EP Solar LandStar LS-EU Series User manual

LS-EU Series
—— Solar Charge Controller
USER
MANUAL

LS-EU Series
—— Solar Charge Controller
Nominal System Voltage
LS0512EU/LS1012EU
12VDC
LS1024EU/LS2024EU
12/24VDC
Maximum PV Input
Voltage
LS0512EU/LS1012EU
30V
LS1024EU/LS2024EU
50V
Nominal
Charge/Discharge Current
LS0512EU
5A
LS1012EU/LS1024EU
10A
LS2024EU
20A
USB Output
ALL
5VDC/1.2A
LandStar

Contents
1 Important Safety Information.......................................... 1
2 General Information.........................................................2
3 Installation Instructions................................................... 3
3.1 Mounting................................................................ 3
3.2 Wiring.....................................................................4
4 Operation......................................................................... 5
4.1 LED Indicators....................................................... 5
4.2 Setting Operation....................................................7
5 Protection and Troubleshooting.......................................8
5.1 Protection................................................................8
5.2 Troubleshooting......................................................9
6 Technical specifications.................................................11

1
1 Important Safety Information

Read all of the instructions and cautions in the manual before
beginning installation.

There are no user serviceable parts inside the controller. Do not
disassemble or attempt to repair it.

Install external fuses/breakers as required.

Disconnect the solar module and fuse/breakers near to battery before
installing or adjusting the controller.

Do not allow water to enter the controller.

Confirm that power connections are tightened to avoid excessive
heating from loose connection.

2
2 General Information
LS-EU series solar charge controller, with beautiful, economic,
practical, simple and easy to use, etc. It has various unique functions：
It can be judged battery voltage intuitively with Battery indicator.
High efficient Series PWM charging, increase the battery lifetime
and improve the solar system performance.
Use MOSFET as electronic switch, without any mechanical switch
LED indicators indicate battery voltage state.
Adopt temperature compensation, correct the charging and
discharging parameters automatically and improve the battery
lifetime.
Electronic protection: over charging, over discharging, overload, and
short circuit.
Reverse protection for battery.

The USB will provide 5VDC that can charge for electronic
equipment.

3
3 Installation Instructions
3.1 Mounting
Read through the entire installation section first before beginning
installation.
Be very careful when working with batteries. Wear eye protection.
Have fresh water available to wash and clean any contact with
battery acid.
Uses insulated tools and avoid placing metal objects near the
batteries.
Explosive battery gasses may be present during charging. Be certain
there is sufficient ventilation to release the gasses.
Avoid direct sunlight and do not install in locations where water can
enter the controller.
Loose power connections and/or corroded wires may result in
resistive connections that melt wire insulation, burn surrounding
materials, or even cause fire. Ensure tight connections and use cable
clamps to secure cables and prevent them from swaying in mobile
applications.
Use with Gel, Sealed or Flooded batteries only.
Battery connection may be wired to one battery or a bank of batteries.
The following instructions refer to a singular battery, but it is
implied that the battery connection can be made to either one
battery or a group of batteries in a battery bank.
Select the system cables according to 3.5A/mm2current density.

4
3.2 Wiring
1. Connect components to the charge controller in the sequence as
shown in above picture and pay much attention to the “+” and
“-”.Always power the battery First.
2. After power the battery, check the battery indicator on the
controller, it will be green. If it’s not green, please refer to chapter
5.
3. The load should be DC applicant with the same rated voltage as
battery’s. Controller offers power to loads through the battery
voltage.

5
4 Operation
4.1 LED Indicators
Charging and load status indicator
Table 4-1
Indicator
Indicator
Status
System
Status
Note
Charging
status
indicator
On
Charging
Normal
Fast
Flashing
over
voltage
refer to section 5
load
status
indicator
On
ON
When the load
amp is 1.25times
of rated current
for 60 seconds,
or the load amp
is 1.5 times of
OFF
OFF
Slowly
Flashing
Overload
Charging status indicator
Load status indicator
LED1
Setting
button
Solar Module
Terminals
Battery
Terminals
Load
Terminals
Mounting
Holes
LED2
LED3
LED4

6
rated current for
5 seconds
Fast
Flashing
Short
Circuit
refer to section 5
Battery status indicator(LED1、LED2、LED3、LED4)
Battery LED indicator(The parameters in the table below is for 12VDC
system at 25℃, for 24VDC system ,the parameters is doubled)
Table 4-2
LED1
LED2
LED3
LED4
Battery Status
Slowly
Flashing
×
×
×
Under voltage
Fast
Flashing
×
×
×
Over discharged
Battery LED indicator status during voltage is up
○
○
×
×
＞12.8V
○
○
○
×
＞13.4V
○
○
○
○
＞14.1V
Battery LED indicator status during voltage is down
○
○
○
×
＜13.4V
○
○
×
×
＜12.8V
○
×
×
×
＜12.4V
“○”LED indicates on “×”LED indicates off

7
4.2 Setting Operation
Load Work Mode Setting
When the controller is powered on, press the setting button to control
the load output. Press the button once, the ON/OFF status will be
changed corresponding. The USB Output is ON only when the Load
Work Mode is at ON status, otherwise, it is OFF.
Battery Type Setting
Press the setting button for more than 5 seconds, battery indicator
LED1, LED2, LED3 will be flashing correspondingly. Then press the
setting button to choose Sealed, Gel, and Flooded battery type, when
you finish choosing, stop pressing the button, the setting is finished till
the digital tube stop flashing. The parameters indicated are shown
below:
Battery type selection Table4-4
LED1
LED2
LED3
Battery type
○
×
×
Sealed lead acid battery
○
○
×
Gel battery
○
○
○
Flooded battery
“○”LED indicator on “×”LED indicator off

8
5 Protection and Troubleshooting
5.1 Protection
·Load Overload
If the load current exceeds the maximum load current rating(exceeds
1.25 times of rated current), the controller will disconnect the load
with a short delay. Overloading must be cleared up through reapply
power or pressing the setting button.
·Load Short Circuit
Fully protected against load wiring short-circuit(exceeds 2 times of
rated current) automatically. After one automatic load reconnect
attempt, the fault must be cleared by reapply power or pressing the
setting button.
·Battery Reverse Polarity
Fully protection against battery reverse polarity, no damage to the
controller will result. Correct the mistake of wiring to resume normal
operation.
·Damaged Local Temperature Sensor
If the temperature sensor short-circuited or damaged, the controller
will be charging or discharging at the default temperature 25℃to
prevent the battery damaged from overcharging or over discharged.

9
·High Voltage Transients
PV is protected against high voltage transients. In lightning prone
areas, additional external suppression is recommended.
5.2 Troubleshooting
Trouble Shooting Table 5-1
Faults
Possible
reasons
Troubleshooting
Charging LED
indicator off
during daytime
when sunshine
falls on PV
modules
properly.
PV
array
disconnection
Check that PV and
battery wire connections are
correct and tight.
charging LED
indicator fast
flashing
Battery voltage
higher than
over voltage
disconnect
voltage(OVD)
Check if battery voltage over
high. Disconnect the solar
module
Battery LED1
indicator
SLOWLY
FLASHING
Battery
under
voltage
When load output is normal,
LED status will return to ON
automatically when fully
charged.

10
Battery LED1
indicator
FAST
FLASHING.
Battery
over
discharged
When the controller cut off
the output automatically,
LED status will return to ON
automatically when fully
charged.
Load LED
indicator
SLOWLY
FLASHING
Over load
Please reduce the load and
press the button once, the
controller will resume to
work after 3s
Load LED
indicator
FAST
FLASHING
Short circuit
when the first short-circuit
occurs, the controller will
automatically resume to
work after 10s; when a
second short-circuit occurs,
press the button, the
controller will resume to
work after 3s
No LED
indicator
battery voltage
lower than 6V
Measure battery voltage with
multimeter. Min.6V can start
up the controller
No charging
status LED
indicator with
normal
connection
input voltage of
solar module
lower than
battery voltage
Measure the input voltage of
solar module, the input
voltage must be higher than
battery voltage

11
6 Technical specifications
Electrical Parameters Table 7-1
Description
Type
Parameter
Nominal System Voltage
LS0512EU/LS1012EU
12VDC
LS1024EU/LS2024EU
12/24VDC
Max.batt.Volt.to the
controller
LS0512EU/LS1012EU
16V
LS1024EU/LS2024EU
32V
Rated Battery Current
LS0512EU
5A
LS1012EU/LS1024EU
10A
LS2024EU
20A
Charge Circuit Voltage
Drop
ALL
≤0.26V
Discharge Circuit Voltage
Drop
ALL
≤0.15V
Self-consumption
ALL
≤6mA
Temperature Compensation Coefficient Table7-2
Description
Parameter
Temperature Compensation
Coefficient(TEMPCO)*
-5mV/℃/2V (ref)
* Compensation of equalize, boost, float and low voltage disconnect
voltage
Environmental parameters Table 7-3
Environmental parameters
Parameter
Working temperature
-35℃～+55℃
Storage temperature
-35℃～+80℃
Humidity
≤95% N.C.

12
Enclosure
IP30
Mechanical Parameters Table 7-4
Type
LS0512EU
LS1012EU
Overall
Dimension
109.7(4.32)x65.5(2.58)x
20.8(0.82)mm(inches)
120.3(4.74)x67(2.64)x
21.8(0.86)mm(inches)
Mounting
dimension
100.9(3.97)mm(inches)
111.5(4.39)mm(inches)
Mounting hole size
Φ4.5
Φ4.5
Terminal
2.5mm²
4mm²
Weight
95g
103g
Mechanical Parameters Table 7-5
Type
LS1024EU
LS2024EU
Overall
Dimension
120.3(4.74)x67(2.64)x
21.8(0.86)mm(inches)
148(5.83)x85.6(3.37)x
34.8(1.37)mm(inches)
Mounting dimension
111.5(4.39)mm(inches)
138(5.43)mm(inches)
Mounting hole size
Φ4.5
Φ4.5
Terminal
4mm²
6mm²
Weight
102g
/

Final interpretation right of the manual belongs to our company.
Any changes without prior notice!
Version number: V1.3
