3-circuit connector
Mounting instructions
1

23000053406
English
Read the instructions carefully
before installation and com-
missioning!
Leave the instructions for
users/customers for future
reference!
General safety information
Warning!
Risk of electric shock!
Prior to maintenance, cleaning and instal-
lation work, disconnect mains cables and
check the power is switched off.
Attention!
- The electrical contractor has respon-
sibility for ensuring the electrical,
mechanical and thermal compatibility
between the track connector and track
system.
- Installation requires specialist electri-
cal knowledge and must only be carried
out by an approved specialist.
- When installing, always observe the
national installation and accident pre-
vention regulations.
- When installation is complete, check
the function of the protective conduc-
tor on the track.
Intended use
- Installation and operation is only
permissible with ERCO track and acces-
sory parts.
- The track is suitable for use in dry
interiors only.
Installation information
- Observe the position of the earth
conductor. Various versions are avail-
able (fig. 1).
- Attach end plate 79302 or 79322 to
the free track ends (fig. 2).
- Connect the connectors according to
the operating modes (fig. 3):
1-circuit operation
Connection to the 250V power supply
max. 3 control circuits/load circuits
fuse protection max. 16A
3-circuit operation
Connection to the 250-440V
(240-415V) power supply
3 control circuits/load circuits
fuse protection max. 3x16A
3-circuit operation only for lumi-
naires with Multi Dim mode phase
dimming or Push Dim
Connection to the 250-440V
(240-415V) power supply as shown in
the drawing.
2 control circuits / 1 load circuit. Load
circuit L3 with continuous phase fuse
protection max. 16A
Electrical installation
For 3-circuit installation: to avoid any
damage to the control gear, the neutral
conductor must never be connected or
disconnected during operation.
Cleaning
Always clean carefully using a soft
cloth and a commercially available,
ph-neutral, alcohol-free, non-abrasive
cleaning agent.
