Cabletron Systems SPECTRUM FRX6000 Operating manual

0DLQWHQDQFH
*XLGH
Document number
09-41-06-105-03 The Complete Networking SolutionTM

iii
Notice
Cabletron Systems reserves theright to make changes in specifications and
other information contained in this document without prior notice. The
readershould in all cases consult Cabletron Systems to determine whether
any such changes have been made.
Thehardware, firmware, and/orsoftwaredescribed in this manualis subject
to change without notice.
IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR
ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL
DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO
LOST PROFITS) ARISING OUTOFOR RELATED TO THISMANUAL
OR THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON
SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR SHOULD HAVE
KNOWN, THE POSSIBILITY OF SUCH DAMAGES.
Copyright 1997, 1998 by Cabletron Systems, Inc. All rights reserved.
Printedin the United States ofAmerica.OrderNumber: FRX6-MNT-DOC.
Also see third-party software copyrights in theNetlink
FRX4000 & FRX6000 User Guide.
Netlink is a trademark ofCabletron Systems, Inc. All other product desig-
nations are the property of their respective owners.
Statements of Compliance
United States (FCC)
Theequipmentprovided byCabletron Systems,Inc.anddocumented in this
manual has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment.
Thisequipmentgenerates,uses, and canradiateradio frequencyenergy and,
if not installed and used in accordance with the installation manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in
which casethe userwill berequired to, at his/herown expense, takethe nec-
essary measures toeliminate the interference.

iv FRX6000 Maintenance Guide, Rev 03
To ensurecompliancewith theClassA FCClimits,useonly shielded cables
with this equipment. Any cableinstalled above a ceiling or below a floor
must be of amaterial and construction approved by UL for that application.
Canada
This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus set out in the Radio InterferenceRegula-
tions of the Canadian Department of Communications.
Le present appareil numerique n'emet pas de bruits radioelectriques
depassant les limits applicables auxappareils numeriques de laclass Apre-
scrites dans le Reglement surlebrouillageradioelectrique edicte parle min-
istere des Communications du Canada.
About This Manual
This manual is intended for use by field service personnel either directly
employed by orcontracted by Cabletron Systems,Inc.Themanualprovides
information that will aid in troubleshooting and maintaining an FRX6000.
You should also have a Netlink FRX4000 & FRX6000 User Guide for ref-
erence.
Some of the operations described in this manual can lead to
damage to the hardware and/or software if not performed
correctly. This manual should be used only byqualified
service personnel.
Revision History
Rev Date Reason for Update
01 December 1996 Initial release
02 March 1997 CD-ROM
03 March 1998 Release 4.0
Terminology and Conventions
This typeface represents general text. This typeface represents computer
input and output.
In on-screen versions of the document, cross references that arelinks to
other places in the document are shownin blue.

v
This symbol points to an informational noterelating to thetext,
table, or figure that immediately precedes orfollows it.
This symbol and text identifies a cautionary note, the
content ofwhich is more critical to heed than an informa-
tional note.
This symbol and text identifies a warning, intended to
prevent either injury to the user or major damage to
hardware, software, or system operation.
References to these keyboard keys appear in the manual and/or on the
screen:
"[N]"—is a reference to a key on your keyboard (where “N” is thekey).
"Enter"—means that you should type in the information,then press the
[Enter] key.
"Type"—is similar to "Enter", except that the word “[Enter]” follows
the information to be typed (e.g., "type n [Enter]").
"Press"—means press (hit, strike)the key once. Pressing the[Enter]
key afterwards is not necessary.
"[Ctrl]"—followed by one ortwo other key designations,mustbe struck
simultaneously with the other keys shown.
If a statement ends with a reference to a key—for example, “....then press
[Enter].”—the period is not part ofthe data to beentered.Ifa period should
be entered, it will be shown as "[.]." The same applies to all other punctu-
ation.
Wheninstructedto, for example, “press [A],[B] from the MainMenu,” this
meanspress[A], then [B], not [A] comma [B].
Screen displaysare provided to show thegeneral appearance of
actual screens. Theyareonly examples—they do not neces-
sarily represent an operational system.
Related Documents
The Netlink FRX4000 & FRX6000 User Guide is shipped with each
FRX6000. Additional copies of this and other Cabletron documents can be
ordered from Cabletron Systems, Inc.,or your local distributor ofCabletron
products.

vi FRX6000 Maintenance Guide, Rev 03

vii
Table of Contents
Chapter 1— Hardware Overview
Chassis ...........................................................................1-1
Cards ..............................................................................1-2
RLP ............................................................................1-2
LAN Adapters ............................................................1-3
Operator Interfaces ........................................................1-3
Chapter 2—Diagnostic Procedures
Reviewing Boot Messages .............................................2-5
BootMessages ...........................................................2-6
Running theBIOS Setup Program ...............................2-17
COMPortInterfaceControls .......................................2-20
Chapter 3—Testing & ReplacingComponents
Removing theChassis Cover .........................................3-4
Testing Component Voltages .........................................3-4
Replacing the Power Supply ..........................................3-5
Replacing the Hard Disk Drive ......................................3-7
Replacing the 3.5”Diskette Drive ...............................3-11
Replacing the Fan Filter ...............................................3-13
Replacing a Fan ...........................................................3-14
Adding or Replacing Cards ..........................................3-16
Appendix A—Configuration Drawings
Cards .............................................................................A-1
Cables ............................................................................A-4
I/O Cables .................................................................A-4
Auxiliary Console Cables .........................................A-8
Appendix B—Configuring LAN Card Software
SMC EtherCard Configuration ..................................... B-2
SMC TokenCard Configuration ....................................B-3
IBM Token Ring Adapter Configuration ...................... B-4
Startup Files .................................................................. B-5
CONFIG.SYS ........................................................... B-5
PROTOCOL.INI ....................................................... B-5
Appendix C—Installing FRX6000 Software
Index

viii FRX6000 Maintenance Guide, Rev 03
List of Figures
1-1 FRX6000 Chassis............................................................ 1-1
1-2 RLP with I/OBox and Cables......................................... 1-2
1-3 Lan Cards ........................................................................ 1-3
2-1 Port Status Display.......................................................... 2-2
2-2 Main Menu...................................................................... 2-3
2-3 Rackmount BIOS Setup Menu...................................... 2-17
3-1 Rackmount Chassis, Front View..................................... 3-1
3-2 Rackmount Chassis, Rear View...................................... 3-2
3-3 Rackmount Chassis, Interior View.................................. 3-3
3-4 Removing the Chassis Cover .......................................... 3-4
3-5 Disk Drive Cables ...........................................................3-6
3-6 Power Supply Cables.......................................................3-6
3-7 Power Supply Mounting Screws..................................... 3-7
3-8 Removing the Chassis Faceplate..................................... 3-8
3-9 Removing theHard Drive ...............................................3-8
3-10 Hard Disk Drive Cables .................................................. 3-9
3-11 BIOS Setup Menu ......................................................... 3-10
3-13 Removing theDiskette Drive........................................ 3-12
3-14 Diskette Drive Cables.................................................... 3-12
3-15 Removing the Chassis Faceplate................................... 3-13
3-16 Removing the Fan Filter................................................ 3-14
3-17 Removing Fans.............................................................. 3-15
3-18 Installing a Card ............................................................ 3-16
A-1 RLP and I/O Assembly................................................... A-1
A-2 SMC EtherCard Plus ...................................................... A-2
A-3 SMC TokenCard Elite.................................................... A-2
A-4 CPU Module................................................................... A-3
A-5 RS-232 Cables................................................................ A-4
A-6 V.35 Cables.................................................................... A-5
A-7 RS-449 Cables................................................................ A-6
A-8 X.21 Cables.................................................................... A-7
A-9 Auxiliary Console Cable, FRX6000 to PC .................... A-8
A-10 Console Cable Converter,FRX6000 to Terminal..........A-8
A-11 Auxiliary Console Cable, FRX6000 to Modem............. A-9

ix
List of Tables
2-1 BIOS Setup Parameters..................................................2-18
B-1 RLP Addresses................................................................B-1

Chapter 1
Hardware Overview
The NetlinkTM FRX6000is used toprovide concentration and access
to remote devices. Each FRX6000 supports up to sixty-four serial
interfaces, and can function as central-site devices for remote
FRX4000s, SmartSwitch 1800s, and/or 9W004s. The FRX6000 pro-
vides local and remote switching, and (on devices with videointer-
faces) feature an intuitive, menu-based management structure that
allows complete local and remotecontrol of other Cabletron frame
relay devices.
Detailed product descriptions can be found in the Netlink FRX4000
&FRX6000 User Guide.
Chassis
Figure1-1 FRX6000 Chassis

1-2 FRX6000MaintenanceGuide,Rev 03
Cards
RLP
The RLP, an i960 RISC-based line processor, provides serialinter-
faces on the FRX6000.
Figure1-2 RLPwith I/O Box and Cables
RLP LIC 1
I/O Box
RLP Cables
I/O Cables to Modems
and User Devices
LIC 2
02
13
46
57

Hardware Overview 1-3
LAN Adapters
An FRX6000 can contain one or two LAN cards (Two Ethernet, or
one Ethernet and one Token Ring).
Figure 1-3 Lan Cards
Operator Interfaces
The FRX6000 does notrequire any operator intervention for normal
operation. However, akeyboard and VGA monitor are necessary for
local software installation, and a local monitor or local/remote asyn-
chronous terminal(via the COM1 port) are necessary for configu-
ration and monitoring.
The async terminal’s keyboard musthave[F1]–[F10] function keys as
well as [PgUp] and [PgDn] keys.
Ethernet Token Ring
RJ45
DB15
BNC
DB9
RJ45

1-4 FRX6000MaintenanceGuide,Rev 03
Standard PC keyboard functionkeys arerepresentedasfollows on a
VT100.(^[is[Esc], and the following character is an uppercase letter
O.)
Standard VT100
Keyboard Keypad Map to:
[F1] [PF1] ^[0P
[F2] [PF2] ^[0Q
[F3] [PF3] ^[0R
[F4] [PF4] ^[0S
[F5] [5] ^[0u
[F6] [6] ^[0v
[F7] [7] ^[0w
[F9] [,] (comma) ^[0l
[F10] [.] (period) ^[0n
[PgUp] [Up Arrow] ^[0A
[PgDn] [Down Arrow] ^[0B
Each FRX6000 is shipped with cables to allow connection to the
device from an ASCI terminal orfrom a PC with terminal emulation.
(See Figure A-9 through Figure A-11.)
A keyboard and video device can also be connected via one of these
methods:
●ASCII terminal/keyboard (or PC with terminal emulation)
connected to an async PAD port in the local FRX6000.
●ASCII terminal/keyboard (or PC with terminal emulation)
connected to an async PADport in a remoteCabletron frame
relay device (FRX6000, FRX4000, SmartSwitch 1800, or
9W004), through a network, into an X.25 port in the local
FRX6000.
●Keyboard and videodeviceon aremoteCabletronframerelay
device.
Remotemonitoring and configuration ofanyFRX6000
with IP and SNMPconfigured can be performed via
Cabletron’s Spectrumnetwork managementplatform, or
viaa HewlettPackard® workstation with HPOpenView
and Netlink OmniView.

Chapter 2
Diagnostic Procedures
All of the procedures in this chapter require an attached
VGA monitor. You should alsohave a diagnostic diskette
(suchas CheckIt®)anda bootable 1.4MBblank diskette,
to analyze the system configuration.
Once an FRX6000 is operational, much diagnostic information is
availablethrough menu-leveloperations (described in the Netlink
FRX4000& FRX6000 UserGuide). However, some problemsmight
arise that do not readily identify themselves through system error
messagesorobviouschangesin operation. Thischapter describesthe
procedures for verifying correct configuration and operation of an
FRX6000. It also provides some guidelines for pursuinga solution if
there is aproblem.
When an FRX6000 is switched on, the following should occur:
●The fan(s) and the power light on the front panel will come on.
●BIOS identifying information will be displayed.
●There will be a short beep as memory is tested, and the screen
will display the memory being counted.
●Each disk drive’s access light willcome on as the disks are
searched for the necessary DOS boot files.
●As the software is loaded, messages will be displayed.
If there are problems during boot-up, error messages will be dis-
played, and the process will continue after the message has been dis-
played for a short time (so watch the screen carefully).

2-2 FRX6000MaintenanceGuide,Rev 03
Once the software has correctly loaded, a screen similar to the fol-
lowing will be displayed.
Figure 2-1 Port Status Display
From this screen, you should be able to log into the Main Menu
(Figure 2-2), which is the starting point for configuration and oper-
ation procedures.
Node Name=node 10
Port Status Display (Page 1)
L P Type PPS Conn# State L P Type PPS Conn# State
0 0 X25 62 4 Operational 0 1 X25 127 12 Operational
0 2 X25 112 7 Operational 0 3 X25 60 6 Operational
0 4 SNA 110 3 Operational 0 5 X25 87 5 Operational
1 0 ASY 0 0 Link_disable 1 1 X25 88 4 Operational
F1: C ontinue

Diagnostic Procedures 2-3
Figure2-2 Main Menu
It can probably be asssumed that if you are reading this chapter, the
node did not boot correctly as described. The remainder of this
chapterdescribes steps foridentifying and fixing someproblems.
Certain problems may beeasy to track down; for example:
●If there seems to be no power at all, check to make sure the
powercord issecurely connected atbothends and thatthere is
power (of the appropriate voltage) at the receptacle.
●If there is power but the hardware does not seem to be func-
tioning properly, verify the correct setting of the AC voltage
selector switch. (See Chapter 3.)
●If there is an obvious problem with one or more hardware
components, go to Chapter 3.
●If the node appears to boot correctly but there is a communi-
cation problem with an async terminal, go to "COM Port
Interface Controls" on page 2-20.
Node Name = node 10
Software Version 4.0
M A I N M E NU
A Configuration
B Operation
C Status Displays
D Events
E Statistics
F Reports
Sekect:

2-4 FRX6000MaintenanceGuide,Rev 03
If the problem is less clear, follow this plan:
Reboot with diagnostic
diskette and
run diagnostics
Is
FRX6000
software starting?
(should see boot
messages)
No
Power on and
monitor screen
messages
Was
problem
identified?
Can
BIOS setup
(pa
g
e 2-17)
fix it?
Run BIOSsetup
(seepa
g
e 2- 17 ),
then reboot
Yes Yes No
Yes
Monitor boot
messages
(see pa
g
e 2-5)
Is
FRX6000
software
starting?
Yes
No
Is
there still a
problem? Yes
No
Yes Yes
No
No
No
Yes
All
done Contact Cabletron Systems Technical Support at:
Phone: [phone]
FAX: [phone]
E-mail: [e-mail]
Fix, then
reboot
Can
you fix the
problem?
Can you
identifythe
problem?
Can you
identifythe
solution?
No

Diagnostic Procedures 2-5
Reviewing Boot Messages
As an FRX6000 boots, screen information tracks the loading of
cards, verifies configuration file format,and displays any errors.
This data is displayed only until the FRX6000 software is running;
however, it issaved ina file named BOOTRPT.TXT, and the operator
canlater display it in a report. Thiscan be used asa tool to verifythat
startup ofthe node proceeded without errors,orto remindthe userof
the number and types of RLPs in the node. If there is an error
reported, the data may aid in fixing the problem.
If a node is shut down, then rebooted, the existing BOOTRPT.TXT
filewillberenamed BOOTBAK.TXT,anda newBOOTRPT.TXT will
be created. BOOTRPT.TXT and BOOTBAK.TXTcan be used as
follows:
1. Display and review the data from the “current” boot of the node.
2. Address any reported problems.
3. Re-boot thenode.(This copies theprevious boot data to a
backup file.)
4. Display the new boot data, and compare it to the previous data.
This will show whether the problem was fixed. Also, a problem
that occurred during the previous boot-up will often be cleared
upby re-booting.
Todisplaythe data fromthe current boot-up, press [C] at the Reports
Menu (or [F], then[C] from the Main Menu). To display the data from
the previous boot-up (saved in a file called BOOTBAK.TXT), press
[D] at the Reports Menu (or [F], [D] from the Main Menu).

2-6 FRX6000MaintenanceGuide,Rev 03
Boot Messages
Many boot messagesare “normal”messages, and are described here
simply for information. Others are error messages, and include rec-
ommended action. After taking the recommended action for an error
message, reboot the node. If the problem has not been corrected,
contact Cabletron Systems Technical Support at:
Phone: [phone]
FAX: [phone]
E-mail: [e-mail].
Boot messages are listed below in alphabetical order.
Boot Time: nn/nn/19nn–nn:nn:nn
Meaning: This is the date and time of the current boot-up.
Action: None.
Buffers: Xmt count “n,” Xmt size “n,” Rcv count “n,” Rcv size “n”
Meaning: These values denote the numbers and sizes of the
pre-fetch buffers used by the LANinterface.
Action: None.
Can’t Initialize Memory, “NNN”.CMP
Meaning: There is not enough memory in the FRX6000 to
load the RLP software(if “NNN” is "BOOTUP")or
the VxWorks software (if “NNN” is "VXWORKS").
An FRX6000 has 1 MB of memory, but only the
640 KB of base memory is needed to load and run
the software. If one of these messages isdisplayed,
some of that base memory is faulty.
Action: Check all the installed memory for proper seating.
If it is all securely installed, replaceeach module
and reboot, one ata time.
Can’t open COFF file, “NNN”.CMP
Meaning: Either the compressed boot(if“NNN”is "BOOTUP")
or VxWorks (if“NNN” is "VXWORKS") file handle
could not be foundduring RLP softwareloading.
