Vizio SB3241n-H6 User manual

USER MANUAL
Model: SB3241n-H6
VIZIO 4.1 Sound Bar
Please read this guide before using the product.
M
odel: SB3241n-H6
VIZI
O
4.1
S
ound Bar
FPO

IMPORTANT SAFETY INSTRUCTIONS
Your Unit is designed and manufactured to operate within dened design limits, and misuse may result in electric shock or re. To prevent your Unit from being damaged,
the following rules should be observed for its installation, use, and maintenance. Please read the following safety instructions before operating your Unit. Keep these
instructions in a safe place for future reference.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as when the power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
• To reduce the risk of electric shock or component damage, switch o the power before connecting other components to your Unit.
• Unplug the power cord before cleaning your Unit. A damp cloth is sucient for cleaning. Do not use a liquid or a spray cleaner on your Unit. Do not use abrasive
cleaners.
• Always use the accessories recommended by the manufacturer to insure compatibility.
• When moving your Unit from an area of low temperature to an area of high temperature, condensation may form in the housing. Wait before turning on your Unit to
avoid causing re, electric shock, or component damage.
• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your Unit and to protect it from overheating, be
sure these openings are not blocked or covered. Do not place your Unit in a bookcase or cabinet unless proper ventilation is provided.
• Never push any object into the slots and openings on your Unit enclosure. Do not place any objects on the top of your Unit. Doing so could short circuit parts causing a
re or electric shock. Never spill liquids on your Unit.
• Do not block the subwoofer ports. Allow for 1-2 inches of space around all sides for ventilation.
• WARNING: Exposure to loud sounds can damage your hearing causing hearing loss and tinnitus (ringing or buzzing in the ears). With continued exposure to loud
noises, ears may become accustomed to the sound level, which may result in permanent damage to hearing without any noticeable discomfort.
• When connected to a power outlet, power is always owing into your Unit. To totally disconnect power, unplug the power cord.
• Do not overload power strips and extension cords. Overloading can result in re or electric shock.

IMPORTANT SAFETY INSTRUCTIONS
• The wall socket should be located near your Unit and be easily accessible
• Keep your Unit away from moisture. Do not expose your Unit to rain or moisture. If water penetrates into your Unit, unplug the power cord and contact your dealer.
Continuous use in this case may result in re or electric shock.
• Do not use your Unit if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer immediately. Do not try to
repair your unit yourself.
• Avoid using dropped or damaged appliances. If your Unit is dropped and the housing is damaged, the internal components may function abnormally. Unplug the power
cord immediately and contact your dealer for repair. Continued use of your Unit may cause re or electric shock.
• Do not install your Unit in an area with heavy dust or high humidity. Operating your Unit in environments with heavy dust or high humidity may cause re or electric
shock.
• Ensure that the power cord and any other cables are unplugged before moving your Unit.
• When unplugging your Unit, hold the power plug, not the cord. Pulling on the power cord may damage the wires inside the cord and cause re or electric shock. When
your Unit will not be used for an extended period of time, unplug the power cord.
• To reduce risk of electric shock, do not touch the connector with wet hands.
• Insert the remote control batteries in accordance with instructions. Incorrect polarity may cause the battery to leak which can damage the remote control or injure the
operator.
• See the important note and rating located on the back of the unit.
• WARNING: This equipment is not waterproof. To prevent a re or shock hazard, do not place any container lled with liquid near the equipment (such as a vase or
ower pot) or expose it to dripping, splashing, rain, or moisture.
• CAUTION: Danger of explosion or re if batteries are mistreated. Replace only with the same or specied type.
• Do not leave the batteries exposed to direct sunlight for a long period of time with doors and windows closed. Do not disassemble the batteries or dispose of it in re.
• Where the MAINS plug or appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
• No naked ame sources,such as lighted candles,should be placed on the apparatus.
• The ventilation should not be impeded by covering the ventilation openings with items,such as newspapers, table-cloths, curtains, etc.
• The equipment shall be used at maximum 35 degree C ambient temperature.
WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
The lighting ash with arrowhead symbol
within an equilateral triangle is intended
to alert the user to the presence of not
isolated dangerous voltage within the
product that may be sucient magnitude
to constitute a risk of shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and servicing instructions in the
literature accompanying the appliance.
Warning: This equipment is a Class II or
double insulated electrical appliance. It
has been designed in such a way that it
does not require a safety connection to
electrical earth.

TABLE OF CONTENTS
Package Contents......................................................................................................................................1
Controls & Connections ............................................................................................................................2
First-time Setup.........................................................................................................................................6
Using the Remote ......................................................................................................................................12
Proper Placement ......................................................................................................................................13
Mode & Level Settings...............................................................................................................................15
Using Button Combinations......................................................................................................................19
Programming the Sound Bar ....................................................................................................................20
Bluetooth Pairing.......................................................................................................................................21
Using Bluetooth Mode...............................................................................................................................22
Connecting to a Voice Assistant ..............................................................................................................23
Advanced Setup.........................................................................................................................................25
Connecting with HDMI ARC ......................................................................................................................26
Connecting a Subwoofer...........................................................................................................................28
Wall-mounting............................................................................................................................................29
Register Your Product................................................................................................................................31
Customer Service ......................................................................................................................................32
Help & Troubleshooting.............................................................................................................................33
Limited Warranty .......................................................................................................................................34
Legal & Compliance ...................................................................................................................................37
Specications ............................................................................................................................................38

ENG - 1
Package Contents
Stereo RCA to
3.5mm Audio Cable
3.5mm to 3.5mm
Audio Cable
Digital Optical
Cable
2 x Power Cables
Wall Mount Template User Manual Quick Setup Steps
Remote Control
with 2x AAA Batteries
2 x Surround Speaker
Audio Cables
VIZIO
Sound Bar Wireless Subwoofer
2 x Wall
Mount Brackets
(Sound Bar)
Surround Speakers
4 x Cable
Ties
2 x Wall
Mount Brackets
(Surround Speakers)
4 x Wall
Mount Screws
HDMI Cable

ENG - 2
Controls & Connections
Back of Sound Bar
*Supports .WAV and .MP3 le format playback only.
Power Port

ENG - 3
Controls & Connections
**Only use this port to connect a Voice Assistant device. See Connecting to a Voice Assistant on page 23 for more information.
Digital Optical
Audio In
HDMI (ARC)
to TV
AUX VA**
Analog Audio In
(Stereo 3.5mm)
USB*In
AUX In
Analog Audio In
(Stereo 3.5mm)

ENG - 4
Controls & Connections
Top of Sound Bar
Volume
Increase or decrease the
loudness of the audio.
Bluetooth Input
Hold to pair.
(See ‘Bluetooth Pairing’ for more information.)
Input
Press to change the audio source.
Power
Press to turn on or o.

ENG - 5
Controls & Connections
Surrounds ON / OFFAC IN
Power Button
LED Indicator
Power Port
Back of Subwoofer
Back of Surround Speakers
Surround Speaker Ports
Connects to surround speakers
Left: blue cable / Right: gray cable
Surround Speaker Ports
(Connects to Subwoofer)

ENG - 6
First-time Setup
1Choose the best possible connection cable type and connect it to your TV.*
Be sure the TV port is an audio
output, not an audio input.
Back of Sound Bar

ENG - 7
3.5mm to
RCA cable
GOOD
OROR
BETTER
Digital Optical
Cable**
HDMI ARC
Cable
First-time Setup
**Some TVs do not pass through digital audio:
When using the digital input, if there is no audio, try:
• setting the TV output to PCM, or
• connecting directly to your Blu-ray or other source.
*Not all TVs have the audio outputs shown.
To connect the sound bar directly to your other
devices (Blu-ray player, game system, etc.) see
your device’s user manual.
BEST

ENG - 8
2Connect the power cable to the sound bar AC IN as shown.
Plug the power cable into an electrical outlet.
First-time Setup
Back of Sound Bar

ENG - 9
Surrounds ON / OFFAC IN
Connect the surround speakers to the subwoofer using the included surround speaker
audio cables. Cable ties are included to wrap unused cable length.
3
Match the color-coded speaker cable to the matching speaker port color.
Blue for left surround and grey is for right surround.
First-time Setup

ENG - 10
5
Plug the power cable into a
power outlet.
Connect the power cable to
the subwoofer.
AC IN
4
The subwoofer should
automatically power on and
link to the sound bar when
plugged in. The LED will glow
to solid to confirm.
ON / OFF
6
First-time Setup
Back of Subwoofer
Surrounds ON / OFFAC IN

ENG - 11
After turning on both your TV and sound bar, it will automatically begin searching for an active input.*
The LED indicator on the front of the sound bar will begin cycling in different colors through inputs
until an audio source is detected.**
You can press the INPUT button to switch between audio
sources. For example, if you connected your TV to HDMI (ARC),
set the sound bar to HDMI-ARC.
7Remove the battery cover by gently
sliding it away from the remote. 8Insert the included batteries and gently slide the battery cover back into place.
9
To p To p
*Occurs only during rst-time set up.
**Auto detect function only occurs once when the sound bar is rst powered on. To enable this feature
again, you must do a Factory Reset (see the Using Button Combinations on page 19 for more
information) or press and hold the INPUT button for 4 seconds.
When needed, VIZIO recommends replacing the batteries that came with
this remote with two, new Duracell ‘AAA’ alkaline batteries.
First-time Setup
Tip: Pressing the INPUT button will stop the auto
detect function.
Input Power

ENG - 12
Using the Remote
Volume +/-
Increase and decrease volume
Setup Settings
Change setup settings
Eect Settings
Change audio eect settings
Previous
Return to previous track.
(Changes audio settings in menu)
Mute
Mute/unmute.
(Long press to turn LED power indicator and voice
notications on/o)
Power
Turn on or o
OK
Select an option, play or pause.
(Long press for Info)
Next
Skip to the next track.
(Changes audio settings in Menu)
Display
Displays Sound Bar Settings
Input
Change the input source.*
(Long press for Auto Input Search.)
Bluetooth
Press to go to Bluetooth Mode
(Long press for Pairing Mode)
Up/Down
Cycle through settings and options
EQ Settings
Change equalizer settings
Level Settings
Change audio leveling settings
*Press INPUT then Previous to select previous input.
Specic inputs will show a dierent LED color:
• AUX In: Green
• AUX VA: Violet
• Digital Optical: Red
• HDMI (ARC): Magenta
• Bluetooth: Blue
• USB: Orange

ENG - 13
Proper Placement
For the best surround sound experience, position the sound bar, subwoofer, and surround sound
speakers as shown. The sound bar should be close to ear level.
Note: Do not block the subwoofer port.
Sound bar should be centered below the TV.
Subwoofer
Left surround
speaker
Right surround
speaker

ENG - 14
Proper Placement—Front Surround Mode
In rooms where ideal placement of the surround sound speakers is not practical, you can also place the sound
bar, subwoofer, and surround sound speakers as shown below. Front Surround Mode will utilize DTS Virtual:X to
produce a virtual surround sound experience.
To use this placement, please refer to the Surround Sound mode setting on page 18.
Sound bar should be centered below the TV.
Note: Do not block the subwoofer port.
Subwoofer
Left surround
speaker
Right surround
speaker

ENG - 15
Mode & Level Settings
LED Indicators are located here.
Press each setting button and use the Up/Down buttons to access
the different settings. Each setting will be displayed on the remote
control’s LCD display. The LED indicators will behave differently with
each function.
Function LED Behavior Description
Equalizer Mode Press the EQ button and use the Up/Down buttons to toggle between preset equalizer
settings: Movie, Music, Direct, and Game.
Note: Movie mode is on by default.
Bass Level Two center LEDs
indicate bass level 0.
LEVEL > Bass > Use the Next/Previous buttons to increase/decrease the bass level.
The LED indicators will move to the top with increasing level and to the bottom with
decreasing level.
Treble Level Two center LEDs
indicate treble level 0.
LEVEL > Treble > Use the Next/Previous buttons to increase/decrease the treble level.
The LED indicators will move to the top with increasing level and to the bottom with
decreasing level.
Dialogue Level LED at the bottom
indicates level 0.
LEVEL > Dialogue > Use the Next/Previous buttons to increase/decrease the dialogue
level. The LED indicators will move to the top with increasing level and to the bottom with
decreasing level.
Subwoofer Level Two center LEDs
indicate subwoofer
level 0.
LEVEL > Subwoofer > Use the Next/Previous buttons to increase/decrease the level
of the subwoofer. The LED indicators will move to the top with increasing level and to the
bottom with decreasing level.
Note: Decreasing the level to the minimum turns o the subwoofer.
EQ
Bass
Subwoofer
Treble
Dialogue
Direct
Game Music
Movie

ENG - 16
Mode & Level Settings
Function LED Behavior Description
Surround Level Two center LEDs indicate
surround level 0.
LEVEL > Surr Lvl > Use the Next/Previous buttons to increase/decrease the surround
sound level. The LED indicators will move to the top with increasing level and to the bottom
with decreasing level.
Note: Surround must be ON to adjust the surround level.
Surround Balance Two center LEDs
indicate surround
balance is centered.
LEVEL > Surr Bal > Use the Next/Previous buttons to increase/decrease the surround
balance level on each side. The LED indicators will move to the top with balance levels to the
right and down with balance levels to the left.
Info —SETUP > Info > OK to have the sound bar verbally announce the current sound bar input
and audio type being played with corresponding LED indicators.
Auto VA
SETUP > Auto VA > Use the Next/Previous buttons to toggle between connecting
the sound bar to a Voice Assistant through Bluetooth (BT), AUX, Both, or OFF. Refer to
Connecting to a Voice Assistant on page 23 for more information.
Note: Default setting is Both.
Eco Power Mode
Eco Power Mode
On
SETUP > EcoPwr > Use the Next/Previous buttons to enable/disable Eco Power Mode.
When ON, the sound bar will go into standby after a period of inactivity. The sound bar will
automatically turn o when no audio signal is detected. O disables this feature.
Note: Default setting is O
Eco Power Mode
O
Input Search The LED indicator
color will change
per specic input.
SETUP > Input Search > OK to initiate an automatic input detection sequence. This is the
same as a long key press of the INPUT button on the remote. Specic inputs will show a
dierent LED color:
• AUX In: Green
• AUX VA: Violet
• Digital Optical: Red
• HDMI (ARC): Magenta
• Bluetooth: Blue
• USB: Orange
Surr Lvl
Surr Bal
Info
Auto VA
Eco Pwr
BT
AUX
O
Both
Input Srch
