EPS SK202 Series User manual

SK202 Specification 1 of 4
SK202
GigE contactless connectivity
1. Overview
SK202 is a pair of RF modules with H&V horn antenna and G-PHY to achieve
1Gbps data rate Ethernet to 60GHz millimeter Wave RF signal conversion. The input
of SK202 is an RJ45 Gigabit Ethernet Connector supporting 10/100/1000Base-T.
SK202 modules are based on leading edge ST60A2 mmW RF transceiver and the
output consist in an RF transmission of the corresponding SGMII signal over several
centimeter.
2. Features
60GHz V-Band transceiver with ST60A2
Gigabit Ethernet short range contactless connectivity, preferred 3cm
Full duplex, horizontal transmission, Controlled Auto negotiation
RJ45 MDI interface Ethernet input
Used in pairs
3. Application
LED panels for modular display walls
Video surveillance camera and robotics
Contactless Ethernet applications
4. Block diagram
Board outlook:

SK202 Specification 2 of 4
5. Assembly
PCB installation:
Unit: mm
Note:
(1) If a metal cover is used, a window should be added for microwave signal. Plastic
or other microwave insensitive materials can be used to fill the window.
(2) The DC socket and the USB MICRO-B socket are connected together. The USB
MICRO-B socket is only used to supply the power. Please do not connect them
both at the same time.
(3) It is recommended that the installation distance (‘A’) is at least 1 cm, the typical
value is 2 cm, and the maximum is 5 cm（-40~50℃，High temperature will affect
the max working distance）.
6. Characteristics
Recommended operating conditions and electrical characteristics
Symbol
Description
Minimu
m
Typical
Maximum
Unit
VIN
Power supply
4.4
12
16
V
CIN
Input current(*)
-
50
80
mA
P
Total Power consumption
-
0.6
-
W
TA
Ambient Operating
Temperature, for SK202A/B
0
-
70
℃
TJ
Maximum Junction
Temperature
-
-
125
℃
TSTG
Storage Temperature
-40
105
℃
Fosc
Carrier Frequency
60.3
60.4
60.5
GHz
* when power supply is 12V and Ethernet is active.

SK202 Specification 3 of 4
7. Auto-negotiation
The Ethernet PHY supports 1Gbps, 100Mbps and 10Mbps speeds. In order for
two Ethernet modules to communicate correctly, care must be taken that the PHY on
both modules negotiate the same speed. The auto-negotiation is always enabled on the
Realtek PHY. It takes place independently between a module and the device
connected on its RJ45 port. It is the responsibility of the application to ensure the
auto-negotiation result is the same for both Ethernet modules.
For example, if one module is connected to a 100Mbps modem, the PC
connected on the other module should be configured to guarantee the auto-negotiation
result is also 100Mbps.
More details are available in the User Manual.
8. Order Information
Part
number
Description
SK202A
GigE contactless module with Realtek RTL8211FS, Port A
SK202B
GigE contactless module with Realtek RTL8211FS, Port B
NOTE:
Port A: with vertical polarized horn antenna for transmitting and horizontal
polarized horn antenna for receiving.
Port B: with horizontal polarized horn antenna for transmitting and vertical
polarized horn antenna for receiving.
FCC Part 15:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generate, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.

SK202 Specification 4 of 4
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
RF exposure warning
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This product may not be collocated or operated in conjunction with any other antenna
or transmitter
This equipment must be installed and operated in accordance with provided
instructions and the antenna(s) used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be collocated or
operating in conjunction with any other antenna or transmitter.
