Epson S5U1C88816P User manual

CMOS 8-BIT SINGLE CHIP MICROCOMPUTER
(Peripheral Circuit Board for S1C88816/8F360)
S5U1C88816P Manual
MF1337-02a

NOTICE
No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko
Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any
liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or
circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such
as medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there
is no representation or warranty that anything made in accordance with this material will be free from any patent or copyright
infringement of a third party. This material or portions thereof may contain technology or the subject relating to strategic
products under the control of the Foreign Exchange and Foreign Trade Law of Japan and may require an export license from
the Ministry of International Trade and Industry or other approval from another government agency.
© SEIKO EPSON CORPORATION 2001 All rights reserved.

Devices
S1 C 88104 F 0A01
Packing specifications
00 : Besides tape & reel
0A : TCP BL 2 directions
0B : Tape & reel BACK
0C: TCP BR 2 directions
0D: TCP BT 2 directions
0E : TCP BD 2 directions
0F : Tape & reel FRONT
0G: TCP BT 4 directions
0H: TCP BD 4 directions
0J : TCP SL 2 directions
0K : TCP SR 2 directions
0L : Tape & reel LEFT
0M: TCP ST 2 directions
0N: TCP SD 2 directions
0P : TCP ST 4 directions
0Q: TCP SD 4 directions
0R: Tape & reel RIGHT
99 : Specs not fixed
Specification
Package
D: die form; F: QFP
Model number
Model name
C: microcomputer, digital products
Product classification
S1: semiconductor
Development tools
S5U1 C 88348 D1 1
Packing specifications
00: standard packing
Version
1: Version 1
Tool type
Hx : ICE
Ex : EVA board
Px : Peripheral board
Wx: Flash ROM writer for the microcomputer
Xx : ROM writer peripheral board
Cx : C compiler package
Ax : Assembler package
Dx : Utility tool by the model
Qx : Soft simulator
Corresponding model number
88348: for S1C88348
Tool classification
C: microcomputer use
Product classification
S5U1: development tool for semiconductor products
00
00
S1C88 Family
Configuration of product number

S5U1C88816P MANUAL EPSON i
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
CONTENTS
S5U1C88816P Manual (Peripheral Circuit Board for S1C88816/8F360)
In this manual we will provide explanations covering such areas as the installation of the S1C88816/8F360
Peripheral Circuit Board (S5U1C88816P) that provides the S1C88816/8F360 emulation functions to the
debugging tool ICE (S5U1C88000H5) for the 8-bit single chip microcomputer S1C88 Family, and the
operating test procedure.
For details on the functions and operation of the ICE, refer to the manual that has been prepared for it.
Contents
1 INTRODUCTION ______________________________________________ 1
1.1 S5U1C88816P Outline ............................................................................................. 1
1.2 S5U1C88816P Components ..................................................................................... 1
1.3 S5U1C88816P External Diagram............................................................................ 1
2 INSTALLATION INTO THE ICE (S5U1C88000H5) __________________ 2
3 PRECAUTIONS________________________________________________ 3
3.1 Precaution for Operation ......................................................................................... 3
3.2 Differences from Actual IC....................................................................................... 3
4 NAMES AND FUNCTIONS OF PARTS ____________________________ 5
5 CONNECTION TO TARGET SYSTEM_____________________________ 6
6 OPERATION CHECK___________________________________________ 9
7 PRODUCT SPECIFICATIONS ___________________________________ 10

S5U1C88816P MANUAL EPSON 1
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
1 INTRODUCTION
1 INTRODUCTION
1.1 S5U1C88816P Outline
The S5U1C88816P board provides the peripheral
circuits other than the core CPU, for the S1C88816/
8F360. Consequently, you should install it into the
ICE and use it as the emulator for the S1C88816/
8F360 models.
The S5U1C88816P is equipped with LEDs and
terminals for monitoring the internal operating
conditions, I/O connection connectors for the
target system and other appropriate devices.
1.2 S5U1C88816P Components
When unpacking the S5U1C88816P, check that the
following goods are present:
(1) S5U1C88816P board .......................................1
(2) I/O connection cable (80-pin/40-pin flat type ×2) .. 2 sets
(60-pin/30-pin flat type ×2) .. 1 set
(3) I/O connector for target system (40-pin) .........4
(30-pin) .........2
(4) Cable for monitor terminal (10-pin) ................1
(5) S5U1C88816P Manual (Peripheral Circuit
Board for S1C88816/8F360) (this manual) .....1
(6) Warranty ..........................................................1
(7) Warranty registration card ...............................1
(8) Report on the factory test .................................1
(9) Note for using ..................................................1
1.3 S5U1C88816P External Diagram
Fig. 1.3.1 S5U1C88816P external drawing
Note: Keep the JP switch on the S5U1C88816P
board as it was set prior to factory shipment.
In no case should you remove it or change
it.
I/O #2
I/O #1
I/O #3
MONITOR
VSVD
LCDC
SVDON
OSCC
VDC1
RESET
LCD4.5V
LCD5.5V
EXLCD
HVLD
MODE
VDC2
VDC0
EPSON
E0C88816/F360Peripheral circuit board
PRC88816
Mother board J2 connector
Mother board J1 connector
RESET switchLED
VSVD volume
Monitor connector for LED
I/O#2 connector
I/O#3 connector
I/O#1 connector
Monitor pins
GND
OSC1CR
VR3 (OSC3CR ADJ)
VR2 (OSC1CR ADJ)
OSC3CR
∗The name 'PRC88816' on the
development tool is the old
name of the product.

2EPSON S5U1C88816P MANUAL
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
2 INSTALLATION INTO THE ICE (S5U1C88000H5)
2 INSTALLATION INTO THE ICE (S5U1C88000H5)
Insert the S5U1C88816P along by the upper guide rail of the ICE, until it touches the edge of the
S5U1C88816P.
Note: The S5U1C88816P may fail to operate if it is not adequately mounted, so be sure to mount it
securely.
ICE88UR
I/O#2
I/O #1
I/O #3
MONITOR
VSVD
LCDC
SVDON
OSCC
VDC1
RESET
LCD4.5V
LCD5.5V
EXLCD
HVLD
MODE
VDC2
VDC0
EPSON
E0C88816/F360Peripheralcircuitboard
PRC88816
∗The name 'ICE88UR' on
the development tool is the
old name of the product.

S5U1C88816P MANUAL EPSON 3
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
3 PRECAUTIONS
3 PRECAUTIONS
Take the following precautions when using the S5U1C88816P:
3.1 Precaution for Operation
(1) Turn the power of all equipment off before
connecting or disconnecting cables.
(2) In normal use, other than when evaluating
power voltage changes, you should turn the
VSVD volume completely to the right.
When the SVD reset function has been selected
using the mask option, resetting will occur
when the VSVD volume is completely to the
left, due to the detection of low voltage, causing
the operation of the S5U1C88816P to stop.
Even if the SVD reset function has not been
selected using the mask option, since it will be
set to SVD reset function ON by default setting
until loading the mask option therefore, be sure
to turn the VSVD volume all the way to the
right when starting.
(3) The ICE has a built-in power supply fixed at 5
V. When the LCD drive power is externally
supplied to the S5U1C88816P installed in the
ICE, it must be 5 V or less. If an external LCD
drive power of more than 5 V is used to supply
the VC1–VC5 terminals of the S5U1C88816P,
both units may be destroyed due to the differ-
ence of the interface voltage in the ICE.
If external power is selected by mask option, it
is impossible to adjust contrast by setting the
LCD contrast adjustment registers LC0 to LC3
(register settings become invalid).
(4) The ICE discriminates between maximum
mode and minimum mode according to the
value set in the bus mode setup register
(FF00H•D6, D7). Note, however, that maxi-
mum/minimum mode is selected by mask
option in the S1C88816 and address FF00H is a
general-purpose register that does not indicate
the set mode. Therefore, it is necessary to write
data to bits D6 and D7 in address FF00H in the
initial routine executed after an initial reset to
configure the mode in the ICE.
The S1C88xxx needs writing to FF00H and
FF01H after an initial reset for releasing the
interrupt mask. At this time, the above D6 and
D7 bit data can be written simultaneously.
The values to be set are as follows:
For maximum mode: FF00H•D6 = "1", D7 = "1"
For minimum mode: FF00H•D6 = "0", D7 = "0"
3.2 Differences from Actual IC
Caution is called for due to the following function
and property related difference with the actual IC.
If these precautions are overlooked, it may not
operate on the actual IC, even if it operates on the
ICE with the S5U1C88816P installed.
(1)I/O differences
The logic level (5 V for the S5U1C88816P),
output drive capability and pull up resistance
are different. For this reason, an added circuit
such as a level shifter may be necessary when
interfacing with the target system. Also input
setup time is different therefore, when a circuit
requiring consideration of the input response
time, such as a key matrix, is used, you should
design the system and the software according
to the spec. for the actual IC.
(2)LCD differences
The output drive capability is different.
Since there will be difference with the actual IC
even for the drive voltage, you should design
the system and the software in order to adjust
the characteristics.
(3)Analog comparator differences
The response time and characteristics of the
analog comparator are different. Consequently,
you should design the system and the software
according to the spec. for the actual IC.
(4)Current consumption differences
The current consumption evaluation is impos-
sible.
(5)Function differences
<SVD circuit>
The SVD function is implemented by varying
the apparent power supply voltage with the
VSVD volume.
<Oscillation circuit>
• The S5U1C88816P has a built-in crystal oscilla-
tion circuit for OSC1. The crystal oscillation
frequency is fixed at 32.768 kHz.
• The OSC1 crystal oscillation circuit is the same
regardless of whether the gate capacitor is
connected or not.

4EPSON S5U1C88816P MANUAL
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
3 PRECAUTIONS
• If OSC1 is used in an oscillation frequency other
than 32.768 kHz, select "USER CLOCK" in the
"OSC1 SYSTEM CLOCK" of the "S5U1C88816P
OPTION" using winfog, and supply an external
clock with the desired frequency to the OSC1
terminal. Or select CR oscillation and adjust its
oscillation frequency using the VR2 control on
the S5U1C88816P. When adjusting the fre-
quency, use the OSC1CR pin on the board for
monitoring the CR oscillation frequency.
• The S5U1C88816P has built-in three types of
OSC3 oscillation circuits, crystal oscillation
circuit (4.9152 MHz), ceramic oscillation circuit
(8 MHz) and CR oscillation circuit (variable
frequency).
• If OSC3 is used in an oscillation frequency other
than 4.9152 MHz (crystal) and 8 MHz (ceramic),
select "USER CLOCK" in the "OSC3 SYSTEM
CLOCK" of the "S5U1C88816P OPTION" using
winfog, and supply an external clock with the
desired frequency to the OSC3 terminal. Or
select CR oscillation and adjust its oscillation
frequency using the VR3 control on the
S5U1C88816P. When adjusting the frequency,
use the OSC3CR pin on the board for monitor-
ing the CR oscillation frequency.
• When using an external clock for OSC1 or
OSC3, adjust the external clock (amplitude: 5 V
±5%, duty: 50% ±10%) and input into the OSC1
or OSC3 terminal with VSS as GND.
• In the S5U1C88816P, the oscillation stability
time of the OSC3 is short compared with the
actual IC. You should assure the time from
OSC3 oscillation start to OSC3 system clock
change (min. oscillation stability time required)
according to the actual IC using software.
• The timings such as the oscillation start and
stop times are different from those of the actual
IC because the logic level of S5U1C88816P is
higher than it of actual IC.
• When switching the clock from OSC3 to OSC1,
be sure to switch OSC3 oscillation OFF with
separate instructions. Using a single instruction
to process simultaneously can cause a malfunc-
tion of the CPU.
• Do not turn the OSC3 oscillation circuit ON in
the low power mode.
Do not switch over the operating mode (normal
mode ↔high speed mode) in the OSC3
oscillation circuit ON status, as this will cause
faulty operation.
<Internal power supply circuit>
On the actual IC, you can change over the
internal power voltage (set by VDC2, VDC1
and VDC0), but in the S5U1C88816P you
cannot change the actual power voltage, simply
by changing VDC2, VDC1 and VDC0.
For this reason, since the S5U1C88816P will
operate, even if the stable time required for
changeover is not taken, you should be sure
that the stable time is provided by the software.
Also, since the usable frequency of OSC1 and
OSC3 depends on the internal power voltage,
you should refer to the Technical Manual for
the S1C88816 or S1C8F360 and take care so as
not to operate it with an inappropriate combi-
nation.
When turning the OSC3 oscillation circuit after
switching the operating voltage, you should
allow a voltage stable waiting time of 5 msec by
the software.
<LCD drive power>
• When the internal LCD power is selected using
winfog, the S5U1C88816P generates the same
LCD drive voltage regardless of the selected
voltage (4.5 V or 5.5 V). However, the selected
voltage level is indicated with the LED.
• When external LCD power is selected using
winfog, the internal LCD power supply circuit
is disconnected and an external power can be
supplied to the VC1–VC5 terminals.
• Since the internal LCD power voltage is lower
than the power supply voltage (5 V), the
display contrast may be lowered if a 5.5 V LCD
panel is used. To check the LCD display in this
case, select external LCD power using winfog
and supply 5 V for the LCD drive voltage.
<Accessing unused addresses>
• When reading or writing to/from an unused
address in the I/O space and ROM/RAM
space, the value is undefined. Be aware that the
undefined value in the S5U1C88816P is differ-
ent from the actual IC.
• When the S5U1C88816P is used with the ICE,
accessing unused addresses can be detected
using the 88816.PAR (for S1C88816) or
88F360.PAR (for S1C8F360) file.

S5U1C88816P MANUAL EPSON 5
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
4 NAMES AND FUNCTIONS OF PARTS
4NAMES AND FUNCTIONS OF PARTS
This section describes the names and functions of the parts of the S5U1C88816P.
I/O#1
I/O#2
MONITOR
LCDC
VSVD
RESET
SVDONOSCCVDC1
LCD4.5V
LCD5.5V
EXLCDHVLDMODEVDC2VDC0
PRC88816
E0C88816/F360 Peripheral circuit board
EPSON
I/O#3
Fig. 4.1 Panel layout
(1)RESET switch
This switch resets the S5U1C88816P circuit, and
provides the reset signal to ICE.
(2)VDC2, VDC1 and VDC0 LEDs
The LED will go ON/OFF according to the
below combinations, depending on the internal
operating voltage that has been set.
Table 4.1 Display of VDC2, VDC1 and VDC0 LED
(8)LCD4.5V LED
This LED goes ON when the 4.5 V LCD power
supply is used.
(9)LCD5.5V LED
This LED goes ON when the 5.5 V LCD power
supply is used.
(10) EXLCD LED
This LED goes ON when an external LCD power
supply is used.
(11) VSVD volume
This is the volume for varying the power
supply voltage apparently to confirm the
supply voltage detection function. (Refer to
Section 3.2, "Differences from Actual IC".)
(12) LED monitor connector (MONITOR)
This is a connector for monitoring the above
LED signals. The following signals are output
from the connecter pins.
1 pin: VSS 2 pin: VDC0
3 pin: VDC1 4 pin: VDC2
5 pin: OSCC 6 pin: LCDC
7 pin: TBD 8 pin: TBD
9 pin: SVDON 10 pin: HVLD
Fig. 4.2 Pin assignment of LED monitor connector
(13) I/O #1, I/O #2 and I/O #3 connectors
These are the connectors for connecting the I/O
and LCD. The I/O cables (80-pin/40-pin ×2 flat
type and 60-pin/30-pin ×2 flat type) are used
to connect the S5U1C88816P to the target
system.
1 pin
2 pin
(3)OSCC LED
This LED goes ON when the OSCC register is
set to "1" and OFF when the register is set to "0".
(4)MODE LED
This LED goes ON when the S1C88 Core CPU
operates in maximum mode and OFF when it
operates in minimum mode.
(5)SVDON LED
This LED goes ON when the SVDON register is
set to "1" also during auto sampling operation,
and OFF when the register is set to "0".
(6)HVLD LED
This LED goes ON when the OSCC register or
BZON register is set to "1" and OFF when the
register is set to "0".
Furthermore, the LED goes ON during buzzer
or melody output when heavy load protection
mode is selected by mask option.
(7)LCDC LED
This LED goes ON when the LCD0 and LCD1
registers are set to "1" and OFF when the
registers are both set to "0".
Internal
operating voltage
1.3 V
2.2 V
3.3 V
VDC2
OFF
OFF
ON
LED
VDC1
OFF
ON
OFF
VDC0
ON
OFF
OFF

6EPSON S5U1C88816P MANUAL
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
5 CONNECTION TO TARGET SYSTEM
5 CONNECTION TO TARGET SYSTEM
This section describes how to connect the S5U1C88816P to the target system.
Note: Turn the power of all equipment off before connecting or disconnecting cables.
(1) The I/O #1, I/O #2 and I/O #3 connectors are
used to connect the S5U1C88816P to the target
system.
Use the attached I/O connection cable (80-pin/
40-pin ×2 flat type and 60-pin/30-pin ×2 flat
type) for connection. Connect the 80-pin and
60-pin connectors to the S5U1C88816P side and
the 40-pin ×2 and 30-pin ×2 connectors to the
target system side.
Be careful as power (VDD) is supplied to I/O #1
and #2 connectors.
(2) If a clock of a frequency other than that gener-
ated*by the internal oscillation circuit is
necessary, an external clock can be used by
selecting the external clock option. Use the
function option generator (winfog) to select the
external clock input. When using the ICE, load
the function option HEX data (C8816XXX.FSA,
XXX is a customer code) to the ICE.
∗ The following shows the internal oscillation
clock frequencies:
OSC1 crystal oscillation: 32.768 kHz
OSC3 crystal oscillation: 4.9152 MHz
OSC3 ceramic oscillation: 8 MHz
When CR oscillation is selected for OSC1 or
OSC3, the oscillation frequency can be adjusted
using the variable resistor (VR2 for OSC1, VR3
for OSC3) on the S5U1C88816P. Since the CR
oscillation frequency monitor pins (OSC1CR for
OSC1 and OSC3CR for OSC3) are provided on
the board for connecting a frequency counter or
other equipment, use them when adjusting the
oscillation frequency. The initial CR oscillation
frequencies of OSC1 and OSC3 are undefined,
so they should be checked using the OSC1CR
and OSC3CR monitor pins.
EPSON
I/O#2
I/O#1
I/O#3
CN2-1
(40pin)
CN2-2
(40pin)
CN1-2
(40pin)
CN3-1
(30pin)
CN3-2
(30pin)
CN1-1
(40pin)
I/O connection cable
To target board
To target board
mark
Fig. 5.1 Connection of target system

S5U1C88816P MANUAL EPSON 7
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
5 CONNECTION TO TARGET SYSTEM
(3) I/O connector pin assignment for S1C88816
Table 5.1 lists the I/O connector pin assignment when using the S5U1C88816P for the S1C88816.
Table 5.1 Pin assignment of I/O connector (for S1C88816)
40-pin CN1-1
I/O#1 connector
40-pin CN1-2
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Pin name
VDD
VDD
VSS
VSS
K00
K01
K02
K03
K04
K05
K06
K07
K10
N.C.
P00
P01
P02
P03
P04
P05
P06
P07
P10
P11
P12
P13
P14
P15
P16
P17
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
R26
R27
N.C.
N.C.
N.C.
N.C.
R34
N.C.
N.C.
N.C.
R50
R51
Pin name
COM0
COM1
COM2
COM3
COM4
COM5
COM6
COM7
COM8
COM9
COM10
COM11
COM12
COM13
COM14
COM15
40-pin CN2-1
I/O#2 connector
40-pin CN2-2
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Pin name
VDD
VDD
VSS
VSS
RESET
N.C.
OSC1
OSC3
VC1
VC2
VC3
VC4
VC5
SEG0
SEG1
SEG2
SEG3
SEG4
SEG5
SEG6
SEG7
SEG8
SEG9
SEG10
SEG11
SEG12
SEG13
SEG14
SEG15
SEG16
SEG17
SEG18
SEG19
SEG20
SEG21
SEG22
SEG23
SEG24
SEG25
SEG26
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Pin name
SEG27
SEG28
SEG29
SEG30
SEG31
SEG32
SEG33
SEG34
SEG35
SEG36
SEG37
SEG38
SEG39
SEG40
SEG41
SEG42
SEG43
SEG44
SEG45
SEG46
SEG47
SEG48
SEG49
SEG50
COM31
COM30
COM29
COM28
COM27
COM26
COM25
COM24
COM23
COM22
COM21
COM20
COM19
COM18
COM17
COM16
30-pin CN3-130-pin CN3-2
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Pin name
SEG51
SEG52
SEG53
SEG54
SEG55
SEG56
SEG57
SEG58
SEG59
SEG60
SEG61
SEG62
SEG63
SEG64
SEG65
SEG66
SEG67
SEG68
SEG69
SEG70
SEG71
SEG72
SEG73
SEG74
SEG75
SEG76
SEG77
SEG78
SEG79
SEG80
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Pin name
SEG81
SEG82
SEG83
SEG84
SEG85
SEG86
SEG87
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
MOUT
MOUT
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
I/O#3 connector

8EPSON S5U1C88816P MANUAL
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
5 CONNECTION TO TARGET SYSTEM
(4) I/O connector pin assignment for S1C8F360
Table 5.2 lists the I/O connector pin assignment when using the S5U1C88816P for the S1C8F360.
Table 5.2 Pin assignment of I/O connector (for S1C8F360)
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Pin name
VDD
VDD
VSS
VSS
K00
K01
K02
K03
K04
K05
K06
K07
K10
K11
P00
P01
P02
P03
P04
P05
P06
P07
P10
P11
P12
P13
P14
P15
P16
P17
R00
R01
R02
R03
R04
R05
R06
R07
R10
R11
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
R12
R13
R14
R15
R16
R17
R20
R21
R22
R23
R24
R25
R26
R27
R30
R31
R32
R33
R34
R35
R36
R37
R50
R51
COM0
COM1
COM2
COM3
COM4
COM5
COM6
COM7
COM8
COM9
COM10
COM11
COM12
COM13
COM14
COM15
Pin name No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Pin name
VDD
VDD
VSS
VSS
RESET
MCU/MPU
OSC1
OSC3
VC1
VC2
VC3
VC4
VC5
SEG0
SEG1
SEG2
SEG3
SEG4
SEG5
SEG6
SEG7
SEG8
SEG9
SEG10
SEG11
SEG12
SEG13
SEG14
SEG15
SEG16
SEG17
SEG18
SEG19
SEG20
SEG21
SEG22
SEG23
SEG24
SEG25
SEG26
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Pin name
SEG27
SEG28
SEG29
SEG30
SEG31
SEG32
SEG33
SEG34
SEG35
SEG36
SEG37
SEG38
SEG39
SEG40
SEG41
SEG42
SEG43
SEG44
SEG45
SEG46
SEG47
SEG48
SEG49
SEG50
COM31
COM30
COM29
COM28
COM27
COM26
COM25
COM24
COM23
COM22
COM21
COM20
COM19
COM18
COM17
COM16
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Pin name
SEG51
SEG52
SEG53
SEG54
SEG55
SEG56
SEG57
SEG58
SEG59
SEG60
SEG61
SEG62
SEG63
SEG64
SEG65
SEG66
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Pin name
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
40-pin CN1-1
I/O#1 connector
40-pin CN1-2 40-pin CN2-1
I/O#2 connector
40-pin CN2-2 30-pin CN3-130-pin CN3-2
I/O#3 connector

S5U1C88816P MANUAL EPSON 9
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
6 OPERATION CHECK
6 OPERATION CHECK
Following installation in the ICE, self-diagnosis of the S5U1C88816P is done by means of the below
operating test. The self-diagnostic program (T88816.PSA) and function option HEX data (T88816.FSA)
packed together with the Development Tool for S1C88816 or S1C8F360 are necessary for performing the
below operating test.
Perform the below operation for the ICE.
Diagnostic procedure
(1) Execute by reading the self-diagnostic program (T88816.PSA) with the "LF" of the ICE command and
reading the function option HEX data (T88816.FSA) with the "LO" command.
(2) Check using the VDC0–2, OSCC, MODE, SVDON, HVLD, LCDC, LCD4.5V, LCD5.5V and EXLCD
LEDs on the S5U1C88816P. If the below light statuses are verified following system reset, it is normal.
The cycle count indicates a 1 second interval and the light status of the below LED changes every
second. When it returns to 1 after 20, it then repeats the cycle again.
Cycle count
VDC0
VDC1
VDC2
OSCC
MODE
SVDON
HVLD
LCDC
LCD4.5V
LCD5.5V
EXLCD
1
–
●
–
–
●
✽
–
●
●
–
–
2
●
–
–
–
●
✽
✽
●
●
–
–
3
–
●
–
–
●
✽
–
●
●
–
–
4
–
–
●
●
●
✽
●
●
●
–
–
5
–
●
–
–
●
✽
–
●
●
–
–
6
●
–
–
–
●
✽
✽
●
●
–
–
7
–
●
–
–
●
✽
–
●
●
–
–
8
–
–
●
●
●
✽
●
●
●
–
–
9
–
●
–
–
●
✽
–
●
●
–
–
10
●
–
–
–
●
✽
✽
●
●
–
–
11
–
●
–
–
●
✽
–
●
●
–
–
12
–
–
●
●
●
✽
●
●
●
–
–
13
–
●
–
–
●
✽
–
●
●
–
–
14
●
–
–
–
●
✽
✽
●
●
–
–
15
–
●
–
–
●
✽
–
●
●
–
–
16
–
–
●
●
●
✽
●
●
●
–
–
17
–
●
–
–
●
✽
–
●
●
–
–
18
●
–
–
–
●
✽
✽
●
●
–
–
19
–
●
–
–
●
✽
–
–
●
–
–
20
–
–
●
●
●
✽
●
●
●
–
–
1
–
●
–
–
●
✽
–
●
●
–
–
2
●
–
–
–
●
✽
✽
●
●
–
–
●
:
–:
✽:
ON (lit)
OFF (not lit)
Brinking

10 EPSON S5U1C88816P MANUAL
(PERIPHERAL CIRCUIT BOARD FOR S1C88816/8F360)
7 PRODUCT SPECIFICATIONS
7 PRODUCT SPECIFICATIONS
The components specifications of the S5U1C88816P are listed below.
Monitor terminal cable
S5U1C88816P connector:
3M 7610-5002SC or equivalent
Cable connector (10-pin):
3M 7910-6500SC 1 pcs
Interface: CMOS interface (5 V)
Length: Approx. 40 cm
Accessories
40-pin connector for connecting to target system:
3M 3432-6002LCSC 4 pcs
30-pin connector for connecting to target system:
3M 3440-6002LCSC 2 pcs
S5U1C88816P
Dimensions (mm): 247.5 (W) ×165 (D) ×44.6 (H)
Weight: Approx. 460 g (board)
Power supply: DC 5 V ± 5%, 1 A or less
(power is supplied to mother
board connector from the ICE)
I/O connection cable (80-pin/40-pin x 2, 2 sets)
S5U1C88816P connector:
KEL 8830-80-170L or equivalent
Cable connector (80-pin):
KEL 8822E-080-171 1/1 set
Cable connector (40-pin):
3M 7940-6500SC 2/1 set
Cable: 40-pin flat cable 2/1 set
Interface: CMOS interface (5 V)
Length:
Approx. 40 cm (Two cables are same)
I/O connection cable (60-pin/30-pin x 2, 1 set)
S5U1C88816P connector:
KEL 8830E-060-170
Cable connector (60-pin):
KEL 8822E-060-171 1/1 set
Cable connector (30-pin):
3M 7930-6500SC or equivalent 2/1 set
Cable: 30-pin flat cable 2/1 set
Interface: CMOS interface (5 V)
Length: Approx. 40 cm

AMERICA
EPSON ELECTRONICS AMERICA, INC.
- HEADQUARTERS -
150 River Oaks Parkway
San Jose, CA 95134, U.S.A.
Phone: [phone] Fax: [phone]
- SALES OFFICES -
West
1960 E. Grand Avenue
EI Segundo, CA 90245, U.S.A.
Phone: [phone] Fax: [phone]
Central
101 Virginia Street, Suite 290
Crystal Lake, IL 60014, U.S.A.
Phone: [phone] Fax: [phone]
Northeast
301 Edgewater Place, Suite 120
Wakefield, MA 01880, U.S.A.
Phone: [phone] Fax: [phone]
Southeast
3010 Royal Blvd. South, Suite 170
Alpharetta, GA 30005, U.S.A.
Phone: +1-877-EEA-0020 Fax: [phone]
EUROPE
EPSON EUROPE ELECTRONICS GmbH
- HEADQUARTERS -
Riesstrasse 15
80992 Munich, GERMANY
Phone: [phone] Fax: [phone]
DÜSSELDORF BRANCH OFFICE
Altstadtstrasse 176
51379 Leverkusen, GERMANY
Phone: [phone] Fax: [phone]
UK & IRELAND BRANCH OFFICE
Unit 2.4, Doncastle House, Doncastle Road
Bracknell, Berkshire RG12 8PE, ENGLAND
Phone: [phone] Fax: [phone]
FRENCH BRANCH OFFICE
1 Avenue de l' Atlantique, LP 915 Les Conquerants
Z.A. de Courtaboeuf 2, F-91976 Les Ulis Cedex, FRANCE
Phone: [phone] Fax: [phone]
BARCELONA BRANCH OFFICE
Barcelona Design Center
Edificio Testa, Avda. Alcalde Barrils num. 64-68
E-08190 Sant Cugat del Vallès, SPAIN
Phone: [phone] Fax: [phone]
Scotland Design Center
Integration House, The Alba Campus
Livingston West Lothian, EH54 7EG, SCOTLAND
Phone: [phone] Fax: [phone]
ASIA
EPSON (CHINA) CO., LTD.
23F, Beijing Silver Tower 2# North RD DongSanHuan
ChaoYang District, Beijing, CHINA
Phone: [phone] Fax: [phone]
SHANGHAI BRANCH
7F, High-Tech Bldg., 900, Yishan Road
Shanghai 200233, CHINA
Phone: [phone] Fax: [phone]
EPSON HONG KONG LTD.
20/F., Harbour Centre, 25 Harbour Road
Wanchai, Hong Kong
Phone: [phone] Fax: [phone]
Telex: 65542 EPSCO HX
EPSON TAIWAN TECHNOLOGY & TRADING LTD.
10F, No. 287, Nanking East Road, Sec. 3
Taipei
Phone: [phone] Fax: [phone]
Telex: 24444 EPSONTB
HSINCHU OFFICE
13F-3, No. 295, Kuang-Fu Road, Sec. 2
HsinChu 300
Phone: [phone] Fax: [phone]
EPSON SINGAPORE PTE., LTD.
No. 1 Temasek Avenue, #36-00
Millenia Tower, SINGAPORE 039192
Phone: [phone] Fax: [phone]
SEIKO EPSON CORPORATION KOREA OFFICE
50F, KLI 63 Bldg., 60 Yoido-dong
Youngdeungpo-Ku, Seoul, 150-763, KOREA
Phone: [phone] Fax: [phone]
GUMI OFFICE
6F, Good Morning Securities Bldg.
56 Songjeong-Dong, Gumi-City, 730-090, KOREA
Phone: [phone] Fax: [phone]
SEIKO EPSON CORPORATION
ELECTRONIC DEVICES MARKETING DIVISION
IC Marketing Department
IC Marketing & Engineering Group
421-8, Hino, Hino-shi, Tokyo 191-8501, JAPAN
Phone: [phone] Fax: [phone]
ED International Marketing Department
421-8, Hino, Hino-shi, Tokyo 191-8501, JAPAN
Phone: [phone] Fax: [phone]
International Sales Operations

First issue July, 2000
Printed April, 2001 in Japan A
M
EPSON Electronic Devices Website
ELECTRONIC DEVICES MARKETING DIVISION
http://www.epsondevice.com
(Peripheral Circuit Board for S1C88816/8F360)
S5U1C88816P Manual
