ENERMAX EMK3105PCI User manual

User manual
Basic Usage Unload the Hard drive
Attach the included mylar film as shown.
Pull the spring lock to open the front door.
1.
3.
4.
2.
Place the HDD into EMK3105PCI with its printed label up-sided.
Press the door to push the hard drive into EMK3105PCI until the door is
locked.
EMK3105PCI
1. Smoothly pull the spring lock to open the door. Make sure the key lock
is on a removable position, or the lock would get damaged.
2. Carefully take the hard drive out from EMK3105PCI.
Attention
1. To perform hot-swap function, the host must also support hot-swap.
2. Keep the device out of high temperature and humid environment.
3. If the device or HDD is damaged due to improper operation, we would not take the
responsibility of compensation or repair.

Package content Parts Installation
Taking off one of sockets in the back of host case.
Putting carefully EMK3105PCI to the socket.
Confirming EMK3105PCI is flat, then screw to fix it.
1.
2.
3.
Lock
Unock
Front panel
1. Key lock (A:Lock B:Unock)
2. Spring lock
3. HDD LED indicator
Back panel
1. SATA power connector (15P)
2. SATA data connector (7P)
3. LED access port (4P)
1 2 3 1 2 3
Accessories Quantity
EMK3105PCI 1
SATA 7 pin data cable 1
SATA 15 pin to 4 + 4 pin Power Cable 1
Screws 4
Key 1
IInsulating pad 1
User manual 1
