EOD MEDI EORG User manual

1
INSTRUCTIONS FOR USE OF EOD MEDI EORG™
GENERATOR
Overview
Congratulations on acquiring your new EORG™ (Electronic Oxygen Radical Generator).
The user manual is part of your purchase and is only applicable to EOD MEDI device.
Within this document are important instructions for safety, use of equipment and end of life
disposal. Before using the product for the first time, please fully and carefully read this user
manual. Use of the product in ways other than stipulated here may void your warranty.
Store this document in a safe place, should you need to refer to it later.
Appropriate use
This device is intended for water enrichment with Reactive Oxygen Species (ROS). The
device use with water use only! Do not use with any liquids or additives! Trace amounts of
gaseous Oxygen radicals may be released into the area when the machine is in operation.
While these are not harmful, it is recommended for the machine to be used in a well-
ventilated area. EOD Europe accepts no liability of any damage to materials or persons due
to improper use of the equipment.
Continuous product development and improvement is at the heart of EOD Europe’s ethos
and it is important you ensure the user manual revision is relevant to the device you are
using.
Contents of your order:
1-of EOD MEDI EORG™ Generator + a power cord
1-of Power supply
1-of in-line dip switch
1-of power cord whit plug
1-of user manual (this document)
Technical information:
Power Supply p/n VY-12010000
Rated Voltage (input) 100-240 V AC 50/60 Hz
Rated Current (input) 2.5 A
Rated Voltage (output) 12 V DC
Rated Current (output) 10 A
Safety Protection class I
Dimensions about 15,5 cm (W) x diameter 8 cm
Weight 660 g
Power cord length about 400 cm
Submerged power cord about 170 cm
EOD Europe reserves all rights to technical modifications, improvements, and document
revisions.

2
Safety instructions
Related to warnings
The following warnings are used in this manual as required:
DANGER! High risk: ignoring can lead to the danger of an accident. Failure to comply
may lead to injury or loss of life.
WARNING! Average risk: ignoring a warning can result in injuries or serious material
damage.
General safety instructions
While the operation of the machine does not require a special training, the device is not to
be used by children or vulnerable people without supervision.
WARNING! Any alterations or tampering to the device is not permitted. All service and
refurbishing procedures are to be carried out by qualified technicians or approved service
centers. For all technical support issues, contact the manufacturer or the place of purchase.
DANGER to the children! Packaging material can potentially become a choke hazard, if
misused. Plastic bags can cause asphyxiation.
DANGER to domestic animals:
•Electrical equipment may pose a risk to domestic and commercial animals. In
addition, animals may damage the device. Care must be taken to keep the device
and associated cabling away from animals.
DANGER of electrocution! Do not touch EORG unit when switched on.
DANGER of electrocution:
•The current transformer or switch must not come into contact with water or other
liquids.
•Do not use the device if there is visible damage to the device, current transformer, or
associated switch and cabling.
•You must not replace the power cord on this device. In case of cord damage, the
device must be reported faulty and returned to the manufacturer for repairs.
•Only use a socket outlet with an appropriate supply voltage as identified on the
device.
•Take care to protect cabling against mechanical damage, heat and corrosive
materials
•When removing the current transformer from the power supply, never pull the cable,
but the transformer.
•When an extension cord is used, it must comply with the relevant safety
requirements and regulations.
•Remove the current transformer from the power supply:
•in case of a disturbance,
•when the device is not in use
•before cleaning or servicing

3
•During electrical storms
DANGER of explosion
•Due to the nature of the device, the process generates gaseous components into the
container, which may lead to a pressure build up.
•Only use the EORG device in well ventilated areas and never expose the process to
a source of ignition.
WARNING! Natural rubber components may decompose or dry after prolonged
exposure to ozone water. Some easily oxidized metals and metal alloys can oxidize in long
term use. Examples are copper, brass and zinc plating.
DANGER of infection
•The EOD MEDI device has been designed to be used in clear water. Cloudy water
indicates a high level of contamination. While the EOD MEDI EORG generator is a
very effective water purification system, it alone may not be enough to guarantee
safe drinking water, depending on the contaminants / contamination levels of the
water treated.
•The potential for infection is ambiguous and use of a EORG generator system does
not guarantee absence of contagious diseases.
•Never attempt to use the device on sea water or anything other than water.
DANGER of water quality standards and recommendations for drinking water:
•Please note that when using non-resident safe water as domestic water, different
chemical quality standards and recommendations have been set for domestic water,
which may not be exceeded when water is used for household use.
DANGER of carcinogenic compounds:
•After enriching the water supply with EORG it should be tested to ensure levels of
Bromide and Bromate remain within the tolerances set by the local regulation and
safety guidelines. High amount of bromate is suspected to be carcinogenic and is
formed if bromide-containing water is exposed to aqueous ozone.
DANGER seawater! Do not ozonate seawater.
Emergency and first aid instructions
If strongly ROS enriched water gets into direct contact with eye(s), rinse the eye(s) with
clean water (Not water activated by ROS generator).
Prolonged inhalation of ozone evaporating from water can lead to slight irritation of the
airways. If symptoms occur, remove the person from exposure to fresh air. If symptoms
persist, seek medical attention.

4
Use
Applications
The EOD MEDI EORG™ generator is designed to ozonize water to be both an effective
cleaning agent and disinfectant while remaining safe to drink.
Introduction
•Remove all packaging materials from the device.
•Carefully inspect the unit for signs of mechanical damage.
•Fully unwind the power lead (ensure the switch is in the off-position) and connect
securely into a suitably rated domestic power supply.
•Make sure the dip switch is in O (off)-position.
Before first use, clean the protective coating from the EOD MEDI EORG™ generator
•Fill a container large enough for the EOD MEDI device to be fully submerged in with
clear tap water.
•Fully immerse the EOD MEDI unit in the water.
•NEVER introduce the switch or the current transformer to water, this will cause your
device to go faulty and will be considered misuse of the equipment and is not
covered by the warranty.
•Ensure the wall socket is switched on (where applicable) and switch on the EOD
MEDI device using the dip switch provided.
•Let the device run for ten (10) minutes for all the protective coating from the
electrodes to be dissolved.
•Turn off the EOD MEDI device, give it a swirl in the container and then remove it
from the water.
•Dispose of the water treated after the first run with the machine. Residual protective
coating might be present in the water.
•After this, your EOD MEDI unit will be ready for use.
Ozonation of water (container volume of five liter is assumed and times vary
depending on the size of the container used)
•Follow the steps above
•If you make a cleanser or disinfectant, let the EOD MEDI unit run for 5 minutes.
•If you disinfect drinking water, let the EOD MEDI unit run for 1 minutes and wait 5
minutes before use.
•Turn off the device by turning the dip switch into off-position.
•Remove the current transformer from the wall socket and remove EOD MEDI from
the water. Place EOD MEDI onto a dry towel or similar, to dry off.
•If the water is prepared for it to be used as decontaminant or disinfectant, use the
water as soon as possible (allowing all the microbubbles, or milkiness, to dissolve
into the water after the device is switched off), but within at least 20 minutes after
preparation.
•A simple way to determine if the treated water is still active is to smell if any odor of
ozone (think of the smell after a lightning strike or the smell near a large copying

5
machine) can be detected. While the machine produces a range of different oxygen
radicals into the water, ozone is the one easiest to detect. Ozone will start to decay
back into oxygen immediately after the device is turned off. In 20 °C degree water,
the half-life of ozone is 20 minutes.
•If the water is being treated for it to be used as drinking water, wait until the ozone
has completely disappeared from the water. This takes anywhere from five minutes
to one hour depending on water temperature, iron content and other factors. Water
can be consumed as soon as the smell of Ozone cannot be detected..
Comments
•The EOD MEDI EORG generator works best in cold or cool water (less than 20 °C).
•The EOD MEDI forms ROS and aqueous ozone. Generator does not work in water
with very low electrical conductivity. Therefore, the device should not be used with
e.g. ion exchanged battery water or water purified by reverse osmosis.
•With the EOD MEDI it is not possible to “over ozonize” the water, but it is possible
that the ozonizing does not reach the desired level for the intended purpose. If this
happens, repeat the treatment of water with the EOD MEDI generator.
•Correct operation of the device can be visibly observed as soon as the device is
switched on whilst submerged in clear water. Stream(s) of micro bubbles will start to
rise from the electrolysis plates.
•The water is quickly filled with micro bubbles. When the device is turned off, the
micro bubbles immediately begin to dissolve into the water. The water is ready for
disinfection once most of the micro bubbles have dissolved (i.e. the water resumes a
clear appearance)
Examples and notes
•For the preparation of sufficiently concentrated disinfectant in a water volume of
twenty (20) liters (at 20 °C room temperature), let the device run un-interrupted for
twenty (20) minutes. In a water volume of forty (40) liters, the corresponding
operation time required is forty (40) minutes.
•Continuous use of the EOD MEDI generator for longer than one hour (60 minutes) is
not recommended. In between uses, allow the EOD MEDI generator as well as the
current transformer time to cool down at least 10 minutes before re-use.
NOTE: In highly conductive waters (high TDS value) the device might become
noticeably warm
NOTE: In waters with low electrical conductivity (low TDS value) the reaction might
not start. By adding a trace amount of mineral water into the mix, the reaction should
start.
NOTE: Never add any chemicals or other additives (apart from mineral water) into the
water being treated. This may result into unpredicted chemical compounds
becoming airborne and EOD Europe accepts no liability of any harm to materials or
persons due to this.

6
Storage of the device
When not in use, the device must be kept in a clean and dry area or container. The
apparatus must not be exposed to temperatures outside +60 °C and -20 °C. Allow the
device to entirely dry out before stowing it away.
Maintenance of electrodes
Water typically contains a variety of minerals such as calcium carbonate. These minerals
accumulate slowly onto the surfaces of the electrodes. Accumulation of the calcium may
slow down the electrolysis process. When the micro bubble formation appears weak, clean
the electrodes as identified below
1. Make a mixture of untreated tap water and 10 % white vinegar with one to five ratio,
or alternatively ten parts water and one part of citric acid.
2. Immerse the EOD MEDI generator fully into this mixture for 1 hours (60 minutes). It
is recommended to have the device fully disconnected from the electrical supply as
running the device in the mixture is strictly prohibited.
3. Rinse the device thoroughly with tap water and resume normal operation. After the
decalcify procedure, normal micro bubble formation should resume. If it does not, the
device might be worn out.
Life of the device
The service life of the EOD MEDI generator is approximately 2,000 hours of operation
(which is approximately 24,000 five-minute cycles), during which the power decreases by
about 50 %.
Disposal of parts
Subject to European Directive 2012/19/EU. A deleted waste container is a symbol
used in all EU countries, which means that the product in question does not
belong to the household waste category but must be disposed of separately. The
instructions apply both to the product itself and to accessories bearing the same
symbol. Products thus marked must not be placed in household waste but must
be taken to the electronic and electronic waste collection point.

7
Warranty
Warranty information
This device has a warranty of 12 months from the date of purchase. In the event of defects
in the equipment, the buyer’s legal rights are valid. The following guarantee conditions do
not limit these legal rights.
Warranty conditions
The warranty starts on the date of purchase. If there is a material or manufacturing defect in
the product within one month of the date of purchase, replacement unit or repair of the unit
will be carried out at no extra cost.
Warranty period and legal notifications of deficiencies
The warranty period cannot be extended. Any defects existing at the time of purchase must
be reported immediately to the manufacturer or the sales agent. After the expiry of the
warranty period, repairs and refurbishments are subject to a fee.
Coverage of the guarantee
The device has been carefully manufactured according to strict quality instructions and has
been inspected before its delivery. The manufacturer’s warranty covers material and
manufacturing defects. The warranty does not apply to the product components which are
exposed to normal wear and are thus considered to be consumable parts. The warranty is
invalidated if the product is damaged, used or maintained inappropriately. The proper use
of the product requires all the instructions contained in the instructions to be followed. Use
for purposes not complying with the instructions and not complying with warnings strictly
prohibited. Incorrect or inappropriate use, use of force, repairs made by non-authorized
maintenance services or other tampering with the device invalidates the warranty.
Repair or replacement of the product does not re-validate the original warranty period.
This warranty does not apply to the normal wear of the electrodes and the wear
components that are subject to normal wear and no damage to broken parts, e.g. the
dip switch.
Guarantee for case handling
•Follow the following instructions to ensure that your case is handled quickly:
•Read the documentation that comes with the product carefully before the product is
taken into service. In case of problems that are not resolved by following instructions,
please contact us via email to our customer service [email protected].
•Return of a product considered defective is free of charge to the sales agent you
purchased the device from. Include a written explanation of the defect complete with
the time and date when the defect occurred.

8
Contact:
Charlot OÜ
Helgi tee 1, Peetri küla, 75312 Harjumaa, Eesti
e-mail: [email protected]
https://eod.charlot.ee
*** EOD EUROPE APPRECIATES YOUR CUSTOM ***
Rev. 2.1.2 15.03.2021
