Ericsson W3 Series User manual

Ericsson W3x Series
Mobile Broadband Router for WCDMA/HSPA Mobile Networks
Technical Product Description
Software Release R12

2 221 02-FGB 101 544 Uen H - June 2009
Ericsson W3x Series
Mobile Broadband Router for WCDMA/HSPA Mobile Networks
Technical Product Description
Software Release R12
Abstract
This document describes the Ericsson’s Mobile Broadband Router (MBR),
the W3x product series.
©Ericsson AB – 2008, 2009 All Rights Reserved
Disclaimer
No part of this document may be reproduced in any form without the written
permission of the copyright owner.
The contents of this document are subject to revision without notice due to
continued progress in methodology, design, and manufacturing. Ericsson
shall have no liability for any error or damages of any kind resulting from
the use of this document.

221 02-FGB 101 544 Uen H – June 2009 3
Contents
1ERICSSON W3X SERIES OVERVIEW.....................................7
1.1 INTRODUCTION ............................................................................7
1.2 ERICSSON W30 -DATA ROUTER ..................................................7
1.3 ERICSSON W35 –DATA AND VOICE ROUTER ................................8
1.4 ERICSSON W3X FEATURE SUMMARY ............................................8
2HARDWARE OVERVIEW .......................................................10
2.1 HOUSING...................................................................................10
2.2 MAIN BOARD .............................................................................10
2.2.1 Back Side Interfaces................................................................10
2.2.2 Left Side Interfaces..................................................................11
2.2.3 Right Side Interface .................................................................12
2.2.4 LED Indicators .........................................................................13
2.2.5 SIM/USIM Interface..................................................................14
2.2.6 Mounting..................................................................................14
2.3 ANTENNAS.................................................................................15
2.3.1 Internal UMTS/GSM Antennas ................................................15
2.3.2 External UMTS/GSM Antennas ...............................................16
2.3.3 Internal WLAN Antennas .........................................................16
2.4 POWER SUPPLY.........................................................................16
2.4.1 Power Adapter.........................................................................16
2.4.2 Battery Backup (W35 only)......................................................17
3INTERFACES OVERVIEW......................................................18
3.1 UMTS/GSM RADIO INTERFACES ...............................................18
3.1.1 UMTS.......................................................................................18
3.1.2 GSM/GPRS/EDGE ..................................................................18
3.1.3 HSPA Throughput Rates .........................................................18
3.1.4 Data Transmission...................................................................19
3.1.5 Frequency Bands.....................................................................20
3.2 WIRELESS LAN (WLAN) INTERFACE ..........................................20
3.2.1 Wireless Radio Channels.........................................................21
3.3 USB INTERFACE ........................................................................21
3.4 ETHERNET INTERFACE ...............................................................21
3.4.1 Built-in LED indicators..............................................................22
3.5 TELEPHONY INTERFACE (W35 ONLY)..........................................22
4MOBILE NETWORK FEATURES...........................................23
4.1 PREFERRED ROAMING LIST (PRL) .............................................23
4.2 PDP CONTEXTS ........................................................................23
4.2.1 QoS Profile...............................................................................23
4.3 MOBILE NETWORK .....................................................................23
4.3.1 W35 Frequency Band Selection ..............................................23
4.3.2 W30 Frequency Band Selection ..............................................24
4.3.3 W35 InterRAT and Frequency Hopping...................................24
4.3.4 W30 InterRAT and Frequency Hopping...................................25
4.4 RSCP ALARM THRESHOLD ........................................................25
4.5 SET TIME/DATE FROM MOBILE NETWORK (W35 ONLY)................25
4.6 SECURITY..................................................................................25

4 221 02-FGB 101 544 Uen H - June 2009
4.6.1 PIN Lock ..................................................................................25
4.6.2 Operator Lock ..........................................................................26
5DATA FEATURES...................................................................27
5.1 LAYER 2FUNCTIONS..................................................................27
5.1.1 Bridging LAN and WLAN .........................................................27
5.1.2 WLAN Whitelist........................................................................27
5.2 INTERNET PROTOCOL SERVICES ................................................27
5.2.1 IP Forwarding...........................................................................27
5.2.2 Static Routing...........................................................................27
5.2.3 DNS .........................................................................................27
5.2.4 Dynamic DNS ..........................................................................27
5.2.5 DHCP Server ...........................................................................27
5.2.6 DHCP Relay.............................................................................27
5.2.7 SNTP .......................................................................................28
5.2.8 L2TP Tunneling........................................................................28
5.2.9 Firewall.....................................................................................28
5.2.10 NAT..........................................................................................28
5.2.11 UPnP IGD................................................................................29
5.2.12 VPN Pass-Through..................................................................29
5.2.13 IPsec/VPN Termination............................................................30
5.2.14 IP Quality of Service ................................................................30
5.3 USB SERVICES .........................................................................30
5.3.1 File Sharing..............................................................................30
5.3.2 Printer Sharing.........................................................................31
6VOICE SERVICES (W35 ONLY).............................................32
6.1 NATIONAL PROFILES ..................................................................32
6.1.1 Tones and Signals Profile........................................................32
6.1.2 Voice Codec.............................................................................32
6.1.3 Analog Settings Profile.............................................................33
6.1.4 CLIP Country Profile................................................................33
6.2 GENERAL TELEPHONY FEATURES...............................................33
6.2.1 Inter Digit Timer .......................................................................33
6.2.2 Dial Tone Timeout....................................................................33
6.2.3 Congestion Tone Timeout........................................................33
6.2.4 Local Ringing Timeout .............................................................33
6.2.5 DTMF Duration ........................................................................33
6.2.6 Howler Tone.............................................................................33
6.2.7 On/Off-hook Timeouts..............................................................33
6.2.8 Hook Flash Time......................................................................34
6.2.9 CLIP.........................................................................................34
6.2.10 On Hold Ring ...........................................................................34
6.3 DIAL PROCESS ..........................................................................34
6.3.1 Dial Plan...................................................................................34
6.3.2 Local Call Prefix.......................................................................34
6.3.3 Fixed Number Dialing ..............................................................35
6.3.4 Emergency Calls......................................................................35
6.4 SUPPLEMENTARY SERVICES ......................................................35
6.4.1 Call Waiting..............................................................................35
6.4.2 Call Management with R-codes...............................................35
6.4.3 CLIR.........................................................................................36
6.4.4 Call Return...............................................................................36
6.4.5 Delayed Hotline........................................................................36

221 02-FGB 101 544 Uen H – June 2009 5
6.4.6 Call Forwarding Unconditional.................................................36
6.4.7 Call Forwarding on Busy..........................................................36
6.4.8 Call Forwarding on No Reply...................................................36
6.4.9 Call Forwarding Unreachable ..................................................36
6.4.10 CWI..........................................................................................37
6.4.11 Message Waiting .....................................................................37
7FAX SERVICE (W35 ONLY) ...................................................38
7.1 IMS USER AGENT......................................................................38
7.2 IMS CALL SERVER.....................................................................38
7.3 MEDIA CODEC ...........................................................................38
7.3.1 G.711a-law / GG.711 u-law .....................................................38
7.3.2 T.38..........................................................................................38
7.4 TIMERS .....................................................................................38
7.4.1 SIP Timers...............................................................................38
7.4.2 Registration Timers..................................................................39
7.4.3 VoIP Session Timeout .............................................................39
7.5 SECURITY..................................................................................39
7.6 MEDIA STREAM..........................................................................39
7.6.1 Jitter Buffer...............................................................................39
7.6.2 Echo Canceller.........................................................................39
7.6.3 QoS..........................................................................................39
7.7 INTEROPERABILITY.....................................................................39
8WIRELESS LAN (WLAN) FEATURES ...................................40
8.1 SSID.........................................................................................40
8.2 REGION .....................................................................................40
8.3 CHANNEL SELECTION.................................................................40
8.4 WIRELESS SECURITY .................................................................41
8.4.1 WEP.........................................................................................41
8.4.2 WPA / WPA2............................................................................41
8.4.3 Whitelist ...................................................................................41
9CONFIGURATION AND MANAGEMENT...............................42
9.1 WEB USER INTERFACE...............................................................42
9.2 COMMAND LINE INTERFACE........................................................42
9.3 MANAGEMENT TOOLS ................................................................42
9.3.1 Software Update......................................................................42
9.3.2 Remote Management using TR-069........................................43
9.3.3 Backup and Restore Configuration..........................................43
9.3.4 Reset to Default Configuration.................................................43
9.3.5 System Log..............................................................................43
9.3.6 Fault Management...................................................................44
9.4 INTERFACE STATUS AND STATISTICS ..........................................44
9.4.1 Basic System Information ........................................................44
9.4.2 LAN Interface...........................................................................45
9.4.3 WAN Interface..........................................................................45
9.4.4 WAN Interface Statistics..........................................................46
9.4.5 L2TP Tunnel Status.................................................................46
9.4.6 IPsec/VPN Tunnel Status ........................................................46
9.4.7 Firewall Status .........................................................................46
9.4.8 WLAN Interface........................................................................46
9.4.9 USB Interface...........................................................................47
9.4.10 Telephony Interface (W35 only)...............................................47

6 221 02-FGB 101 544 Uen H - June 2009
9.4.11 Power Management (W35 only) ..............................................47
9.5 SECURITY MANAGEMENT ...........................................................47
9.6 TEMS INVESTIGATION SUPPORT................................................47
10 REGULATORY INFORMATION .............................................49
10.1 APPROVALS...............................................................................49
10.2 WIFI COMPLIANCE .....................................................................49
10.3 ROHS COMPLIANCE ..................................................................49
10.4 USB COMPLIANCE .....................................................................49
10.5 WEEE DIRECTIVE .....................................................................49
10.6 SAR..........................................................................................49
10.7 ENVIRONMENTAL .......................................................................49
10.8 INTENDED USE ..........................................................................50
11 ANTENNA CHARACTERISTICS............................................51
11.1 MEASUREMENT POSITIONS ........................................................51
11.2 RADIATION PATTERNS FOR THE MAIN ANTENNA ..........................52
11.3 RADIATION PATTERNS FOR THE AUXILIARY ANTENNA ..................53
12 ACRONYMS AND ABBREVIATIONS.....................................55

221 02-FGB 101 544 Uen H – June 2009 7
1 Ericsson W3x Series Overview
1.1 Introduction
The Ericsson Mobile Broadband Router (MBR) W3x product series is the
superior solution for providing broadband services to areas with no fixed
broadband infrastructure in a cost efficient way utilizing existing 3G
powered mobile networks. It replaces the Fixed Wireless Terminal (FWT)
W2x product series.
The W3x product series facilitates protected, high-speed Internet access for
multiple users in home and small or branch office environments. It includes
advanced data capabilities such as router and switch functionality, and
provides the users with multiple possibilities for local area connectivity
(Ethernet and WLAN).
The W3x product series consist of two models:
•Ericsson W30 – Data Router
•Ericsson W35 – Data and Voice Router (variants available, see
section 1.3).
With WCDMA/HSPA WAN radio access capability the W3x products are
well suited to provide broadband data access with data speeds similar to
that of fixed line DSL services. The data rate is up to 7.2 Mbps and the up-
link speed is up to 2Mbps.
1.2 Ericsson W30 - Data Router
The Ericsson W30 data router provides data capabilities such as data
access (e.g. Internet) in the respect that it allows multiple computers to be
connected to the router using Ethernet or wireless LAN (WLAN). It also
supports file and printer sharing via the USB port.
Figure 1 - Overview of Interfaces for the Ericsson W30

8 221 02-FGB 101 544 Uen H - June 2009
1.3 Ericsson W35 – Data and Voice Router
The Ericsson W35 data and voice router incorporates the same set of
functions and data features as the Ericsson W30. Additionally, this model
also includes high quality voice and fax services via the telephony
interfaces. A broad range of network related services such as Prepaid
Subscription, CLI (Calling Line Identification), Call Waiting, Call Forwarding,
and Multiparty Conference Calls are available.
WCDMA/HSPA radio access is well suited for combined and efficient data
and voice transmission over the mobile network.
Figure 2 - Overview of Interfaces for the Ericsson W35
The Ericsson W35 is available in two variants each supporting different
combinations of UMTS frequency bands;
•850/1900/2100 MHz
•900/1900/2100 MHz
1.4 Ericsson W3x Feature Summary
The Ericsson W3x features the latest technology, which makes them highly
suitable for everyday broadband services. The main features are:
•Multimode broadband WAN connectivity;
Support antenna diversity and have WCDMA/HSPA
(850/900/1900/2100 MHz) as primary access and
GSM/GPRS/EDGE (850/900/1800/1900 MHz) as fall-back. The
data rate is up to 7.2 Mbps in the downlink direction and up to 2.0
Mbps in the uplink direction.

221 02-FGB 101 544 Uen H – June 2009 9
•Four ports Fast Ethernet switch;
for wired LAN connectivity with rate auto-negotiation and
MDI/MDIX auto-detection support.
•One USB 2.0 port;
for file and printer sharing.
•Wireless LAN Access Point;
An integrated WLAN 802.11b/g access point for wireless LAN
connectivity.
Wireless security features including standard WLAN WEP, WPA,
WPA2, encryptions and MAC Association Control.
•Flexible networking capabilities;
Comprehensive set of networking and IP protocols such as
bridging, routing, DNS, DynDNS, DHCP server/relay, SNTP, and
NAT.
L2TP tunneling providing a mechanism for tunneling Ethernet
frames between two peers over an existing network.
VPN pass-through supporting VPN protocols for standard IPsec
VPN applications.
IPsec/VPN termination supporting one IPsec/VPN tunnel using
Site-to-Site configuration (Tunnel mode).
Stateful packet filtering firewall.
QoS feature for outgoing IP traffic via the WAN interface.
•Voice and fax services (W35 only);
High quality voice and fax services via the telephony interface.
Fax service using SIP and the T.38 protocol.
•Administration and Management;
Local and remote administration and management with SSH2
support.
•End-user Configuration
Built-in web based configuration tool with wizard support for
configuring wireless LAN.
•TR-069
An integrated remote management agent supporting the CPE
WAN Management Protocol (CWMP) as specified in DSL Forum
TR-069 Amendment II. Supports remote software image
installation, shell script execution and a set of configuration and
status parameters.
•TEMS™ Investigation
Support for TEMS Investigation providing possibilities for the
operator to perform real-time diagnostics check and log radio
interface behaviors.

10 221 02-FGB 101 544 Uen H - June 2009
2 Hardware Overview
This chapter describes the hardware of the Ericsson W3x in terms of
housing, interfaces, LED indicators, power supply, and antennas.
2.1 Housing
The housing of the Ericsson W3x is designed to be either wall mounted or
standing on the desk by use of the provided table stand.
The unit (not mounted in the table stand) weighs approximately 380 gr and
measures 185 mm (H) x 106 mm (W) x 45 mm (D).
2.2 Main Board
The main board provides all functionality apart from the radio parts (i.e.
UMTS/HSPA module and WLAN module).
The supported UMTS/HSPA modules are Sierra Wireless MC 8790 and
MC 8792 for Ericsson W35 and Ericsson F3507g for Ericsson W30.
The supported WLAN module is based on Broadcom BCM 4318E.
2.2.1 Back Side Interfaces
The back side of the Ericsson W3x includes the following interfaces:
Figure 3 - W35 back side
