ENJOY VS500 Spa Pak User manual

ENJOY
Your QCA Dream Series Spa
VS500 Spa Pak
OWNER’S MANUAL
This owner’s manual is for YOU! It will show you how to operate and maintain your very own spa.
We think it is important for you to take a few moments and get acquainted with your new spa
operation. Please keep this manual available for references.
QCA Spas would like to congratulate you on your purchase and we sincerely hope you enjoy your
QCA Spa.
SERIAL NUMBER _____________
18 DIGIT SPA NUMBER ____________
DreamSeriesManual VS500.501 1.07

.TABLE OF CONTENTS
Cleaning the Filter Cartridge ............................................................................8
Diagnostic Messages .........................................................................................6
Draining the Water ............................................................................................7
Filter Maintenance.............................................................................................8
Hyperthermia Description .................................................................................3
Initial Start Up....................................................................................................5
Installation Instructions .....................................................................................4
115/230v Installations........................................................................................4
Prevention of Freezing.......................................................................................9
Refilling your Spa...............................................................................................7
Removing the Box Filter Cartridge....................................................................8
Spa and Cabinet Maintenance...........................................................................9
Spa Location.......................................................................................................4
Spa Top Side Control .........................................................................................5
Troubleshooting..................................................................................................9
UL Instructions...................................................................................................3
Vacation Care.....................................................................................................8
Warranty Information .................................................................................10-11
Water Care Program.......................................................................................7-8
Winterizing ........................................................................................................9

UL INSTRUCTIONS
The instructions that you are about to read, are required by
Underwriters Laboratories to be published in your manual.
These instructions are very important for your safety and
QCA would like to encourage you to read and apply all
instructions. Thank you.
IMPORTANT SAFETY INSTRUCTIONS
When installing and using this electrical equipment,
remember to always observe safety precautions, including
the following:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. WARNING-RISK OF CHILD DROWNING.
Extreme caution must be exercised to prevent
unauthorized access by children. To avoid accidents,
ensure that children cannot use a spa or hot tub unless
they are supervised at all times.
3. DANGER – To reduce the risk of injury to persons, do
not remove suction fittings.
4. A pressure wire connector is provided on the inside and
outside of the control box within the unit to permit
connection of a minimum No. 8 AWG (8.4mm2) solid
copper bonding conductor between this point and any
metal equipment, metal enclosures of electrical
equipment, metal water pipe, or conduit within 5 feet
(1.5m2) of the unit as needed to comply with local
requirements.
5. (All permanently installed units must have a GFCI)
This appliance must have a neutrally protected ground-
fault circuit-interrupter. Before each use and with the
unit operating, push the test button. The unit should
stop operating and the reset button should appear. Push
the reset button. The unit should now operate
normally. If the interrupter does not perform in this
manner, a ground current is flowing indicating the
possibility of an electric shock. Disconnect the power
until the fault has been identified and corrected.
6. Install spa in location that will provide drainage of
water away from the spa and away from electrical
components.
7. RISK OF ELECTRIC SHOCK. Install at least 5 feet
(1.5m) from all metal surfaces. (A spa may be installed
within 5 feet of metal surfaces if each metal surface is
permanently connected by a minimum No. 8 AWG
(8.4mm2) solid copper conductor attached to the
wire connector on the terminal box that is provided
for this purpose.)
8. DANGER–RISK OF ELECTRICAL SHOCK. Do
not permit any electrical appliance, such as a light,
telephone, radio, or television, within 5 feet (1.5m) of
the spa or hot tub.
9. To reduce the risk of injury:
a. The water in a spa or hot tub should never exceed
104°F (40°C). Water temperatures between 100°F
(38°C) and 104°F (40°C) are considered safe for a
healthy adult. Lower water temperatures are
recommended for extended use (exceeding 10-15
minutes) and for young children.
b. Since excessive water temperatures have a high
potential for causing fetal damage during the early
months of pregnancy. Pregnant or possibly pregnant
women should limit spa or hot tub water temperatures
to 100°F (38°C).
c. Before entering a spa or hot tub, the user should
measure the water temperature with an accurate
thermometer since the tolerance of water temperature-
regulating devices may vary as much as +/-5°F (3°C).
d. The use of alcohol, drugs, or medication before or
during spa or hot tub use may lead to unconsciousness
with the possibility of drowning.
e. Persons suffering from obesity or with a medical
history of heart disease, low or high blood pressure,
circulatory system problems or diabetes should
consult a physician before using a spa or hot tub.
f. Persons using medication should consult a physician
before using a spa or hot tub since some medications
may induce drowsiness while other medications may
affect heart rate, blood pressure, and circulation.
g. The electrical supply for this product must include a
suitably rated switch or circuit breaker to open all
ungrounded supply conductors to comply with section
422-20 of the National Electrical Code, ANSI/NFPA
70-1987. The disconnecting means must be readily
accessible to the tub occupant but installed at least 5
feet (1.5m) from the tub water. For units used in
other than single-family dwellings, a clearly labeled
emergency switch shall be provided as part of the
installation. The switch shall be readily accessible to
the occupants and shall be installed at least 5 feet
(1.52 m) away, adjacent to, and within sight of the
unit.
Just a quick note,
For your own security...Prolonged immersion in water
that is warmer than normal body temperature can result
in a dangerous condition known as HYPERTHERMIA.
The causes, symptoms, and effects of hyperthermia may be
described as follows: Hyperthermia occurs when the
internal temperature of the body reaches a level several
degrees above the normal temperature of 98.6°F. The
symptoms of hyperthermia include dizziness, fainting,
drowsiness, lethargy, and an increase in the internal
temperature of the body. The effects of hyperthermia
include (1) unawareness of impending hazard, (2) failure
to perceive heat, (3) failure to recognize the need to exit
the spa, (4) physical inability to exit the spa, (5) fetal
damage in pregnant women, and (6) unconsciousness
resulting in a danger of drowning. WARNING - the use of
alcohol, drugs, or medication can greatly increase the risk
of fatal hyperthermia in hot tubs and spas., and an
increase in the internal temperature of the body. The
effects of hyperthermia include (1) unawareness of
impending hazard, (2) failure to perceive heat, (3) failure
to recognize the need to exit the spa, (4) physical inability
to exit the spa, (5) fetal damage in pregnant women, and
(6 unconsciousness resulting in a danger of drowning.
WARNING - the use of alcohol, drugs, or medication can
greatly increase the risk of fatal hyperthermia in hot tubs
and spas.) unconsciousness resulting in a danger of
drowning. WARNING - the use of alcohol, drugs, or
medication can greatly increase the risk of fatal
hyperthermia in hot tubs and spas.
SAVE THESE INSTRUCTIONS
3

Spa Location
The selection of a site for the installation of your spa is a
very important decision and should be undertaken keeping
several factors in mind.
1. Always check your local codes before installing your
spa. A clear understanding of buildings, fences, gates,
electrical and plumbing guidelines will be invaluable.
2. Select a location that will compliment your lifestyle
and your home. The spa will become an integral part
of your life and therefore should be placed
advantageously.
3. The position of the spa in relation to surrounding
terrain should be considered. Locating the spa near or
directly under trees not only cuts off the sun thereby
depriving you of natural heat, but also necessitates the
physical removal of leaves and debris. Airborne dirt
and debris may also be carried into the spa by
prevailing winds. In addition, an uncovered spa with
wind blowing across the top will tend to lower water
temperatures; therefore you may wish to shield your
spa from direct winds.
4. You may wish to consider an indoor installation. An
indoor spa located off of a bedroom or family room
can offer relaxing solitude or enjoyable gatherings of
friends or family. Care should be taken in providing
protection from possible water damage due to
splashing spa should be located on a concrete or
ceramic tile floor with a floor drain. High humidity
levels relating to the spa can also be a source for
damage and should be planned for in the construction
stage.
5. Your portable spa with a cabinet has been designed to
be self-supporting. Any further reinforcement or
support is not required when placed upon a sound
foundation. In order to prevent damage to the cabinet
and spa be certain to locate the spa on a solid, level
foundation capable of maintaining the weight of the
spa when filled with water. The center of the spa or
footwell must be supported at the same level as the
lower perimeter of the cabinet. If the center of the spa
is not supported, special precautions must be taken to
achieve that support.
6. A base of poured concrete is best for this type of
installation. You may wish to use an existing patio but
if you wish to construct a new base for your spa, select
a level, flat area. After removing the topsoil, construct
a square frame using four 2x4's. Usually an area ten
foot square will suffice. When the frame has been
leveled, pour a 3 1/2" base of concrete mix into the
frame leveling the mix by stroking across the top with
another 2x4. Finish the top with the cement float.
When the slab has cured remove the 2x4's and
landscape as desired.
Note: It is necessary to provide drainage of the
compartment for the electrical components.
7. Install your spa in a location, which allows easy access
to the equipment bay.
8. Before filling with water, be sure the spa is in its final
position and that hoses, tools, etc. are not under the
spa.
Installation Instructions
Electrical-General
Prior to performing any service to the spa package turn
OFF ALL primary electric power at the main circuit
breaker or disconnect panel. Opening the front cover of
the electrical control box can make all field electrical
connections.
All electrical connections to this spa package must be
accomplished by a qualified electrician in accordance with
the National Electric Code or the Canadian Electric Code
and in accordance with any local electrical codes in effect
at the time of installation.
All connections should be made in accordance with the
wiring tab enclosed in the electrical control box or the
wiring diagrams within this manual.
These spa packages are designed to operate on 60Hz
Alternating Current only, at a voltage of 120 or 240 volts
as required.
Spa packages with a 120-volt rating require a two wire
electrical service, plus ground (line 1, neutral and ground).
Spa packages with a 240-volt rating require a three wire
electrical service, plus ground (line 1, line 2, neutral and
ground). Connections should be made using copper
conductors only. The connecting wire and circuit breakers
or fuses must all be sized to accommodate the total
Ampere load as specified on the equipment module data
label.
A bonding lug has been provided on the equipment
module to allow connection to local ground points. To
reduce the risk of electrical shock, a #8 AWG solid copper
bonding wire should be run from this lug to any metal
ladders, water pipes or other metal within 5 feet of the spa.
Starting the Spa
1. Fill the spa before plugging into the electrical circuit. -
Be sure all valves are open and all union nuts are tight.
2. Check for plumbing leaks.
3. Be sure all suction valves to the equipment pack are open,
with the handles in line with water flow.
4. Set filtering cycles according to control panel
instructions.
PLEASE NOTE: To Overseas owners
50 Hz, 230-volt units should be wired to the national
code in the country of the owner’s residence.
120 volt Installation w/hard-wire
Equipment modules installed for 120 volt operation,
require a two-wire electrical service, plus ground (line 1,
black), (neutral, white) and (ground, green). Refer to
terminal block diagram. Assure that all the procedures on
the conversion pages have been followed.
240 volt Installation
Units to be operated at 240 volts must have all electrical
connections accomplished by a qualified electrician in
accordance with the National Electric Code, the Canadian
Electric Code or other local electrical codes in effect at the
time of installation. Equipment modules installed for 240
volt operation require a three wire electrical service, plus
ground (line 1, line 2, neutral and ground). Refer to
terminal block diagram.
Assure that all the procedures on the conversion pages have
been followed.
CUSTOMER WARNING:
The National Electric code requires a Ground Fault Circuit Interrupter on all spas, the #160A kit GFCI is available through your
QCA Spa Dealer. Alert your electrician that if another GFCI is used it must have Neutral Protection.
4

5
Dream Series Control
YOUR • QCA • SPA • EQUIPMENT
Initial Start Up
When your spa is first powered up, it will go into Priming
Mode, indicated by “Pr”. Priming mode will last for 5
minutes and then the spa will being to heat the spa and
maintain water temperature in the Standard Mode. During
this cycle do not press any buttons as it will cause the
priming mode to start over.
Temperature Control
The start-up temperature is set at 100ºF. The last
measured temperature is constantly displayed on the LCD.
Note that the last measured spa temperature displayed is
current only when the pump has been running for at least
two minutes.
Press the “Temp” button to display the temperature
previously set. This set temperature is flashed on the
display. Pressing the “Temp” button a second time, while
it is still flashing, will cause the set temperature to
increase or decrease depending on what direction was last
chosen. Each press to follow will change the set
temperature in the same directions. If the opposite
direction is desired, release the pad and let the display
revert to the actual water temperature. Press the button to
display the set temperature, and again to make the
temperature change in the desired direction.
Jets
Touch the “Jets” button once to activate the low speed of
the pump and again for the high speed. Press the “Jets”
button again to turn off the pump. If left running, the
pump’s low speed will automatically turn off after four
hours, and the pump’s high speed will automatically turn
off after 15 minutes. The low speed of the pump runs
when the blower is on. It may also activate for at least
two minutes every 30 minutes to detect the spa
temperature and then to heat to the set temperature if
needed, depending upon mode. When the low speed turns
on automatically, it cannot be deactivated from the panel;
however, the high speed may be started.
Light
Press the “Light” button to turn the light on and off. If left
on, the light automatically turns off after four hours.
Preset Filter Cycles
The first filter cycle begins six minutes after the spa is
energized. The second filter cycle begins 12 hours later.
Filter duration is programmable at the Master Control Pad
for 2, 4, 6, 8 hours or for continuous filtration, (indicated
by “FC”). The default filter time is two hours. To
program, press “Temp”, then “Jets.” Press “Temp” to
adjust. Press “Jets” to exit programming.
Freeze Protection
If the temperature sensors detect a drop below 40ºF
within the heater, then the pump (as well as the heater,
if necessary) will automatically activate to provide
freeze protection. The equipment stays on until the
sensors detect that the spa temperature has risen to
within 15ºF of the set temperature. The blower will
purge for 30 seconds at the end of the freeze
condition.
WARNING
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance
with the manufacturer's instruction, may cause interference to radio and television reception. It has been type tested and
found to comply with the limits for a class B computing device in accordance with the specification in subpart J of part 15
of the FCC rules, which are designed to provide reasonable protection against such interference in a residential installation.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
interference, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the
interference by one or more of the following measurers: Reorient the receiving antenna. Relocate the receiver with respect
to the spa. Move the receiver away from the spa. Plug the receiver into a different outlet so that the receiver and spa are on
different circuits. If necessary, the user may find the following booklet prepared by the Federal Communications
Commission helpful: "How to identify and resolve radio-TV interference problems." This booklet is available from the U.S.
Government Printing Office, Washington, DC 20402, Stock No. 004-00000345-4.
