Resolution CONNECT O2 User manual

RE619 Flood/Temp Range, CryptiX™-Compatible
Home Disaster™ ensor
Features
•Tri-Mode Environmental Sensing:
oFlood/Moisture Sensor
oFreeze – for Furnace Failure
overheat – for Furnace runaway or Air Conditioning failure.
•Cover tamper.
•Strong, reliable RF signal.
•8-10 year battery life on CR123A battery.
•Low Battery indication.
•
8.3x3.5x2.7cm
Key Instructions
•Battery “+” faces towards spring.
•Flood
Alarm: when liquid rises 0.040 inches above sensor bottom.
Tamper: when cover is opened.
Supervisory: every hour.
•Freeze
Alarm: when room temperature drops below 40F.
Tamper: when cover is opened.
Supervisory: every hour.
•verheat
Alarm: when room temperature rises above 100F.
Tamper: when cover is opened.
Supervisory: every hour.
Enrollment
•Place panel in enrollment mode.
•Tamper the device.
•By default the Flood will enroll first – to add just the Freeze or just the
overheat, or use all three, go to resolutionproducts.com/helixsetup
Specifications
Flood sensing:
Freeze Alarm:
verheat Alarm Temp:
Mounting hardware:
Titanium contacts
100K- hm nominal (D N T use an E L resistor)
Transmitter handles 1 or 2 flood elements, no more.
0.04 inch floor spacing to eliminate floor
condensation falses.
Checks for moisture every 5 seconds: needs two
positive moisture checks to send Flood alarm.
(test mode: every second when cover is off)
7.2°C +/- 16.6°C
Restores when temp increases 4F from alarm
37.7°C +/- 16.6°C
Restores when temp decreases 4F from alarm
#6 or #8 screws
Dual Mode mounting:
Screwed to floor
Screwed to wall
Terminal wire capacity: 16 Gauge
Replacement Battery: CR123A 1550 mAH
Temperature Range:
Housing dimensions:
-17°C to 48°C
8.3x3.5x2.7cm
Specifications subject to change without notice.
Internal & Close-up Pictures
Temp Element
Strain relief for
floor mounting
CONNECT O2

Notices
Warranty
5 years warranty
FCC Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference.
This device must accept any interference that may be received, including interference
that may cause undesired operation.
Changes or modifications not expressly approved by the Resolution Products, Inc. could void
the user's authority to operate this equipment.
FCC ID: U5X-RE301
IC Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1)This device may not cause interference, and
( )This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1)l'appareil ne doit pas produire de brouillage, et
( )l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
IC: 8310A-RE301
For further information visit us:
@ www.connect-o2.com.au | 02 9749 5888 | [email protected]
