FeaturesS7-530A
Page 2-1
Section 2
FEATURES
S7-530A Features:
•Intel Pentium®Processor, Pentium Processor with MMX technology, AMD
K5/K6, Cyrix 6x86L/6x86MX & idt C6 operating at 133 ~ 500 MHz with
321 ZIF socket 7 provides scalability to accept faster Processors in the
future.
•Designed with SiS530 Chipset.
•Supports up to 512 Mega of DRAM (minimum of 16 MB) on board, You can
use 168-pin DIMM x 2. It will automatically detect Extended Data Output
(EDO) DRAM at 66MHz only or Synchronous DRAM memory (SDRAM) at
66MHz or 100MHz (please see Section 3-4).
•Supports (2) 16 bit ISA slots, (2) 32 bit PCI slots, (2) independent high perfor
mance PCI IDE interfaces capable of supporting PIO Mode 3/4 and Ultra
DMA 66 devices. The S7-530A supports (2) PCI Bus Master slots and a
jumperless PCI INT# control scheme which reduces configuration confusion
when plugging in PCI card(s).
•Supports ATAPI (e.g. CD-ROM) devices on both Primary and Secondary IDE
interfaces.
•Designed with Winbond W83877TF Multi I/O: (1) floppy port, (1) parallel port
(EPP, ECP), and (2) serial ports (16550 Fast UART).
Note: Japanese “Floppy 3 mode” is also supported
•Built-in ATX 20-pin and supply connector.
•Features Award Plug & Play BIOS. With Flash Memory you can always
upgrade to the current BIOS as they are released.
•S7-530A utilizes a Lithium battery which provides environmental protection
and longer battery life.
•Software power-down when using Windows®95/98.
