EOS SteamRock II Basic User manual

Made in Germany
EOS SteamRock II Basic
steam generator
EN Installation and operation manual
print no. 2902 5194 / 40.22
Subject to technical changes
Version 02 | rmware R0.91

2EN

3
EN
English
Contents
1. Identification..................................................................................................................................5
1.1 Manufacturer..................................................................................................................5
1.2 Copyright .........................................................................................................................5
1.3 Identification of the device........................................................................................5
1.4 Intended use...................................................................................................................5
1.5 Foreseeable incorrect use ..........................................................................................6
1.6 Applicable norms..........................................................................................................6
2. Safety advice........................................................................................................................... 7-12
3. Delivery scope............................................................................................................................ 13
4. Technical Data ............................................................................................................................14
5. Installation
5.1 Installation example.................................................................................................. 15
5.2 Construction and location of components....................................................... 16
5.3 Prerequisites on the installation site...................................................................19
5.4 Mechanical installation ............................................................................................21
5.5 Water and steam pipes............................................................................................. 24
5.6 Mounting the steam pipe .......................................................................................27
6. Electrical installation................................................................................................................30
6.1 SteamRock II Basic 18 kW connection terminals.....................................................30
6.1 SteamRock II Basic 9 kW connection terminals .......................................................31
6.2 SteamRock II Basic 9 -18kWmain circuit diagram........................................... 32+33
6.4-6.5 Connection examples........................................................................................ 34+35
6.7 Leakage current .................................................................................................................. 36
6.7 Special advice for water quality ....................................................................................36
7. Cleaning system ........................................................................................................................ 37
8. Adjustment of the performance.......................................................................................... 39
9. General operation.....................................................................................................................41
9.1 Resetting the safety temperature limiter (STB) ....................................................... 42
10. Cleaning and servicing............................................................................................................43
10.1 Regular maintenance.....................................................................................................43
10.2 Servicing the vaporiser tank / Checking the Niveausensor .............................43
10.3 Dismantle the vaporiser tank with heating spirals.............................................. 46
11. Troubleshooting........................................................................................................................49
12. Recycling......................................................................................................................................49
13. Service Address:.........................................................................................................................51
13. General Terms and Conditions of Service......................................................................... 52

4EN
Safety instructions and important operating instructions are classied. Please familiarise yourself
with the following terms and symbols:
WARNING
Warning
Indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
Caution
Indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE
Notice
Indicates a hazardous situation which, if not avoided, will result in damage to
the unit.
1. General safety instructions
1.1 Safety levels

5
EN
Observe the various qualications required for performing installation, repair,
and service work.
Qualified personnel
Cleaning and service work must be performed only by persons with the follo-
wing qualications:
Qualied personnel: Persons who have been instructed by the distributor
on how to perform service work.
Trained personnel: employees extensively trained by the distributor.
Authorised personnel: Persons with regulatory approval for a specic eld
of work, e.g. electrical installations.
These installation instructions are intended for authorised personnel
familiar with the laws and regulations applicable to electrical instal-
lations at the installation site. Observe the following general safety
instructions during assembly, setup and commissioning.
Risk to life and limb and risk of fire
Risk to life and limb from electric shock and re in the event of improper or faulty
electrical connection. This risk also applies following completion of the installa-
tion work.
The electrical installation of the steam generator and otherelectrical
systems or equipment with a xed mains connection must only be perfor-
med by a trained electrician from an authorised electrical company.
Ensure compliance with the applicable standards and regulations for elec-
trical installation.
The system must be disconnected and removed entirely from the mains
supply before commencing installation and repair work.
The housing cover must only be removed by a trained specialist.
Fire hazard from overheating
Insucient ventilation can lead to device overheating and re.
Do not install the steam generator and control panel in enclosed cabinets
or wood panelling.
Observe the cabin manufacturer‘s safety and installation instructions.
1.2 Mounting and electrical installation

6EN
Touchable glass surfaces on the outside of the cabin must not exceed
76°C. Provide a protective system if needed.
Risk of burns
Touching hot pipelines can result in skin burns.
Insulate hot device parts.
Insulate hot pipelines; they must not remain exposed.
Risk of poisoning from fumes
Descaler can react with other chemicals, which can create poisonous fumes.
Place the container for descaler only under the steam generator and secu-
re it so it does not tip.
Ensure that the container with descaler cannot be mistaken for the cont-
ainer with essence.
When relling a container, ensure that descaler is not poured into the
container for essence.
Never place containers with descaler close to other chemicals.
Never place other chemicals close to the container of descaler.
Risk of scalding
Contact made with hot steam or hot water can result in scalding of the skin.
The steam pipe must always have an unobstructed exit outlet in the cabin
so that excess pressure does not build up in the vaporiser tank.
The hose for excess pressure and the drain outlet for emptying the vapori-
ser tank must be routed in such a way that there is no risk of scalding if hot
water escapes unintentionally.
When commissioning, take measurements to ensure that the set output
does not heat the cabin to over 50°C.

7
EN
Risk of chemical burns
Descaler consists of an acidic solution, which can burn eyes and skin.
Wear eye and skin protection when connecting the descaler line and rel-
ling descaler.
Clean contaminated clothing thoroughly.
Damage to the unit due to high levels of lime
Lime deposits clog the vaporiser tank, slowing down the transfer of heat to the
water. This can lead to malfunctions because of overheating and blockages in
the drain. A water softening system does not replace regular descaling.
Non-compliance with these guidelines resulting in damage to the unit renders
the warranty void.
Check the hardness of the water before installing the unit.
In locations where the water is high in calcium carbonate (above 5° dH), a
water softening system is recommended.
If the level on the hardness scale is 11° dH or above, connecting a water
softening system to the steam generator is recommended.
A water softening system is required if the steam generator is used com-
mercially.
Damage to the unit
Corrosive or heavy saline atmospheres damage the contacts in the control pa-
nel, in the relay box and in the sensors.
The control panel and sensors should not be installed in a corrosive or
heavy saline atmosphere.
Damage due to incorrect mounting location
The device is not suitable for outdoor use!
It must be operated only inside buildings and may not be exposed to
environmental conditions such as extreme humidity and moisture or the
possible formation of condensation or corrosive substances in the ambi-
ent air, as well as other weather conditions.
Similarly, excessive cold and extreme exposure to sunlight must be pre-
vented.
Protect the unit accordingly if there is an increased risk of mechanical
damage.

8EN
1.3 Operator instruction
The technician and/or distributor must instruct the operator of the steam gene-
rator in the general safety instructions when commissioning the unit. The opera-
ting instructions must be given to the operator.
Risk of electric shock
A risk to life and limb from electric shock and re arises in the event of improper
repair work. This risk also applies after work is completed.
The housing cover must only be removed by a trained specialist.
Repairs and installations must only be performed by a trained specialist.
The system must be disconnected and removed entirely from the mains
supply before commencing repair work.
Use only original spare parts from the manufacturer.
Risk of burns and chemical burns
Touching hot parts may lead to skin burns and chemical burns of the skin.
The operator must be familiar with the unit‘s hot parts and be able to
identify them.
The operator must be familiar with the settings for the heat output and/or
steam supply and understand how it is controlled.
Health risks
Spending time in a steam room can lead to serious health risks or even death for
persons with health impairments.
Persons with health disorders must consult with a doctor before visiting a
steam room.
Equipment damage due to overuse
The uninterrupted operation time of the steam room can lead to property da-
mage.
In a commercial steam room, the steam generator must be set so that it
turns itself o after a specic period of time.
If the steam generator does not shut itself o, usage must be supervised
at all times.
Inspect the cabin before each use.

9
EN
1.4 Standards and regulations
For an overview of the standards that were observed during design and
construction of the sauna heaters, please refer to the individual product‘s
technical data sheet that can be downloaded from www.eos-sauna.com.
Local regulations also apply to the installation and operation of heating, sauna,
and steam room systems.
Operation by children or persons with reduced mental capacity
This unit should not be used by children or persons with reduced
mental capacity or limited physical or sensory abilities.
Children must be supervised to ensure they do not play with the unit.
Children and persons who have not received proper instruction must not
clean or service the system.

10 EN
2.1 Manufacturer
EOS Saunatechnik GmbH
Schneiderstriesch 1
D-35759 Driedorf, Germany
Tel.: [phone]
Fax: [phone]
2.2 Copyright
The copyright owner of the present installation manual and operating guide is EOS Saunatechnik
GmbH.
Copyright as per DIN ISO 16016:
The copying and distribution of this document, as well as the use and communicatio n of its con-
tents without express authorisation, are not permitted. Compensation will claimed in the event of
infringements. All rights reserved with regard to patent claims or submission of design or utility
patent.
2.3 Idenfication of the unit
Product name:
EOS SteamRock II Basic
2.4 Information about the unit
Nameplate
The nameplate is attached to the underside of the base of the housing.
Dampfgenerator
Type EOS SteamRock II Basic
Art.-Nr. 94 XXXX 0X
XXX V XN AC XX kW
0 Pa (0 bar)
Made in Germany
EOS-SAUNATECHNIK GmbH, Schneiderstriesch 1, 35759 Driedorf
S-No. 23.21 00001
AProduct description
BModel name
CProduct code (item no.)
DSupply voltage (model dependent)
EOperating pressure Pascal (bar)
FCountry of origin
GManufacturer
HProduction date
ISerial number
A
B
C
D
E
F
G
H I
2. Identikation

11
EN
2.7 Intended use
The SteamRock II Basic steam generator is designed to produce steam for a steam room or a sauna
with humid operation. The SteamRock II Basic is operated with an external control unit, like for
instance the Econ S2 or EmoTouch 3/LSG-Steam, which is not included in the scope of delivery and
must be approved by EOS Saunatechnik GmbH.
2.8 Foreseeable misuse
The following are considered instances of foreseeable misuse:
The output of the steam generator does not match the cabin volume.
The steam generator and the control unit are connected incorrectly.
The unit is operated without knowledge of or compliance with the safety instructions.
Operating, service and maintenance requirements are not observed.
The unit is operated after technical or other modications are made to the steam genera-
tor.
The unit is operated by children or persons with reduced mental capacity or by persons
who have not been thoroughly instructed in its use.
The use by persons with certain ailments or health conditions, such as for instance heart
and cardiovascular disorders, which might lead to physical injuries through the use of a
sauna or a steam room (a doctor should be consulted in advance).
2.5 Models
2.6 Cabin volume for each output capacity
Model Power output Steam production Fuse protection Weight
Type 1 3 kW 6 kg/h 3 x 16 A 27 kg
6 kW 8 kg/h
9 kW 12 kg/h
Type 2 3 kW 6 kg/h 3 x 35 A 29 kg
6 kW 8 kg/h
9 kW 12 kg/h
12 kW 16 kg/h
15 kW 20 kg/h
18 kW 24 kg/h
The output capacity of the unit must be calculated for each installation individually and account
for the size of the cabin and the design.
The output capacity is calculated using the following formula:
Room volume [m³] x K1 x K2 = output capacity [kW]
The following applies:
K1: ventilated room = 0.75, unventilated room = 0.52
K2: lightweight construction (e.g. acrylic panels) = 1; Tiled rigid foam panels = 1.25; Tiled concrete
walls = 1.50; Solid wall made of concrete, stone or similar with tiles = 2.00.

12 EN
3. Scope of delivery
The SteamRock II Basic scope of delivery includes:
SteamRock II Basic steam generator
4 screws 5 x 40 with 4 dowels F6 for installing the steam generator on the wall
2-part brass union 1 1/4“ - 35 mm for steam pipe connection
0,5 m connection hose for water supply 3/8“ - 3/4“
5 l container for descaler liquid with rod electrode (level sensor)
Installation & user manual
Pre-mounted power supply cable with CEKON type plug (16A or 32A)
Steam outlet, 1 1/4“ external thread
Accessories
Description Item no.
Descaler liquid„SteamClean“, 5 kg canister. Acid solution. 2001.6065
Steam outlet, 1 1/4“ outer thread, white plastic 2001.5575
Container for essences, with level probe, 5 l volume 94.6298

13
EN
4. Specications
Dimensions H x W x D [mm] 670 x 460 x 350 mm
Weight [kg] 28 kg (type 1 - 9 kW) / 30 kg (type 2 - 18 kW)
Water supply pressure [bar] 2 - 8 bar
Operation pressure max. [bar] Pressureless type steam generator
Performance at 3 bar [steam/h] 3 kW - 4 kg/h, 6 kW - 8 kg/h, 9 kW - 12 kg/h, 12 kW - 16
kg/h, 15 kW - 20 kg/h, 18 kW - 24 kg/h
Vaporizer tank High grade stainless steel
Internal overheating protection Thermofuse with capillary sensor, 3-pole circuit
breaker
Heating system Inner heating elements, switchable in 3 kW steps
Drain and cleaning system Integrated automatic draining and descaling system
(requires optional descaling liquid).
Note: descaler must be foaming.
Water drain 1“ drain pipe at the unit’s bottom side
Water level control Automatic through integrated level probe
Control system not included (external control unit required)
Water supply ¾“ external thread
Steam output 1 1/4“ external thread, with 2-part brass union
Ambient temperature (operation / storage) 5°C to 45°C / 0°C to 60°C
Ambient humidity (operation) 30% bis 75%
Outputs / Connections • Mains (pre-mounted mains cable)
• Connection for external control unit
• Connection for level sensor in the descaler tank
• Connection for level sensor in the fragrance
container
Power output [kW] type 1 - 3.0 / 6.0 / 9.0 kW (9 kW default)
type 2 - 9 / 12 / 15 / 18 kW (18 kW default)
Fuse protection [A] type 1 - 3 x 16 A
type 2 - 3 x 32 A
Min. cross section power supply line type 1 - 5 x 2,5 mm²
type 2 - 5 x 6,0 mm²
Power supply 400 V 3N ~, 50/60 Hz, with pre-mounted mains
cable with Cekon-type plug

14 EN
1000
300
150-250
1600 - 1700
5.1 Installation example
drain
steam pipeline
steam outlet
cabin lighting
door
sensor
drain in the steam cabin
container for descailer
* For installation details of the tem-
perature sensor please refer to the
installation manual of the respec-
tive control unit.
steam generator
duct vent (ceiling panel)
5. Installation

15
EN
5.2 SteamRock II Basic - position of key components
Top view
*The prime heating element (G) has a special colour-coded marking of the connection wire. This
specially marked heating element (G) is located next to the overheating limiter fuse (F). After dis-
connection make sure, that this heating element (G) is connected to the same colour-coded wire.
Incorrect connection may lead to damages to the unit.
Adrain line of the pressure relief valve
Bpressure relief valve with drain
Cdescaler liquid supply hose
Dwater tank lid
Etube for overheating limiter fuse (STB)
Fmounting nuts SW 19 and connection terminals for *heating elements
Gwater level probe (level sensor)
Hrinsing and lling
Isteam output pipe with exible pivot joint
Jchassis (rear side with ventilation holes)
example of the 9 kW unit
NOTICE
C
B
A
J
I
H
G
F
D
E

16 EN
drain line from pres-
sure relief valve
Status LED for operation
states and error signals
Bottom view
water supply, 3/4” ex-
ternal thread
water tank drain, 1“ external
thread
cable to descaler level probe
mains connection*
9 kW: with pre-mounted cable and CEE-plug 16A
18 kW: with pre-mounted cable and CEE-plug 32A
no pre-mounted power plug for single-phase connection!
white hose for descaler (plugs
into the container for descaler)
steam output, 1 1/4”
external thread
connection (strain reliefs) for cable
connection to control unit
* The cable gland of the mains cable has a warrant
seal. Make sure not damage the seal. Warranty void
by damaged or removed seal.
All incoming and outgoing connections go through
the bottom panel (steam pipe may also lead up-
wards) and are accessible from outside.

17
EN
Overview without external housing
steam generator tank
main terminal bank with
colour-coded terminals
main board
water supply line
dual way magnet valve
(water supply)
Status LED for operation
condition and error signals
F-fuses for heating elements
9 kW - F1/F2/F3
18 kW - F1/F2/F3/F4/F5/F6
descaler pump
pressure relief valve drain
thermal fuse (STB)
with reset button
drain valve with actuator
contactors
Mains cable is tted with a Cekon plug
(not with single-phase connection)
pressure relief valve
descaler supply hose
example of a 18 kW unit
Y-distributor Flush / Fill

18 EN
5.3 Installation location requirements
The steam generator is only intended for installation outside of steam rooms and is connected to
the room via a steam pipe. The following climatic conditions must be met at the installation site:
Ambient temperature during operation 5°C to 40°C
Air humidity during operation 30% to 75% rel. air humidity
Storage temperature: 0°C to 60°C
Steam room requirements
Floor drain
Air extractor so that temperature control works properly
Steam generator requirements
Stable wall for installation as the total weight can equal approx. 45 kg.
Near the unit: Mains connection 400 V 3N ~, with standardised CEE plug sockets (not for
single-phase connection)
Drain outlet below the unit or in close proximity
Water supply line in close proximity
Length of steam pipe, max. 10 m
All pipelines and connections must be accessible for service.
The room in which the steam generator is installed should be as near to the steam room as
possible so that the pipeline distances are as short as possible.

19
EN
alle Maße in mm
all sizes in mm
535
670
min. 500
1000
460
420
min. 250 min. 250
NOTICE
Damage due to inadequate installation site
The steam generator may vibrate slightly when the water boils.
If the wall bearing capacity is insucient or the wall is of poor quality, the steam generator can-
not be securely installed and may fall o.
Before installation, check the quality and bearing capacity of the wall intended for installation.
The wall must be able to support a total weight of max. 45 kg.
Before installation, check how the steam pipe is to be laid. Standard routing leads the line out
from the steam generator downwards.
Measurements for installation
The following distances must be observed:
Distance bet-
ween drill holes
Horizontal: 420 mm
Vertikal: 535 mm
On the side to the
left and right
Min. 250 mm
Top Min. 500 mm
Bottom Approx 1000 mm
The space underneath the unit must not be
occupied by other installations.

20 EN
The steam generator is mounted on the wall with four (4) retaining screws and suitable anchors.
Note that the steam generator may vibrate slightly when the water boils. Ensure that you have
sucient hardware for securing it if you do not use the supplied screws and anchors.
Necessary steps:
Preparing for installation
Loosen the vaporiser from the shipping plate
Removing the housing cover
Mounting the vaporiser
Hardware + tools:
Four 5 x 40 screws; four F6 anchors (included in scope of delivery)
Spirit level
6mm drill
Phillips screwdriver
Recommendation: 2 persons to mount the vaporiser
Preparing for installation
1. NOTICE Ensure that the holes are aligned vertically and horizontally. Use a spirit level.
Drill two (2) holes above and below.
Distance between lower edge and the oor: min 1000 mm
Distance to the ceiling: min. 550 mm
Horizontal distance between drill holes: 420 mm
Vertical distance between drill holes: 535 mm
2. Insert the anchors and screw in the top two screws. Allow the screws to
protrude approx. 3 mm so you can hang the vaporiser on them.
5.4 Mounting the steam generator
3
alle Maße in mm
535
420
