User Manual
TR250 -TR560 -TR560s
This manual was written to help you understand the operation and maintenance
of your TREKKER ®. It’s important for you to understand your new TREKKER ®, its
features and operations so that your first ride will get you the most from your
new scooter and keep it maintained for optimum performance and safety.
It is also important that your first ride on a new TREKKER ® is taken in a
controlled environment, away from vehicles, obstacles and other hazards.

Handlebar
Left side Right side
Hand operated acceleration throttle Hand operated acceleration throttle

Front & Rear disc brake leavers
Handle operated mechanical brake; the disk brakes are activated by clamping
handle broke to the round brake leaver located on the handlebars.
Left side Right side
Rear disc brake leavers Front disc brake leaver
acceleration throttle
Adjustments: Disc Brake leaver adjustment

Charging procedure
Charging your batteries should be done by the following order:
While holding charger in hand, plug the charger into a standard 110/220-volt
electrical out-lot.
Next, locate the charger socket under the key switch (see sketch above ).
Plug the charger head into the Charger Socket.
Keep your charger on the floor, or any optional cool surface while charging.
Charging Indication: Red light – charging, Green light – Fully charged.
When batteries are fully charged, unplug charger form the charge socket and replace
cap over the charge socket. Only then unplug the cable from the electric out-let.
Important: Handle your charger with care. Do not drop it, as the charger is
mostly sensitive when heated up. Make sure to keep it clean & away from wet
or humid surfaces.
For optimum performance charging the batteries after every use is recommended for
extended battery life.

Batteries Replacement
Even with proper care, rechargeable batteries will not last forever. When batteries will
not hold a charge, please call the local distributor.
Important:
These batteries are Lithium based and must be recycled properly.
Do not throw; Do not recycle any battery into the household waste or trash.
Please make sure to contact your local dealer and return the battery for proper
disposal.
Wheel Inflation
Inflating wheels every week with 28-38 psi pressure will insure smooth ride.

Timing belt adjustment and replacement: TR560/TR560s
Periodic adjustment of the Timing belt is required. The belt will become loose after
hours of operation. When it does, the belt will create a popping noise during
acceleration. When this occurs, you must tighten drive belt immediately.
Contact your local dealer and come in for a check-up service
To tighten belt, loosen up slightly the three bolts connecting the motor housing to frame
(located on the rear left side of the frame), then slide the motor housing as needed
towards the front (recheck belt tension) close the bolts making sure they are firmly
locked. If belt is damaged or worn please contact your local distributor for a
replacement.
Range and speed
When fully charged, the Trekker will cover approximately 23 km on level ground with a
load weight of 75kg. Top speed –
25km/h.
Note: these figures were measured at optimal conditions.

Riding Instructions:
Before riding, be sure to have a clear unobstructed level path ahead of the
rider, and turn the key switch to “on” position.
Hold handlebars; place your front foot onto the platform with your hand on
the throttle.
Go ahead and push off like a regular push scooter.
To engage the motor, accelerate smoothly do not squeeze throttle to its
end at one time!
To disengage the motor and to Slow/Stop, release the throttle and press
the brake with your hand.
Use the brake to control your speed.
As you become a more skilled rider, you will use a combination of brake
and power to achieve optimum operation consumption strategy.
Incase you encountered a problem, before rushing to take the Trekker to your local dealer,
Please check the following troubleshooting guide or call your local distributor. Most issues
can be easily solved by phone.
All repairs and/or replacements will be performed or processed through the local distributor.
Thank you for reading and understanding this manual. Please keep safe!
and enjoy your ride!
Again, thank you for purchasing Trekker.
We are always looking to improve our products and we welcome your comments.

TR560 /TR560s– Measurements:
Length: 120 cm
Width: 56 cm
Height: 102.5 - 107 cm
Weight: 27kg
Load capacity: 130 kg
Color: Choice of RAL colors
Technical Specifications:
DC Electric Motor : 24 Volt , 250 Watt
Battery: Lithium ion 15amp/h *
Range: 25km*
Charging time: Up to 3.5 hours
Maximum Speed: 25km/h
Breaking system: Heavy duty front & rear disc break
Wheels: 10" inflated
Belt drive
Front and rear lights ,Seat + License plate holder, Bell, Home Charger.
TR250 – Measurements:
Length 102cm
Width 26cm
Height 114.5
Weigh 17kg
Load capacity 100kg
Choice of RAL colors
Technical Specifications
BLDC hub motor: 36v 250 watt BLDC hab motor
Battery Lithium ion 6, 55 amp/h
Maximum speed: 25km/h
Braking system: Heavy duty front & rear disc break.
Wheel size: 10" inflated
Lights: Operate when scooter is on. Bell, home charger
