EOD MINI EORG User manual

1
INSTRUCTIONS FOR USE OF EOD MINI EORG GENERATOR
Overview
Congratulations on acquiring your new EORG (Electronic Oxygen Radical Generator).
The user manual is part of your purchase and is only applica le to EOD MINI device. Within this document
are important instructions for safety, use of equipment and end of life disposal. Before using the product for
the first time, please fully and carefully read this user manual. Use of the product in ways other than
stipulated here may void your warranty. Store this document in a safe place, should you need to refer to it
later.
Appropriate use
This device is intended for water enrichment with Reactive Oxygen Species (ROS). The device must not e
used with any liquids other than water, more so water without any additives. Trace amounts of gaseous
Oxygen radicals may e released into the area when the machine is in operation. While these are not
harmful, it is recommended for the machine to e used in a well-ventilated area. EOD Europe accepts no
lia ility of any damage to materials or persons due to improper use of the equipment.
Continuous product development and improvement is at the heart of EOD Europe’s ethos and it is important
you ensure the user manual revision is relevant to the device you are using.
Contents of your order:
1-off EOD MINI EORG Generator complete with a power cord
1-off Power supply
1-off in-line dip switch
1-off user manual (this document)
Te hni al information:
Power Supply p/n VY-12001500
Rated Voltage (input) 100-240 VAC 50/60 Hz
Rated Current (input) 1.5A
Rated Voltage (output) 12VDC
Rated Current (output) 1.5 A
Safety Protection class II
Dimensions 66mm (W) x 60mm (D) x 45mm (H)
Weight 90g
Power cord length 1300mm
EOD Europe reserves all rights to technical modifications, improvements, and document revisions.

2
Safety instru tions
Related to warnings
The following warnings are used in this manual as required:
 DANGER! High risk: ignoring can lead to the danger of an accident. Failure to comply may lead to injury or
loss of life.
 WARNING! Average risk: ignoring a warning can result in injuries or serious material damage. / Failure to
heed the warning could result in injury or serious damage to property
General safety instru tions
While the operation of the machine does not require a competent person, the device is not to e used y
children/vulnera le people without supervision.
 WARNING! Any alterations or tampering to the device is not permitted. All service and refur ishing
procedures are to e carried out only y qualified technicians or approved service centers. For all technical
support issues, contact the manufacturer or the place of purchase.
 DANGER to the children! Packaging material can potentially ecome a choke hazard, if misused. Plastic
ags can cause asphyxiation.
 DANGER to domestic animals:
Electrical equipment may pose a risk to domestic and commercial animals. In addition, animals may
damage the device. Care must e taken to keep the device and associated ca ling away from
animals.
DANGER of electrocution:
The current transformer or switch must not come into contact with water or other liquids.
Do not use the device if there is visi le damage to the device, current transformer, or associated
switch and ca ling.
You must not replace the power cord on this device. In case of cord damage, the device must e
reported faulty and returned to the manufacturer for repairs.
Only use a socket outlet with an appropriate supply voltage as identified on the device.
Take care to protect ca ling against mechanical damage, heat and corrosive materials
When removing the current transformer from the power supply, never pull the ca le, ut the
transformer.
When an extension cord is used, it must comply with the relevant safety requirements and
regulations.
Remove the current transformer from the power supply:
in case of a distur ance,
when the device is not in use
efore cleaning or servicing
During electrical storms

3
 DANGER of explosion
Due to the nature of the device, the process generates gaseous components into the container,
which may lead to a pressure uild up.
Only use the EORG device in well ventilated areas and never expose the process to a source of
ignition.
 WARNING! Natural ru er components may decompose or dry after prolonged exposure to ozone water.
Some easily oxidized metals and metal alloys can oxidize in long term use. Examples are copper, rass and
zinc plating.
 DANGER of infection
The EOD MINI device has een designed to e used in clear water. Cloudy water indicates a high
level of contamination. While the EOD MINI EORG generator is a very effective water purification
system, it alone may not e enough to guarantee safe drinking water, depending on the
contaminants/contamination levels of the water treated.
The potential for infection is am iguous and use of a EORG generator system does not guarantee
a sence of contagious diseases.
Never attempt to use the device on sea water or anything other than water.
 DANGER of water quality standards and recommendations for drinking water:
Please note that when using non-resident safe water as domestic water, different chemical quality
standards and recommendations have een set for domestic water, which may not e exceeded
when water is used for household use.
 DANGER of carcinogenic compounds:
After enriching the water supply with EORG it should e tested to ensure levels of Bromide and
Bromate remain within the tolerances set y the local regulation and safety guidelines. Bromate is
suspected to e carcinogenic and is formed if romide-containing water is exposed to aqueous
Ozone.
Emergen y and first aid instru tions
If strongly ROS enriched water gets into direct contact with eye(s), rinse the eye(s) with clean water (Not
water activated y ROS generator).
Prolonged inhalation of ozone evaporating from water can lead to slight irritation of the airways. If
symptoms occur, remove the person from exposure to fresh air. If symptoms persist, seek medical attention.

4
Use
Appli ations
The EOD MINI EORG Generator is designed to enrich water to e oth an effective cleaning agent and
disinfectant while remaining safe to drink.
Introdu tion
Remove all packaging materials from the device.
Carefully inspect the unit for signs of mechanical damage
Fully unwind the power lead (ensure the switch is in the OFF-position) and connect securely into
a suita ly rated domestic power supply.
Make sure the dip switch is in OFF-position.
Before first use, lean the prote tive oating from the EOD MINI EORG generator
Fill a container large enough for the EOD MINI Device to e fully su merged in with clear tap water.
Fully Immerse the EOD MINI unit in the water.
NEVER introduce the switch or the current transformer to water, this will cause your device to go
faulty and will e considered misuse of the equipment and not covered y the warranty.
Ensure the wall socket is switched on (where applica le) and switch on the EOD MINI device using
the dip switch provided.
Let the device run for ten (10) minutes for all the protective oil from the electrodes to e dissolved
Turn off the EOD MINI device, give it a swirl in the container and then remove it from the water.
Dispose of the water treated after the first run with the machine. Residual oil might e present in
the water.
After this, your EOD MINI unit will e ready for use.
Enri hing of water ( ontainer volume of one liter is assumed and times very depending on the size of the
ontainer used)
Follow the steps a ove
If you make a cleanser or disinfectant, let the EOD MINI unit run for 5 minutes.
If you disinfect drinking water, let the EOD MINI unit run for 1 minutes and wait 5 minutes efore
use.
Turn off the device y turning the dip switch into OFF-position.
Remove the current transformer from the wall socket and remove EOD MINI from the water. Place
EOD MINI onto a dry towel or similar, to dry off.
If the water is prepared for it to e used as decontaminant or disinfectant, use the water as soon as
possi le (allowing all the micro u les, or milkiness, to dissolve into the water after the device is
switched off), ut within at least 20 minutes after preparation.
A simple way to determine if the treated water is still active is to smell if any odor of ozone (think of
the smell after a lightning strike or the smell near a large copying machine) can e detected. While
the machine produces a range of different oxygen radicals into the water, Ozone is the one easiest
to detect. Ozone will start to decay ack into Oxygen immediately after the device is turned off. In
20oC degree water, the half-life of ozone is 20 minutes.

5
If the water is eing treated for it to e used as drinking water, wait until the ozone has completely
disappeared from the water. This takes anywhere from five minutes to one hour depending on
water temperature, iron content and other factors. Water can e consumed as soon as the smell of
Ozone cannot e detected any more.
Comments
The EOD MINI EORG Generator works est in cold or cool water (less than 20°C).
The EOD MINI forms ROS and aqueous ozone. Generator does not work in water with very low
electrical conductivity. Therefore, the device should not e used with e.g. ion exchanged attery
water or water purified y reverse osmosis.
With the EOD MINI it is not possi le to “over enrich” the water, ut it is possi le that the enriching
does not reach the desired level for the intended purpose. If this happens, repeat the treatment of
water with the EOD MINI Generator.
Correct operation of the device can e visi ly o served as soon as the device is switched on whilst
su merged in clear water. Stream(s) of micro u les with a milky appearance will start to rise from
the electrolysis plates.
The water is quickly filled with micro u les, ecoming milky in appearance. When the device is
turned off, the micro u les immediately egin to dissolve into the water. The water is ready for
disinfection once most of the micro u les have dissolved (i.e. the water resumes a clear
appearance)
Examples and notes
For the preparation of sufficiently concentrated disinfectant in a water volume of five (5) liters (at
20oC room temperature), let the device run un-interrupted for twenty (20) minutes. In a water
volume of ten (10) liters, the corresponding operation time required is forty (40) minutes.
Continuous use of the EOD MINI ROS generator for longer than one hour (60 minutes) is not
recommended. In etween uses, allow the EOD MINI ROS generator as well as the current
transformer time to cool down, should they have ecome warm during the process.
NOTE: In Highly ondu tive waters (high TDS value) the devi e might be ome noti eably warm
NOTE: In waters with low ele tri al ondu tivity (low TDS value) the rea tion might not start. By adding a
tra e amount of mineral water into the mix, the rea tion should start.
NOTE: Never add any hemi als or other additives (apart from mineral water) into the water being
treated. This may result into unpredi ted hemi al ompounds be oming airborne and EOD Europe
a epts no liability of any harm to materials or persons due to this.
Storage of the devi e
When not in use, the device must e kept in a clean, dry, area or container. The apparatus must not e
exposed to temperatures outside + 60 °C and -20 °C. Allow the device to entirely dry out efore stowing it
away.
Maintenan e of ele trodes
Water typically contains a variety of minerals such as calcium car onate. These minerals accumulate slowly
onto the surfaces of the electrodes. Accumulation of the calcium may there y slow down the electrolysis
process. When the micro u le formation appears weak, clean the electrodes as identified elow

6
1. Make a mixture of untreated tap water and 10% white vinegar with one to five ratio, or alternatively
ten parts water and one part of citric acid.
2. Immerse the EOD MINI Generator fully into this mixture for 1 hours (60 minutes). It is recommended
to have the device fully disconnected from the electrical supply as running the device in the mixture
is strictly prohi ited.
3. Rinse the device thoroughly with tap water and resume normal operation. After the de-calcifying
procedure, normal micro u le formation should resume. If it does not, the device might e in
need or refur ishment or has ecome faulty. In either case, contact the manufacturer or the place of
purchase for technical support.
Life of the devi e
The service life of the EOD MINI ROS Generator is approximately 2,000 hours of operation, which is
approximately 24,000 five-minute cycles.
Disposal of parts
su ject to European Directive 2012/19/EU. A deleted waste container is a sym ol used in all EU
countries, which means that the product in question does not elong to the household waste
category ut must e disposed of separately. The instructions apply oth to the product itself and
to accessories earing the same sym ol. Products thus marked must not e placed in household
waste ut must e taken to the electronic and electronic waste collection point.

7
Warranty
Warranty information
This device has a warranty of 12 months from the date of purchase. In the event of defects in the
equipment, the uyer’s legal rights are valid. The following guarantee conditions do not limit these legal
rights.
Warranty onditions
The warranty starts on the date of purchase. If there is a material or manufacturing defect in the product
within one month of the date of purchase, replacement unit or repair of the unit will e carried out at no
extra cost.
Warranty period and legal notifi ations of defi ien ies
The warranty period cannot e extended. Any defects existing at the time of purchase must e reported
immediately to the manufacturer or the sales agent. After the expiry of the warranty period, repairs and
refur ishments are su ject to a fee.
Coverage of the guarantee
The device has een carefully manufactured according to strict quality instructions and has een inspected
efore its delivery. The manufacturer’s warranty covers material and manufacturing defects. The warranty
does not apply to the product components which are exposed to normal wear and are thus considered to e
consuma le parts. The warranty is invalidated if the product is damaged, used or maintained
inappropriately. The proper use of the product requires all the instructions contained in the instructions to
e followed. Use for purposes not complying with the instructions and not complying with warnings strictly
prohi ited. Incorrect or inappropriate use, use of force, repairs made y non-authorized maintenance
services or other tampering with the device invalidates the warranty.
Repair or replacement of the product does not re-validate the original warranty period.
This warranty does not apply to the normal wear of the ele trodes and the wear omponents that are
subje t to normal wear and no damage to broken parts, e.g. the dip swit h.
Guarantee for ase handling
Follow the following instructions to ensure that your case is handled quickly:
Read the documentation that comes with the product carefully efore the product is taken into
service. In case of pro lems that are not resolved y following instructions, please contact us via
email to our customer service [e-mail].
Return of a product considered defective is free of charge to the sales agent you purchased the
device from. Include a written explanation of the defect complete with the time and date when the
defect occurred.
Contact:
Charlot OÜ
Helgi tee 1, Peetri küla, 75312 Harjumaa, Eesti
e-mail: [email protected]
https://eod. harlot.ee
