EPSON ActionNote 800 Series
Serial
External
keyboard/
mouse
Phone jack
RS-232C, programmable, asynchronous,
9-pin, D-sub male connector
Auto-sensing, 6-pin mini-DIN connector
for a PSI 2-type external keyboard,
keypad, or pointing device
Standard RJ-11 connector with optional
internal fax/ modem installed
Speaker Internal; automatically disabled when
optional audio card is installed and
Line-out is used
Audio input
and output Connectors for microphone, Line-in, and
Line-out when optional audio card is
installed
Port replicator
Keyboard
Connector for ActionPort™ replicator
85 keys; 101-key keyboard compatible;
embedded numeric keypad; Fn key for hot
key commands
Trackpad
Fax/Modem
Built-in pointing device with two buttons
Optional internal 14.4 baud send/ receive
fax/ modem
Volume Knob adjusts sound of internal speaker or
Control audio card (if installed)
Software
Latest versions of MS-DOS® and Microsoft
Windows™Borland® SideKick® for
Windows; ClarisWorks® for Windows;
trial versions of CompuServe® WinCIM,®
America Online,® and OAG FlightDisk;®
drivers and utilities for PCMCIA card
slots, video system, and trackpad; on-line
version of User’s Guide, Windows manual,
and other manuals; power management
utilities; all installed on the hard disk
drive; refer to Software Support Card for
details on EPSON’s support policy
Mass Storage
Hard disk drive
LED Panel
Name
Meaning
Computer is on
Green -Standby mode; press any key to
return to full power
Flashing green -Suspend mode; press
Suspend/Resume button to return to full
power
Orange -battery is charging normally
Green -battery is fully charged
Flashing orange -battery is not installed
correctly or is damaged
Computer is accessing the diskette drive
Computer is accessing the hard disk drive
Computer is accessing a PC card
Num Lock is on, which activates the
embedded numeric keypad
Caps Lock is on
Scroll Lock is on
Power
Suspend
Charge
Diskette drive
Hard disk drive
PCMCIA
One removable internal IDE hard disk
drive, 2.5-inch form factor; maximum
height 19 mm; Setup automatically
recognizes and configures drives that
support the IDE interface; parameters for
the Toshiba MK1824FCV are as follows:
Num Lock
Caps Lock
Scroll Lock
Capacity 335MB
Heads 16
Sectors 63
WP Com 0
Power Sources
AC adapters
Cylinders 682
Landing Zone
682
Diskette drive Internal 3.5-inch diskette drive; 720KB or
1.44MB format; supports lower power
consumption
Lightweight
AC adapter
(A882051)
2 folding connectors
6 ft (2 meters)
100 VAC to 240 VAC
50/60 Hz
19 VDC, 1.23 Amp
maximum
International
AC adapter
(A882101)
6 ft (2 meter) cable
6 ft (2 meters)
100 VAC to 240 VAC
50/60 Hz
19 VDC, 1.5 Amp
maximum
3.4” (86 mm) 3.4” (86 mm)
2.2” (56 mm) 2.2” (56 mm)
1.1” (28 mm) 1.1” (28 mm)
7.8 oz (220 g) 9 oz (255 g)
Specification
AC connection
LCD Screen
DC cable
Input voltage
Screen type
(all backlit)
Input frequency
Passive color Active colorMonochrome
640 x 480,64
gray shades
9.4 inches
Resolutions
and colors 640 x 480
256 colors
640 x 480
256 colors Output voltage
Diagonal
measurement 10.3 inches 10.4 inches
Length
Setup Program Stored in ROM; accessible by pressing F8
at system startup; includes power
management utilities
Width
Height
Weight
AN800-2
12/9/94
