ENNOPRO CEBA 158V Instruction sheet

EnnoPro Group Limited Product Model:CEBA158V
1
Address:7th Floor, Huarong Building, Qiaolian East, Bulong Road, Longgang District,Zip Code:
518129 | Shenzhen, Guangdong, China
Tel:[phone] fax:[phone]-812
Web:www.cebabattery.com E-mail: [e-mail]
EnnoPro Group Limited
Ni-MH Batteries for HEV Product Instruction
PRESENTED TO :
MODELNO. : CEBA 158V
DATE :
CUSTOMER CODE :
(Items for Specification Approval)
Prepared By
Yunbo,Wang
Drawn by
Liangliang, Yin
Checked By
Chunming, Jia
Approved By
Shengbiao, Cao
(Items for Customer Approval )
Checked By
Approved By
RoHS

EnnoPro Group Limited Product Model:CEBA158V
2
Address:7th Floor, Huarong Building, Qiaolian East, Bulong Road, Longgang District,Zip Code:
518129 | Shenzhen, Guangdong, China
Tel:[phone] fax:[phone]-812
Web:www.cebabattery.com E-mail: [e-mail]
1.Application Scope
This specification applies to the following model’s rechargeable cylindrical Ni-MH batteries that
EnnoPro Group Limited supplies.
2.Model No. : CEBA 158V
3.Specification Parameter
Item
Specification
Dimension
Length (mm) ×Width (mm) ×Height (mm)
385×41×75
Approximate Weight (kg)
23
Typical Capacity(mAh)
6500
Minimum Capacity (mAh)
6000
Nominal Voltage (V)
158.4
Peak Discharge (30C discharge for 10S)
voltage≥105.6V
Peak Charge (15C charge for 10S)
voltage≤220V
Continuous Discharge (15C discharge for 60S)
voltage ≥118.8V
Specific Power
≥1000W/kg
Specific Energy
≥40Wh/kg
High Temperature Performance ( 55℃1C discharge rate)
≥90%
Low Temperature Performance (-20℃1C discharge rate)
≥85%
Charge Retention Performance (28days charge retention rate)
≥80%
Working Temperature Range
-40℃to +55℃
Cycle Life (C/2 charge, 1C discharge)
≥1000cycles
4.Cautions of Battery Pack Transportation and Storage
4.1 Avoid violent vibration and external force impact, don’t cast, roll, invert, extrude, and stack too high
during handling and transportation of battery pack.
4.2 Protect the battery pack from rain during the transportation, and the ambient temperature is not over
55℃.
4.3 Store the battery pack in a cool and dry place and the temperature range is 5-25℃when you are not
using it.

EnnoPro Group Limited Product Model:CEBA158V
3
Address:7th Floor, Huarong Building, Qiaolian East, Bulong Road, Longgang District,Zip Code:
518129 | Shenzhen, Guangdong, China
Tel:[phone] fax:[phone]-812
Web:www.cebabattery.com E-mail: [e-mail]
5.maintenance regulations
The SOC of our battery pack is 60%~80% when leaving the factory, in long-term storage, battery should
be stored in a charged state (usually the SOC is 80%). Have a charge and discharge maintenance to
battery pack when the storage time is over 6 months or battery module’s voltage is 15V,to prevent the
battery performance’s decline caused by the self-discharge. The maintenance regulations are as follows:
（1）Discharge: 2A discharge to 132V (that is to say: single cell 1.0V)
（2）Interval: 30 minutes
（3）Charge: 1.3A charge for 5 hours (voltage≥198V, -ΔV≥0.2V and temperature ≥50℃)
（4）Interval: 1hours
（5）Discharge: 2A discharge to 132V (that is to say: single cell 1.0V)
（6）Interval: 30 minutes
（7）Charge: 2A charge for 2.4 hours
6.Installation Cautions of battery pack
Notes: Installing this product should only be attempted by a qualified technician, the voltage of the
battery pack is very high, which has the shock hazards, so when installing the battery pack, you should
wear insulating gloves and use insulated handle tools.
6.1 Please operate according to assembly manual during the installation of Prius battery pack.
6.2 Do not mix our battery modules with those of other manufacturers, or new battery modules in use
with semi-used battery modules, and don’t mix battery modules within a battery pack with those in other
battery pack.
6.3 Don’t twist and bend battery modules and accessories when assembling battery pack.
6.4 Don’t connect the anode and cathode of battery module in reverse when assembling battery pack,
to prevent short circuits.
6.5 Fasten bolts and nuts with appropriate torque, avoid loose connection or damaging other accessories
with too big torque.
7. Use Cautions of battery pack
7.1 Ensure the normal operation of car management system during the use process, and forbid over-
charge and over-discharge to battery.
7.2 As storage battery is charged by gasoline engine, so external power supply charge is not needed.
However, if the vehicle parks for a long time, the electricity of high power storage battery will run out.
Therefore, be sure to drive the car for at least 30minutes or 16Km every several months.
7.3 If there is leaked liquid, don’t touch the spilled liquid, because this may be the alkaline electrolyte
that hybrid battery leaks. If skin and eyes contact to this liquid, please flush with plenty of water at once,
or if possible, wash with boric acid solution and see the doctor at once.

EnnoPro Group Limited Product Model:CEBA158V
4
Address:7th Floor, Huarong Building, Qiaolian East, Bulong Road, Longgang District,Zip Code:
518129 | Shenzhen, Guangdong, China
Tel:[phone] fax:[phone]-812
Web:www.cebabattery.com E-mail: [e-mail]
8.Quality warranty
8.1 The battery is guaranteed for 12 months.
8.2 The battery is not within the warranty range in the following situation:
a.The battery damage caused by failing to in accordance with the provisions of the transport, storage,
installation and using.
b.The battery damage caused by an external force (such as traffic accidents, natural disasters ) or by
external short circuit during using process.
c.The battery damage caused by the out of control of BMS.
9. Appendix
EnnoPro Group Limited has the right to change and revise Product specification without any advance
notice.
