Enforcement Technology Group Wireless First Responder User manual

WIRELESSFIRSTRESPONDER
OPERATINGMANUAL
Version:ETG‐WFR‐OPS‐2017
Copyright2017©.EnforcementTechnologyGroup,Inc.(ETGI).ContentsSubjecttoChangeWithoutNotice.
TABLEOFCONTENTS:
TOPIC PAGE#
StandardComponents&Accessories 1
LoudspeakerOverview/Controls 2
VHFWirelessTransmitterPackOverview/Controls 3
LoudspeakerBatteryCharging/Maintenance 4
GeneralOperatingSafetyGuidelines 5
Remote/RFWirelessOperations 6‐7
Local/WiredOperations 8
Loudspeaker,VHFWirelessTransmitterPack&MicrophoneSpecifications 9

STANDARDCOMPONENTS&ACCESSORIES:
1.
HandheldMicrophone
with¼”(6.35mm)Plug
AudioCablewith1/8”
(3.5mm)Plugs
LoudspeakerwithIntegrated/InternalVHFWirelessReceiver
(includes12vRechargeableBattery)
VHFWirelessTransmitterPack
(includes9vAlkalineBattery)
ACPowerCord
ACPowerAdapter/Charger
LoudspeakerCustom/PaddedDeploymentCase
RemoteVolume
ControlDial
HeadsetMicrophone
with1/8”(3.5mm)
Plug
LapelMicrophone
with1/8”(3.5mm)
Plug
DigitalVoiceRecorder
(includesMicroUSBCableand(2)AAAlkalineBatteries)
IMPORTANTNOTE:
StandardComponents&AccessoriesfeaturedinthisOperatingManualare
subjecttochangewithoutnotice.

LOUDSPEAKEROVERVIEW/CONTROLS
4
5 9
367
1
3
4
7
8
2
5
6
1TheWIRELESSAUDIORECIEVER
PLUGallowsunittoreceive/
projectaudiosignalstransmitted
bythe“VHFWirelessTransmitter
Pack.”
IMPORTANTNOTE: The
WIRELESSAUDIORECIEVERPLUG
must beinsertedintotheLINEIN
jackfortheunittobecapableof
receivingaudiosignals
transmittedbythe“VHFWireless
TransmitterPack”(illustrated
below).
IftheWIRELESSAUDIORECIEVER
PLUG isnot insertedintotheLINE
IN jack,theunitwillnot
receive/projectaudiosignals
transmittedbythe“VHFWireless
TransmitterPack.”Seethe
“REMOTE/RFWIRELESS
OPERATIONS”sectionofthis
manualformoreinformation.
2
COMPARTMENTFORBATTERY
ANDSHOULDERSTRAP
Toinsertthebattery,openthe
compartment’scover.The
bottomhalfofthecompartment
isusedforthebattery.Open
thelatchtoaccessthebattery
compartment.
Insertbatteryasfollows:
Theterminalsmust facetheunit
withthepositiveterminal(red)
onthesideoftheunit’scontrol
panel(totheleft,asseenfrom
therearpanel).Insertbattery
andclosethelatch.Closethe
batterycompartment.
IMPORTANTNOTE: Theunit
shipswithaninternal
rechargeablebatterythatcan
powercontinuousoperationsfor
6to8hours(approx.).We
recommendthatbatteryisfully
chargedpriortoinitial
operations.Seethe
“LOUDSPEAKERBATTERY
CHARGING/MAINTENANCE”
sectionofthismanualformore
information
TherotaryMICLEVELdial
allowsoperatortoadjustthe
volumeprojectionlevelofthe
unit.
POWERswitchturnsthe
unitonandoff.When
turnedon,theLEDofthe
switchlightsup.
LOWBATLEDindicates
thattherechargeable
batteryneedstobe
charged.
CHARGELEDflashes
yellowaslongasthe
rechargeablebatteryis
charging.Itturnsoffwhen
thebatteryisfullycharged.
Connectthesupplied
“HandheldMicrophone
with¼”(6.35mm)Plug”
totheMICINjack for
“LOCAL/WIRED
OPERATIONS.”
Connectanexternalaudio
source(DigitalVoice
Recorder,CDplayer,MP3
player,etc.)totheLINEIN
jackfor“LOCAL/WIRED
OPERATIONS.”
Connectthepowersupply
viathepolarizedDCIN
connector.Afittingpower
adapterissupplied.Use
thedeviceonlywiththe
includedpowersupply.
9
8
2.

VHFWIRELESSTRANSMITTERPACKOVERVIEW/CONTROLS
3
4
25
1Connecttheaudiosourcethatistobewirelessly
transmittedandprojectedthroughthe
LoudspeakerunittotheMICINjack.
Seethe“REMOTE/RFWIRELESSOPERATIONS”
sectionofthismanualformoreinformation.
IMPORTANTNOTE: TheLoudspeakerunit’s
WIRELESSAUDIORECIEVERPLUGmust be
insertedintotheLINEINjackfortheunitto
receive/projectthesoundprovidedbythedevice
thatisconnectedtoMICINjackofthe“VHF
WirelessTransmitterPack”(illustratedbelow).
IftheWIRELESSAUDIORECEIVERPLUG isnot
insertedintotheLoudspeakerunit’sLINEIN jack,
theunitwillnot receive/projectaudiosignals
transmittedbythe“VHFWirelessTransmitter
Pack.”
TheLED willturnonwhenthePOWER switch
issettothe“TXF1ON”or“TXF2ON”
position.TheLED willturnoffwhenthe
POWER switchissettothe“TXOFF”position.
IMPORTANTNOTE:TheunitwillNOT
wirelesslytransmitaudioifthePOWER switch
issettothe“TXF2ON”position.
9VBATTERYCOMPARTMENT
Toinsertthebattery,openthebattery
compartmentbyslidingthecoverdownwards.
Insertthebatteryinaccordancewiththepolarity
(+/‐)decalcontainedwithinthecompartment.
Onceinserted,closethebatterycompartmentby
slidingthecoverupwards.
IMPORTANTNOTE:Theunitshipswitha9v
alkalinenon‐rechargeablebatterypre‐installed.If
the“VHFWirelessTransmitterPack”doesNOT
poweron(i.e.LED doesNOT turnon),installa
fresh/new9valkalinebattery.
SetthePOWER switchtothe“TXOFF”position
topowerofftheunit.
124
35
SetthePOWER switchtothe“TXF1ON”
positiontopowerontheunit/allowforwireless
audiotransmission.
IMPORTANTNOTE:TheunitwillONLY be
capableofwirelesslytransmittingaudiowhen
thePOWER switchissettothe“TXF1ON”
position.
TheunitwillNOT wirelesslytransmitaudioifthe
POWER switchissettothe“TXF2ON”position.
3.

LOUDSPEAKERBATTERYCHARGING/MAINTENANCE
TheLoudspeakerunitshipswithaninternalrechargeablebatterythatcanpowercontinuousoperationsfor
6to8hours(approx.).WerecommendthattheLoudspeakerunit’sbatteryisfullychargedpriortoinitial
operationsasfollows:
1. Connectthe“ACPowerAdapter/Charger”tothe“ACPowerCord.”
2. Connectthe“ACPowerCord”toa120velectricalwalloutlet.
3. Inserttheplugofthe“ACPowerAdapter/Charger”intotheLoudspeakerunit’sDCIN powerjack.
NOTE: Theunit’sCHARGELEDflashesyellowaslongasthebatteryischarging.Batterychargingmaytakeup
to(4)hours.
4. WhentheLoudspeakerunit’sbatteryisfullycharged(unit’sCHARGE LEDturnsoff),disconnectthe“AC
PowerCord”fromthewalloutletandthe“ACPowerAdapter/Charger”fromtheunit.
5. Oncefullycharged,disconnectthe“ACPowerAdapter/Charger”andACPowerCord.“ 
IMPORTANTNOTE: TopreventdamagetotheLoudspeakerunit’sbatterydueto“overcharging,”ALWAYS
disconnectthe“ACPowerAdapter/Charger”afterthebatteryhasbeenfullycharged.
IMPORTANTBATTERYMAINTENANCE/STORAGEINFORMATION:
TheLoudspeakerunitusesasealedlead‐acidgelbatterythatwillslowlyself‐dischargewhentheunitisNOT inuse.
PriortostoringtheLoudspeakerunitforanextendedperiod,
fullychargethebatterybeforestorageandthenchargeagainevery(3)months.
Thelead‐acidbatteryneedstoberechargedevery(3)monthsforcontinuedoperation.
PleasereplacethebatteryiftheLoudspeakerunitoperatingtimenoticeablydecrease,
evenafterafullchargecycle.
ReplacementbatteriesmaybepurchasedbycontactingEnforcementTechnologyGroup,Inc.(ETGI)
directlyat414‐276‐4471.
LoudspeakerBatteryChargingSet‐UpDiagram
120vElectrical
WallOutlet
ACPowerCord ACPower
Adapter/Charger
LoudspeakerUnit
4.

GENERALOPERATINGSAFETYGUIDELINES:
Read,follow,heedallwarningsandkeepthisoperatingmanual.
•DoNOT usetheLoudspeakerunitnearwaterorduringsevereweather.
•Clean only with dry cloth
•DoNOT throw,droporaggressivelyhandletheLoudspeakerunit
and/ortheVHFWirelessTransmitterPackastheycontain“sensitive”
electroniccomponents.
•ALWAYS placetheLoudspeakerunitits“Custom/PaddedDeployment
Case”foraddedprotectionduringoperations.
•Toavoidfeedback,Loudspeakershouldbepositionedatleast100ft.
(30m)awayfromcommunicatorduring“REMOTE/RFWIRELESS
OPERATIONS.”
•DoNOT usecomponentsnearANY heatsourcesuchasradiators,heat
registers,stovesorotherdevices(includingamplifiers)thatproduce
heat.
•UnplugtheLoudspeakerunitduringlightningstorms.
•ReferallservicingtoEnforcementTechnologyGroup,Inc.(ETGI)
personnel.Servicingisrequiredwhenacomponenthasbeendamaged
inanyway,suchaspowersupplycordorplugisdamaged,liquidhas
beenspilledorobjectshavefallenintoacomponent,componenthas
beenexposedtorainormoisture,componentdoesNOT operate
normallyorcomponenthasbeendropped.
•CAUTION!: Toreducetheriskofelectricshock;doNOT removethetop
cover(ortherearsection)oftheLoudspeakerunitasNO user
serviceablepartsarelocatedinside.
•CAUTION!: TheLoudspeakerunitcontainsarechargeablebattery.
RechargeablebatteriesmustNOT beexposedtofire– thisposesa
DANGEROFEXPLOSION.Incorrectlyreplacingthebatteryposesa
DANGEROFEXPLOSION.Onlyusebatteriesofthesametype.The
capacityofthebatterymaydiminishatlowtemperatures.
•CAUTION!: TheLoudspeakerunitiscapableofdeliveringsound
pressurelevelsinexcessof105dB,whichmaycausepermanent
hearingdamage.
•ALWAYS performthe“LOUDSPEAKERBATTERY
CHARGING/MAINTENANCE”procedurescontainedwithinthismanual
eachtimeaftertheequipmenthasbeendeployed/used.
LEGALDISCLAIMER:Enforcement
TechnologyGroup,Inc.(ETGI)
acceptsnoliabilityforanyloss
whichmaybesufferedbyany
personwhorelieseitherwhollyor
inpartuponanydescription,
photograph,orstatement
containedherein.Technical
specifications,appearancesand
otherinformationaresubjectto
changewithoutnotice.
5.

REMOTE/RFWIRELESSOPERATIONS:
Toprojectanoperator’slivevoicewirelesslythroughtheLoudspeakerunitviathesupplied“Lapel
Microphone”or“HeadsetMicrophone,”pleasefollowtheinstructionsbelow:
1. PreparetheLoudspeakerunitfor“REMOTE/RFWIRELESSOPERATIONS”
byinsertingtheWIRELESSAUDIORECEIVERPLUG intotheunit’sLINEIN
jack.IMPORTANTNOTE:TheWIRELESSAUDIORECIEVERPLUGmust be
insertedintotheLINEINjackfortheunittobecapableofreceivingaudio
signalstransmittedbytheVHFWirelessTransmitterPack
(refertodiagram1.0).
Diagram1.0
2. PoweruptheLoudspeakerunitbypressingtheunit’sPOWER switch.
NOTE: Whenpoweredup,thePOWER switchLEDwillturnon.
5. PowerontheVHFWirelessTransmitterPackbysettingthedevice’sPOWER switchtothe“TXF1ON”position.
NOTE: Whenpoweredontheunit’sLEDwillturnon.
3. Insertthemaleplugofthesupplied“RemoteVolumeControlDial”into
theMICINjackoftheVHFWirelessTransmitterPack
(refertodiagram1.1).
Diagram1.1
4. Connectthesupplied“LapelMicrophone”or “Headset
Microphone”byinsertingthecomponent’smaleplugintothe
jackofthe“RemoteVolumeControlDial”thatisconnectedto
theVHFWirelessTransmitterPack(refertodiagram1.2for
illustrationof“HeadsetMicrophone”connection).
Diagram1.2
6. Theoperator’svoicethatispickedupbythemicrophoneconnectedtotheVHFWirelessTransmitterPackvia
the“RemoteVolumeControlDial”willbewirelesslytransmittedandprojectthroughtheLoudspeakerunit.
NOTE: Toincrease/decreasetheprojectionvolumeoutputleveloftheLoudspeakerunit,adjustthediallocated
onthe“RemoteVolumeControlDial.”
IMPORTANTWIRELESSAUDIOTRANSMISSIONDETAILS:
TheeffectivewirelessaudiotransmissionrangebetweenthesuppliedVHFWirelessTransmitterPackand
Loudspeakerunitisapproximately150to200ft.(40to60m).Thereareseveralfactorsthatcanimpactorprevent
wirelesssignaltransmission.Tohelpensurewirelesssignaltransmissionatthemaximumeffectiverange,please
establishaclear,lineofsight(LOS)paththatisfreeof“obstacles”betweentheVHFWirelessTransmitterPackand
Loudspeakerunitduringoperations.
6.

REMOTE/RFWIRELESSOPERATIONS:
Toprojectanexternal audio source (Digital Voice Recorder, CD player, MP3 player,etc.)wirelesslythroughthe
Loudspeakerunit,pleasefollowtheinstructionsbelow:
1. PreparetheLoudspeakerunitfor“REMOTE/RFWIRELESS
OPERATIONS”byinsertingtheWIRELESSAUDIORECEIVER
PLUG intotheunit’sLINEINjack.IMPORTANTNOTE:The
WIRELESSAUDIORECIEVERPLUGmust beinsertedintothe
LINEINjackfortheunittobecapableofreceivingaudio
signalstransmittedbytheVHFWirelessTransmitterPack
(refertodiagram1.0).
Diagram1.0
2. PoweruptheLoudspeakerunitbypressingtheunit’s
POWER switch.NOTE: Whenpoweredup,thePOWER
switchLEDwillturnon.
5. PowerontheVHFWirelessTransmitterPackbysettingthedevice’sPOWER switchtothe“TXF1ON”position.
NOTE: Whenpoweredontheunit’sLEDwillturnon.
6. PoweruptheexternalaudiosourcethatisconnectedtotheVHFWirelessTransmitterPackviathe“Audio
Cablewith1/8”(3.5mm)Plugs.”
7. Tobeginwirelessaudiotransmission/projection,press/selecttheexternalaudiodevice’sPLAY button/control.
NOTE: Toincrease/decreasetheprojectionvolumeoutputleveloftheLoudspeakerunit,adjustthevolume
controlslocatedontheconnectedexternalaudiosource.
3. Inserta maleplugofthesupplied“AudioCablewith1/8”
(3.5mm)Plugs”intotheMICINjackoftheVHFWireless
TransmitterPack
(refertodiagram1.1).
4. Inserttheremainingplugofthesupplied“AudioCable
with1/8”(3.5mm)Plugs”intothe1/8”(3.5mm)audio
outputjack(i.eEARorSPEAKER)oftheexternalaudio
source(refertodiagram1.2forillustrationof“DigitalVoice
Recorder”connection).
Diagram1.1
Diagram1.2
7.

LOCAL/WIREDOPERATIONS:
Toprojectanoperator’slivevoicethroughtheLoudspeakerunitviathesupplied“HandheldMicrophonewith
¼”(6.35mm)Plug,”pleasefollowtheinstructionsbelow:
Diagram1.0
2. PoweruptheLoudspeakerunitbypressingtheunit’sPOWER switch.
NOTE: Whenpoweredup,thePOWER switchLEDwillturnon.
1. Insert the plug of the supplied “Handheld
Microphone with ¼” (6.35mm) Plug”intothe
Loudspeaker unit’s MIC IN jack
(refertodiagram1.0).
3. Activatethe“HandheldMicrophonewith¼”(6.35mm)Plug”bysettingthedevice’sON/OFFswitchupwards
totheON position.
4. Theoperator’svoicethatispickedupbythe“HandheldMicrophonewith¼”(6.35mm)Plug”willbeprojected
throughtheLoudspeakerunit.NOTE: Toincrease/decrease the projection volume output level, adjust the
Loudspeakerunit’srotaryMIC LEVEL dial.
Toprojectanexternal audio source (Digital Voice Recorder, CD player, MP3 player,etc.)throughtheLoudspeaker
unit,pleasefollowtheinstructionsbelow:
Diagram1.1
1. Inserta maleplugofthesupplied“AudioCable
with1/8”(3.5mm)Plugs”intotheLINEINjackof
theLoudspeaker unit.
(refertodiagram1.1).
Diagram1.2
2. Inserttheremainingplugofthesupplied
“AudioCablewith1/8”(3.5mm)Plugs”
intothe1/8”(3.5mm)audiooutputjack
(i.eEARorSPEAKER)oftheexternalaudio
source(refertodiagram1.2forillustration
of“DigitalVoiceRecorder”connection).
3. Poweruptheexternalaudiosourcethatisconnectedtothe
Loudspeakerunitviathe“AudioCablewith1/8”(3.5mm)Plugs.”
4. Tobeginaudioprojection,press/selecttheexternalaudiodevice’s
PLAY button/control.NOTE: Toincrease/decreasetheprojection
volumeoutputleveloftheLoudspeakerunit,adjustthevolume
controlslocatedontheconnectedexternalaudiosourceand/orthe
Loudspeakerunit’srotaryMICLEVELdial. 8.

LOUDSPEAKER,VHFWIRELESSTRANSMITTERPACK&
MICROPHONESPECIFICATIONS
LAPEL
MICROPHONE:
Omni‐Directional/ElectretCondenserwith1/8”
(3.5mm)Plug
HEADSET
MICROPHONE:
Omni‐Directional/ElectretCondenserwith1/8”
(3.5mm)Plug
HANDHELD
MICROPHONE:
Dynamic/Hyper‐cardiodewith3ft.(1m)
CoiledCablewith¼”(6.35mm)Plug
WEIGHT: ~8.1lbs(3.67kg)withbatteryinstalled
DIMENSIONS: 8.5"X7.1"X11.2"(217mmX180mmX284mm)
INPUTS:
MICIN: ¼”(6.35mm)TRSConnectorJack,Unbalanced
LINEIN: 1/8”(3.5mm)TRSConnectorJack,Unbalanced
POWER:
PowerSupply: 12vdc/2600mAh
ChargeTime: ~4hrs
OperatingTime: ~6to8hrs
(unlimitedwhenconnectedtoexternalpower)
A/CPower
Adapter/Charger: 18vdc/3A
MainsVoltage: 100‐240v~,50/60Hz,1.5A(switchingmode
adapter)
INTEGRATED/INTERNALVHFWIRELESSRECEIVER:
RxFREQUENCY
CHANNEL: VHFFrequency:169.445MHz,
MODULATION
SYSTEM: FM
POWERSUPPLY: IntegratedwithLoudspeakerRechargeable
Battery
POWER
CONSUMPTION: 25mA
LoudspeakerSpecifications: VHFWirelessTransmitterPackSpecifications:
MicrophoneSpecifications:
WEIGHT: ~6oz.(170.10g)withbatteryinstalled
DIMENSIONS: 3.0"X2.50"X0.75"(144.30mmX63.5mmX
19.05mm)
TxFREQUENCY
CHANNEL: VHFFrequency:169.445MHz
MODULATION
SYSTEM: FM
EFFECTIVETx
RANGE: 150to200ft..(45to60m)LineofSight(LOS)
INPUT: 1/8”(3.5mm)Jack
POWERSUPPLY: 9vAlkalineBattery(non‐rechargeable)
POWER
CONSUMPTION: ~30mA
IMPORTANTNOTE:
StandardComponents&AccessoriesfeaturedinthisOperatingManualare
subjecttochangewithoutnotice.
9.
