ENHULK DS175 User manual

20V Blower/Sweeper
DS175
Please Read Carefully Before Use
Original Instruction Manual
SYVIO TECHNOLOGY.CO.LIMITED
ROOM A,8/F,wok Cheung Building,635-637
Shanghai Street,Mong kok,Hong Kong
0086-133-2298-6467
[e-mail]
Made in China

Safety Instruction
Safety Instructions
General Power Tool Safety Warnings
Use personal protective equipment. Always wear
eye protection. Protective equipment such as a
dust mask, nonskid safety shoes, hard hat or
hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personal injury.
Do not overreach. Keep proper footing and balance
at all times. This enables better control of the
power tool in unexpected situations.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust related hazards.
Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can
cause severe injury within a fraction of a second.
Power Tool Use And Care
Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for
which it was designed.
Do not use the power tool if the switch does not
turn it on and o". Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
Disconnect the plug from the power source
and/or remove the battery pack, if detachable,
from the power tool before making any
adjustments, changing accessories, or storing
power tools. Such preventive safety measures
reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the
hands of untrained users.
Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect
the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
tions provided with this power tool. Failure to follow
all instructions listed below may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future
reference. The term "power tool" in the warnings
refers to your mainsoperated (corded) power tool
or battery-operated (cordless) power tool.
Work area safety
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
whichmay ignite the dust or fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
Electrical Safety
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
Avoid body contact with earthed or grounded sur-
faces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock..
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
If operating a power tool in a damp location is un-
avoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal Safety
Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
WARNING Read all safety warnings, instruc-
tions, illustrations and specifica-
EN
1

Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended
could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe
handling and control of the tool in unexpected
situations.
Battery Tool Use And Care
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal
to another.Shorting the battery terminals
together may cause burns or a fire.
Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause
irritation or burns.
Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or
temperature above 130°C may cause explosion.
Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
Service
Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
In case of damage and improper use of the
battery, vapours may be emitted. The battery
can set alight or explode. Ensure the area is
well ventilated and seek medical attention
should you experience any adverse effects. The
vapors may irritate the respiratory system.
Do not open the battery. There is a risk of short
circuiting.
The battery can be damaged by pointed
objects such as nails or screwdrivers or by
force applied externally. An internal short
circuit may occur, causing the battery to burn,
smoke, explode or overheat.
Only use the battery with products from the
manufacturer. This is the only way in which you
can protect the battery against dangerous
overload.
Protect the battery against heat, e.g.
against continuous intense sunlight,
fire, dirt, water and moisture. There is
a risk of explosion and short circuiting.
Safety Instruction
Never service damaged battery packs. Service of
battery packs should only be performed by the
manufacturer or authorized service providers
Safety Instructions For Blower
Do not blow any harmful substances, e.g. beech
or oak wood dust, rock dust or asbestos. These
substances are classified as carcinogenic.
Do not blow any liquids. The penetration of
liquids increases the risk of an electric shock.
Pay attention that bystanders are not injured by
foreign objects that are blown off by the product.
Keep your fingers away from the openings of the
power tool during operation. Only operate the
blower with a nozzle attached. The rotating fan
can injure you.
Ensure that the workplace is well ventilated. Do
not let children use the power tool unsuper- vised.
Children are at risk of injuring themselves this way.
Wear additional personal protective equipment
such as protective glasses and a protective mask.
Wearing personal protection equipment
appropriate to the conditions reduces your
exposure to hazardous substances.
2

Read all warnings and instructions.
Failure to follow the warnings and instructions
can cause electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The charger must not be used for non-recharge-
able, ordinary batteries.
Adequate ventilation is required.
The information on current and voltage on the
battery pack must comply with those of the charger.
Do not expose the charger to water splashes and rain.
Do not throw exhausted or damaged batteries
into water or fire. Environmental guidelines must
be followed.
A defective or not chargeable battery must be
treated as special waste / hazardous waste. Put it
in a special collection point. Do not throw it in the
normal household waste neither into water or fire.
Place the charger far from any heat source.
To reduce the risk of electric shock, pull the plug
instead of the power cord out from the socket, if
you want to disconnect the charger from the mains.
Do not disassemble the charger. Bring it to an
authorized repair service, if service or repair is
required. Improper installation can result in
electrical shock, death and fire.
This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance.
Cleaning and user maintenance shall not be
made by children.
Do not leave the equipment unattended while it
is operating, to avoid the risk of fire, burns and
electric shocks.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
Symbols
Read the operator’s manual
Always use eye/ear protection, Wear
dust mask and safety helmet.
Do not expose to rain
Warning of hazard
Keep bystanders away
Do not dispose of waste batteries as
unsorted municipal waste.
Do not burn
Li-Ion battery This product has been
marked with a symbol relating to
‘separate collection’ for all battery
packs and battery pack. It will then be
recycled or dismantled in order to
reduce the impact on the environment.
Battery packs can be hazardous for
the environment and for human
health since they contain hazardous
substances.
Product Description
And Specifications
Intended Use
The power tool is intended for blowing away
non-harmful substances (e.g. sawing debris,
metal chips, stone dust, etc.) produced during
sawing, drilling or grinding. Drill holes can also
be blown out with the appropriate accessories.
The power tool is not suitable for blowing hot,
flammable or explosive materials.
WARNING
Read all the safety and general
instructions. Failure to observe the
safety and general instructions may
result in electric shock, fire and/or
serious injury.
Please observe the illustrations at the
beginning of this operating manual.
Warning For Charger
3

Technical Data
20V Blower/Sweeper
Article number DS175
Voltage 20VDC
Air speed 110-160MPH
No-load speed 12000-18000RPM
A
B
C
D
Do not continue to push the speed adjust switch
after the tool has been automatically power off.
The lithium-ion battery is protected against
deep discharge by Electronic Cell Protection
(ECP). A protective circuit switches the power
tool off when the battery is drained.
Removing The Battery
The battery is equipped with two locking levels
to prevent the battery from falling out if the
battery release button is pressed unintentio-
nally. As long as the battery is inserted in the
power tool, it is held in position by means of
a Spring.
Assembly
Battery Charging
Use only the chargers listedinthe technical data.
Only these chargers are matched to the lithium
-ion battery of your power tool.
The battery is supplied partially charged. To
ensure full battery capacity, fully charge the
battery in the charger before using your tool
for the first time.
The lithium-ion battery can be charged at any
time without reducing its service life. Interrupt-
ing the charging process does not damage the
battery.
Diagram of the power tool on the graphics page.
Product Description And Specifications
4
(1) Blower Tube
(2) Tube-Release Button
(4) Battery
(5) Handle
(6) Speed adjust switch
(3) Air inlet
Product Features
1
2
3
4
5
6

5
–To remove the battery (4), press the release
button and pull the battery upwards and
out of the power tool. Do not use force to do
this.Follow the instructions on correct disposal.
Fitting the blower accessories.Remove the battery
before cleaning or performing maintenance work
on the power tool, before making tool adjustments,
changing accessories or storing the power tool.
This safety measure prevents the power tool from
being started accidentally.
Cleaning
Operation
Starting Operation
Switching On/Off
After fully-charged the battery pack, carefully fit
it into the blower with a "click". Make sure the bat-
tery pack is tight enough fitted with the blower.
-To switch on the blower/sweeper,Push speed
adjust switch(6) to position 1 for eco blower force.
Push speed adjust switch(6) to position 2 for
powerful blower force.
-To switch off the blower/sweeper, push the
speed adjust switch (6) to position off.
Working Advice
Never blow dirt in the direction of bystanders.
Always hold the power tool approx. 3 cm above
the ground when working.Do not blow hot, flam-
mable or explosive material.
The blower is intended for residential use only.
Use the blower outdoors to move debris from
hard surfaces. This blower is not designed to
clear leaves from large grassy areas, or move
wet, heavy debris.
Before cleaning or performing any maintenance,
remove the battery from the blower/sweeper, use
clean cloths to remove dirty, dust, oil, grease, etc.
Always use only a soft, dry cloth to clean the
plastic parts, never use detergent or alcohol.
Always wear safety googles when cleaning tools
with compressed air.
Cleaning And Maintenance
All maintenance should be carried out by a
qualified person, do not try to repair any defect.
When servicing, use only identical replacement
parts. Use of any other part could create a
hazard or cause product damage.
WARNINGS
Storage
1. Switch the product off and remove the battery
packs.
2.Clean the product and re-pack to original
package.
3.Store the product and its accessories in a dark,
dry, frost-free, well-ventilated place..
4.Always store the product in a place that is
inaccessible to children. The ideal storage
temperature is between 10°C and 30°C.
5.We recommend using the original package for
storage or covering the product with a suitable
cloth or enclosure to protect it against dust.
Transportation
1. Switch the product off and remove the battery
packs.
2.Re-pack to original package.
3.Protect the product from any heavy impact or
strong vibrations which may occur during
transportation in vehicles.
4.Secure the product to prevent it from slipping or
falling over.
Maintenance and transportation

6
Guarantee
Guarantee
Dear Customer,
This equipment is provided with a 2-year guarantee
from the date of purchase. In case of defects, you
have statutory rights against the seller of the
product. These statutory rights are not restricted by
our guarantee presented below. Terms of Guarantee
the term of the guarantee begins on the date of
purchase, please retain the original receipt and it’s
required as proof of purchase. If a material or
manufacturing defect occurs within 2-year of the
date of the purchasing, we will repair or replace the
product for you free of charge. This guarantee
requires the defective equipment and proof of
purchase to be presented within the 2-year period
with a brief written description of what constitutes
the defect and when it occurred. If the defect is
covered by our guarantee, you will receive either the
repaired product or a new product. No new
guarantee period begins on repair or replacement of
the product.
Guarantee Period And Statutory
Claims For Defects
The guarantee period is not extended by the
guarantee service. This also applies for replaced or
repaired parts. Any damages and defects already
present at the time of purchase must be reported
immediately after unpacking.
Troubleshooting
Fault Cause Remedy
Low battery power
The Blower/Sweeper
doesn’t run
Blower/Sweeper stop
suddenly
Bad connect between electrical
connection
Too hot for the machine or battery
pack
Charge the pack
Take out the pack or cigarette
charger and re-fit it
Waiting for a time and let it cool
