Ergonomic products N3A Series User manual

Specication and Installation Guide
Product ID: N3A
950-093 Manual version: B
N3A Series: 32” Inwall Comfort Station
Standard and Extended Counter surface shown.

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 2
Thank you for purchasing the Ergonomic Products N3A Series 32” InWall Comfort
Station.
Years of research by dentists, engineers and designers have made this a uniquely eective
product in the industry. We stand behind our equipment, and genuinely believe it to be the
best available on the market.
Should you have any questions regarding the product’s installation or use, please don’t
hesitate to call our customer service specialists at 1-866-ERGO-4-US. We may also be
reached via email at [e-mail].
We hope you enjoy the benets and quality of your new equipment and look forward to
handling your future needs as you and your practice continue to grow!
CONTENTS:
1. Specications.................................................................... 3
2. Required Tools / Unpacking and Installation........................ 5
3. Installation ................................................................................. 6
4. Maintenance............................................................................... 7
5. Warrenty Information ............................................................... 8
QUESTIONS?
Call our Customer Service Specialists at:
1-866-ERGO-4-US.

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 3
1 - SPECIFICATIONS
IDEAL LOCATION CONFIGURATION
For Right Handed Doctor rooms, the 32” InWall Comfort
is best used with a left-oriented sink, placed on centerline
of the operatory, though some lee-way is ne. If the unit
needs to be shifted, most doctor’s will place the unit closer
to the toe, rather then head.
The centerline of the cabinet remains the
same, if purchased with the extended shelf.
For alternate room layouts or equpiment
congurations, position unit so that right
side of cabinet lines up with head of chair
when reclined.
STANDARD FEATURES
- Corian counter-top
- Additional product storage behind mirror
- Open glove and bib storage
- Chrome faucet
- Brushed stainless sink
- Utility access panel
Mirror
Storage Space
Paper Towel
Holder
Corian Sink
Lower Access
Panel
DOCTOR TREATMENT
ROOM
(TYPICAL)
2'-4"
3'
3'
4'
8'-4" 4'-2"
5'-6" ±6" 5'-6" ±6"
Lower Cover
Plate
*Extended Surface Shown
Glove Box
Storage
OPTIONAL FEATURES / CONFIGURATIONS
- Available with sink oriented to the left
or right (or without sink)
- Extended counter available (either orientation)

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 4
1 - SPECIFICATIONS CONT’D
PLUMBING SPECIFICATIONS
Unit is supplied with Delta 570 Single Lever Faucet
and 1-1/4” 90 degree Tail-piece.
Plumber To Provide:
- 1/2” Hot and Cold domestic supply lines with
straight 1/4 turn-stop and 3/8” compression
- 1-1/2” DWV with P-Trap as shown
Note: All height dimensions are referenced ABOVE
the FINISHED FLOOR (“AFF”).
When planning the rough opneing. it is critical
to measure from the installed Finished Floor,
or account for its eventual depth if it is not yet
installed.
Product Dimensions
Site Planning
FLOOR
32"
30-1/2"
30"
16"
46-3/4"
32"
71-1/4"
70-3/4"
70-1/4"
OVERALL DIMENSION
48"
MINIMUM ROUGH OPENING
UNIT DIMENSION
SUPPLIES
GLOVE
STORAGE
MIRROR
REMOVABLE
ACCESS COVER
REMOVABLE
ACCESS COVER
FLOOR
32"
30-1/2"
30"
32"
71-1/4"
70-3/4"
70-1/4"
OVERALL DIMENSION
MINIMUM ROUGH OPENING
UNIT DIMENSION
SUPPLIES
GLOVE
STORAGE
MIRROR
REMOVABLE
ACCESS COVER
REMOVABLE
ACCESS COVER
FINISHED
FLOOR
30-1/2"
69"
HOT & COLD SUPPLIES BEHIND
DRAIN 1-1/2" TO BACK WALL
ENTER FROM FLOOR OR SIDE WALL
11 1/2"
DUPLEX OUTLET
& DATA JACK
MOUNT IN WALL
CAVITY FACE UP
10"
3"
6"
9 1/4"
IF METAL STUDS
INSERT WOOD BLOCKING
INTO CHANNEL FOR
FASTENING SUPPORT
OPEN FOR
RECESSED
CABINETRY
9"
Note: Left sink shown, other congurations
are available.
70 3/4”

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 5
2 - REQUIRED TOOLS / UNPACKING and INSPECTING
REQUIRED
TOOLS
Phillips Head Screw Driver
Electric Drill
3/8” Drill Bit and Counter Sink
Level
PARTS LIST Check that the conguration/options for your product(s) are correct. If anything is damaged or
missing, please contact Ergonomic Products customer service at 1-866-ERGO-4-US.
The following items come
pre-installed on the base unit
Hinged Mirror
Lower Access Panel
Lower Cover Plate

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 6
3 - INSTALLATION
Position lower assembly so that bottom of face frame sits on the oor. If the oor is not level or
opening is not plumb, some shimming may be required.
1. Place lower assembly into cavity, make scribe lines for removal of base board molding
around cavity to compensate for lower assembly.
2. Insert Lower assembly into opening.
3. Finish fastening lower assembly by fastening four (4) screws* using pre-drilled holes.
*Suggested screw size #8 2-1/2 at head screw

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 7
3 - INSTALLATION
1. Install Upper Assembly, making sure it sits fully on lower section and tight against wall.
2. Secure same as Lower Assembly with (4) at-head screws* using pre-drilled holes.
*Suggested screw size #8 2-1/2 at head screw

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 8
3 - INSTALLATION
1. To install the Lower Access Panel on all 32” Inwalls: Insert the bottom edge of the Lower Access
Panel (g. 17) rst and rotate upper edge of the Lower Access Panel into position, Reverse this
process for the removal of the Lower Access Panel.
2. To install the lower cover plate on all 32” Inwalls; Insert top of lower cover plate, lift and rotate
into position and release. (See g. 18)

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 9
4 - MAINTENANCE
Cleaning instrucons
Painted and Anodized Aluminum Surfaces
Clean with mild detergent, damp cloth and dry thoroughly aer cleaning.
Do NOT use alcohol or solvent based cleaners, ScotchBrite or other abrasive pads.
CORIAN® Surfaces
Clean with warm, soapy water or any non-abrasive ammonia based cleaner or disinfectant. Dry
thoroughly aer cleaning. For tougher stains, use Clean EnCounters® from DuPont.
Do NOT use window-cleaning soluons (they will leave a waxy build-up), ScotchBrite or other
abrasive pads.
For more informaon on cleaning CORIAN surfaces, go to:
hp://www.dupont.com/products-and-services/construcon-materials/surface-design-materials/
brands/corian-sol¬id-surfaces/arcles/how-to-clean-corian.html

950-093 N3A manual ver Bergonomic products • 198 Airport Rd • Fall River, MA 02720 • 866-374-6487
32” InWall Comfort Station
Model N3A
PAGE 10
5 - WARRANTY INFORMATION
Ergonomic Products oers the following warranty on our products:
• 5-year limited warranty on all Corian® surfaces*
• 3-year warranty on all RapidCarts®**
• 5-year warranty on all EP 3 Series® Patient Chairs***
• 3-year warranty on all Workstations®
• 3-year warranty on all EP Lighting****
• 3-year warranty on STS Manifold and Sliding Track Assembly
• 1-year warranty on all cabinetry, laminates and components
• 1-year warranty on all storage tubs and bins
• 3rd party components carry the original manufacturer’s warranty:
– 1-year warranty on scalers
– 1-year warranty on cure lights
– 1-year warranty on Ultraleather upholstery
– 1-year warranty on BienAir Electric Motors
– 1-year warranty on STS Articulating Arm and Motor
* Limited to manufacturer’s defects only
** Excludes powder-coated RapidCarts® tops (1 year warranty)
*** Excludes upholstery (1 year warranty)
**** Excludes bulbs
Discontinued parts or components cannot be serviced once the warranty has expired. Additional 3rd-party
sources may be available.
We promise to oer you prompt, inexpensive repairs. Products under warranty will be fixed as quickly as
possible and service will be done on-site if possible. If a product must be returned to our technical center, it will
be returned to you without additional shipping charges. If the time needed to repair it will aect your practice
schedule, we will try to provide a loaner so as to not interrupt your service to your patients. In an emergency, our
Doctor Delivery Power Channels® will ship overnight.
Should your oce damage equipment, due to improper use or inadequate installation or maintenance, we’ll still
make sure to fix your problem promptly. The warranty will not apply. There is no warranty for fabric damaged by
infection control products.
We promise to keep working to inspire you with our products and services. We want to hear from you and help
you to continue to improve your practice.
Sincerely,
The Sta at Ergonomic Products, Inc.
