Dimension One Spas Nautilus User manual

Page 1 of 2
Note: 1. Subject to change without notice.
2. Reference DOC-1235 REV A.
Specification, Nautilus
Doc-1480 Rev -A Rev Date: 10/31/05
Nautilus Specifications Dimension One Spas
Sha
p
eS
q
uare
Seatin
g
Ca
p
acit
y
7
Shell Material Ultralife™ / Granitex™ / Gelo
y
®
Dimensions 91½" x 91½" x 36" H /
(
232cm X 232cm x 91.4cm H
)
Corner Radii 16"
(
41 cm
)
Water Ca
p
acit
y
370 Gallons
(
1324 Liters
)
Dr
y
Wei
g
ht 885 lbs
(
401 k
g)
Shi
pp
in
g
Wei
g
ht 885lbs
(
424 k
g)
Full Wei
g
ht 3967 lbs
(
1800 k
g)
Skirt Material
Pol
y
Floor Yes
Water Treatment S
y
stem Ultra Pure™
Plumbin
g
S
y
stems 3
Filters/Covera
g
e 2 / 75 s
q
. ft.
Gate Valves 4
VCR Jet® - Air Ad
j
ustable/Directional 2
VCR Jet® - Rotator 5
VCR Jet® - Dual Rotator 3
VCR Jet® - Multi Port S
p
inner 3
VCR Jet® - Mini Rotator 12
VCR Jet® - Mini Directional 4
VCR Jet® - Euro Directional 4
VCR Jet® - Euro Rotator 0
VCR Jet® - Mini Directional in NFJ 8
T
yp
hoon Jet 1
Ozone Jet 1
Heater Return Jet 1
Pum
p
Returns 4
Diverter Valves 2
Floor Drains 1
Skimmer 8” Weir
D
y
namic Massa
g
e Se
q
uencer w/ control
p
anel No
NeckFlex® Jet Pillows 2
Headrest Pillows 2
Stereo s
y
stem O
p
tional Wireless* * Wireless stereo not available for ex
p
ort
Water Feature O
p
tional*
Water Feature Volume control O
p
tional*
Cu
p
Holders 3
Tactile Thera
py
Foot & hand
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak
(
Continuous
)
HP 4.0
(
2.5
)
H
p
3.6
(
2.0
)
HP
Jet Pum
p
s # of Pum
p
s/S
p
eed Two / Dual Two / sin
g
le
Circulation
p
um
p
11
Fountain
p
um
p
O
p
tional* O
p
tional*
Electrical System Domestic (60Hz) Export (50Hz)
Volta
g
e 240 240
Am
p
era
g
e 50/40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7
,
4.0
,
5.5 kW FastFlo 2.9 kW
Thermostat Electronic Electronic
Li
g
ht 1 with o
p
tional LED Multi color LED
Control S
y
stem MSPA-MP-D12 MSPA-MP-D11-CE
U
pp
er Control Scrollin
g
Messa
g
e Center Scrollin
g
Messa
g
e Center
Auxiliar
y
U
pp
er Control Yes Yes
Pro
g
rammable Yes Yes
Special Features
General
Water System
Domestic Synthetic - Export Wood or Synthetic

Note: Subject to change without notice.
Specification, Nautilus
Doc1480- Rev -A Rev Date: 10/31/05
Nautilus Specifications Dimension One Spas
Nautilus
1. Stereo/subwoofer optional.
2. Engineering specs may differ slightly from brochure.
3. For E-Z lifter installation allow 18” (45.7cm) clearances on the backside of the spa.
4. Alternative cabinets may add significant weight. Ask your dealer for exact details
5. This is the approximate location for drilling a hole if you must bring the power line in through the bottom of the spa.
Be careful not to puncture a plumbing line inside the equipment compartment(drill from the inside compartment out).
Top View of Spa
THE EDGES OF SPA BASE.
SUPPORTED CONSISTENT WITH
ON BOTTOM OF SPA, TO BE
THIS 3 FOOT SQUARE AREA,
91 1/2 in [232 cm]
Shell
See Caution
91 in [231 cm]
Skirt
89 in [225 cm]
Pedestal
Base
23 1/2 in [60 cm]
34 1/2 in [88 cm]
56 1/2 in [143 cm]
67 1/2 in [171 cm]
27 in [67 cm]
Recommended location for
Electrical
Inlet
11 in [28 cm]
Hose Bib/
Water Drain
32 in [81 cm]
3 1/2 in [9 cm] 16 in [41 cm]
75 in [191 cm]
Pedestal Base
Front View of Spa
91 in [231 cm]
Hose Bib/
Water Drain
Door Extends
Under Spa Lip
Vent
Equipment
Compartment
Vent Vent
See Note 5
91 1/2 in [232 cm]
89 in [225 cm]
Control
Spa Lip
35 1/2 in [90 cm]
R16 in [R41 cm]
16 in [41 cm]
16 in [41 cm]
Subwoofer
Architectural Specification
Caution:
Due to manufacturing tolerances there could be some
minor differences between the actual spa and the drawing above.
If site planning is critical to such tolerances, be sure to measure your actual spa.
Page 2 of 2
