Eslem SLA33 User manual

OPERATION INSTRUCTIONS
A33 FULL BODY AIR-MASSAGE CHAIR
SAVE THESE INSTRUCTIONS

01
Thanks for purchasingthis product.Please read thismanual instruction
carefully in orderto know howto use thisproduct correctly beforeoperation.
Please pay moreattention to someimportant safety warningand keep this
manual book properlyfor future use. Note: Our Company reserves the right
to revise thedesign and descriptionof this productwithout any furthernotice.
Please refer tothe actual colorof this product.
02
04
05
16
16
Safety and maintenance
Name and functionof components
Function & Efficacy
Method of usage
Product specification
CONTENTS

0302
Don t allow children to touch moveable part of this product.
Please use well-grounding power supply suited to this product.
Please pull out the plug after use or before cleaning to avoid injury or
Damage to the product.
Please operate this product according to this manual instruction.
Don t use accessories which are not recommended.
Don t use this product outdoors.
Please read this manual instruction carefully before operation.
Any other usage that is not listed in this manual instruction is forbidden.
20 minutes of usage each time is recommended.
Please don t use it if the leather is broken or damaged.
Please don t use it if the cover or leather is damaged.
Please don t use it if the radiator hole is covered or blocked.
Please don t drop anything into this product.
Please don t fall asleep while using this product.
Please don t use it if drunk or feel unwell.
Please don t use it within one hour after having meal.
Please don t make the massage function too strong for avoiding
Injury.
2. Environment for usage.
Please don t use it under high temperature and moist environment such as
bathroom.
Please don t use it immediately while the environmental temperature
changes sharply.
Please don t use it under heavy-dusty or caustic environment.
Please don t use it where there is not enough space or not good ventilation.
3. People who are not suitable to use this product.
People who are suffering from osteoporosis are not suitable to use this product.
People who are suffering from heart disease or carrying electronic medical
equipment such as heart pacemaker are not suitable to use this product.
People who are suffering from fever are not suitable to use this product.
Pregnant women or women that are in menses period are not suitable to use this
product.
People who got injured or skin disease are not suitable to use this product.
Children under 14-year old or people mentally unbalanced without being
Supervised are not allowed to use this machine.
People who are told by doctor to have rest or people who feel unwell are not
suitable to use this product.
People whose bodies are wet are forbidden to use this product.
The appliance has a heated surface.persons insensitive to Heat must be
careful when usingthe appliance.
4. Safety.
Check the voltage if it is suitable to the specification of this product.
Don t use wet hand to pull the plug.
Don t make water go inside this product to avoid electric shock or cause
damage to this product.
Don t damage the wires or change the circuit of this product.
Don t use wet cloth to clean the electric parts such as switch and plug.
Be away from this product under power cut state to avoid injury if the power
comeback suddenly.
Stop using this product while it works abnormal, and please consult local agent
immediately.
Stop using this product if you feel unwell, and please consult health care doctor.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its
Service agent or similarly qualified persons in order to avoid a hazard.
5. Maintenance.
This product should be maintained by certain appointed agents, users are
prohibited to disassemble or maintain by themselves.
Please don t forget to cut the power after usage.
Don t use this product if the socket looses.
If this product will be left unused for long, please curl up the wires and reserve this
product in dry and dustless environment.
Don t reserve this product under high temperature or near fire and avoid
longtime direct sunshine.
Please clean this product by dry cloth. Don t use thinner, benzene or alcohol.
The mechanical components of this product are specially designed and made,
it is not necessary to be specially maintained.
Don t use edged res to thrust this product.
Don t roll or pull this product above uneven ground, it should be lifted before
moving.
Please use it intermittently; don t make this product work continuously for long.
6. Solution of ordinary malfunctions.
It is nature movement voice if the motor sounds while in usage.
If the controller can t work normally, please check the plug and socket if they
are connected strongly and make sure the switch is turned on.
If the rated working time is over, the product will automatically activate the
power-off button; If this product works continuously for long, the temperature
protector will make the product automatically power-off, it should be used again
after half an hour s rest.
If the detachable cord / supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
Hazard.
1.IMPORTANT SAFETY WARNING.
Safety and maintenanceSafety and maintenance

04 05
Name and function of components Function & Efficacy
1.Pillow pad
2.Controller
3.Arm air bag components
4.Seat cushion
5.Leg rest frame
6.Foot rest frame
7.backrest pad
8.Armrest
9.remote controller pocket
10.backrest cover
11.Controller support
12.MP3 Player Box
13. Moving wheels
14.Power cord and plug
15.Earphone socket
16.power plug socket
17.Power switch
18.Fuse box
Function
1. This product is designed with a set of smart 3D mechanical hands, which can
move up and down, stretching back and forth, four-wheel driven with muted
design.
2. The shoulder part is designed with automatic detection and micro adjustment
function; body curve and massage points automatic detection, it can
automatically adjust the distance of massage hands' moving back and forth
according to the detected body curve and massage points, to make the
massage more humanistic and scientific.
3. Designed with automatic massage programs
4. Air pressure,waist twist, swing hip, waist stretch and other specific massage
functions.
5. Manually select the upper body massage; three massage position options of
overall, partial and fixed position; six massage methods of shoulder grasping,
kneading, tapping, shiatsu, kneading&flapping and 3D; five massage speed
levels available; under tapping and shiatsu massage status, the width of the
massage hand can be adjusted in five levels.
6. Arm air massage function (built-in 26 airbags), leg air massage function (built-in
38 airbags), with 3 intensity adjustments
7. Upper-body air massage: neck and shoulder air massage function (built-in 8
airbags), seat air massage function (built-in 16 airbags)
8. MP3 music displayer. pause, previous, next, volume up, volume down.
9. Back heating function. Use carbon fiber as infrared heating source
10. The footrest can be extended to suit various heights .
11. Footrest lifting and backrest lift adjustment
12. Auto-sitting function, massage Massage hands can automatically return to
Original position after turning off.
13. VFD display
14. MP3 player, earphones, U disc
Effectiveness
Release fatigue
Accelerate blood circulation
Release muscle fatigue
Release muscle tension
Release nerve pain
Release the muscle pain.
1
2
4
5
15 16 17
8
ON/OFF FUSE
11
10
12
3
7
9
14
18
6
13

0706
ON/OFF FUSE
Method of usage Method of usage
1.Switch power supply on
Diagram of theswitch position ofpower supply Diagram of plugin
2.Adjust angle of backrest and footrest
Footrest up button: press this button and the footrest will
recline slowly, release the button it will stop.
Footrest down button: press this button and the footrest
will decline slowly, release the button it will stop.
Backrest up button:press this buttonthe backrest will
recline slowly. release thebutton it will stop.
Backrest down button:press this buttonthe backrest
will decline slowly. release thebutton it willstop.
Position adjust up button: press this button the backrest
will recline and the footrest will decline slowly. release
the button it will stop.
Position adjust down button: press this button the
backrest will decline and the footrest will recline.
release the button it will stop.
3D
SPEED WIDTH
BACK STRETCH
ARM
UPPER BODY
CALF
AIRBAG
WAIST
STRETCH
POSITION
ADJUST
FOOT
REST
BACK
REST
BACK
INTENSITY
BACK WARMER SOLE ROLLER
AUTO
ADJUST
SHOULDER
WAIST
TWIST
SWING
HIP
Auto
WHOLE
BODY AIRBAGS

0908
F6
Shoulder
adjust
H1~H4
( )
3D
F7
F8
H1
( )
H1~H2
( )
H1~H2
( )
H1~H2
( )
H1~H2
( )
F5
Method of usage Method of usage
3. Start massage
1). Press the red power button to start massage, the massage chair will recline
automatically.
2). Automatically detecting shoulder position and massage points, please wait till
dection finished.
3). It sounds [di di di...] after detection finished. Now, please adjust the shoulder
position by pressing up or down button. It will run automatic massage if there is no
adjustment on shoulder position within 10 seconds.
Move the massage balls upward to a suitable position.
Move the massage balls downward to a suitable position.
ADJUST
SHOULDER
ADJUST
SHOULDER
High shoulder position
suitable shoulder position
Low shoulder position
4 . Choose massage methods
Automatic massage
Relax: relax muscles and bones
Ease: accelerate blood circulation
Ache Release: make deep massage to relax the
ache position
Fatigue recover: release the fatigue and activate body
Note: Press the buttons repeatedly and choose different automatic
massage methods, thefour automatic massagemethods can run
circularly.
Specific massage
Whole-body air massage:air massage on
neck&shoulder, waist, buttock, arms and thigh
positions will workat the sametime.
Waist twist: focus on waist massage, the waist airbags
make waist twist leftside and rightside, meantime the
seat airbags make hip-swing massage
Waist stretch: When the calf airbags work and squeeze calf
part, the backrest lays down and calfrest pulls down to
stretch the waist part, then return to original position and
repeat above actions. Meantime the seat airbags and
massage mechanism works.
Upper-body manual massage
Shoulder grasp: 1method available withspeed and
strength adjustment
Shiatsu: 2 methodsavailable with speed,width and
strength adjustment.
Kneading: 2 methodsavailable with speedstrength
adjustment.
Flapping: 2 methodsavailable with speed,width
and strength adjustment.
Kneading&Flapping: 2 methodsavailable with
speed strength adjustment.
3D: 4 methodsavailable with speedand strength
adjustment.
Speed: 5 levesavailable
Width: 5 levels available (only under flapping and
shiatsu status).
UPPER BODY
WAIST
TWIST
SWING
HIP
WAIST
STRETCH
SPEED
WIDTH
AUTO
AUTO
AUTO
AUTO
Swing Hip:focus onhip massage,swing hip
machanism and seatcushion pressure operating
makes hip swing left and right

11
10
ON/OFF FUSE
Music
Other manual functions:
Method of usage Method of usage
Backrest stretch (can be operated under all manual modes
except shoulder grasp status).
Fixed massage
Partial massage
Overall massage
Position adjustment
(under fixed and partial
status, the position can
be adjusted).
Massage
mechanism up
Massage
mechanism down
Lower-body manual air massage
Foot: foot air massage with 3 strength available
When foot air massage is working, the footrest
stretch function will run automatically
Upper-body: neck&shoulder, waist and seat
air massage
Arm: arm air massage with 3 strength available
Note: Under automatic massage status, it can adjust the relative air massage
strength by pressing any button of Arm, Upper-body and Foot
Foot roller: with 3 speed levels available
Backrest heating: backrest infrared heating massage,
can be felt after 3 minutes
Upper-body strength adjustment with 5 levels available:
Stronger: press this button to increase the strength of
backrest massage
Weaker: press this button to decrease the strength of
backrest massage.
Music on and off
Previous
Next
Volume up
Volume down
Music
4. Shut off power and finish massage
Press red power button during massage to stop all massage functions
immediately, the backrest and footrest will return to original position
automatically.
After rated working time, all massage functions will be finished but backrest and
footrest won't return to original position.
Switch power off
Figure (switch power off)
Power switch position map power switch method map
BACK STRETCH
BACK STRETCH
BACK STRETCH
ARM
UPPER BODY
CALF
SOLE ROLLER
BACK WARMER

1312
Figure Figure
Figure
Figure
A
B
USB
USB
Method of usage Method of usage
5.How to downloadmp3 music :
1.Turn offthe power ofmassage chair .
2.Pull out theu-disk from theMP3 player .
3.Insert the u-disk into USB port of PC (Windows Xp Windows 2000
WindowsNT.)
4.Download your favorite MP3 format music into U-disk .if fails , please
firstly format thedisk.
5.Delete the USBMass Storage Deviceon the PCafter complete download .
6.Pull out theU-disk from PC
7.Insert U-disk to the USB port of MP3 player
8.Now MP3 music was renewed . you may turn on the power of massage
chair .
Note :
1.If fails toplay MP3 music,please firstly formatthe U-disk onPC before
Download.Then follow the instruction to insert the U-disk intoUSB port of
Mp3 player.
2.Except the U-disk, do notremove or loosethe MP3 player.
6. Amrest installationand notice.
1).Check if theinner supporting gear are well fixed onto related seat
frame position.(figure 1)
2).Pull the zipon the loweredge of thearmrest.
3).Open the bigand small coveroutside the armrest(shownas figure 2)
4).Lift the amrest and ready to install on the chair, pull air-pipe and valve
from the seat frame and cross them through relative hole on the armrest
side.(figure 3)
5).Push the slidingsets in thefront part of armrest into the inner supporting
Gear.(figure 4)
6).Push the endof the armrestinto the revolvingshaft.(figure 5)
A.Upper fixing cover B.Lower fixing cover
Figure
123

14 15
Figure Figure
Figure Figure
Figure
Figure
Figure Figure
Method of usage Method of usage
7).Gently hold the armrest side.When revolve the shaft, firstly put into cage
ring, then put into big washer and wrest the locknut by specialized tools.
(Figure 6).
8).Thread the socket head cap screws into upper tightening cap (Figure 7),
then use the provided wrench to screw in upper supporting gear and
wrest screw tight.
9).Thread the socket head cap screws into lower tightening cap (Figure 7),
then use the provided wrench to screw in lower supporting gear and
wrest screw tight.
10).Respectively connect air pipe and valve connector with relavent
connectors on theiron plate ofarmrest (Figure 8).
11).Check if the armrest is well fixed. If there isn't much swing,close the big
and small coveroutside the armrest.(Figure 9).
12).Close the zipperof lower armrestand finish installation.
Be careful don'tput stress onthe
two sides ofarmrest in orderto
support the body (Figure10)
Be careful don'tput stress
inwardly on upperarm airbag
support board (Figure11)
Thread head padair pipe and
detection lines intopocket
(Figure 12)
Respectively connect the
backrest trachea accordingto
the number (Figure 13)
Enlarge sketch map

16 17
Method of usage Product specification
7.FLOOR PROTECTION
Put theheavy massagechairs onthe woodfloor fora longtimemay
damage thefloor, so please place a carpet or other object to avoid this
damage.
Caution: Donot movethe chairswith itswheels onwood floor, rough
ground orin anarrow space.Two peopleare requiredto liftthe chair.
8.METHOD OFMOVEMENT
Make surethat all wires are far above the ground, tilt the backrest
backward toa certaindegree (withthe gravitycenter restingon the
wheels), pushthe chairforward or backward with your hands and finally
resume thechair tothe normalposition ina slowand gentlemanner.
Material introduction: PVC, PA, steel parts and electric &ele
-ctron parts
MATERIAL PU LEATHER CLOTH WOOD
Model: A33
Description: Full Body Air-massage Chair
Rated Voltage: 110-120V~ 60Hz
220-240V~ 50Hz 60Hz
Rated PowerInput: 280W
Rated WorkingTime: 15Minutes
Safety Design: Class
