Erhard Junghans calibre J890 User manual

6 7
Instruments of time.
86 saw the dawn of a new era in German watch manu -
facturing, with the visionary and entrepreneur Erhard
Junghans. Today, for the Erhard Junghans brand ”Made in
Germany“ once again stands for timekeeping instruments
of the utmost precision and value-adding functionality
with a classic, design-oriented style.
With pioneering spirit and creative energy Erhard
Junghans breathed new life into traditional values, in the
process leaving a permanent impression on the course of
time.
Today, as was the case in those days, Schramberg has
witnessed the coming together of individuals to produce
the exceptional – just as Erhard Junghans did in his era.
The same intention. A new beginning.
ENGLISH

8 9
Contents Page
General instructions for use 20 –2
Operating elements and functions
Aerious Chronoscope 22 – 25
General information 26 – 27

20 2
General instructions for use
Win ing the watch
Your Erhard Junghans Aerious is equipped with a screwed-in crown. In
the home setting (crown in position A) the crown is screwed in. By turn-
ing it to the left you get to the position for winding the watch (crown in
position B). If you can feel that the crown will turn freely, you can wind
up the automatic movement by hand. 2-3 turns of the crown suffice to
set the movement in motion. It is better to wind the watch completely,
as this guarantees maximum accuracy and power reserve (including
after removal of the watch). The watch should be worn after winding in
order for the automatic winding mechanism to maintain a fully-wound
state (via the rotor movement).
Setting the ate
Pull the crown to Position C (fast adjustment). The date can be altered by
turning the crown to the right. Rotate the crown until the date of the pre-
vious day is displayed. (The actual date is then adjusted with the setting
of the time).
Important: Date alteration should not be performed between 8 PM and
3 AM, as in this period the date is switched automatically by the move-
ment and damage may be caused to the switching mechanism.
If the month has less than 3 days, the date must be forwarded to the st
of the following month by hand.
Setting the time
Pull the crown to Position D. This stops the movement.
To set the watch accurately to the second it helps to stop the movement
when the second hand is over the 60. Now turn the crown to the left. As
soon as the hour hand passes midnight the date is switched to the cur-
rent date. Turning the crown further enables the precise time to be set,
accurate to the minute marker. Return the crown to Position B to start the
second hand.
Note:
After winding up and setting your watch you must always screw the
crown back into place. Only with the crown screwed in can the watch’s
waterproof level of 0 ATM be assured. To screw the crown in, press it
gently and at the same time turn it to the right until it locks firmly into
place.

M
A
D
E
I
N
G
E
R
M
A
N
Y
AUF
AB
60
45 15
30
6
12
93
30
20 10
25
5
3
7
11
8
4
6
C
B
AD
2
10
1
9
22 23
Operating the Aerious Chronoscope
Initiating time measurement
Begin the chronograph function by pressing the start-stop pusher ( 0).
Stopping time measurement
Stop the chronograph function by pressing the start-stop pusher again ( 0).
Resetting
Press the reset pusher ( ). This resets all three stopwatch hands to their
zero position.
A ing measure times
Stop times may be added by pressing the start-stop pusher ( 0) again
after the initial measurement, in place of the reset pusher ( ). The stop-
watch hands will then recommence from the stopped position.
Power reserve in icator
The power reserve indicator states the time remaining before the watch
will stop.
”Auf“ – Indicates the status of a fully-wound spring. This signifies a power
reserve of > 48 hours.
”Ab“ – Indicates an unwound spring. This signifies a very low or no
power reserve.
Hour hand
2 Minute hand
3 Second hand
4 Date display
5 Power reserve display
6 Screw crown
7 Stopwatch second hand
8 Stopwatch minute hand
9 Stopwatch hour hand
0 Start/stop pusher
Reset pusher

24 25
Technical information calibre J890
Mechanical movement with date and power reserve indicator,
Chronoscope with stop second, stop minute and stop hour
Bi-directional automatic ratchet winding mechanism
Finishing: ”Côtes de Genève“ finishing on bridges and rotor,
blued screws
4 jewels
28,800 vibrations per hour
Power reserve > 48 hours (without chronoscope function)
Anti-magnetic as per DIN 8309
Spring: Flat spring

26 27
Care
Watch and strap can be cleaned with a dry or slightly dampened soft
cloth. Note: do not use chemical cleaning agents (e.g. benzine or paint
thinners). This may result in damage to the surface.
Service
Service tasks such as repairs to glass, seal or strap should only be
performed by specialist retailers. We therefore recommend that you
contact an Erhard Junghans specialist retailer.
A partner in your vicinity can be located at www.erhard-junghans.de or
we will be happy to name you one on the following telephone number
+49.7422 8-888.
General information
Water resistance
Your Erhard Junghans watch has been tested for water resistance to a
pressure of 0 ATM. This test indicates that your watch is suitable for
wearing in the shower, when swimming and also snorkelling. It should
not be worn when diving. The 0 ATM water resistance status applies to
factory-new watches only. External influences, such as damage to the
crown, pushers and glass, may affect water resistance. It is therefore
important that you have your watch examined. If moisture has entered
the watch, this must be investigated by customer service without delay.
Water entering the watch may result in damage. We therefore recom-
mend that you contact an Erhard Junghans specialist retailer.
Strap
Your Erhard Junghans watch is equipped with a high quality wrist strap,
which has been tested extensively at our company. It should be noted
that leather straps are not suitable for wearing in water and should not
be subjected to strong UV rays. Please use an original strap if you choose
to replace your strap.

Erhard Junghans
c/o Uhrenfabrik Junghans GmbH & Co. KG
Postfach 00 · D-7870 Schramberg
www.erhard-junghans.de
42.7 2-0466 / 4330226 / 0909
