NETGEAR PS105 User manual

NETGEAR print servers let you share printers among all users on the network without
having to dedicate a PC for print serving and without complex setup and configuration.
These print servers connect directly to the network and can be placed anywhere convenient
to the users. With a built-in network hub, the
PS105 is an all-in-one connectivity solution
for the SOHO users—providing file, print, and
resource sharing as well as network gaming.
™
NETGEAR
PS105/110
MODELS
10and 100Mbps PrintServers
YOUR CHOICE:
10 OR 100 Mbps
Free 24x7
TECHNICAL SUPPORT
PS105
10 Mbps Print Server
•Provides a built-in Ethernet Hub, saving space
and cost.
•Lets you share your printer and network your
PCs all in a few easy steps.
Best for home office or small business with 2 to 4
PCs, with or without an existing network in place.
PS110
10/100 Mbps Print Server
•Connects 2 parallel printers, e.g., a high-speed laser
printer and a color printer.
•Attaches to a 10 or 100 Mbps hub or switch,
providing effortless transition from Ethernet to
Fast Ethernet.
Best for small business or small office with multiple
printers and a 10 or 100 Mbps network.
Auto-sensing 10/100 Mbps network port (PS110).
Easy installation with FirstGear™, a Windows-based
configuration tool.
Extensive LED indicators for at-a-glance
status check.
Flash EPROM for easy download of
software updates.
KEY FEATURES
Built-in 4-port Ethernet hub to save space and
cost and a BNC port for serving coax networks
(PS105).
Simultaneous support for Windows, NetWare,
and UNIX printing.
Support for HP, Canon, Epson, and all major
parallel printers.
KEY FEATURES
•Built-in network hub
•All major network
software
•All major parallel
printers
•Easy installation
•Extensive LED
indicators
www.NETGEAR.com

PS105 PS110
Printer Port One IEEE 1284 Two IEEE 1284
bi-directional parallel-port bi-directional parallel-ports
Network Port Four 10BASE-T ports (RJ-45) One speed-sensing 10/100 Mbps port
IEEE 802.3i Ethernet compliant (RJ-45) compliant with
One 10BASE-2 port (BNC) IEEE 802.3i Ethernet and
IEEE 802.3u Fast Ethernet
Status LED
Unit power, collision power, collision
Printer connection link, activity, alert link, activity, alert (per printer port)
Network connection link, receive (per network port) link, 10 or 100 Mbps, receive, transmit
Network Protocol
TCP/IP, IPX/SPX, and NetBEUI
Dimensions
W 189 mm (7.41") D 122 mm (4.81") H 21 mm (1.21")
Weight
0.73 kg (1.6 lbs)
Power Specification
12V DC 0.6A max; 7W AC
Localized plug for North America, Japan, UK, Europe,Australia
Environmental Specifications
Operating temperature 0 to 40ºC (32 to 104ºF)
Operating humidity 90% maximum relative humidity,noncondensing
Electromagnetic Compliance
CE Mark, commercial
FCC Part 15 Class B
EN 55 022 (CISPR 22), Class B
VCCI class B ITE
Safety Agency Approvals (Power Adapter)
UL listed (UL 1950)
CSA certified (CSA 22.2 #950)
TUV licensed (EN 60 950)
T-Mark
Warranty
Print server: 5 years
Power adapter:2years
PACKAGE
CONTENTS
•Print server
•Power adapter
•Quick Installation
Guide
•Resource CD
•Warranty card
•Phone card
SPECIFICATIONS
123
NETWORK
4
PRINTER 12VDC 1.2A
Normal/Uplink
PS105 print server
Router for
Internet access
TYPICAL NETWORK SETUP
NETWORK
PRINTER 1 PRINTER 2 12VDC 1.2A
Model PS110 Print Server NETGEAR Model
DS108 hub
Auto10/100 Mbps DUALSPEED
10 Mbps
100 Mbps
NETGEAR™is a trademark of NETGEAR, Inc. Other brand and product
names are trademarks or registered trademarks of their respective holders.
Information is subject to change without notice. All right reserved.
NETGEAR Inc.
4500 Great America Parkway
Santa Clara, CA 95054
USA
Phone: 1-888-NETGEAR
E-mail: [email protected]
www.NETGEAR.com
In-Country Phone Support
(24x7 phone support in English,
local language support during
office hours.)
Australia 1800-787-638
Austria 00800-06384327
(00800-0-NETGEAR)
Denmark 808-82179
Canada 1-888-NETGEAR
Finland 0800-111-036
France 0800-77-17-53
Germany 00800-06384327
(00800-0-NETGEAR)
Hong Kong 001-800-1233-4566
Japan 0120-66-5402
Korea 00308-11-0319
Netherlands 0800-023-0981
New Zealand 00800-1233-4566
Norway 800-12041
Singapore 001-800-1233-4566
Sweden 0200-298-298
Switzerland 00800-0638-4327
(00800-0-NETGEAR)
United Kingdom 020-7216-0014
United States 1-888-NETGEAR
All Other Countries [phone]
November 2000
