OWNER'S MANUAL
SF208CW
SF208CW
Ceiling Speaker
Ceiling Speaker
Safety Tips
Readers
Warning Such as the inappropriate use of staff will cause
injury, death and property damage.
●Please be sure to use the former reading detailed notes.
●Really pay attention to this manual and a safety with the important warning.
●Recommend that you keep this manual for future reference.
When installed loudspeakers
●Definitely will not be allowed to speakers and any exposure in the rain-wet
or water, may be inconsistent with ,or fire.
●Restricted by the provisions of the speakers on the voltage, such as the
use of high voltage may cause electric shock or fire disaster. Is no pruning,
distorted, or replacement of damaged wires.
●Avoid instability in the installation or set up speakers, such as shaking the
table or flat surface , the speaker can avoid falling caused personal injury
or property damage.
●Speakers will be installed in support of the speaker or the weight of a solid
shelf. Speaker swap can be avoided caused personal injury or property
damage.
●Wet hands must not be admitted into or plugs, may lead to electric shocks.
●The allocation of plugs, make sure that pull plugs, rather than pull wires.
The use of a damaged power line of machinery may cause fire or electric
shock.
●Mobile speaker, you plug the prior allocated. If the speaker and plugs may
be moving together will cause fire or electric shock.For plugs,identified as
plugs for grip.
●Will not be allowed to speakers on the vent cover. May cause internal
heating caused by the fire.
●Avoid speakers installed in the humidity or dust, direct contact with the
sun, from the near-electric, or smoke or steam, may cause fire or electric
shock.
Common warning signs and security
The manual shown warning signs and security is to prevent the improper
operation due to personal injury arising from the loss of property, please
read before using this product must understand that this manual security
symbols and Warning to indicate fully aware of potential risks.
Dear customers,your use of the broadcasting company speaker series. We
would like to extend my heartfelt thanks to all of the Company manufactured
products have been tested before, the commitment to keep its quality. Loud -
speakers broadcast Pan-for hotels, commercial buildings, supermarkets,
schools, leisure and entertainment venues, is your ideal choice. For your
installation, commissioning and use of this product, the installation please
read this note.

Model
Power Taps@100V
Power Taps@70V
SPL(1W/1M)
Input
Impedance
Freq Resp
Weight
Cutout size
Dimensions
SF208CW
5W/10W/20W/40W
2.5W/5W/10W/20W/40W
90dB±3dB
90-20KHz
245mm
280X195mm
2.5Kg
Black:Com,Red:2KΩ,
1KΩ,500Ω,250Ω,125Ω
70V/100V/8Ω
SF208CW
1.100V input a pressure signal to prohibit the switching of the hit "-"
position
2.When the switch position in 8Ω, bans the importation of 70V, 100V
pressure signal
Note
Step 1 The ceiling opening size, the wiring through the hole to open a
good connection on the speaker.
Step 2 The mask opening speaker.
Step 3 Speakers installed in the ceiling and fixed. So close to the edge
of the ceiling speakers, rotating clockwise and tighten the screws.
Label stickers
Specifications
Installation
Dimension
195 mm
280 mm
280 mm
280 mm
195 mm
20.00 mm
40.00 mm
Power Taps@100V
Power Taps@70V
Impedance
Freq Resp
5W/10W/20W/40W
2.5W/5W/10W/20W/40W
90dB±3dB
90-20KHz
( )
SPL 1W/1M
2KΩ/1KΩ/500Ω/250Ω/125Ω/8Ω
Model
SF208CW
CEILING SPEAKER
SF208CW
