Erbauer ETBV18-Li User manual

Original Instructions - MNL_ETBV18-Li_GB_V1_220127
EAN: 5059340253244
ETBV18-Li
ORIGINAL INSTRUCTIONS
V10122 BX220IM
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 1 1/27/22 3:45 PM

2
Safety instructions 3
Product description 12
Assembly 17
Use 20
Care & maintenance 23
Guarantee 28
Declaration of conformity 29
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 2 1/27/22 3:45 PM

3
Safety instructions
IMPORTANT SAFTY INSTRUCTIONS
READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE!
1. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
2. Before vacuuming, remove any large, sharp or sharpedged
objects to avoid damage to the lters and / or product.
3. Do not vacuum any hot or incandescent objects, liquids,
chemicals or ammable materials.
4. Do not use the product without tting a lter rst.
5. Carry, pull and push the product only by the handle, not
by the hose.
6. Lay out the hose in such a way that no unintentional
pulling or tripping over is possible.
7. Do not attempt to modify the product in any way.
8. Only use attachments and accessories recommended by
the manufacturer.
9. Never use the product to vacuum up ammable or
combustible liquids, such as gasoline, photocopier powder
or volatile substances; and do not use the product in areas
where these liquids are present. Do not vacuum up acids.
10. Do not vacuum up any objects which are toxic, cancer
causing, combustible, or any other dangerous materials,
such as asbestos, asbestos dust, arsenic, barium,
beryllium, lead, pesticides, or any other substances
hazardous to health.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 3 1/27/22 3:45 PM

4
11. DANGER OF FIRE! Never vacuum up any objects which
are burning or smoldering, such as cigarettes, cigarette
butts, matches, or hot ashes.
12. WARNING! Operators shall be adequately instructed on
the use of this product!
13. WARNING! The product is not suitable for picking up
hazardous dust!
14. CAUTION! This product is for indoor use only!
15. CAUTION! This product shall be stored indoors only!
16. WARNING! Switch the product off and remove the battery
before cleaning, maintaining, replacing attachments /
accessories or converting to another function!
BLOWER SAFETY WARNINGS
Training
1. Read the instructions carefully. Be familiar with the
controls and the proper use of the product.
2. Never allow people unfamiliar with these instructions to
use the product. Local regulations may restrict the age of
the operator.
3. The operator or user is responsible for accidents or
hazards occurring to other people or their property.
Preparation
1. Obtain ear protection and safety glasses. Wear them at all
times while operating the product.
2. While operating the product always wear substantial
footwear and long trousers. Do not operate the product
when barefoot or wearing open sandals. Avoid wearing
clothing that is loose tting or that has hanging cords or
ties.
3. Do not wear loose clothing or jewellery that can be drawn
into the air inlet. Keep long hair away from the air inlets.
4. Operate the product in a recommended position and only
on a rm, level surface.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 4 1/27/22 3:45 PM

5
5. Do not operate the product on a paved or gravel surface
where blown material could cause injury.
6. Before using, always visually inspect to see that the
bolts and other fasteners are secure and the housing is
undamaged. Replace worn or damaged components in
sets to preserve balance. Replace damaged or unreadable
labels.
7. Never operate the product while people, especially
children or pets are nearby.
8. To prevent dust irritation the wearing of a face mask is
recommended.
Operation
1. Keep proper balance and footing at all times. Do not
overreach.
2. If the product should start making any unusual noise or
vibration, immediately switch off and allow the product to
stop. Disconnect the battery and take the following steps
before restarting and operating the product:
- inspect for damage;
- replace or repair any damaged parts;
- check for and tighten any loose parts.
3. Keep the battery and battery docking port clean and free
of debris and other accumulations to prevent damage.
4. Do not transport this product while it is running.
5. Switch off the product and remove the battery. Make sure
that all moving parts have come to a complete stop
- whenever you leave the product;
- before clearing blockages;
- before checking, cleaning or working on the product;
6. Walk, never run.
7. Operate the product only in daylight or in good articial
light.
8. Do not blow hard objects such as nails, bolts, or rocks.
9. Apply extra care when cleaning debris from stairs or other
tight areas.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 5 1/27/22 3:45 PM

6
ADDITIONAL SAFETY WARNINGS FOR BATTERY PACK
1. Battery pack needs to be charged before use. Always
refer to the charger’s instruction and charge it properly.
2. Remove the battery pack from the product when not
in use.
3. Don’t maintain the battery pack on the charger when
not in use.
4. After extended periods of storage, it may be necessary
to charge and discharge the battery pack several
times to obtain the maximum performance.
5. Longer life and better performance can be obtained
if the battery is charged when the air temperature is
between 18°C and 24°C. Do not charge the battery in air
temperature below 5°C or above 40°C. This is important
as it can prevent serious damage to the battery.
6. Do not charge battery in a damp or wet location.
Following this rule will reduce the risk of electric shock.
7. Do not disassemble the battery and avoid mechanical
damage to the battery. Risk of short circuit and fumes
may be emitted. Ensure fresh air and seek medical
assistance in the event of discomfort.
8. When disposing of battery pack, keep the battery
pack of different electrochemical systems separate
from each other.
9. Exhausted batteries are to be removed from the appliance
and safely disposed of.
10. If the appliance is to be stored unused for a long period,
the batteries should be removed.
11. The supply terminals are not to be short-circuited.
12. Do not carry or store battery together with necklaces,
hairpins or other metal objects.
13. Do not pierce the battery with nails, strike the battery with
a hammer, step on the battery or otherwise subject it to
strong impacts or shock.
14. Do not solder directly onto the battery.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 6 1/27/22 3:45 PM

7
15. Do not expose battery to water or salt water, or allow the
battery to get wet.
16. Do not disassemble or modify the battery.
17. Do not place the battery in or near re, on stoves or other
high temperature locations. Do not place the battery in
direct sunlight, or use or store the battery inside cars in
hot weather.
18. Do not place the battery in microwave ovens, high-
pressure containers or on induction cookware.
19. If you intend to store a battery for a period without use
then store battery at room temperature (19°C to 25°C),
charged to about 30 – 50% of capacity. When storing for
very long periods boost charge the battery once per year
to prevent over discharge.
The following information applies to professional users only
but is good practice for all users:
ADDITIONAL SAFETY WARNINGS FOR CONSTRUCTION
DUST
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce the
risks associated with silica, wood and gypsum dusts.
Construction workers are one of the at-risk groups within this
because of the dust that they breathe: silica dust is not just a
nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts in things
like sand, sandstone and granite. It is also commonly found in
many construction materials such as concrete and mortar. The
silica is broken into very ne dust (also known as Respirable
Crystalline Silica or RCS) during many common tasks such as
cutting, drilling and grinding. Breathing in very ne particles of
crystalline silica can lead to the development of:
• Lung cancer
• Silicosis
• Chronic Obstructive Pulmonary Disorder/Chronic
obstructive pulmonary disease (COPD)
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 7 1/27/22 3:45 PM

8
And breathing in ne particles of wood dust can lead to the
development of Asthma. The risk of lung disease is linked to
people who regularly breathe construction dust over a period
of time, not on the odd occasion.
To protect the lung, the COSHH Regulations sets a limit on
the amount of these dusts that you can breathe (called a
Workplace Exposure Limit or WEL) when averaged over a
normal working day. These limits are not a large amount of
dust: when compared to a penny it is tiny – like a small pinch
of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
Please always work with approved safety equipment, such
as those dust masks that specially designed to lter out
microscopic particles and use the dust extraction facility at all
time.
For more information please see the HSE website:
http://www.hse.gov.uk/construction or http://www.hse.gov.uk/
pubns/cis69.pdf
VIBRATION AND NOISE REDUCTION
To reduce the impact of noise and vibration emission, limit
the time of operation, use low-vibration and low-noise
operating modes as well as wear personal protective
equipment.
Take the following points into account to minimise the vibration
and noise exposure risks:
1. Only use the product as intended by its design and these
instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure they
are in good condition.
4. Keep tight grip on the handles/grip surface.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 8 1/27/22 3:45 PM

9
5. Maintain this product in accordance with these instructions
and keep it well lubricated (where appropriate).
6. Plan your work schedule to spread any high vibration tool
use across a longer period of time.
7. Prolonged use of the product exposes the user to
vibrations that can cause a range of conditions collectively
known as hand-arm vibration syndrome (HAVS) e.g.
ngers going white; as well as specic diseases such as
carpal tunnel syndrome. To reduce this risk when using
the product, always wear protective gloves and keep your
hands warm.
EMERGENCY
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the safety
instructions and follow them to the letter. This will help to
prevent risks and hazards.
1. Always be alert when using this product, so that you
can recognise and handle risks early. Fast intervention
can prevent serious injury and damage to property.
2. Switch off and disconnect from the power supply if
there are malfunctions. Have the product checked by a
qualied professional and repaired, if necessary, before
you operate it again.
RESIDUAL RISKS
Even if you are operating this product in accordance
with all the safety requirements, potential risks of injury
and damage remain. The following dangers can arise in
connection with the structure and design of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken attachments
or the sudden impact of hidden objects during use.
3. Danger of injury and property damage caused by ying
objects or poor power tool accessories.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 9 1/27/22 3:45 PM

10
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with active
or passive medical implants! To reduce the risk of
serious or fatal injury, we recommend persons with
medical implants to consult their doctor and the
medical implant manufacturer before operating this
product!
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 10 1/27/22 3:45 PM

11
x1
1
WARNING! Please read all safety warnings carefully and be
sure that they are fully understood before handling the tool.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 11 1/27/22 3:45 PM

12
Product description
1
12
3
4
5
6
7
11
11a
12
13
89
10
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 12 1/27/22 3:45 PM

13
A
3
2.
1.
1.
B
8
C D
1.
2.
13a
13
2. 1.
E F
2
13
13a
13b
6a
1.
2.
13
6
3
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 13 1/27/22 3:45 PM

14
G
10
9
13c
13
H
13
13b
13a
12
1. 2.
I J
2.
1.
4
11a
11b
2.
1.
11a
K L
11a
11c
2.
1. 2
ON
OFF
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 14 1/27/22 3:45 PM

15
M9 10 13 N
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 15 1/27/22 3:45 PM

16
Part index
The index below refers to Fig. 1 on page 7.
1. Carrying handle
2. On/off switch O/I
3. Cover latches (X2)
4. Tank latches (X2)
5. Tank
6. Hose port
7. Upper cover
8. Battery docking port
9. Crevice nozzle
10. Floor nozzle
11. Motor unit
a) Cartridge lter
12. Blower port
13. Hose
Symbols
On the product, the rating label and within these instructions you will nd among others
the following symbols and abbreviations. Familiarise yourself with them to reduce
hazards like personal injuries and damage to property.
V Volt, (direct current voltage) mAh Milliampere per hour
°C Celsius degree kg Kilogram
mm Millimetre m Metres
kPa Kilopascal dB(A) Decibel (A-rated)
m/s² Metres per second squared Ø Diameter
Lock / to tighten or secure Unlock / to loosen
Wear protective, slip-resistant footwear.
Always wear eye protection. Always wear ear protection.
Wear respiratory protection. Wear protective gloves.
Note / Remark. Caution / Warning.
Read the instruction manual.
Switch the product off and remove the battery before assembly, cleaning,
adjustments, maintenance, storage and transportation.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 16 1/27/22 3:45 PM

17
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
UK Conformity Assessed.
WEEE symbol. Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check with your
Local Authority or local store for recycling advice.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week of
manufacturing (Wxx).
Technical data
General
Rated voltage : 18 V
Capacity : 14 L
Degree of protection : IPX4
Protection class : III
Weight : 4.8 kg
Suction hose : Φ36 mm
Dimensions : approx. 447mm x 268mm x 353mm
For use with battery pack and charger as below:
Battery pack model : EBAT18-Li-2 / EBAT18-Li-4 / EBAT18-
Li-5 / EHPB18-Li-4 / EHPB18-Li-8
Charger model : EC18-Li / EFC18-Li / EMC18-Li
Ambient temperature range for tool
and battery : -10 °C to 40°C
Rating label explanation
ETBV18-Li = Model number
E = ERBAUER
TBV = Tool Box Vacuum
18 = Rated voltage
Li =Lithium-Ion battery
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 17 1/27/22 3:45 PM

18
Assembly
Technical data
01 Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices, if applicable.
3. Make sure the delivery contents are complete and free of any damage. If you
nd that parts are missing or damaged do not use the product and contact your
dealer. Using an incomplete or damaged product represents a hazard to people
and property.
4. Ensure all the accessories and tools needed for assembly and operation are at
your disposal, including suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Keep plastics bags, sheets and small parts away from children. There is
a danger of choking and suffocation!
WARNING! The product and the packaging are not children’s toys!
Keep plastics bags, sheets and small parts away from children. There is
a danger of choking and suffocation!
Wear protective gloves for this assembly work and always lay the product
on a at and stable surface while assembling.
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the battery pack to the product before it is completely
assembled!
NOTE: Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 18 1/27/22 3:45 PM

19
02 Battery pack 02 (Fig. A, B, C)
WARNING! Make sure that the on/off switch (2) is in “O” position (refer
to Controls - On/off switch).
Attaching / removing the battery pack (not supplied)
1. Unlock both upper cover latches (3) (Fig. A, step 1) and open the upper cover (7)
(Fig. A, step 2).
2. Align the sliding slots of the battery pack with the battery docking port (8) and slide
the battery pack in to attach it. Ensure it clicks in place (Fig. B).
3. To remove the battery pack, press down the release button (Fig. C, step 1) and pull
out the battery pack from the battery docking port (8) (Fig. C, step 2).
03 Hose and nozzles (Fig. D, E, F, G, H)
The hose (13) is pre-assembled on the suction port (6a) for vacuuming.
Removing:
1. Rotate the locking ring (13a) anti-clockwise to unlock the hose (13) (Fig. D, step 1).
2. Remove the hose from the suction port (6a) (Fig. D, step 2).
Assembling for vacuuming:
1. Place the locking ring (13a) into the suction port (6a) (Fig. E, step 1). Rotate the
locking ring slightly to ensure its locating pin (13b) sits properly.
2. Rotate the locking ring (13a) clockwise to lock the hose (13) (Fig. E, step 2).
3. Place the hose (13) through the hose port (6), close the upper cover and secure it
with cover latches (3) (Fig. F).
4. Connect the required nozzle (9, 10) onto the hose connector (13c) (Fig. G).
Assembling for blowing:
1. Place the locking ring (13a) into the blower port (12) (Fig. H, step 1). Rotate the
locking ring slightly to ensure its locating pin (13b) sits properly.
2. Rotate the locking ring (13a) clockwise to lock the hose (13) (Fig. H, step 2).
04 Cartridge lter (Fig. I, J, K)
This product is designed for dry and wet vacuuming as well as blowing.
The cartridge lter (11a) arrives assembled on the motor unit (11) and can be replaced
with a new lter when necessary.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 19 1/27/22 3:45 PM

20
WARNING! Always use the cartridge lter (11a) for dry and wet
vacuuming.
Removing:
1. Lock both cover latches (3). Unlock both tank latches (4) (Fig. I, step 1) and remove
the motor unit (11) with upper cover (7) (Fig. I, step 2).
2. Place the motor unit with upper cover upside down on a at, stable surface (Fig. J).
3. Rotate the cartridge lter (11a) anticlockwise to unlock it.
4. Remove the cartridge lter (11a) from the motor unit (11) to expose the oating ball
assembly (11b).
Assembling:
1. Slide the cartridge lter (11a) onto the oating ball assembly frame (11c) (Fig. K,
step 1).
2. Rotate the cartridge lter clockwise to lock it (Fig. K, step 2).
3. Close the tank (5). Secure it with both tank latches (4). Ensure the motor unit sits
properly on the tank and the connection is properly sealed.
05 Nozzles
A choice of nozzles is supplied in the scope of the delivery of this product.
Illustration Description Application
Floor nozzle
(10)
Tiles, wooden oors, carpets
Crevice
nozzle (9)
Crevices, corners, cracks and
other places hard to reach.
MNL_ERBAUER_18 V vacuum cleaner_ETBV18-Li_IMGB_V1_220127.indd 20 1/27/22 3:45 PM
