Casio 5427 User manual

Basic Operations
This section provides an overview of the watch
and explains operations that are common to
all modes.
Note
●The illustrations included in this
operation guide have been created
to facilitate explanation. An
illustration may differ somewhat
from the item it represents.
General Guide
⑦
③①②
⑤
④
⑥
AHour hand
BDigital display
CMinute hand
DSmall hour hand
ESmall minute hand
FDot display
GSecond hand
MA1503-EA © 2015 CASIO COMPUTER CO., LTD.
Indicators and Displays
⑤
①②
⑧
⑨
⑩
④
③
⑥⑦
ADST indicator
Appears when the indicated time is summer
time.
BAirplane indicator
Indicates the watch is in the Airplane Mode.
Communication with a phone is disabled.
CPM indicator
Appears when the time in the dot display is a
p.m. time.
DAM/PM indicator
Indicates whether the small hour and minute
hands are showing an a.m. time [A] or p.m.
time [P].
EAlarm indicator
Appears when an alarm is turned on.
FHand shift indicator
Flashes while the hands are shifted.
Ge mark
When the watch is connected with a phone,
the second hand points to e.
HOFF mark
When the watch is in the Alarm Mode and the
alarm is disabled, the second hand points to
“OFF”.
ION mark
When the watch is in the Alarm Mode and the
alarm is enabled, the second hand points to
“ON”.
JR mark
When the watch is standing by for connection
with a phone, the second hand points to “R”.
Navigating Between Modes
Your watch has the modes shown below.
CC
DD
Bluetooth connection
Alarm Mode Stopwatch Mode
(Approximately
0.5 seconds)
DD
Timekeeping Mode
Timer Mode
Use (D) to navigate between modes. Hold
down (D) for about two seconds to enter the
Timekeeping Mode. To connect with a phone,
hold down (C) for about 0.5 seconds.
Important!
●(C) is not a crown, so you should not
pull on it. It is a button that you
operate by pressing it. Forcibly
pulling on (C) can cause damage to
and malfunction of the watch.
Operation Guide 5427
1

Selecting a Timekeeping
Mode Digital Display Format
In the Timekeeping Mode, you can use the
operation below to change the contents of the
digital displays.
A
Seconds
Minute
Hour
Day of the week
Day
Note
●Pressing (E) will cause the currently
selected Home Time City to appear
in the dot display. After a few
seconds, the display will return to its
normal information.
Home Time City
●When the watch connects with a
phone by Mobile Link, Home Time
City information is obtained from the
phone. Such information is indicated
by a diamond mark (¿) to the left of
the city name.
Shifting the Hands
Hour and minute hand shift moves the hands
for easy viewing of display info.
1. To shift the hour and minute hands, hold
down (B) as you press (D).
●This will cause the hour and minute
hands to move to a position where they
do not block the digital display.
●The hand shift indicator flashes while
the hands are shifted.
Example:
Shifting the hands when it is 10:35
Hand shift indicator
2. To return the hands to their normal
positions, hold down (B) as you press
(D) again.
Note
●This function can be used in any
mode.
●While hands are shifted, watch
button operations are the same as
when hands are unshifted.
●Changing to another mode returns
the hands to their normal positions.
●Shifted hands will return to their
normal positions if no button
operation is performed for one hour.
●In all modes, hands shift
automatically while settings are
being configured. They move back
to their normal positions after
settings are complete.
Solar Charging
What is solar charging?
This watch runs on power supplied from a
rechargeable (secondary) battery that is
charged by a solar panel. The solar panel is
integrated into the face of the watch, and
power is generated whenever the face is
exposed to light.
Charging the Watch
When you are not wearing the watch, put it in
a location where it is exposed to bright light.
While you are wearing the watch, make sure
that its face (solar panel) is not blocked from
the light by the sleeve of your clothing. Power
generation efficiency is reduced even when
the face of the watch is blocked only partially.
NOYES
Important!
●Depending on light intensity and
local conditions, the watch may
become hot to the touch when
exposed to light for charging. Take
care to avoid burn injury after
charging. Also, avoid charging the
watch under high-temperature
conditions like the ones described
below.
ーOn the dashboard of a vehicle
parked in the sun
ーNear an incandescent light bulb or
other source of heat
ーUnder direct sunlight or in other
hot areas for long periods
Operation Guide 5427
2

Charging Times
The table below shows general guidelines for
charging times under various light sources.
Actual charging time depends on your local
environment.
Light Intensity Charge Level
1
Charge Level
2
High
p
Low
A3 hours 35 hours
B8 hours 130 hours
C12 hours 208 hours
D147 hours -
Charge Level 1:
Time from dead battery until hand movement
starts
Charge Level 2:
Time from hand movement starts until a full
charge
Light Intensity
ASunny day, outdoors (50,000 lux)
BSunny day, near a window (10,000 lux)
COvercast day, near a window (5,000 lux)
DIndoor fluorescent lighting (500 lux)
Note
●Actual charging time depends on the
local charging environment.
Remaining Charge and Dead
Battery
The charge level is indicated by watch hand
movement. Functions become disabled as
battery power goes low.
Important!
●Should battery go low or go dead,
expose the face (solar panel) to light
as soon as possible.
Note
●While [R] is flashing, some functions
are temporarily disabled to avoid
running down the battery.
●Low Battery Power
In the Timekeeping Mode, the second hand
jumps at two-second intervals. Other watch
functions operate normally.
Second hand
If power drops even further, all hands will
stopped at 12 o’clock and [CHG] will flash.
●Dead Battery
All hands are stopped at 12 o’clock and digital
displays are blank.
Power Saving Function
Leaving the watch in a dark location for about
one hour between the hours of 10 p.m. and 6
a.m. will cause the second hand to stop, and
the watch to enter Level 1 power saving. If the
watch is left in this condition for six or seven
days, all hands will stop at 12 o’clock and the
watch will enter Level 2 power saving.
Level 1:
Second hand stops and digital displays go
blank to save power.
Level 2:
All hands stop moving, Bluetooth connection
is terminated, alarms are turned off, and digital
displays go blank to save power.
●Recovering from Power Saving
Operation
Press any button or place the watch in a well-
lit area to recover from power saving.
Note
●You can enable or disable Power
Saving.
lConfiguring Power Saving Function
Settings
Using Mobile Link with
a Mobile Phone
While there is a Bluetooth connection
between the watch and phone, the watch time
setting is adjusted automatically in
accordance with the phone’s time setting.
Note
●This function is available only while
CASIO WATCH+ is running on the
phone.
●This section describes watch and
phone operations.
X : Watch operation
Y : Phone operation
Getting Ready
A Installing required app on your
phone
To use the watch with a phone, first tap one of
the links below and install the “CASIO WATCH
+” app on the phone.
●iOS (iPhone)
https://itunes.apple.com/us/app/
id760165998?ls=1&mt=8
●Android (GALAXY, etc.)
https://play.google.com/store/apps/details?
id=com.casio.watchplus
B Configuring Bluetooth settings
Enable the phone’s Bluetooth.
iPhone Users
1. Y On the Home Screen, tap “Settings” n
“Bluetooth”.
2. Y Enable “Bluetooth”.
3. Y Tap “Settings” to return to the “Settings”
screen.
4. Y Tap in the following sequence:
“Privacy” n “Bluetooth Sharing”.
5. Y Enable “CASIO WATCH+”.
Operation Guide 5427
3

Android Users
Y Enable Bluetooth.
●If you are presented with a choice between
“Bluetooth” and “Bluetooth Smart”, select
“Bluetooth Smart”.
Note
●For details about setting
procedures, see your phone
documentation.
C Pairing the watch with a phone
Before you can use the watch in combination
with a phone, you first need to pair them. Once
the watch is paired with a phone, you normally
do not need to pair them again.
1. Move the phone you want to pair with
close to (within one meter of) the watch.
2. Y On the Home Screen, tap the “CASIO
WATCH+” icon.
3. Y Select “ECB-500” and then tap “Next”.
4. Y Perform operations as instructed by the
app.
●If a pairing prompt message appears,
perform the operation shown on the
phone screen.
●When paring is complete, the second
hand will move to e to indicate
connection.
5. Y Tap “Start”.
This displays the CASIO WATCH+ top
screen.
Note
●If pairing fails for some reason,
perform the procedure again from
step 2.
Auto Time Adjustment
The watch can be set to adjust its time setting
automatically each day in accordance with the
phone time.
●Using Auto Adjust
Schedule auto adjust for times the watch and
phone are normally close to each other as
shown in the illustration below.
●While you sleep at night
22:00
●While you work at your desk in the afternoon
14:00
Important!
●Even if there is no Bluetooth
connection when the auto adjust
time is reached, a connection is
established and adjustment is
performed automatically. The
connection is automatically
terminated after time adjustment is
complete.
Note
●The watch’s Home Time City is also
changed to the city set on the phone.
●World Time times are also
automatically adjusted.
●Setting the Auto Adjust Time
Use CASIO WATCH+ on the phone to set the
auto adjust time.
1. Y On the Home Screen, tap the “CASIO
WATCH+” icon.
This displays “Searching for watch...”.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap in the following sequence: f n
“Watch settings”.
4. Y Tap “Time adjustment”.
●Perform the operation shown on the
phone screen.
Note
●Actual adjustment of the watch time
setting will occur about 30 seconds
after the auto adjust time.
Example: When 22:00 is set as the
auto adjust time, watch time setting
adjustment will start 30 seconds
after 22:00.
Operation Guide 5427
4

●Triggering Immediate Time Adjustment
The watch will adjust its time setting to that of
the phone immediately after they are
connected with each other. Whenever you
want to adjust the watch’s time setting perform
the procedure below to connect with a phone.
1. Y On the Home Screen, tap the “CASIO
WATCH+” icon.
This displays “Searching for watch...”.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone, and the time setting of
the watch will adjust to the phone’s time
setting.
City name
Note
●If the watch’s current time was set by
the CASIO WATCH+ app, there will
be a diamond mark (¿) to the left of
the time on the watch’s dot display.
Configuring World Time
Settings
Features
Specifying a World Time City with CASIO
WATCH+ causes the city’s time to be
indicated by the small hour and minute hands.
Watch settings can be configured for auto
summer time switching for the World Time
City.
Note
●CASIO WATCH+ World Time lets
you select from among
approximately 300 cities as the
World Time City.
Specifying a World Time City
1. Y Tap the “CASIO WATCH+” icon.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap “World time”.
4. Y Specify a World Time City by inputting a
city name or by tapping its location on the
on-screen map.
5. Perform the operation shown on the
phone screen. The World Time setting will
be reflected on the watch.
●In the Timekeeping Mode, you can
check the World Time with the watch’s
small hour hand and minute hand.
World Time hour and minute
Note
●If the watch’s World Time was set by
the CASIO WATCH+ app, there will
be a diamond mark (¿) to the left of
the time on the watch’s dot display.
Configuring the Summer Time
Setting
1. Y Tap the “CASIO WATCH+” icon.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap “World time”.
4. Y Specify a World Time City by inputting a
city name or by tapping its location on the
on-screen map.
If your currently specified World Time City
observes summer time, the summer time
period will appear on the display.
5. Y Select the summer time switching
method you want to use.
●“Auto”
The watch switches between standard
time and summer time automatically.
●“OFF”
The watch always indicates standard
time.
●“ON”
The watch always indicates summer
time.
6. Perform the operation shown on the
phone screen.
Note
●When “Auto” is selected for
standard/summer time switching,
the watch will switch between
standard time and summer time
automatically. Do not need to
change the time setting manually for
changes between summer time and
standard time. Even if you are in an
area that does not observe summer
time, you can leave the watch’s
summertime setting as “Auto”.
●Changing the summer time setting
on the watch also will change the
CASIO WATCH+ summer time
setting.
●A CASIO WATCH+ screen shows
information about summer time
periods.
Operation Guide 5427
5

Swapping Your Current Location
Time and World Time
1. Y Tap the “CASIO WATCH+” icon.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap “World time”.
4. Y Tap “Home time k World time”.
5. Perform the operation shown on the
phone screen to swap your current
location time with the World Time.
●In the Timekeeping Mode, you can
check the World Time with the watch’s
small hour hand and minute hand.
n
Current location timeCurrent location time
World TimeWorld Time
After swappingBefore swapping
Note
●This function comes in handy when
you need to move to another time
zone. For details about how to use it,
see “Moving to Another Time Zone”.
Configuring Timer Settings
1. Y Tap the “CASIO WATCH+” icon.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap “Timer”.
4. Y Perform the operation shown on the
phone screen.
Setting the Alarm
1. Y Tap the “CASIO WATCH+” icon.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap “Alarm”.
4. Y Perform the operation shown on the
phone screen.
Adjusting Hand Alignment
If the hands are out of alignment even though
auto time adjustment is being performed, use
CASIO WATCH+ to adjust them.
1. Y Tap the “CASIO WATCH+” icon.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap in the following sequence: f n
“Watch settings”.
4. Y Tap “Adjusting home positions”.
5. Y Perform the operation shown on the
phone screen.
Phone Finder
You can use phone finder to trigger a tone on
the phone to make it easy to find. The tone is
forced to sound even if the phone is in the
manner mode.
Important!
●Do not use this function in areas
where phone call tones are
restricted.
●The tone sounds at a high volume.
Do not use this function when
listening to phone output over
earphones.
1. X If the watch is connected with a phone,
press (C) to terminate the connection.
n
After disconnectionConnected
Operation Guide 5427
6

2. X Hold down C for about three seconds
until [FIND] appears on the dot display.
This will cause the watch’s second hand
to move to e and the phone will sound a
tone.
●It will take a few seconds before the
phone tone sounds.
3. X Press any button to stop the tone.
●You can press any watch button to stop
the phone tone only during the first 30
seconds after it starts to sound.
Configuring Watch Settings
You can use CASIO WATCH+ to specify the
Bluetooth connection auto disconnect time,
auto time adjustment timing and other
settings.
1. Y Tap the “CASIO WATCH+” icon.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap in the following sequence: f n
“Watch settings”.
4. Y Select the setting you want to change
and then perform the operation shown on
the phone screen.
Changing the Home Time
City Summer Time Setting
1. Y On the Home Screen, tap the “CASIO
WATCH+” icon.
This displays “Searching for watch...”.
2. X Hold down (C) for about 0.5 seconds
until the second hand points to the R mark.
The second hand will move to e when a
connection is established between the
watch and phone.
3. Y Tap in the following sequence: f n
“Watch settings”.
4. Y Tap “Summer time setting”.
5. Y Select the summer time switching
method you want to use.
●“Auto”
The watch switches between standard
time and summer time automatically.
●“OFF”
The watch always indicates standard
time.
●“ON”
The watch always indicates summer
time.
6. Perform the operation shown on the
phone screen.
Connection
Cancelling a Connection with a
Phone
n
After disconnectionConnected
Pressing (C) terminates the Bluetooth
connection and return the second hand to its
normal operation.
Connecting with a Phone
This section explains how to establish a
Bluetooth connection between a phone that is
paired with the watch.
●If the watch is not paired with the phone you
want to connect with, perform the procedure
under “CPairing the watch with a phone” to
pair them.
1. Move the phone close to (within one meter
of) the watch.
2. X While the second hand is not pointing to
e, hold down (C) for about 0.5 seconds
until the second hand moves to R.
The second hand will move to e, which
indicates that Bluetooth connection is
complete. The home time city name will
also appear.
Important!
●If you have problems establishing a
connection, it could mean that
CASIO WATCH+ is not running on
the phone. On the phone’s home
screen, tap the “CASIO WATCH+”
icon. Then on the watch, hold down
the (C) button for about 0.5 seconds.
Note
●The connection will be terminated if
you do not perform any operation on
the watch or phone for a fixed
amount of time.
To specify the connection limit time,
perform the following operation with:
use CASIO WATCH+ to select
“Watch settings” n “Connection
time”, and then specify a setting of 3
minutes, 5 minutes, or 10 minutes.
Operation Guide 5427
7

Entering the Watch Airplane Mode
Use the Airplane Mode to disable Bluetooth
radio wave emissions.
Enter the Airplane Mode when in a hospital, in
an aircraft, or anywhere else where radio wave
emissions are restricted.
Important!
●The functions below are disabled in
the Airplane Mode.
ーAuto adjust
ーPhone finder
ーBluetooth connection
X Hold down (D) for about five seconds, until
the Airplane Mode indicator appears.
●Each time (D) is held down for about five
seconds, the watch will enter or exit the
Airplane Mode.
Airplane indicator
Unpairing
To unpair the watch from a phone, delete the
pairing information from CASIO WATCH+, the
phone, and the watch.
●Deleting Pairing Information from
CASIO WATCH+
1. X If the watch is connected with a phone,
press (C) to terminate the connection.
n
After disconnectionConnected
2. Y On CASIO WATCH+, tap “Connection
settings”.
3. Y In “Previously registered watch”, tap the
watch you want to unpair.
4. Y Tap “Delete pairing registration”.
5. Y Tap “Yes”.
This deletes the watch’s pairing
information from CASIO WATCH+.
●Deleting Pairing Information from a
Phone
iPhone Users
1. Y On the Home Screen, tap “Settings” n
“Bluetooth”.
2. Y Tap g next to “CASIO ECB-500”.
3. Y Tap “Forget this Device”.
This deletes the watch’s pairing
information from the phone.
Android Users
1. Y On the App screen tap: “Settings” n
“Bluetooth”.
2. Y Tap j next to “CASIO ECB-500”.
3. Y Tap “Unpair”.
This deletes the watch’s pairing
information from the phone.
4. Y Scroll the status bar downwards and
open the notification panel.
5. Y Tap e (Bluetooth) to disable Bluetooth,
and then re-enable it.
Note
●Note that the actual operation you
need to perform depends on the type
of phone you are using. For details,
see your phone documentation.
●Deleting Pairing Information from the
Watch
1. X Hold down (A) for about two seconds.
[SET] will appear first, followed by the
Home Time City name.
2. X Hold down (C) for about five seconds.
Pairing information is deleted after [CRL]
appears.
n
3. X Press (A) twice to return to the
Timekeeping Mode.
If you purchase another phone
You need to perform the operation below
whenever you want to establish a Bluetooth
connection with a phone that is different from
the one you are currently connected with.
1. Unpairing
2. Perform pairing again.
Connecting a Different Watch to a
Phone
You should perform the steps below before
pairing a different watch with the phone, such
as after you buy a new watch.
●Pairing the Watch with a Phone
1. Y On CASIO WATCH+, tap “Connection
settings”.
2. Y Tap “Connect new watch”.
3. Y Select the name of the watch you want
to connect to and then tap “Next”.
●From this point, follow the instructions
that appear on your phone’s screen to
complete the pairing operation.
●Connecting with a Watch that is Already
Paired
1. Y On CASIO WATCH+, tap “Connection
settings”.
2. Y From the “Previously registered watch”
list, tap the name of the phone you want to
connect with.
3. Y Tap “Connect to this ***”.
●Follow the instructions that appear on
your phone’s screen to complete the
connection operation.
Important!
●A phone can be connected with only
one watch at a time. To connect to
another watch, you need to
terminate the current connection.
Operation Guide 5427
8

Watch Settings
While the watch is connected to a phone, it will
automatically adjust its date and time settings
to those of the phone. If the watch is not
connected to a phone, use the procedure
below to adjust its date and time settings.
Getting ready
Perform this procedure in the Timekeeping
Mode. Use (D) to navigate to the Timekeeping
Mode.
lNavigating Between Modes
Timekeeping Mode
Specifying a Home Time City
Use the procedure in this section to select a
city to use as your Home City. If you are in an
area that observes summer time, you can also
enable or disable summer time.
Important!
●The World time will not be correct if
you select the wrong city as your
Home Time City.
Note
●Your watch has 40 built-in cities that
you can select as a Home Time City.
If you are using the watch in a
location that is not among the built-
in cities, use the built-in city that is in
the same time zone as your location.
For information about built-in cities,
see the “City Name List”.
1. Hold down the (A) button for about two
seconds.
[SET] will appear first, followed by the
Home Time City name.
2. Use (B) and (E) to scroll through city
names until the one you want to use as
your Home City is displayed.
●Holding down (B) or (E) scrolls city
names at high speed.
3. To change the summer time setting, press
(D).
●If you don’t want to change the summer
time setting, press (A) twice to exit the
setting screen.
4. Press (E) to cycle through the summer
time settings below.
●[AT]
The watch switches between standard
time and summer time automatically.
●[--]
The watch always indicates standard
time.
●[ON]
The watch always indicates summer
time.
5. Press (A) twice to exit the setting screen.
Note
●The summer time setting of the
watch is “AT (Auto)” when you
purchase it, so it will switch between
standard time and summer time
automatically. You do not need to
switch between standard time and
summer time manually. Even if you
are in an area that does not observe
summer time, you can leave the
watch’s summer time setting as “AT
(Auto)”.
●For information about summer time
switching dates, see the Summer
Time Table.
●If the currently indicated time is
summer time, the DST indicator will
be shown on the display.
DST indicator
Setting the Time and Date
1. Hold down the (A) button for about two
seconds.
[SET] will appear first, followed by the
Home Time City name.
2. Press (D) six times until the seconds digits
are flashing on the display.
Seconds
3. Press (E) to reset the seconds count to 00.
●If the seconds count is between 30 and
59 when you press (E), 1 will be added
to the minute count.
4. Press (D) so the hour setting is flashing.
Hours
5. Set the date.
●Use (B) and (E) to change the currently
flashing value.
●Each press of (D) cycles the flashing
setting in the following sequence: hour,
minute, year, month, day, seconds.
6. Press (A) twice to exit the setting screen.
Operation Guide 5427
9

Switching between 12-hour
and 24-hour Timekeeping
1. Hold down the (A) button for about two
seconds.
[SET] will appear first, followed by the
Home Time City name.
2. Press (D) four times until the current
setting ([12H] or [24H]) is flashing on the
display.
3. Press (E) to toggle the setting between
[12H] (12-hour timekeeping) and [24H]
(24-hour timekeeping).
4. Press (A) twice to exit the setting screen.
Note
●While 12-hour timekeeping is
selected, the PM indicator will
appear on the display while a p.m.
time is shown.
PM indicator
Summer Time
Summer time, which is also known as Daylight
Saving Time (DST), advances the time setting
one hour, 30 minutes, or some other amount
of time from standard time (STD) during the
summer months. Whether or not and how
summer time is used depends on your country
or local area. Summer time is not used in some
countries and local areas.
Selecting a Setting Item
Each press of (D) cycles the Timekeeping
Mode settings screen content in the sequence
shown below.
nnnnnnnnnnnn
Day
Month
Year
Minute
Hour
Seconds
Power Saving Setting
12/24-hour timekeeping
Illumination duration
Tone ON/OFF
Summer time
Home Time City
World Time
World Time lets you look up the current time
in any one of 40 cities around the globe.
Getting ready
Perform this procedure in the Timekeeping
Mode. Use (D) to navigate to the Timekeeping
Mode.
lNavigating Between Modes
Timekeeping Mode
World time
Checking the Time in Another
Zone
1. Hold down the (A) button for about two
seconds.
[SET] will appear first, followed by the
Home Time City name.
2. Press (A).
3. Use (B) and (E) to scroll through city
names until the one you want is displayed.
This will cause the current time in the
selected city to appear.
●Holding down (B) or (E) scrolls city
names at high speed.
City name
4. Press (A) to return to the Timekeeping
Mode.
The small hour and minute hands will
indicate the current time in the city you
selected.
Time of selected city
Operation Guide 5427
10
