Epson C12C824052 (Internal Type-B 10/100Base-T High Speed Ethernet Print... User manual

Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
R4CB110
User’s Guide Rev.C
Front.fm A5 size
8/21/03
R
EpsonNet 10/100 Base Tx High Speed Int. Print Server
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written permission of Seiko Epson Corporation.
The information contained herein is designed only for use with this Epson product. Epson
is not responsible for any use of this information as applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this
product or third parties for damages, losses, costs, or expenses incurred by purchaser or third
parties as a result of: accident, misuse, orabuse ofthis product or unauthorized modifications,
repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with
Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation shall not be liable against any damages or problems arising from
the use of any options or any consumable products other than those designated as Original
Epson Products or Epson Approved Products by Seiko Epson Corporation.
EPSON and EPSON ESC/P are registered trademarks and EPSON Stylus™ is a trademark
of Seiko Epson Corporation.
NetWare and Novell are registered trademarks of Novell, Inc.
Apple, Macintosh, AppleShare, LaserWriter, AppleTalk, LocalTalk, EtherTalk,
OpenTransport, Kanji-Talk, and Rendezvous are registered trademarks of Apple Computer,
Inc.
PostScript is a registered trademark of Adobe Systems, Inc.
Unix is a registered trademark in the United States and other countries, licensed exclusively
through X/Open Company Limited.
IBM, OS/2, OS/2 Warp, WebExplorer, NetFinity, AIX are trademarks of IBM Corp.
LANDesk, NetPort are trademarks of Intel Corp.
Microsoft, Windows, Windows NT, Internet Explorer, ActiveX are registered trademarks of
Microsoft Corp.
SPARC, SunOS, Solaris, Java are trademarks of Sun Microsystems, Inc.
SCO UNIX, SCO UnixWare are registered trademarks of The Santa Cruz Operation, Inc.
HP, HP-UX, PCL, HPGL are registered trademarks of Hewlett-Packard Company.
This product Includes software developed by the University of California, Berkeley, and Its
contributors.
General Notice: Other product names used herein are for identification purposes only and may be
trademarks of their respective owners. Epson disclaims any and all rights in those marks.
Copyright © 2003 by Seiko Epson Corporation, Nagano, Japan.
®
User’s Guide
NPD0282-00

ii
R4CB110
User’s Guide Rev.C
Front.fm A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
FCC Compliance Statement
For United States Users
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio or television
reception. However, there is no guarantee that interference will not occur in a particular
installation. If thisequipment does cause interference to radio and television reception,which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures.
❏Reorient or relocate the receiving antenna
❏Increase the separation between the equipment and receiver
❏Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
❏Consult the dealer or an experienced radio/TV technician for help.
WARNING
The connection of a non-shielded equipment interface cable to this equipment will invalidate
the FCC Certification of this device and may cause interference levels which exceed the limits
established by the FCC for this equipment. It is the responsibility of the user to obtain and
use a shielded equipment interface cable with this device. If this equipment has more than
one interface connector, do not leave cables connected to unused interfaces.
Changes or modifications not expressly approved by the manufacturer could void the user’s
authority to operate the equipment.
For Canadian Users
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
For European Users
This device complies with EU directives, 89/336/EEC.

iii
R4CB110
User’s Guide Rev.C
Front.fm A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
DECLARATION of CONFORMITY
According to 47CFR, Part 2 and 15 for Class B Personal Computers and
Peripherals; and/or CPU Boards and Power Supplies used with Class B
Personal Computers:
Declare under sole responsibility that the product identified herein, complies
with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device. Each
product marketed, is identical to the representative unit tested and found to
be compliant with the standards. Records maintained continue to reflect the
equipment being produced can be expected to be within the variation
accepted, due to quantity production and testing on a statistical basis as
required by 47CFR §2.909 Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that
may cause undesired operation.
We: Epson America, Inc.
Located at: MS 3-13
3840 Kilroy Airport Way
Long Beach, CA 90806
Telephone: [phone]
Trade Name: Epson
Type of Product: Network Interface Card
Model: EU-74

iv
R4CB110
User’s Guide Rev.C
Front.fm A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee

v
R4CB110
User’s Guide Rev.C
UG.TOC A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Contents
Introduction
About Your Print Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Warnings, Cautions, and Notes . . . . . . . . . . . . . . . . . . . . . . . . . .3
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Supported Epson Printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Features of the Print Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Print Server Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
About the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Terms and Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Chapter 1 Installing Components on Your Computer
About Installing Components on Your Computer. . . . . . . . . . . . . .15
Windows Me/98/95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Windows Server 2003 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Windows NT 4.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Mac OS 8.x to 9.x. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

vi
R4CB110
User’s Guide Rev.C
UG.TOC A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Chapter 2 How to Set Up the Print Server
Connecting the Print Server to the Network . . . . . . . . . . . . . . . . . . 31
Installing EpsonNet WinAssist/MacAssist . . . . . . . . . . . . . . . . . . . 34
For Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
For Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Setting an IP Address Using EpsonNet WinAssist . . . . . . . . . . . . . 37
Setting an IP Address Using EpsonNet MacAssist . . . . . . . . . . . . . 43
Chapter 3 EpsonNet WinAssist Configuration Utility
About EpsonNet WinAssist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Menu Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Timeout option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Search method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Search options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Firmware update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Details of the Configuration Dialog Box. . . . . . . . . . . . . . . . . . . . . . 56
Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
NetWare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
MS Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
AppleTalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
IPP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
About Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Configuring the Print Server Using EpsonNet WinAssist
EasySetup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Chapter 4 EpsonNet MacAssist Configuration Utility
About EpsonNet MacAssist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Menu Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Timeout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Network path search setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Search options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

vii
R4CB110
User’s Guide Rev.C
UG.TOC A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Details of the Configuration Dialog Box . . . . . . . . . . . . . . . . . . . . . .86
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
AppleTalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
IPP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
About Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Configuring the Print Server Using EpsonNet MacAssist
EasySetup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Chapter 5 Installing the Printer Driver
Windows Me/98/95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
LPR printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Internet printing (Windows 98/95) . . . . . . . . . . . . . . . . . . . . . .99
Internet printing (Windows Me) . . . . . . . . . . . . . . . . . . . . . . .100
Microsoft Network Shared printing . . . . . . . . . . . . . . . . . . . .101
Installing a printer driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Using the NET USE command . . . . . . . . . . . . . . . . . . . . . . . . .103
Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
LPR printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Internet printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Microsoft Network Shared printing . . . . . . . . . . . . . . . . . . . .108
Installing a printer driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Using the NET USE command . . . . . . . . . . . . . . . . . . . . . . . . .109
Windows Server 2003 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
LPR printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Internet printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Microsoft Network Shared printing . . . . . . . . . . . . . . . . . . . .115
Installing a printer driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Using the NET USE command . . . . . . . . . . . . . . . . . . . . . . . . .117
Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
LPR printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Internet printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Microsoft Network Shared printing . . . . . . . . . . . . . . . . . . . .121
Installing a printer driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Using the NET USE command . . . . . . . . . . . . . . . . . . . . . . . . .123

viii
R4CB110
User’s Guide Rev.C
UG.TOC A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Windows NT 4.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
LPR printing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Internet printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Microsoft Network Shared printing . . . . . . . . . . . . . . . . . . . . 125
Installing a printer driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Using the NET USE command . . . . . . . . . . . . . . . . . . . . . . . . 127
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Mac OS 8.x to 9.x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
OS/2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
LPR printing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
NetBEUI printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Chapter 6 Settings for NetWare Server
Introduction to NetWare Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Supported systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
About modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Instructions for Using NetWare . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Using Bindery Print Server (NetWare 3.x/4.x) . . . . . . . . . . . . . . . 138
Using NDS Print Server (NetWare 4.x/5.x/6.0) . . . . . . . . . . . . . . 139
Using Remote Printer Mode (NetWare 3.x) . . . . . . . . . . . . . . . . . . 140
Using Bindery Remote Printer Mode (NetWare 4.x) . . . . . . . . . . 144
Using NDS Remote Printer Mode (NetWare 4.x/5.x/6.0) . . . . . . 146
Using the NDPS Gateway. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Outline of settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Making printer environment . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Creating an NDPS Manager . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Creating a Printer Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Configuring for NetWare using EpsonNet WinAssist . . . . 157
Setting the printer on client workstations . . . . . . . . . . . . . . . 158
Instructions for Using a Dial-Up Network . . . . . . . . . . . . . . . . . . . 159
Using a dial-up network in each mode . . . . . . . . . . . . . . . . . 159
When there is a primary server at the dial-up destination . 160
When there is a primary server in the local network. . . . . . 162

ix
R4CB110
User’s Guide Rev.C
UG.TOC A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Chapter 7 Settings for UNIX
Introduction to UNIX Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
lpr filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
Setting Up Different UNIX Systems Using the lpr Command . . .164
Setting up for SunSoft Solaris 2.4 or later . . . . . . . . . . . . . . . .165
Setting up for SunOS 4.1.4 or later. . . . . . . . . . . . . . . . . . . . . .166
Setting up for IBM AIX 3.2.5 or later and 4.1.3 or later. . . . .167
Setting up for HP-UX 9.05 or later . . . . . . . . . . . . . . . . . . . . . .168
Setting up for SCO UNIX 4.2 or later (Open Server). . . . . . .169
Using the ftp Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171
Chapter 8 EpsonNet Direct Print
About EpsonNet Direct Print. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
Installing EpsonNet Direct Print . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
Setting Up Your Printer Using EpsonNet Direct Print . . . . . . . . .175
Adding a printer located in the same segment . . . . . . . . . . .176
Adding a printer beyond a router . . . . . . . . . . . . . . . . . . . . . .178
Adding a printer from the Printers folder . . . . . . . . . . . . . . .180
Installing the printer driver. . . . . . . . . . . . . . . . . . . . . . . . . . . .182
Configuring the Printer Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .184
Windows Me/98/95/NT 4.0 . . . . . . . . . . . . . . . . . . . . . . . . . .184
Windows XP/Server 2003/2000. . . . . . . . . . . . . . . . . . . . . . . .186
Chapter 9 EpsonNet Internet Print
About EpsonNet Internet Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . .189
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190
Installing EpsonNet Internet Print . . . . . . . . . . . . . . . . . . . . . . . . . .190
Setting Up Your Printer Using EpsonNet Internet Print . . . . . . . .191
Windows 98/95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191
Windows NT 4.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .196
Status Alert Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199

x
R4CB110
User’s Guide Rev.C
UG.TOC A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Chapter 10 EpsonNet WebAssist
About EpsonNet WebAssist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Supported Web browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
About Web browser setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Configuring the Print Server Using EpsonNet WebAssist. . . . . . 202
Opening Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Configuration - Network Screens . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
NetWare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
AppleTalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
MS Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
IPP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Optional Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Administrator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Chapter 11 EpsonNet WebManager
About EpsonNet WebManager . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222
EpsonNet WebManager Functions . . . . . . . . . . . . . . . . . . . . . . . . . 223
EpsonNet WebManager Operating Structure . . . . . . . . . . . . . . . . 224
Installing EpsonNet WebManager. . . . . . . . . . . . . . . . . . . . . . . . . . 226
Starting EpsonNet WebManager . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Opening the Online Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

xi
R4CB110
User’s Guide Rev.C
UG.TOC A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Chapter 12 Troubleshooting
General Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .229
Problems Specific to Your Network Environment . . . . . . . . . . . . .233
Windows Me/98/95 environment . . . . . . . . . . . . . . . . . . . . .233
Windows 2000/NT environment. . . . . . . . . . . . . . . . . . . . . . .234
Macintosh environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .235
NetWare environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .236
Initializing the Print Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .237
Setting the Interface Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .238
Using EpsonNet Win/Mac/WebAssist . . . . . . . . . . . . . . . . .238
Using jumpers on the print server . . . . . . . . . . . . . . . . . . . . . .238
Appendix A Tips for Administrator
Selecting a Printing Method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241
Printing from Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241
Printing from Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .242
Features of the Printing Methods . . . . . . . . . . . . . . . . . . . . . . . . . . .242
LPR (TCP/IP) printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .242
Internet printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .243
Microsoft Network Shared printing . . . . . . . . . . . . . . . . . . . .243
Setting an IP Address Using the arp/ping Command . . . . . . . . .244
Checking the LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .245
Setting and checking the new IP address . . . . . . . . . . . . . . . .246
Instructions on Using a Dial-Up Router. . . . . . . . . . . . . . . . . . . . . .247
Function of Universal Plug and Play . . . . . . . . . . . . . . . . . . . . . . . .248
Uninstalling Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .249
Windows Me/98/95/2000/NT 4.0 . . . . . . . . . . . . . . . . . . . . .249
Windows XP/Server 2003. . . . . . . . . . . . . . . . . . . . . . . . . . . . .249
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .249

xii
R4CB110
User’s Guide Rev.C
UG.TOC A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Appendix B Specifications
Print Server Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
Regulatory Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
Reliability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
Network Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
Index

Introduction 1
R4CB110
User’s Guide Rev.C
INTRO.FM A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Introduction
About Your Print Server
The EpsonNet 10/100 Base Tx High Speed Int. Print Server is a
print server that plugs into an optional interface slot of an Epson
printer to enable the printer to connect directly to your network.
Because the print server supports multiple protocols and
automatically detects protocols on your network, you can print
from Microsoft®Windows®, Apple®Macintosh®, UNIX®, and
IBM®OS/2 applications.
Use EpsonNet WinAssist/MacAssist/WebAssist, the
configuration utilities provided with your product, to quickly and
easily configure the print server to use protocols such as TCP/IP,
NetWare, NetBEUI, AppleTalk®, IPP, and SNMP.
Note:
The EpsonNet WinAssist/MacAssist/WebAssist utility configures the
print server to work only with protocols that exist on your network. This
does not imply that you can use all of the above-mentioned protocols on
your network or operating system. The protocols that the print server
can use may vary depending on the operating system and the network
configuration.

2Introduction
R4CB110
User’s Guide Rev.C
INTRO.FM A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Important Safety Instructions
Read all of these instructions and save them for later reference.
❏Do not install or uninstall the print server with wet hands.
❏Be careful not to drop or crush the print server when
installing.
❏Keep the print server away from humidity and dust.
❏Do not allow children to handle the print server.
❏When installing or uninstalling the print server, be sure to
remove the Ethernet cable, turn off your printer, and then
unplug the power cord to avoid electric shock.
❏Avoid using the print server if there is smoke, strange smell,
or strange sound; otherwise this could cause fire or electric
shock. Instead, immediately turn off the printer, unplug the
power cord, and then contact your Epson dealer. Do not
repair it yourself because this is dangerous.
❏Do not disassemble or modify the print server unless
specifically instructed in the guide. This could cause injury,
electric shock, or fire.

Introduction 3
R4CB110
User’s Guide Rev.C
INTRO.FM A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
About This Guide
This User’s Guide contains information about using the print
server on a network. It includes how to set up the print server,
install the configuration software, and modify network settings
of your printer and computers.
For information about your printer, see the manual shipped with
your printer.
Note:
❏This guide is written for network administrators, and many of the
steps included here require detailed network knowledge and
administrator rights.
❏The term network administrator refers to the person responsible for
maintaining the network. “Administrator” is synonymous with
“Supervisor” in this guide.
❏The term “print server” refers to the EpsonNet 10/100 Base Tx High
Speed Int. Print Server in this guide.
❏Some screen shots in this guide may list a printer name other than
your printer. This difference does not alter the instructions.
Warnings, Cautions, and Notes
wWarnings
must be followed carefully to avoid bodily injury.
cCautions
must be observed to avoid damage to your equipment.
Notes
contain important information and useful tips on the operation of the
print server.

4Introduction
R4CB110
User’s Guide Rev.C
INTRO.FM A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Package Contents
Your print server package includes the following items:
❏Print server (The utility EpsonNet WebAssist is pre-installed
on this server.)
❏Software CD-ROM containing:
-- EpsonNet WinAssist
-- EpsonNet MacAssist
-- EpsonNet Direct Print
-- EpsonNet Internet Print
-- EpsonNet WebManager
-- User’s Guide (PDF-format manual)
-- Acrobat Reader (for Windows only)
❏Online Guide Supplement Sheet
Note:
You need to supply items such as a computer with an Ethernet network
interface, an Epson printer with an optional interface slot, and an
Ethernet cable (Category 5 shielded twisted-pair cable).

Introduction 5
R4CB110
User’s Guide Rev.C
INTRO.FM A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Operating Environment
The print server supports the following environments.
OS Version Protocol
Windows 98
Windows 98 SE
Windows 95
- TCP/IP (using EpsonNet Direct
Print)
IPP (using EpsonNet Internet
Print)
NetBEUI
Windows Me - TCP/IP (using EpsonNet Direct
Print)
IPP
NetBEUI
Windows XP
(Home,
Professional)
Windows Server
2003
Windows 2000
(Professional,
Server)
- TCP/IP (using LPR, Standard
TCP/IP Port, or EpsonNet Direct
Print)
IPP
Windows NT 4.0 with
Support Pack 5 or
higher
- TCP/IP (using LRP or EpsonNet
Direct Print)
IPP (using EpsonNet Internet
Print)
NetBEUI
Macintosh Mac OS X 10.x,
9.x, 8.x
AppleTalk

6Introduction
R4CB110
User’s Guide Rev.C
INTRO.FM A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Note:
❏Only the Intel version of Windows NT is supported.
❏The multi-user environment of Mac OS 9 is not supported.
❏If you use the printer in a dial-up router environment, you must set
an IP address for the printer. Make sure the IP address is suitable
for the segment; incorrect IP address may generate unexpected
dial-up.
NetWare 3.x Bindery mode
4.x/IntranetWare NDS mode
Bindery emulation mode
5.x/6.0 NDS Queue-based print
system
NDPS
OS/2 (OS/2 Warp
Connect, OS/2
Warp Server)
V3
V4
TCP/IP (lprportd)
NetBEUI
UNIX Sun OS 4.1.4 or
later: SPARC
lpr, ftp
SunSoft Solaris 2.4
or later: SPARC
and x86
SCO UNIX 4.2 or
later
SCO UnixWare
2.01 or later
HP/UX 9.05 or
later
IBM AIX 3.2.5 or
later and 4.1.3 or
later
OS Version Protocol

Introduction 7
R4CB110
User’s Guide Rev.C
INTRO.FM A5 size
8/21/03
R
Proof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Supported Epson Printers
The print server can be installed for the following Epson printers
(as of August, 2003).
❏Ink Jet Printer:
Stylus Pro 4000
Note:
The supplied current must be 800 mA or higher. (900 mA or higher is
recommended.)
Features of the Print Server
❏Provides high performance.
❏Connects an Epson printer equipped with an optional
interface slot to the network.
❏Supports multiple protocols, such as TCP/IP, NetWare,
NetBEUI, AppleTalk, and IPP.
❏Supports 100Base full duplex, 100Base half duplex, 10Base full
duplex, and 10Base half duplex.
❏Supports DHCP.
❏Supports Automatic Private IP Addressing (APIPA) that
assigns an IP address automatically to the print server even if
there is no DHCP server on the network.
❏Supports the Dynamic DNS function.
❏Supports SNMP and MIB.
❏Support Rendezvous on Mac OS X 10.2.4 or higher.

8Introduction
R4CB110
User’s Guide Rev.C
INTRO.FM A5 size
8/21/03
LProof Sign-off:
KOW M. Arai H. Tomizawa
K. Nishi
NOC K. Lee
Print Server Operation
The status lights and status sheet provide you with important
information about the operation and configuration of the print
server.
Status lightStatus sheet button
RJ-45 connector
Data light
