Esperia KRH-M202 User manual

Thank you for purchasing ESPERIA product.
Please read this owner’s manual carefully before operang this unit.
Store it in safe place with this manual.
Memorizing radio staon to the memory
1. Press the [BAND] buon to select FM1, FM2, FM3, and MW , and select the desired
staon.
2. Then search the desired station by the seek or the manual tuning.
3. Press any button (from ① to ⑥) for 3 seconds or longer.
・The preset channel number will be indicated on the display.
・ON each band ( FM1, FM2, FM3, and MW ), 1station can be put on the memory on each of the
button from ① to ⑥.
Auto Store Memory (SCAN)
During the radio mode, by pressing and releasing [SCAN] Button will automatically store a strong signal station
in memory from the channel 1 to the channel 6.
NOTE :
By this operation, the current data in the memory will be erased.
When the expected radio station is not be able to store in the memory by the SCAN function, Please store the
radio station in the memory manually.
Owner’s manual
KRH-M202
12/24V Bluetooth®/USB/MP3/WMA
AM/FM Stereo Radio
24V/12V
MP3/WMA
Operaonal Panel
②LCD (Liquid Crystal Display)
The receiving band and frequency or the current me will be indicated on the display.
④Scan [SCAN] Buon
By pressing and releasing the buon the scan tuning will start automacally and the strong signal
are memorized on memory.
③Clock (CLOCK ADJ.) [CLOCK, CLOCK ADJ. ] Buon
On the Radio Mode, pressing this buon will indicate the current me and pressing it again will
resume frequency display.
Aer 3 seconds, the me display will automacally change to the frequency display.
Press and hold to enter in Clock Adjustment Mode.
⑤Tuning Buons [TUNE∧,∨]
By pressing [TUNE∧] or [TUNE∨] buon the receiving frequency will be up or down.
By pressing the buon more than 2 second, the seek tuning will start.
When the strong signal staon is received the seek will stop.
Please press the buon again if you want to stop the seek tuning.
①Power Buon
Press the Buon to power ON. Press again to power OFF.
⑥Preset Memory Buon[①～⑥]
On each band (FM1,FM2,FM3 and MW), One staon is memorized on the memory from the channel
1 to the channel 6.
Refer to the secon “Memorizing radio staon to the memory”
⑦Bands Select Buon [BAND]
By pressing the buon, the receiving band will be selected as shown.
FM1→FM2→FM3→MW
The receiving band and frequency will be indicated on the display.
⑧Volume Control Buon [VOL＋,－]
By pressing the [VOL+] buon, the sound volume will increase.
By pressing the [VOL–] buon, the sound volume will decrease.
⑫AUX-IN jack（Auxiliary Audio In Put）
Open the rubber cap and connect the portable audio device by the cable the stereo mini plug(3.5mm)
Please cover the AUX-IN jack with the rubber cap dustproof or waterproof, when you do not need to con-
nect the portable audio device.
Seng the Clock
When you hold down the [CLOCK] (CLOCK ADJ.) Buon for 2 seconds or more, the clock display
ashes and the clock adjustment mode is entered.
In clock adjustment mode
Pressing the [TUNE H] button to adjust hour.
Pressing the [TUNE M] button to adjust minute.
The clock display will return by pressing the [CLOCK] (CLOCK ADJ.) Buon again.
⑬USB Input Terminal
Open the rubber cap and connect a USB storage device.
Please cover the USB input terminal with the rubber cap for dustproof or water proof, when you
do not need to connect the USB storage device.
Listening the radio
1. Set the ignion key to ACC or ON and press the [POWER] buon to turn on the radio.
2. Select the desired band FM or MW by the [BAND] Button.
3. Select the desired station by a [① to ⑥] button or a [TUNE] Button.
4. To turn o the radio, press the [POWER] buon.
Manual tuning
SEEK tuning
Press the [TUNE∧] or [TUNE∨] Button, the received frequency shifts one step.
Pressing the [TUNE] Button for 2 second or longer, the seek tuning will be start and stop at the available
frequency.
Specicaons
General
Power Source ：DC12V～24V
Power Consumpon ：Less than 2A
Rated Output Power ：16W + 16W(4Ω)
Normal Output Power：14W + 14W（10％TDH，4Ω)
Dimension ：179(w)×50(H)×91(D)mm
FM secon
Receiving Frequency Range：87.5～108.0MHz(EU)
87.9～108.0MHz(USA)
Usable Sensivity ：3µV(S/N 30dB)
S/N Rao ：50dB
MW secon
Receiving Frequency Range：531～1602kHz(EU)
530～1710kHz(USA)
Usable Sensivity ：20µV(S/N 20dB)
AUX secon
AUX IN ：Stereo mini jack(φ3.5)，
Rated Input Power :1V
Normal Input Power :90mV
Bluetooth
Specicaon ：Ver5.0
Bluetooth Class：Class2
(Maximum Distance
10m) Frequency Range：2.402GHz～2.48GHz
Prole ：HFP V1.5,A2DP V1.2,AVRCP V1.0
USB
Specicaons：USB2.0/1.0
Support Format
・MP3：MPEG1,2,2.5
Audio Layer 2,3
・WMA：Windows Media TM Audio
Support File System
：FAT16/FAT32 File system
Maximum Output :DC5V / 0.5A
FM Mode
※Preset the frequency
by each 6ch.
Preset Memory Channel
It is displayed while receiving in stereo.
■General
USB ：USB Mode
BT ：Bluetooth Mode
AUX ：AUX Mode
※For USB Mode or Bluetooth Mode only
Volume Level
Audio Operaon
■Radio mode
Radio funcon
FM1
FM2
FM3
MW ：AM mode
Stereo
Frequency / Clock
Funcon
USB Operaons
Connect a USB storage device to USB socket on the this unit.
Press the [MODE] Button and select the USB Playback Mode.
During the USB Playback Mode. “USB”will be indicated on the display.
During playback, follow the instruction below to control playback.
NOTE : ・Please connect/uncomment the USB storage device in a other than USB mode.
・ESPERIA does not guarantee compatibility with all USB storage device
・Be sure to use the extension cable for the USB socket.
・Please do not connect other than USB memory device. Can not charge the smartphone.
・ESPERIA cannot be liable for any data loss or damage and improper access of USB storage
device.
① Previous Track[ ] Button
Skip to the previous track. Press and hold this button to rewind fast-rewind.
② Play/Pause[ ] Buon
Pause or resume playback.
③Stop [ ] Button
Stop playback.
Press the Play Button, playback starts at the top of current track
④Next Track[ ] Button
Skip to the next track. Press and hold this button to rewind fast-forward.
⑤Repeat [ ] Button
Repeat the current track and Press the Repeat Button again, turn off the
Repeat Mode.
⑩Bluetooth LED
When this LED lights up, the Bluetooth device is connected. Flashes in pairing standby mode.
⑨Bluetooth [B] buon
Press the buon to connect to the last Bluetooth compable device that has registered (Pairing).
If you press and hold for 2 seconds or more, connecon (registraon) is released and the pairing
standby mode is set.
⑪Mode Select Buon [MODE]
Pressing the buon, a source will be selected as shown.
If USB memory is not connected, USB mode will skip aer any seconds.
FM or MW →USB →Bluetooth →AUX
USB AUXIN
-2.32dBm(for EU)

Pairing Bluetooth deviceｓ
When connecng a Bluetooth deviceｓ for the rst me, mutual registraon is required.
Pairing enables this unit and other devices to recognize each other.
※Please rst enable Bluetooth funcon of the Bluetooth device before pairing.
For details, please refer to the manual of Bluetooth device.
1.Press the [MODE] Buon to select the funcon Bluetooth mode.
2.Enable Bluetooth on the Bluetooth device.
3.Press and hold the Bluetooth Buon unl the sounds connected. (tow beep sounds)
※When "P" ashes on the display, it is in pairing standby mode.
4.Select "CAR RADIO" with Bluetooth device.
※Only one pair of Bluetooth devices can be paired with this unit. If you want to pair other devic-
es, repeat steps 1 to 4 again.
Play audio of Bluetooth device
If you have already registered (pairing) in the Bluetooth device, make sure that the Bluetooth
LED is turning on light. Press the [MODE] buon to switch to the BT mode.
In BT mode Bluetooth device can be operated with ① to ⑤ buons.
① Previous Track[ ] Button
Return to the beginning of the current track.
Press the button again to skip to the previous track.
② Play/Pause[ ] Buon
Pause or resume playback.
④Next Track[ ] Button
Skip to the next track.
⑤Repeat [ ] Button
invalid in Bluetooth mode.
Trouble shoong
Problem Cause Measure
Can not connect a Blue-
tooth device
Bluetooth connecon is not
established
Depending on your Bluetooth device, some items that
takes me to connect may not be automacally recon-
nected.
Please check that the Bluetooth LED,
if it does not turn on the light on me, please pair again
according to "Pairing Bluetooth devices".
Another Bluetooth devices
is connected.
If another Bluetooth device is connected, pair it again
according to "Pairing Bluetooth device".
Cannot remotedly control
Bluetooth devices.
AVRCP prole is not con-
nected
Please disconnect all connected Bluetooth devices and
pair it again according to "Pairing Bluetooth device".
The connecon link be-
tween devices may be bro-
ken
Again according to "Pairing Bluetooth device".
does not support AVRCP Please check the support prole of Bluetooth device..
Bluetooth device volume is
low
The volume of the Bluetooth device will be aected.
Please set the volume of the Bluetooth device to an
appropriate value.
No sound heard
The output desnaon of
the Bluetooth device is not
set to "CAR RADIO"
Please conrm that the Bluetooth device music output
desnaon is in "CAR RADIO"
Can not talk on the phone This unit does not support
Bluetooth calling.
Depending on the model of
the mobile phone, you may
connect to this unit with the
call prole.
Please change the microphone seng from this unit to
the mobile phone microphone on the call screen accord-
ing to the instrucon manual of your mobile phone.
Bluetooth audio playback
stops aer incoming call
Audio may not resume aer
phone interrupt.
Aer the call ends, please again according to "Pairing
Bluetooth device".
Reseng the radio
・This radio has an AUX input jack for portable device.
・Be sure to use the cable stereo mini plug(3.5mm)for the AUX-IN jack.
・Pressing the [MODE] Button and select the AUX mode.
・During the AUX mode, “AUX” will be indicated on the display.
・The volume controls of portable device should be adjusted approximately same as currently portable audio
device should be adjusted approximately same as currently listening radio sound volume level.
・Volume control buttons are able to control the sound with this unit
AUX Funcon
Using Bluetooth wireless technology
Mobile phones and audio devices that support Bluetooth can be connected to use with
this unit.
You will be noed that there is an incoming call by connecng the mobile phone.
※This unit will not support calls for the reason of No microphone is installed.
In order to use Bluetooth devices must be able to match certain proles. this unit is compable
with following proles.
Incoming mobile phones
HFP(Hands-Free Prole)
Bluetooth audio
A2DP(Advanced Audio Distribuon Prole)
AVRCP(Audio/Video Remote Control Prole)
Note: The Bluetooth word mark and logos are owned by the Bluetooth SIG, inc. and any use of
such marks by ESPERIA Co.,Ltd Is under licensed. Other trademarks and trade names are those of
their respecve owners.
Problem Cause Measure
Nothing happens when
buons are pressed.
display is not accurate.
CPU malfuncon due to
noise etc.
Reset this unit according to "Reseng the radio".
Aer reseng, preset memory etc. all disappear, please
set again.
General
Problem Cause Measure
Sound is noisy It is not on the frequency of
the broadcasng staon
Please adjust to the correct frequency.
Antenna does not extend
(when using pillar antenna)
When using a radio, please use with the pillar antenna
extend.
The antenna is not ground-
ed or not installed properly
Please consult your dealer.
Antenna power supply not
connected
The booster built-in antenna needs to connect the power
supply to the antenna.
For details, please consult your dealer.
Display unusual frequencies CPU malfuncon due to
noise etc.
Reset this unit according to "Reseng the radio".
Aer reseng, preset memory etc. all disappear, please
set again.
USB Playback
Problem Cause Measure
No sound heard The USB storage device
contains no MP3/WMA les.
Record MP3/WMA les properly to the USB storage de-
vice.
The les are not proper
MP3/WMA format.
Use only properly encoded MP3/WMA les.
Sound is
Interrupted or has noise.
The MP3/WMA
Files are improperly
Encoded.
Use only properly encoded MP3/WMA les.
The device isn’t
recognized
The device is Damaged. Disconnect the USB storage device and reconnect. If the
device is sll not recognized, try replacing with a dierent
device.
Connectors are loose.
The USB memory is not
formaed with FAT32 /
FAT16
Format the USB storage device with the FAT32 / FAT16
le system and write the MP3 / WMA le.
Be sure to back up the USB memory before formang.
Radio
Bluetooth
46-202-002-29 20210617 EN
Co.,ltd.
2-8-85,YOSHINODAI,KAWAGOE-CITY SAITAMA-PREF.,JAPAN
③Stop [ ] Button
Music that is playing stops.
Bluetooth device incoming call
If the Bluetooth device has already been connected (Bluetooth LED is lit), this unit is in standby
mode for incoming calls.
When receiving a call, "CALL" appears on the liquid crystal display, the volume of the car stereo
automacally mutes, and the ringing tone of the phone is played from the speaker.
CAUTION: There is a funcon to reconnect to the last connected device by turning
the power on.
Prevent incorrect connecon when leaving this unit in (car etc.),
Press and hold Bluetooth buon unl it sounds"beep", then please release pairing.
CAUTION: In case no sound is detected from this unit, please see to it that the Bluetooth
compable device music output desnaon is in "CAR RADIO" Please check.
Please reset this device in trouble such as when frequency display is dierent and when switch-
ing is impossible etc.
Hold down the Bluetooth buon and press the power buon.
Manufacturer Hidaka Corporation
203, East of Building 1, Paibang Jialian Industrial Area, Silian
Community, Henggang Street, Longgang District, Shenzhen
City, Guangdong Province, P.R.China
Factory Address:

English：
Declaraon of conformity
We use this model KRH-M505
In accordance with the provisions of the 2014/53/EU and
2011/65 EU direcve, we have established basic require-
ments and other relevant rules.
Italiano：
Dichiarazione di conformità
Noi siamo questo modello KRH-M505
2014/53 / UE e 2011/65 in conformità con le disposizioni
della direva europea, che deniscono i requisi di base e di
altri regolamen pernen.
Ees:：
vastavusdeklaratsioon
Me oleme seda mudelit KRH-M505
2014/53 / EL ja 2011/65 vastavalt sätetele Euroopa Liidu
direkivi, millega määratletakse põhilised nõuete ja
teiste asjakohaste määrustega.
Deutsch：
Konformitätserklärung
Wir sind dieses Modell KRH-M505
2014/53 / EU und 2011/65 mit den Besmmungen der EU-
Richtlinie in Einklang, die grundlegenden Anforderungen und
den anderen relevanten Vorschrien zu denieren.
Nederlands：
verklaring van overeenstemming
We zijn dit model KRH-M505
2014/53 / EU en 2011/65 in overeenstemming met de be-
palingen van de EU-richtlijn, het deniëren van de funda-
mentele eisen en andere relevante voorschrien.
Ελληνικά：
δήλωση συμμόρφωσης
Είμαστε αυτό το μοντέλο ΚΚΗ-M505
2014/53 / ΕE και 2011/65 σύμφωνα με τις διατάξεις της
οδηγίας της ΕΕ, που καθορίζει τις βασικές απαιτήσεις και
άλλες σχετικές διατάξεις.
Hrvatska：
Izjava o sukladnos
Mi smo ovaj model KRH-M505
2014/53 / EU i 2011/65, u skladu s odredbama direkve EU,
deniraju osnovne zahtjeve i druge relevantne propise.
Svenska：
Försäkran om överensstämmelse
Vi är den här modellen KRH-M505
2014/53 / EU och 2011/65 i enlighet med bestämmelserna i
EU-direkvet, som denierar de grundläggande kraven och
andra relevanta bestämmelser.
Español：
Declaración de conformidad
Somos este modelo KRH-M505
2014/53 / UE y 2011/65 de conformidad con las disposi-
ciones de la direcva de la UE, que denen los requisitos
básicos y otras regulaciones relevantes.
Slovenskú：
vyhlásenie o zhode
My sme tento model KRH-M505
2014/53 / EÚ a 2011/65 v súlade s ustanoveniami smernice
EÚ, ktoré denujú základné požiadavky a iné relevantné
predpisy.
Slovenski：
izjava o skladnos
Mi smo ta model KRH-M505
2014/53 / EU in 2011/65 v skladu z določbami direkve EU,
ki opredeljuje osnovne zahteve in druge ustrezne predpise.
Český：
prohlášení o shodě
My jsme tento model KRH-M505
2014/53 / EU a 2011/65 v souladu s ustanoveními směrnice
EU, které denují základní požadavky a další relevantní
předpisy.
dansk:
overensstemmelseserklæring
Vi er denne model KRH-M505
2014/53 / EU og 2011/65 i overensstemmelse med bestem-
melserne i EU-direkvet, som denerer de grundlæggende
krav og andre relevante bestemmelser.
Français：
Déclaraon de conformité
Nous sommes ce modèle KRH-M505
2014/53 / EU et 2011/65, conformément aux disposions de
la direcve européenne, dénissant les exigences de base et
d'autres règlements pernents.
Magyar：
Megfelelőségi nyilatkozat
Mi ez a modell KRH-M505
2014/53 / EU és a 2011/65 a rendelkezéseivel összhangban
az uniós irányelv, amely meghatározza az alapvető követel-
ményeinek és egyéb vonatkozó előírásoknak.
suomi：
vaamustenmukaisuusvakuutus
Olemme tätä mallia KRH-M505
2014/53 / EU ja 2011/65 mukaises määräysten EU-
direkivin, jossa määritellään perusvaamukset ja muut asi-
aankuuluvat määräykset.
Български:
Декларация за съответствие
Ние сме този модел KRH-M505
2014/53 / EC и 2011/65 в съответствие с разпоредбите на
директивата на ЕС, които определят основните
изисквания и другите приложими разпоредби.
Polska：
Deklaracja zgodności
Używamy tego modelu KRH-M202
Zgodnie z przepisami dyrektywy 2014/53/UE i 2011/65 UE
ustanowiliśmy podstawowe wymogi i inne odpowiednie
przepisy.
Português：
declaração de conformidade
Nós somos este modelo KRH-M505
2014/53 / UE e 2011/65, em conformidade com as dis-
posições da direcva da UE, denindo os requisitos básicos e
outros regulamentos relevantes.
Latvijas：
atbilstības deklarācija
Mēs esam šis modelis KRH-M505
2014/53 / ES un 2011/65 saskaņā ar ES direktīvas noteikumi-
em, kuros noteiktas pamatprasības un citus būskus noteiku-
mus.
Lietuvių：
akes deklaracija
Mes šis modelis KRH-M505
2014/53 / ES ir 2011/65 pagal ES direktyvos nuostatų,
apibrėžiančių pagrindinius reikalavimus ir kitus susijusius
teisės aktus.
Română：
declaraţie de conformitate
Suntem acest model de KRH-M505
2014/53 / UE și 2011/65, în conformitate cu dispozițiile di-
recvei UE, care denesc cerințele de bază și alte regle-
mentări relevante.
Icelandic：
Samræmisyrlýsing
Við erum þea líkan KRH-M505
2014/53 / ESB og 2011/65 í samræmi við ákvæði lskipunar
ESB, sem skilgreina grunnkröfur og aðrar viðeigandi reglu-
gerðir.
Norsk：
samsvars~~POS=TRUNC
Vi er denne modellen KRH-M505
2014/5 3/ EU og 2011/65 i samsvar med bestemmelsene i EU
-direkv, som denerer de grunnleggende kravene og andre
relevante bestemmelser.
Türkçe：
uygunluk Beyanı
Bu modelin KRH-M505 vardır
2014/53 / AB ve 2011/65 temel gereksinimleri ve diğer ilgili
düzenlemeleri tanımlayan AB direkf hükümlerine uygun
olarak.
Seapáinis：
dearbhú comhréireachta
Tá muid an múnla KRH-M505
2014/53 / AE agus 2011/65 i gcomhréir le forálacha na treor-
ach AE, lena sainmhínítear na ceanglais bhunúsacha agus ri-
alacháin ábhartha eile.
Ġappuniż：
dikjarazzjoni ta 'konformità
Aħna dan il-mudell KRH-M505
2014/53 /UE u 2011/65 skond id-dispożizzjonijiet tad-
Direva tal-UE, li jiddenixxu r-rekwiżi bażiċi u regolamen
relevan oħra.
Co.,ltd.
2-8-85,YOSHINODAI,KAWAGOE-CITY SAITAMA-PREF.,JAPAN
TEL:[phone] FAX:[phone]

2
FCC 15B ClassB
CAUTION
Changes or modicaons not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not occur in a
parcular installaon. If this equipment does cause harmful interference to radio or tele-
vision recepon, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the re-
ceiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
IC
(EN)
This device complies with Industry Canada’s licence-exempt RSSs. Operaon is subject to
the following two condions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause un-
desired operaon of the device.
(FR)
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitaon est autorisée aux deux condions suivantes;
1) l’appareil ne doit pas produire de brouillage;
2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
suscepble d’en compromere le fonconnement.
SAR test
(EN)
This equipment complies with FCC/IC radiaon exposure limits set forth for an uncon-
trolled environment and meets the FCC radio frequency (RF) Exposure Guidelines and
RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low lev-
els of RF energy that it deemed to comply without maximum permissive exposure evalu-
aon (MPE). But it is desirable that it should be installed and operated keeping the radi-
ator at least 20cm or more away from person’s body (excluding extremies: hands,
wrists, feet and ankles).
(FR)
Cet équipement est conforme aux limites d’exposion aux rayonnements énoncées pour
un environnement non contrôlé et respecte les règles les radioélectriques (RF) de la FCC
lignes directrices d'exposion et d’exposion aux fréquences radioélectriques (RF) CNR-
102 de l’IC. Cet équipement émet une énergie RF très faible qui est considérée conforme
sans évaluaon de l’exposion maximale autorisée. Cependant, cet équipement doit
être installé et ulisé en gardant une distance de 20 cm ou plus entre le disposif rayon-
nant et le corps (à l’excepon des extrémités : mains, poignets, pieds et chevilles).
Co.,ltd.
2-8-85,YOSHINODAI,KAWAGOE-CITY SAITAMA-PREF.,JAPAN
TEL:[phone] FAX:[phone]/06
