Energize En-Seek PL116 User manual

GSM/GPRS/GPS LOCATOR
En-Seek PL116
USER MANUAL
U Preface
Thank you for purchasing GPS Locator. This manual shows how to operate the device smoothly and
correctly. Make sure to read this manual carefully before using this product. Please note that
specification and information are subject to changes without prior notice in this manual. Any change
will be integrated in the latest release.
1

Content
1 Summary ----------------------------------------------------------------------------------------------- 3
2 Application ---------------------------------------------------------------------------------------------- 3
3 Hardware Description ------------------------------------------------------------------------------- 3
3.1 Front Face ----------------------------------------------------------------------------------------- 3
3.2 Rear Face -------------------------------------------------------------------------------------------- 4
3.3 Interior ---------------------------------------------------------------------------------------------- 4
4 Specifications --------------------------------------------------------------------------------------- 5
5 SIM Card Installation ------------------------------------------------------------------------------------- 6
6 Startup ------------------------------------------------------------------------------------------------------ 7
7 Usage ------------------------------------------------------------------------------------------------------ 7
8 Track Modes ------------------------------------------------------------------------------------------------- 7
8.1 Initialization ----------------------------------------------------------------------------------- 7
8.2 Password Setting ----------------------------------------------------------------------------- 7
8.3 Authorization ----------------------------------------------------------------------------------- 8
8.4 Auto-Track --------------------------------------------------------------------------------------- 9
8.5. Tlimit Function--------------------------------------------------------------------------------- 10
8.6. GPS refurbish setting ---------------------------------------------------------------------- 10
8.7 Reboot remotely ---------------------------------------------------------------------------- 10
8.8 Geo-fence ----------------------------------------------------------------------------------- 10
8.9 Movement Alert ---------------------------------------------------------------------- 11
8.10 Overspeed Alert ---------------------------------------------------------------------- 12
8.11 IMEI Checking ------------------------------------------------------------------------ 13
8.12 Time differences setting ------------------------------------------------------------------ 13
8.13 SOS Function ----------------------------------------------------------------- 13
8.14 SMSLINK ------------------------------------------------------------------------- 14
8.15 SMSONE -------------------------------------------------------------------- 14
8.16 Low Battery Alert ------------------------------------------------------------------- 14
8.17 SMS Center ----------------------------------------------------------------- 14
8.18 GSM ID ----------------------------------------------------------------------- 15
8.19 Motion Sensor --------------------------------------------------------------------- 15
8.20 SD Card Function ---------------------------------------------------------------------- 15
8.21 Switch on/off ------------------------------------------------------------------------ 16
9 Monitoring Mode ----------------------------------------------------------------------------- 16
10 Talking Mode ---------------------------------------------------------------------------- 16
11 GPRS Setting ----------------------------------------------------------------------------------- 17
12 Cautions ----------------------------------------------------------------------------------- 18
2

13 Faults & Solutions -------------------------------------------------------------------- 18
1Summary
Working based on existing GSM/GPRS network and GPS satellites, this product can locate and
monitor any remote targets by SMS or GPRS.
2Applications
z Protect child / the old / the disabled / pet etc
z Women Protection
z Manage Personnel
z Vehicle / Fleet management etc
3Hardware Descriptions
3.1 Front Face
SOS Button
Necklace holder
Speaker
USB Port,for charging and
upgrade the firmware
Calling Button
GPS indicator light
GSM indicator light
Working modes indicator
Microphone
3

3.2 Rear Face
Back cover
3.3 Interior
Battery
SIM Card SD Card
4

4Specifications.
Content Specs.
Dim. 80MM*56MM*22MM
Weight 50g
Network GSM/GPRS
Band 850/900/1800/1900Mhz
GPS chip SIRF3 chip
GSM/GPRS
module
SIM900
GPS sensitivity -159dBm
GPS accuracy 5m
Time To First Fix
Reacquisition
0.1s
Cold status
45s
Hot status 1s
Power DC5V input
Battery Chargeable 3.7V 860mAh Li-ion battery
Standby 100hours
Storage Temp. -40°C to +85°C
Operation Temp. -20°C to +55°C
Humidity 5%--95% non-condensing
5SIM card installation
Make sure that there is nocall transfer and call display is on, and PINcode off.
Step:
1. Open the back cover
2. Open the SIM card slot and SD card slot, and put one SIM card and one SD card (for GPRS data)
3. The SMS message must in Text format, can’t be PDU format.
5

Push ownwards to
open the cover
Pull leftwards and
insert the sim card
Fasten downwards ,make sure the SD
card is mounted
SD card is mounted ， then
fasten the sim card rightwards
Put the battery Fasten the cover
upwards
6

6Startup
Put the SIM card and SD card in place, insert the battery and the locator gets power on.
The green led in the middle is power indicator, yellow led on left side is GSM indicator and blue led on
right side is GPS indicator. Green indicator will be flashing quickly, yellow indicator will be on for 2
seconds and blue led does not flash when the locator is getting started. After 20-30 seconds the
green indicator will be on for one second and off for three seconds which means the device is started
and yellow indicator will be on in 3 seconds interval which means the locator is getting GSM signal.
Blue indicator depends on the GPS signal. Good GPSsignal (mainly outdoors) makes the blue
indicator flash in short time interval and weak GPS signal makes it flash in longer time interval. Blue
indicator will not flash where there is no GPS signal. Please use the locator outside for the first time so
that It can get GPS signal easily and quickly.
7Usage
The locator has three working modes: Tracker, Monitor and 2-Way Communication.
8 Track Mode
8.1 Initialization
Send SMS “begin+password” to the locator, it will reply “begin ok” and initialize all the
settings.
TO: Locator
begin123456 From: Locator
begin ok
8.2Password Setting
Send SMS “password+old password+space+new password” (default password: 123456), it will
reply “password ok”
TO: Locator
password123456 888999 From: Locator password ok
7

8.3 Authorization
8.3.1 Send SMS “admin+password+space+cell phone number” to set the first authorized
number, it will reply “admin ok”, The other authorized numbers should be set by the first authorized
number. (Note: There are only 5 numbers you could authorize as admin nos.)
TO: Locator
admin123456 1234567890 From: Locator
Admin ok
8.3.2 Send SMS noadmin+password+space+authorized number to cancel the authorized number.
8.3.3 When an authorized number dials up the unit, it will reply as below:
Lat: 19.566901 long: 73.051258 speed: 0.00 15/04/13 06.54 F:3.85V,1,Signal:F
imei:354776031555378 05 43.5 460 01 2533 720B
Lat: 19.566901 long: 73.051258 == Coordinate
speed: 0.00 == Speed (More Accurate for speeds above 30 Km/hr)
15/04/13 06.54 == Date&Time
F:3.85V == Battery Power
1 == means unit is charging and 0 == means its not charging
Signal:F == means Full GPS signal and L ==means Weak or no GPS signal
354776031555378 == IMEI
05 == Number of satellites overhead (Between 3 to 10)
43.5 == Altitude (More Accurate for higher altitude)
404 == MCC Mobile Country Code
20 == MNC Mobile Network Code
4A48 == LAC Location area code
7501 == Cell ID
8

8.4 Auto-Track
This function can make the locator to send sms or gprs data in fixed interval for fixed times.
8.4.1 Set up: Send SMS t030s005n+password to the unit; it will report the Geo-info at 30s’ interval
for 5 times. (s: second, m: minute, h: hour).You will receive a reply as “t030s005n OK” if the setting is
successful. The setting must be in 3 digits and at maximum 250 times.
Note: the interval must not be less than 5 seconds.
TO: Locator
t030s005n123456
From: Locator
t030s005n ok
8.4.2 Send SMS t030s***n+password to the unit, it will reply sms or gprs data for unlimited times.
You will receive a reply as “t030s***n OK” if the setting is successful.
TO: Locator
T030s***n123456
TO: Locator
T030s***n ok
8.4.3 Cancel: Send notn+password to delete this function and it will reply “notn ok”.
TO: Locator
Notn123456
TO: Locator
Notn ok
9

8.5 Tlimit Function
8.5.1 Send “tlimit+password+ 50” (50M is the distance, 1-6000M set), reply “tlimit ok” (note: this
function is with auto-tracking function only. If the later position is 50M away with the position before,
it will send sms or gprs data. If less than 50M, it will not send in order to save SMS or gprs fee.
8.5.2 Send” tlimit+password+ 0” to cancel this function, the locator will “tlimit ok”.
8.6GPS-refresh setting
Send SMS “GPSAutoSearch+password+space+120”，it will reply “GPSAutoSearch ok”. The
locator will search GPS signal in 120s interval after setting this.
The refreshing time is between 120-600 seconds (120<interval <600)
Longer standby time for longer refreshing time and shorter standby time for shorter refreshing time.
8.7Reboot remotely
Restart+passwored can be sent to the locator to make the CPU restart when GPRS is stopped. The
locator will turn off and restart in 3 minutes after sending this command.
8.8Geo-fence (Set Safe Zone)
Set up a geo-fence (safe zone) around of the locator and it will send message to the authorized
numbers when the locator goes out of the area.
Notes:This function will be invalid if the unit moves outside the safe zone. You need to re-set it if you
want this function again.
8.8.1 Send SMS stockade+password+space+longitude,latitude;longitude,latitude to the unit to
set the restricted district.
Remark: The first longitude & latitude is coordinate of the top left corner of the Geo-fence, while the
second longitude & latitude is the coordinate of the bottom right corner. It will reply stockade ok.
TO: Locator
stockade123456
19.124845e,73.56718
5n;19.777888e,74.555
666n
From: Locator
stockade ok
10

8.8.2 Cancel: Send SMS “nostockade+password” to deactivate this function. It will reply
“nostockade ok”.
TO: Locator
nostockade123456
From: Locator
nostockade ok
8.8.3Response SMS format: stockade!+geo-info. It will alarm one time in each setting.
From:13188888888
lat: 19.566923 long: 74.051331
speed: 0.00 15/04/13 03:33
F:4.32V,0, Signal:F stockade
imei:359587011016261 05 41.5
460 01 2533 720B
8.9 Movement Alert
This function is used for the owner to get alarm when the locator is moved.
8.9.1 Setup: Send SMS move+password to the unit to set the movement alert, it will reply move ok
TO: Locator
move123456
From: Locator
move ok
11

8.9.2 Cancel: Send SMS nomove+password to deactivate the movement alert, it will reply move ok
Response SMS format: :move!+geo-info. It will alarm one time in each setting.
From: Locator
lat: 19.566923 long: 73.051331
speed: 0.00 15/04/13 03:33
F:4.32V,0, Signal:F move
imei:359587011016261 05 41.5
460 01 2533 720B
8.10Overspeed Alert:
This function is used to control the user’s driving speed.
8.10.1 Setup: Send SMS speed+password+space+ the speed, For example: speed123456 080, it
will reply” speed ok”
TO: Locator
speed123456 080
From: Locator
speed ok
8.10.2 Cancel: Send SMS”nospeed+password “to deactivate the overspeed alert, it will reply”
nospeed ok”
TO: Locator
nospeed123456
From: Locator
nospeed ok
12

Response SMS format: speed+080!+Geo-info (suppose the speed is 80km/h).
From: Locator
lat: 22.566923 long: 114.051331
speed: 0.00 15/04/13 03:33
F:4.32V,0, Signal:F speed080
imei:359587011016261 05 41.5
460 01 2533 720B
Remark: It is recommended that the speed alarm is set at not less than 80km/h in order to make this
function accurate.
8.11 IMEI Checking:
Send SMS” imei+password: to the unit, it will reply imei350001122222222 ok.
TO: Locator
Imei123456
From: Locator
imei350001122222222 ok
8.12 Time Zone setting
Send “time zone+password + GMT time” ,reply “ time zone ok”. (note: if GMT time is positive, just
write the number. If time zone is negative, have to write”–“. For Indian Standard Time: SMS time
zone123456 5.3 (IST is GMT+5.3)
TO: Locator
Time zone123456 5.3
TO: Locator
Time zone123456 -1
From: Locator
time zone ok
13

8.13SOS Button
Press the SOS for 3 second, it will send “ help me !+ Geo-info” to all the authorized numbers. In case
if the unit is continuously sending help me messages then if any authorized number replies SMS “
help me!” to the locator then it will stop sending such SMS.
8.14SMS LINK
8.14.1
Send “smslinkone+password”, the device will reply a Google map link to admin number. The
position can be checked directly on a smartphone
Format：http://maps.google.com/maps?f=q&hl=en&q=19.567610,73.051227&speed: 0.00 15/04/13
14:36 F:4.22V Signal:F imei:012207000691839
8.14.2
Send “smslink+password”, it will reply “smslink ok” .The locator will send the following SMS format
always.
http://maps.google.com/maps?f=q&hl=en&q=22.567610,114.051227&speed: 0.00 15/04/13 14:36
F:4.22V Signal:F imei:012207000691839
8.14.3
Send “smstext+password”, it will reply “smstext ok”. The locator will reply normal SMS format for
this command.
8.15SMS ONE
Send “smsone+password”. The locator will reply one SMS to admin number or gprs server
depending on the settings.
8.16 Low Battery Alert
When the battery power is less than 3.7 V, it will send low battery alert to admin
number.
8.17SMS Center
8.17.1Setup: Send SMS adminsms+password+space+cell phone number to SMS center.
The locator will reply Geo-info & authorized number to sms center number even if the admin
numbers call or send command to the locator.
Response SMS format: authorized number+Geo-info
8.17.2Cancel: Send SMS noadminsms+password to cancel the SMS center.
14

8.18 GSM ID
There is GSM ID in each SMS from the locator. The location of the locator can be found according to
the GSM ID in case of no GPS signal. GSM ID is made up of MCC(MobileCountry Code),
MNC(MobileNetwork Code), LAC (Location area code) and Cell ID.
(refer 8.3.3) Position Accuracy is 50 to 100 meters depending on cell towers.
Remark: GSM ID is not sent when locator is in maplink mode.
8.19 Motion Sensor
This function is for alarm when locator is touched.
8.19.1Setup: Send shake+password+space+1-10 to the locator to set up this function. (1-10 means
the level of intensity)
8.19.2 Send SMS shake+password+space+1 is the least sensitivity. Have to shake the locator
strongly to get the alert.
8.19.3Send SMS shake+password+space+10 is the highest sensitivity. Have to shake the
locator slightly to get the alert.
8.19.4 Cancel: Send SMS shake+password+space+0 to remove this function.
8.20 SD card function
A mini SD card can be inserted in the locator’s SD card slot. The GPRS data can be saved in the SD
card if GPRS is off. It will send data to the GPRS server again when GPRS is on.
8.20.1 Setup: Send SMS sdlog+password+space+1 to activate the sd card-saving function.
Cancel: Send SMS sdlog+password+space+0 to the locator to deactivate this function
8.20.2 Setup: Send SMS readsd+password+space+1 to ask the locator to send data in the SD card
to the GPRS server.
Cancel: Send SMS readsd+password+space+0 to ask the locator to stop sending data in the SD
card to the server.
15

8.21 Switch on/off
8.21.1 Switch off
Press TALK button and SOS button for three seconds at same time, the green indicator will flash
quickly until it is off.
8.21.2 Switch on
Press TALK button and SOS button for three seconds at same time, the green indicator will flash
quickly until it is on.
9 Monitoring Mode (voice surveillance mode)
Send SMS monitor+password, the locator replies “monitor ok” then the locator will get
through automatically when you call and listen to its surrounding sound/voice.
10 Talking Mode
10.1 Send “talk+password”，it will reply “talk ok”， When authorized numbers call the locator, it will
ring several tones and get through automatically for 2-Way communication.
10.2 Send “volume+password+60” ,it will reply “volume ok”
The volume can be set between 0 to 99 to make the volume louder or lower
Note: To set the default track mode, SMS tracker+password to the unit, it will reply “tracker ok!” and
restore to “track”mode.
10.3Dial authorized numbers automatically
TALK button can be pressed for 3 seconds until it stops flashing quickly to get help from the authorized
numbers in emergency. The locator can call to the authorized numbers one by one and you can hear
the calling. The locator will stop calling if any authorized number answers the call.
10.4 Press TALK button for 3 seconds to cancel the 2-Way communication.
11 GPRS setting
APN (Access Point Name), IP, PORT have to be set up for gprs function. APN user, APN password
has to be set up. So please contact with the GSM operator for them.
11.1 Set GPRS protocols
11.1.1 Set TCP protocols:
Gprsmode+password+space+0 to set up TCP protocol, locator will reply gprsmode ok.
(Note: TCP is the default mode in the firmware)
16

11.1.2 Set UDP protocols:
Gprsmode+password+space+1 to set up UDP protocol, locator will reply gprsmode ok.
11.2 Set IP address and port:
Setup: adminip+password+space+IP address+space+port.
If setup successfully, the locator will reply SMS “adminip ok”
Cancel: Send SMS noadminip+password
Adminip+password is the command from SMS to GPRS mode when IP, PORT are set up in the
first GPRS setting.
11.3 Set APN
Setup: apn+password+space+specify apn content.
If setup successfully, the locator will reply SMS “apn ok”.
Cancel:The old APN will be invalid automatically when a new APN is set.
11.4 Set APN’s User Name
Setup: apnuser+password+space+the sim card’s user name.
If setup successfully, the locator will reply SMS “apnuser ok”.
Cancel:The old APN user name will be invalid automatically when a new APN user name is set.
11.5 Set APN’s Password
Setup: apnpasswd+password+space+the sim card’s password.
If setup successful, the locator will reply SMS “apnpasswd ok”.
Cancel:The old APN password will be invalid automatically when a new APN password is set.
11.6 GPRS setting
The locator will hang off the calling in gprs mode when authorized number calls to the locator, then
send gprs data to the server.
GPRS Message Format: S/N + Authorized Number + GPRMC + UTC Time + Status+ Latitude +
N/S Indicator + Longtitude+ W/E Indicator + Speed + Bearing + Date + Magnetic variation + Variation
sense + Mode +Checksum+ Signal + Command + IMEI number + GPS signal fix + Altitude + Battery
status + Batteryvoltage +charging status(0-not charing,1-charging) +Length of command + CRC16
checksum+ GSM ID(4 parts)CELL ID
Example:
100312033421,13145826175,GPRMC,033421.851,A,2234.0209,N,11403.0733,E,1.87,347.73,12031
0,,,A*62,F,help me, imei:354776036842240,03,73.5,F:4.14V,0,138,46772,460,01,2533,720B
17

12Cautions
Pleasecomply with the instructions to extend the unit life:
1. Keep the unit dry. Any liquid, i.e. rain, moisture, may destroy or damage the inside circuitry.
2. Don’t use & store the unit in dusty places.
3. Don’t put the unit in overheated or overcooled places.
4. Handle carefully. Don’t vibrate or shake it violently.
5. Clean the unit with a piece of dry cloth. Don’t clean in chemicals, detergent.
6. Don’t paint the unit, this may cause some foreign materials left in between the parts.
7. Don’t disassemble or refit the unit.
8. Please use the battery and charger provided by manufacturer. Using other batteries and chargers
will cause unwanted situation.
9. Don’t dismount the antenna randomly, or use other antennas. This may interfere with the
transmission, and increase the radiation as well.
10. Kindly use GPRS function if you are aware with the technical working of GPRS, APN and web
servers.
13Faults & The solutions
Faults Solution
Startup Fail Check the battery and see if it is fully charged or
correctly installed.
Hangup Fail In existence of an authorized number, if an unauthorized number dials
up the unit. Please initialize the unit and re-set the authorized
numbers. Check if SIM card’s call display is on or not.
Monitor Fail
Check if the authorized number is setup or is the unit in the
coverage of signals.
Location report in
digits of zeros.
Don’t use it in the place beyond reach of signals. Place the
unit outdoors, especially when starting it up.
18
