EPV Peregrine Tension 235 User manual

Rev.072512-JA 1 www.elitescreens.com/epv
Peregrine Tension / 235 /
RearPro Series:
Tab-tensioned Electric Motorized Projection Screen
User’s Guide
Important Safety & Warning Precautions
Make sure to read this user’s guide and follow all procedures below.
Caution: The Screen’s Black Top Drop is already set to its maximum drop distance. There is NO extra top Black
Drop in the roller. Please be aware of this. Any attempts to increase the top black drop will void your warranty
with Elite Screens. Unapproved changes or modifications (except for cutting the power cord for hardwire
installations) to this unit are prohibited and will void your warranty. For more information, please contact our
Technical Support Department at [phone] Ext. 604.
Please retain this user’s guide for future reference.
To avoid damaging the unit do not use with any unauthorized accessories not
recommended by the manufacturer.
Handle the unit carefully during transportation to avoid any damages.
To ensure safe and reliable operation, direct connection to a properly grounded power source is
advised.
The power outlet supplying power to the unit should be close to the unit and easily accessible.
Do not install the unit on uneven or inclined surfaces.
Do not place any heavy objects over the power cord.
Position the power cord properly to avoid creating a trip obstacle.
To avoid an electrical shock or fire due to a loose contact or short circuit, do not overload the
power cord.
The internal & external parts of this unit are not end user serviceable. Do not attempt to
disassemble this unit by yourself. Only authorized technicians can open and make repairs to this
unit.
Make sure the power source that this unit is connected to has a continuous power flow.
If there is need to use an extension cord, make sure the cord has an equal rating as the appliance
to avoid overheating.
Do not handle the power plug when your hands are wet or your feet are in contact with water.

Rev.072512-JA 2 www.elitescreens.com/epv
Do not use this unit under the following circumstances:
Disconnect the power cord under the conditions of heavy rain, wind thunder or lightning.
Avoid direct sun light, rain shower and moisture.
Keep away from fire sources and high temperature to prevent this device from overheating.
Cut off the power supply first before transportation or maintenance.
To avoid possible injury and/or an electric shock, do not attempt to use this screen if there is
obvious damage or if there are any evident broken parts.
Installation Warning
The instructions provided in this user’s guide are for reference only. The installer must insure that proper
mounting hardware is used to provide adequate strength suitable for the installation. Elite Screens is not
liable for any faulty installations. For limit adjustment instructions, please contact our Technical Support
Department at [phone] Ext. 604.
The Screen’s Top Black Drop is already set to its maximum drop distance. There is NO extra top black
drop in the roller. Please be aware of this as any modification attempts will void your warranty.
Individual modifications to this product are prohibited and will void the warranty with the manufacturer.
Please contact Elite Screens Customer Service for any questions.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. There
is no guarantee that the interference will not occur on a particular installation. If this equipment causes
harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures.
Reorient or relocate the receiving antenna of the device which may be casing the
interference.
Increase the separation between the screen and the device’s receiver.
Connect the equipment into a different power outlet other than the device.
Pre-Installation
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
3. In order to protect the screen from exposure to stains, keep the screen out of contact with foreign
particles such as dust, sawdust, and/or liquids.
NOTE
Regardless of the mounting method, the screen should be securely supported so that vibrations or
pulling on the viewing surface will not cause the casing to become loose or fall. The installer must insure
all fasteners used are of adequate strength and suitable for the installation location.

Rev.072512-JA 3 www.elitescreens.com/epv
Accessories for Peregrine Tension Series
Please make sure all accessories listed below are included before proceeding.
Red+ Green - Red +
Control System for Peregrine Tension Series
5-12 Volt Trigger Cable
1. 5-12V Trigger: The built-in 5-12V trigger plugs
directly into the screen’s RJ-45 input and allows
your screen to synchronize its drop & rise with
the projector’s power cycle. The screen deploys
when the projector powers on and will retract
when the projector powers off. The 5-12 volt
adaptor connects to your projector’s trigger
output via a separate cable that may or may not
be provided by the manufacturer of the
projector. The trigger feature will not work
without an output cable from the projector, but
it can be tested by connecting the Red (+) and
Green (-) cable to a 9-volt battery.
Red: DC 12 +
Green: 0 V -
2. 3 -Way Wall Switch: The 3-way wall switch is a
wall mount control box with an up/stop/down
button and plugs directly into the screen’s RJ-45
input.
3. IR “Eye” Receiver: The IR “Eye” Receiver plugs directly into
the screen’s RJ-45 input to present a low profile line-of-sight
control option for your IR remote control even in a recessed
ceiling installation. The IR “Eye” Receiver is compatible with
3rd party IR controllers.
IR “Eye” Receiver
A.
IR Remote
B.
RF Remote
C. 3-way wall switch
D. IR eye
receiver
G.
AAA batteries
E.
5-12v trigger
F. In-wall
RJ45 module

Rev.072512-JA 4 www.elitescreens.com/epv
UP
Stop
Down
6. In-wall RJ45 Module: The RJ45 module connects to a local wall switch for Up/Down control of your
electric screen. Please follow the diagram below for instructions on how to connect this accessory.
Steps to attach Elite Screens Motorized Screen to your local wall switch
1. Attach the in-wall module (Part #: ZIW-Module) to your local wall switch as shown in diagram above.
2. Attach an RJ45 Ethernet cable (not included) to the ZIW-Module and the other end to the RJ45 input
on your Elite electric screen
3. After testing the connection, place the in-wall switch module in/on the wall and wire the Ethernet
cable into the wall and complete the setup.
Hardware Parts List for Peregrine Tension Series
Please make sure all items listed below are included before proceeding with the installation.
Installation Instructions
1. Insert each Bolt (B) through the right & left slide channel located on the top of the screen’s case.
Hardware Parts List
QTY
A. Screw & Dry Wall Anchor
2or 3
B. Bolt
2 or 3
C. Masonry Screw & Anchor
2 or 3
D. Extruded Hanging Bracket
2 or 3
4. IR Remote Control: The Infrared functions by direct
line of sight contact with a beam range of 30 feet.
5. RF Remote Control: The radio waves eliminate the
need for a direct line of sight with a range of 100 feet.
A
B
C
D
120”& above models x 3
Note: Please be aware that Ethernet cables have length
limitations so please make a test first before concealing the
cable into the wall.
channel

Rev.072512-JA 5 www.elitescreens.com/epv
2. Slide the Extruded Hanging Bracket (D) through the rail located below the slide channel until it
meets with the top of the Bolt (B) and slightly secure the lug-nuts located on the top & bottom of
the bolt to attach the bracket.
3. Mark the installation location to drill your hole. Insert the proper screw and secure the bolts to the
bracket.
4. Example of the Peregrine Tension installed to a wall, ceiling, and enclosed soffit.
How to adjust the Tension String
This adjustment is not required. The screen’s tension has been set to achieve its best performance. Please
contact Elite Screens for assistance to avoid damaging the screen and voiding your warranty.
1. If the tension string is loose, pull and turn the tension knob clockwise to tighten the string. To
release the tension, pull and turn the knob counter-clockwise.
For a local Elite Screens contact or Technical Support, please visit
www.elitescreens.com
Top hole for ceiling installation
Back hole for wall installation
Flush mount
to wall
Flush mount
to ceiling
Enclosed
installation
*Allow 2” of spacing between the
front and back of the screen casing.
Tension Knob
rail
