3 mm. (Fig. 16)
> Slowly turn the upper band pulley (5) clockwise by hand. The saw blade (23)
should run in the middle of the pulley. If it does not, you will have to adjust the
tilt of the upper blade pulley (5). (Fig. 14)
> If the blade tends to run to the back of the blade pulley , i.e. towards the machine
frame, turn the setting screw (11) anti-clockwise while turning the blade pulley by
hand until the blade runs in the middle. (Fig. 15)
> If the blade tends to run to the front edge of the blade pulley, turn the setting
screw (11) in a clockwise direction. (Fig. 15)
> After setting the upper band pulley you need to check the blade position on the
lower band pulley (8). The blade should run in the middle of the band pulley (8),
as above. If it does not, you will have to adjust the tilt of the upper band pulley (5)
again. (Fig. 14)
> Turn the upper band pulley several times until the adjustment to the upper band
pulley has an effect on the blade position of the lower band pulley.
Adjusting the upper band guide
19
ENB542BDS by ENERGER Before you start
Getting started...
GB
IE
Fig. 14 Fig. 15
clockwise
counterclockwise
> Close the left side cover when you have finished adjusting the blade and tighten
the fixing knobs with the screwdriver.
5
23
8
11

Adjusting the work table to 90°
> Move the upper blade guide to the top.
> Undo the fixing handle (18). (Fig. 17)
> Set the angle between the blade and the table.
> Tilt the work table until it is at an angle of exactly 90° to the blade.
> Re-tighten the fixing handle.
> Undo the nut (35) with 10mm spanner (not supplied). (Fig. 18)
> Adjust the hex screw (36) until it contact with the machine frame.
> Re-tighten the nut (35). Then fasten the hex screw (36) with 3mm hex key (37).
(Fig. 19)
> Undo the recessed head screw locked on the scale pointer (17) to position the
angle scale pointer (17) on the 0° mark on the dial scale (19). (Fig. 17)
> Re-tighten the setting wheel.
> Re-tighten the fixing handle.
> Check the setting before each cut and re-adjust if necessary.
Before you start
Getting started...
GB
IE
ENB542BDS by ENERGER
20
Fig. 17 Fig. 18 Fig. 19
Fig. 16
counterclockwise
12
7
clockwise
18
19
17
35
37
35
36
36
Table of contents
Other Energer Saw manuals
