PXIe-5655 Safety,
Environmental, and
Regulatory Information
PXIe, 7.2 GHz PXI RF
Analog Signal Generator

Safety, Environmental, and
Regulatory Information
Read this document before you install, configure, operate, or
maintain this product. Users are required to familiarize
themselves with installation and wiring instructions in
addition to requirements of all applicable codes, laws, and
standards. Visit ni.com/manuals for more information about
your product, including specifications, pinouts, and
instructions for connecting, installing, and configuring your
system.
Icons
Notice —Take precautions to avoid data loss, loss of
signal integrity, degradation of performance, or damage to
the product.
Caution — Take precautions to avoid injury. Consult the
product documentation for cautionary statements when you
see this icon printed on the product. Cautionary statements
are localized into French for compliance with Canadian
requirements.
PXIe-5655 Safety, Environmental, and Regulatory Information
2 ni.com

Caution: Possibility of Electric Shock —Take
precautions to avoid electrical shock.
ESD Sensitive —Take precautions to avoid damaging the
product with electrostatic discharge.
Safety Guidelines
CAUTION
Observe all instructions and cautions in the user
documentation. Using the product in a manner
not specified can damage the product and
compromise the built-in safety protection.
ATTENTION
Suivez toutes les instructions et respectez toutes
les mises en garde de la documentation
d'utilisation. L'utilisation du produit de toute
autre façon que celle spécifiée risque de
l'endommager et de compromettre la protection
de sécurité intégrée.
Safety Voltages
Connect only voltages that are below these limits.
Absolute maximum input power (LO 0/1 IN) +17 dBm
PXIe-5655 Safety, Environmental, and Regulatory Information
© National Instruments Corporation 3

Absolute maximum reverse power
(LO 0/1 OUT) +18 dBm
Maximum input voltage (REF IN) 3.3 V pk-pk
Measurement Category CAT I/O
PXIe-5655 Safety, Environmental, and Regulatory Information
4 ni.com

Measurement Category
WARNING
Do not connect the product to signals or use for
measurements within Measurement Categories II,
III, or IV, or for measurements on MAINs circuits or
on circuits derived from Overvoltage Category II,
III, or IV which may have transient overvoltages
above what the product can withstand. The
product must not be connected to circuits that
have a maximum voltage above the continuous
working voltage, relative to earth or to other
channels, or this could damage and defeat the
insulation. The product can only withstand
transients up to the transient overvoltage rating
without breakdown or damage to the insulation.
An analysis of the working voltages, loop
impedances, temporary overvoltages, and
transient overvoltages in the system must be
conducted prior to making measurements.
MISE EN GARDE
Ne pas connecter le produit à des signaux dans
les catégories de mesure II, III ou IV et ne pas
l'utiliser pour des mesures dans ces catégories, ou
des mesures sur secteur ou sur des circuits
dérivés de surtensions de catégorie II, III ou IV
pouvant présenter des surtensions transitoires
supérieures à ce que le produit peut supporter. Le
produit ne doit pas être raccordé à des circuits
ayant une tension maximale supérieure à la
tension de fonctionnement continu, par rapport à
la terre ou à d'autres voies, sous peine
d'endommager et de compromettre l'isolation. Le
produit peut tomber en panne et son isolation
risque d'être endommagée si les tensions
PXIe-5655 Safety, Environmental, and Regulatory Information
© National Instruments Corporation 5

transitoires dépassent la surtension transitoire
nominale. Une analyse des tensions de
fonctionnement, des impédances de boucle, des
surtensions temporaires et des surtensions
transitoires dans le système doit être eectuée
avant de procéder à des mesures.
Measurement Category I is for measurements performed on
circuits not directly connected to the electrical distribution
system referred to as MAINS voltage. MAINS is a hazardous live
electrical supply system that powers equipment. This
category is for measurements of voltages from specially
protected secondary circuits. Such voltage measurements
include signal levels, special equipment, limited-energy parts
of equipment, circuits powered by regulated low-voltage
sources, and electronics.
NOTE
Measurement Categories CAT I and CAT O are
equivalent. These test and measurement circuits
are for other circuits not intended for direct
connection to the MAINS building installations of
Measurement Categories CAT II, CAT III, or CAT IV.
Safety Compliance Standards
This product is designed to meet the requirements of the
following electrical equipment safety standards for
measurement, control, and laboratory use:
•IEC 61010-1, EN 61010-1
•UL 61010-1, CSA C22.2 No. 61010-1
NOTE
For safety certifications, refer to the product label
or the Product Certifications and Declarations
section.
PXIe-5655 Safety, Environmental, and Regulatory Information
6 ni.com

EMC Guidelines
This product was tested and complies with the regulatory
requirements and limits for electromagnetic compatibility
(EMC) as stated in the product specifications. These
requirements and limits are designed to provide reasonable
protection against harmful interference when the product is
operated in its intended operational electromagnetic
environment.
This product is intended for use in commercial and light-
industrial locations. However, harmful interference may occur
in some installations, when the product is connected to a
peripheral device or test object, or if the product is used in
residential areas. To minimize interference with radio and
television reception and prevent unacceptable performance
degradation, install and use this product in strict accordance
with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not
expressly approved by NI could void your authority to operate
it under your local regulatory rules.
PXIe-5655 Safety, Environmental, and Regulatory Information
© National Instruments Corporation 7

EMC Notices
Refer to the following notices for cables, accessories, and
prevention measures necessary to ensure the specified EMC
performance.
NOTICE
For EMC declarations and certifications, and
additional information, refer to the Product
Certifications and Declarations section.
NOTICE
Changes or modifications to the product not
expressly approved by NI could void your
authority to operate the product under your local
regulatory rules.
NOTICE
The performance of this product can be disrupted
if subjected to Electrostatic Discharge (ESD)
during operation. To prevent damage, industry-
standard ESD prevention measures must be
employed during installation, maintenance, and
operation.
PXIe-5655 Safety, Environmental, and Regulatory Information
8 ni.com

NOTICE
This product may become more sensitive to
electromagnetic disturbances in the operational
environment when test leads are attached or
when the product is connected to a test object.
NOTICE
Operate this product only with shielded cables
and accessories. Do not use unshielded cables or
accessories unless they are installed in a shielded
enclosure with properly designed and shielded
input/output ports and connected to the product
using a shielded cable. If unshielded cables or
accessories are not properly installed and
shielded, the EMC specifications for the product
are no longer guaranteed.
NOTICE
The length of all I/O cables must be no longer
than 3 m (10 ).
NOTICE
You must install PXI EMC Filler Panels, NI part
number 778700-01, in all open chassis slots.
Electromagnetic Compatibility Standards
This product meets the requirements of the following EMC
standards for electrical equipment for measurement, control,
and laboratory use:
PXIe-5655 Safety, Environmental, and Regulatory Information
© National Instruments Corporation 9

•EN 61326-1 (IEC 61326-1): Class A emissions; Basic
immunity
•EN 55011 (CISPR 11): Group 1, Class A emissions
•AS/NZS CISPR 11: Group 1, Class A emissions
NOTE
Group 1 equipment (per CISPR 11) is any
industrial, scientific, or medical equipment that
does not intentionally generate radio frequency
energy for the treatment of material or
inspection/analysis purposes.
NOTE
In Europe, Canada, Australia and New Zealand
(per CISPR 11) Class A equipment is intended for
use only in non-residential locations.
Environmental Guidelines
NOTICE
This model is intended for use in indoor
applications only.
PXIe-5655 Safety, Environmental, and Regulatory Information
10 ni.com

Environmental Characteristics
Temperature and Humidity
Temperature
Operating
Chassis
with
slot
cooling
capacity
≥58 W1
0 °C to 55 °C
Chassis
with
slot
cooling
capacity
≥38 W2
0 °C to 40 °C
Humidity
Operating 10% to 90%, noncondensing
Storage 5% to 95%, noncondensing
Pollution Degree 2
Maximum altitude 2,000 m (800 mbar) (at 25 °C ambient temperature)
1Tested with chassis fan mode set to Auto and cooling profile set to 58 W/82 W
in NI Measurement & Automation Explorer (MAX). Not all chassis with slot
cooling capacity ≥58 W can achieve this ambient temperature range. Refer to
PXI chassis specifications to determine the ambient temperature ranges your
chassis can achieve.
PXIe-5655 Safety, Environmental, and Regulatory Information
© National Instruments Corporation 11

Shock and Vibration
Random vibration
Operating 5 Hz to 500 Hz, 0.3 g RMS
Non-operating 5 Hz to 500 Hz, 2.4 g RMS
Operating shock 30 g, half-sine, 11 ms pulse
Environmental Standards
This product meets the requirements of the following
environmental standards for electrical equipment.
•IEC 60068-2-1 Cold
•IEC 60068-2-2 Dry heat
•IEC 60068-2-78 Damp heat (steady state)
•IEC 60068-2-64 Random operating vibration
•IEC 60068-2-27 Operating shock
•MIL-PRF-28800F
◦Low temperature limits for operation
Class 3, for storage Class 3
◦High temperature limits for operation
Class 2, for storage Class 3 1
2For chassis with slot cooling capacity = 38 W, the fan speed must be set to
HIGH for use in this ambient temperature range.
PXIe-5655 Safety, Environmental, and Regulatory Information
12 ni.com

◦High temperature limits for operation
Class 4, for storage Class 3 2
◦Random vibration limits for non-
operating Class 3
◦Shock limits for operating Class 2
NOTE
To verify marine approval certification for a
product, refer to the product label or visit ni.com/
certification and search for the certificate.
Power Requirements
+3.3 V DC 1.1 A, typical
+12 V DC 2.4 A, typical
Physical Characteristics
Dimensions
1U, one-slot PXI Express module
2.05 cm × 12.9 cm × 21.1 cm
(0.9 in. × 5.6 in. × 8.3 in.)
For more information, visit ni.com/dimensions
and search by module number.
Weight 570 g (20.1 oz)
PXIe-5655 Safety, Environmental, and Regulatory Information
© National Instruments Corporation 13

Export Compliance
This product is subject to control under the U.S. Export
Administration Regulations (15 CFR Part 730 et. seq.)
administered by the U.S. Department of Commerce's Bureau
of Industry and Security (BIS) (www.bis.doc.gov) and other
applicable U.S. export control laws and sanctions regulations.
This product may also be subject to additional license
requirements of other countries' regulations.
Additionally, this product may also require export licensing
before being returned to NI. The issuance of a Return Material
Authorization (RMA) by NI does not constitute export
authorization. The user must comply with all applicable
export laws prior to exporting or re-exporting this product.
See ni.com/legal/export-compliance for more information and
to request relevant import classification codes (e.g. HTS),
export classification codes (e.g. ECCN), and other import/
export data.
Environmental Management
NI is committed to designing and manufacturing products in
an environmentally responsible manner. NI recognizes that
eliminating certain hazardous substances from our products is
beneficial to the environment and to NI customers.
For additional environmental information, refer to the
Engineering a Healthy Planet web page at ni.com/
environment. This page contains the environmental
regulations and directives with which NI complies, as well as
other environmental information not included in this
document.
PXIe-5655 Safety, Environmental, and Regulatory Information
14 ni.com

EU and UK Customers
Waste Electrical and Electronic Equipment (WEEE) —At
the end of the product life cycle, all NI products must be
disposed of according to local laws and regulations. For more
information about how to recycle NI products in your region,
visit ni.com/environment/weee.
电子信息产品污染控制管理办法（中国
RoHS）
540
e
中国 RoHS — NI 符合中国电子信息产品中限制使
用某些有害物质指令(RoHS)。关于 NI 中国 RoHS 合规性信
息，请登录 ni.com/environment/rohs_china。(For
information about China RoHS compliance, go to ni.com/
environment/rohs_china.)
Product Certifications and
Declarations
Refer to the product Declaration of Conformity (DoC) for
additional regulatory compliance information. To obtain
product certifications and the DoC for NI products, visit
ni.com/product-certifications, search by model number, and
click the appropriate link.
PXIe-5655 Safety, Environmental, and Regulatory Information
© National Instruments Corporation 15

NI Services
Visit ni.com/support to find support resources including
documentation, downloads, and troubleshooting and
application development self-help such as tutorials and
examples.
Visit ni.com/services to learn about NI service oerings such
as calibration options, repair, and replacement.
Visit ni.com/register to register your NI product. Product
registration facilitates technical support and ensures that you
receive important information updates from NI.
NI corporate headquarters is located at 11500 N Mopac Expwy,
Austin, TX, 78759-3504, USA.
PXIe-5655 Safety, Environmental, and Regulatory Information
16 ni.com

PXIe-5655 Safety, Environmental, and Regulatory Information
© National Instruments Corporation 17

Information is subject to change without notice. Refer to the NI Trademarks and Logo Guidelines at
ni.com/trademarks for information on NI trademarks. Other product and company names mentioned
herein are trademarks or trade names of their respective companies. For patents covering NI products/
technology, refer to the appropriate location: Help»Patents in your soware, the patents.txt file on your
media, or the National Instruments Patent Notice at ni.com/patents. You can find information about end-
user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer
to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade
compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES
NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN
AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S. Government Customers: The data contained in this
manual was developed at private expense and is subject to the applicable limited rights and restricted
data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
© 2019–2023 National Instruments
Corporation. All rights reserved.
Printed in Malaysia.
327190B-01 2023-01-12 *327190B-01*
