Murata HN-210D User manual

Revision History
Revision
Date
Author
Change Description
1
05/03/2012
F. Perkins
Initial issue
2
01/16/2015
R. Willett
Reformatted to comply with new Murata V.I.
HN-210D/X
HN-214D/X
RS-232
Serial Modbus
Radio
User Guide
www.murata.com
301/13/2017 R. Willett Updated Copyright
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2012
HN-210D/X, HN-214 D/X Rev. 2.0 01-13-17

Important Regulatory Information
Cirronet Product FCC ID: HSW-2410
IC 4492A-2410
FCC s MPE Requirements
Information to user/installer regarding FCC s Maximum Permissible Exposure
(MPE) limits.
Notice to users/installers using the 24 dBi parabolic dish antenna in conjunction
with all Cirronet RF products.
FCC rules limit the use of this antenna, when connected to Cirronet RF products for
point-to-point applications only. It is the responsibility of the installer to ensure that
the system is prohibited from being used in point-to-multipoint applications, omni-
directional applications, and applications where there are multiple co-located intentional
radiators transmitting the same information. Any other mode of operation using this
antenna is forbidden.
Notice to users/installers using the following fixed antennas, with Cirronet
RF products:
Andrews 24dBi parabolic dish
Andrews 18dBi parabolic dish
Cushcraft 15dBi Yagi,
Mobile Mark 14dBi Corner Reflector,
Mobile Mark 9dBi Corner Reflector
The field strength radiated by any one of these
antennas, when connected to Cirronet RF
products, may exceed FCC mandated RF
exposure limits. FCC rules require
professional installation of these antennas in
such a way that the general public will not be
closer than 2 m from the radiating aperture of
any of these antennas. End users of these
systems must also be informed that RF
exposure limits may be exceeded if personnel
come closer than 2 m to the apertures of any of
these antennas.
Notice to users/installers using the following mobile antennas, with
Cirronet RF products:
Mobile Mark 12dBi omni-directional,
Mobile Mark 9dBi omni-directional,
MaxRad 5dBi whip,
Cirronet Patch antenna,
Ace 2dBi dipole,
Mobile Mark 2dBi Stub
The field strength radiated by any one of these
antennas, when connected to Cirronet RF
products, may exceed FCC mandated RF
exposure limits. FCC rules require professional
installation of these antennas in such a way
that the general public will not be closer than
20 cm from the radiating aperture of any of
these antennas. End users of these systems
must also be informed that RF exposure limits
may be exceeded if personnel come closer
than 20 cm to the apertures of any of these
antennas.
Note: This unit has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate rad
io frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
i ti O ti f thi i t i id ti l i lik l t
www.murata.com
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2012
HN-210D/X, HN-214 D/X Rev. 2.0 01-13-17

Declaration of Conformity
Warning! The RLAN transceiver within this device uses a band of frequencies
that are not completely harmonized within the European Community. Before
using, please read the European Operation Section of the Products User’s Guide for
limitations.
0889 is the identification number of RADIO FREQUENCY INVESTIGATION LTD -
Ewhurst Park, Ramsdell RG26 5RQ Basingstoke, United Kingdom – the Notified Body
having performed part or all of the conformity assessment on the product.
The WIT2410 to which this declaration relates is in conformity with the essential
requirements of the R&TTE directive 1999/5/EC and complies with the following
standards and/or other normative documents:
For Interfaces
For RLAN Transceiver
EN 55022
EN 55024
EN 300 328
EN 301 489 -1, -17
EN 60950
Canadian Department of Communications Industry Canada (IC) Notice
Canadian Department of Communications Industry Canada (IC) Notice
This apparatus complies with Health Canada’s Safety Code 6 / IC RSS 102.
"To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding. Equipment (or
its transmit antenna) that is installed outdoors may be subject to licensing."
ICES-003
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the radio interference regulations of Industry Canada.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les
limites applicables aux appareils numériques de Classe B prescrites dans le règlement
sur le brouillage radioélectrique édicté par Industrie Canada.
www.murata.com
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2012
HN-210D/X, HN-214 D/X Rev. 2.0 01-13-17

WARNING!!
≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡≡
For our Customers who wish to use this product in hazardous locations.
The HN-210D, HN-210DX, HN-214D and HN-214DX radios have been tested by
Underwriters Laboratories Inc. for use in Class I, Division 2, Groups A, B, C, and D
Hazardous Locations as specified in UL1604 and UL/C-UL/Zones(UL2279).
Such areas may have Explosive Gases.
To install these radios in this environment the following steps must be implemented.
The power supply used with the product must be a UL Class 2 rated device.
1) Contract a Qualified Licensed Electrician to install and run the power wiring from
a screw type, hard wired 12 VDC 1A Class 2 Output power supply in a UL Listed
Box and route a conduit to the radio which must be installed in a UL Listed Box
suitable for the environment. The conduit must be gas tight so no gases can
flow through conduit.
2) Any Cirronet products with outdoor radio transceivers (tower mounted) marked
for Hazardous Locations must have the interconnecting multi-conductor cable
run in approved conduit for the hazardous location. The cable must be in the
conduit until out of the Hazardous Location and the conduit must be gas tight so
no gases can flow through conduit.
3) Do NOT remove the power connector to the device while circuit is live.
Disconnect power only while circuit is dead, or the location is known to be non-
hazardous. Failure to do so, may result in a “Risk of Fire or Explosion”
Only then is the unit suitable for a hazardous location.
For more information on Hazardous Locations contact UL and ask for UL1604
requirements. www.ul.com
RF Exposure
WARNING: End Users of these systems must be informed that RF exposure
limits may be exceeded if personnel come closer than 45 cm to the antenna
aperture when exceeding 9 dBi of gain in conjunction with the transceiver.
Repairs
Murata does not recommend field repairs of the radio equipment. Surface
Mount Technology (SMT) has been used in the production of the transceiver
module, which requires specialized training and equipment for proper
servicing. The equipment should be returned to the factory for any repair.
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2012
HN-210D/X, HN-214 D/X Rev. 2.0 01-13-17www.murata.com

Table of Contents
Introduction ..................................................................................................................1
HopNet Benefits...........................................................................................................1
Operating Frequency ...............................................................................................1
HopNet Frequency Hopping Spread Spectrum Advantages....................................2
HopNet Data Integrity............................................................................................... 2
Flexible Power Management.................................................................................... 2
Advanced Features......................................................................................................3
The HopNet Family of Products...................................................................................3
Accessories..............................................................................................................3
Getting Started................................................................................................................4
Install the HopNet Configuration Wizard on a PC. .......................................................4
Connect the HopNet radio to the PC............................................................................4
Set one HopNet radio to act as the base......................................................................5
Run a communications test..........................................................................................7
The Serial Adapter Box................................................................................................8
3 Wire Operation......................................................................................................8
Remote Pin-Out, RS-232 .........................................................................................9
Guidelines for Installation........................................................................................... 10
Aiming the Antenna and Placing the Remote............................................................. 10
Interconnect Cable..................................................................................................... 10
Configuring the Network................................................................................................11
HopNet Configuration Wizard (5.0 or later)................................................................11
About the INIT.INI File................................................................................................ 12
Parameters Tab ..................................................................................................... 13
Network Tab........................................................................................................... 17
Protocol Tab...........................................................................................................20
RF Tools ................................................................................................................ 22
WinCom Window.................................................................................................... 26
Function Keys ........................................................................................................29
Recover.................................................................................................................. 29
Restart ...................................................................................................................30
Saving Configurations................................................................................................ 30
About Protocols..........................................................................................................30
Modbus Operation...................................................................................................... 32
Automatic Addressing............................................................................................ 33
DNP3/DF1 Operation................................................................................................. 33
European Union Operation......................................................................................... 34
Configuration Commands..............................................................................................35
Serial Commands....................................................................................................... 36
Network Commands................................................................................................... 38
Protocol Commands................................................................................................... 41
Status Commands...................................................................................................... 44
Memory Commands................................................................................................... 46
Adapter Commands ...................................................................................................47
Modem Command Summary .....................................................................................48
www.murata.com
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2012
HN-210D/X, HN-214 D/X Rev. 2.0 01-13-17

Troubleshooting ............................................................................................................49
Overview....................................................................................................................49
Introduction............................................................................................................49
Transceiver Requirements.....................................................................................49
Common System Problems........................................................................................50
Guidelines for Reducing Interference......................................................................... 51
Introduction............................................................................................................51
Guidelines for Setting Up the Network...................................................................51
Guidelines for Selecting Your Site..........................................................................51
Guidelines for Avoiding Terrain Obstructions.............................................................52
Customer Support...................................................................................................... 53
Introduction............................................................................................................53
Technical Assistance .............................................................................................53
Factory Repairs...................................................................................................... 53
Technical Specifications................................................................................................ 54
Electrical ................................................................................................................ 54
Mechanical.............................................................................................................55
Environmental........................................................................................................ 55
Glossary of Terms......................................................................................................... 56
Warranty........................................................................................................................58
www.murata.com
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2012
HN-210D/X, HN-214 D/X Rev. 2.0 01-13-17

Introduction
The HopNet family of products provides reliable wireless connectivity for either point-to-
point or point-to-multipoint applications. HopNet products are built around the WIT2410
radio transceiver, which employs frequency hopping spread spectrum technology. This
technology ensures:
•Maximum resistance to noise
•Maximum resistance to multipath fading
•Robustness in the presence of interfering signals
The HN-210D and HN-210DX are NEMA 4X weatherproof versions of the HopNet
product line. The HN-214D, which is a HN-210D with a 4 ft. cable, is also available. The
interface to the HopNet D and DX versions allows the Host to communicate with the
Remote unit through an integrated 50 ft (15 meter) cable. The HopNet D and DX
versions can act as either Bases or Remotes.
The HopNet D Remote has an internally mounted 6 dBi patch antenna. The
built-in antenna of the HopNet D case greatly eases outdoor installation since
no antenna feedline cable or adapters are needed. The 6 dBi antenna gain
increases the radiated EIRP to +24 dBm and the effective receiver sensitivity
to –99 dBm. The HopNet DX has a TNC connector for attaching one of the
following external antennas:
OMNI242 OMNI249
OMNI2412 YAGI2415
RWA242 RWA249
CORNER249 CORNER2414
PAR2418
PAR2424
HopNet Benefits
The HopNet family of products is built with rugged enclosures compliant with
IP 66 and NEMA 4X standards for outdoor and harsh industrial environments.
All Hopnet products work with each other and can be mixed and matched in a
single network. All HopNet Products are WIT2410 compatible and can be
used with WIT2410 OEM based products as well as with the SNAP 2410
10/100Base T access point.
Operating Frequency
The HopNet family operates in the 2.4 GHz ISM band that allows for license-
free use and worldwide compliance.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
7 of 64
www.murata.com

HopNet Frequency Hopping Spread Spectrum Advantages
In the frequency domain, a multipath fade can be described as a frequency
selective notch that shifts in location and depth over time. Multipath fades
typically occupy five percent of the band. A conventional radio system
typically has a five percent chance of signal impairment at any given time due
to multipath fading.
Frequency Hopping Spread Spectrum reduces the vulnerability of a radio
system to interference from jammers and multipath fading by distributing or
spreading the signal over a larger region of the frequency band.
The fade resistant, HopNet frequency-hopping technology employs up to 75
channels and switches channels over 100 times a second to achieve high
reliability throughput.
HopNet Data Integrity
An on-board 3 KB buffer and error correcting over-the-air protocol ensure
data integrity even in the presence of weak signals or jammers. The serial
interface handles both data and control of asynchronous data rates of up to
230 Kbps.
Flexible Power Management
The power can be set at 10 milliwatts or 100 milliwatts using the included
software. Reduced power can reduce the size of the coverage zone, which
may be desirable for multiple network indoor applications. You can also place
the transceiver module in a power-save mode, which enables smart power
management. Smart power management allows a remote unit to drop into a
lower current standby mode during transmission or receiving gaps. This
feature also allows HopNet products to be used in various countries where
the output power requirements may vary due to regulation.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
8 of 64
www.murata.com

Advanced Features
HopNet modems have many advanced features:
•Employ frequency hopping technology with up to 75 channels in the
2401 to 2475 MHz frequency range
•Support digital addressing for up to 64 networks, with 62 remotes per
network.
•Use transparent ARQ protocol
•Use same hardware for all supported data rates
•Supports up to 230 Kbps asynchronous data rates
•Full Duplex operation
•Store setup configuration in nonvolatile memory (FLASH)
•Fast acquisition – less than 2 seconds is the typical time to acquire
hopping pattern
•Smart power management features
The HopNet Family of Products
The HopNet family consists of the following products:
HN-210
HN-210X
HN-210D
HN-214
HN-214X
HN-210DX
HN-214D
HN-214DX
HN-510
SNAP2410
SNAP2410X
SNAP2410D
SNAP2410DX
Accessories
Antennas
Adapter
Power Supplies
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
9 of 64
www.murata.com

Getting Started
A pair of HopNet radios are set up by performing the following steps:
•Install the HopNet Wizard configuration program on a PC
•Connect the HopNet radio to the PC
•Set one HopNet radio as a base radio
•Run a communications test
These steps are described in detail below. Other steps you may want to
perform include:
•Change the baud rate
•Change the radio network number
•Change how fast the radios change frequencies
Refer to the Configuring the Network section of this manual for details on
these steps.
Install the HopNet Configuration Wizard on a PC.
The HopNet Configuration Wizard is located on the software and documentation CD
included in the HopNet radio package. Install the program by inserting the CD in the PC
and following the installation wizard. If autorun has been turned off, double-click on
setup.exe on the CD to start the wizard.
Connect the HopNet radio to the PC.
Plug one end of the serial cable provided to a serial port on the PC.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
10 of 64
www.murata.com

Connect the other end of the serial cable to the DIN rail serial adapter box.
Connect the end of the cable (RJ-45 connector) from the HopNet radio to the DIN rail
serial adapter box.
NOTE: Make sure the RUN/CONFIG switch is in the CONFIG position.
Connect power to the HopNet radio by plugging one end of the wall-mount power
supply into the serial adapter box and the other end into a wall outlet. A green LED on
the serial adapter box will turn on indicating power is present.
Set one HopNet radio to act as the base.
CAUTION: When using a USB to RS-232 adapter, the HN Wizard may not be able to
detect if the HopNet radio is disconnected from the computer. If the HopNet radio is
disconnected from the computer, it is necessary to click on the Restart button on the HN
Wizard screen. This will reload the settings from the radio in case a different radio has
been connected.
When using HopNet radio, one unit, and only one, must be set as the base. All other
HopNet radios must be set as remotes. With a HopNet radio connected to the PC, start
the HopNet Configuration Wizard program by double-clicking on the icon on the
desktop. The HopNet Configuration Wizard will automatically detect which serial port
the HopNet radio is connected to and its baud rate. When the radio has been detected,
the Continue button will appear.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
11 of 64
www.murata.com

Click on the Continue button to bring up the next screen.
The program will read and display the current settings of the HopNet radio. The HopNet
radio is shipped from the factory as a remote. The Remote button on the Wizard screen
will appear depressed indicating the HopNet radio is a remote.
NOTE: The S/N displayed in the bottom left corner is the serial number of the radio
inside the unit and is different from the serial number of the HopNet unit. Both the
HopNet unit serial number and the radio serial number are on the radio unit of the
HopNet product.
To set the HopNet radio as a base, click on the Base button. The Base button will
depress and the Remote button will pop up. The screen heading will change from
“Remote Parameters” to “Base Parameters.”
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
12 of 64
www.murata.com

The Apply Settings button will appear at the bottom of the HopNet Configuration Wizard
screen. Click on the Apply Settings button to set the HopNet radio as the base.
Run a communications test.
To run a communications test, connect one HopNet radio set as a base to one PC
running the Wizard and another HopNet radio set as a remote to another PC running
the Wizard. Verify that the Carrier Detect LED (CD) on the radio is on (red), the fifth
parameter box on the lower left of the window will have DCD (as shown above right).
Click on the Send Data button on the HopNet Configuration Wizard screen on both PCs.
The HopNet radio set up as the base will send the message “This is a test message
from the Base radio.” to the remote HopNet radio. This message will be displayed in the
message window of the Wizard running on the remote PC. The remote HopNet radio
will send the message “This is a test message from the Remote radio.” to the base
HopNet radio. This message will be displayed in the message window of the Wizard
running on the base PC. The test will run continuously until the Stop button is clicked.
NOTE: If your computer has two serial ports, both the base and the remote
HopNet radios can be connected to the same PC and the communications test
run by opening a second window running the Wizard. Open the second window
by simply double-clicking on the Wizard icon on your desktop.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
13 of 64
www.murata.com

The Serial Adapter Box
The HopNet radio remotes interface with the user’s hardware through a serial adapter
box. The interface adapter supplies power and signal to the remote unit. The interface
to the remote unit is a RS-232 male DB-9 serial interface. To have all functions of the
HopNet radio available, including configuration and hardware flow control, the eight
signal lines must be connected.
CONFIG Mode
When the RUN/CONFIG switch is in the CONFIG position, the HopNet radio data
connector is set up as a DCE device. This allows communication with a PC using the
straight-through, serial cable provided with the HopNet radio. The switch must be in the
CONFIG position to run the HN Wizard.
RUN Mode
When the RUN/CONFIG switch is in the RUN position, the HopNet radio data connector
is set up as a DTE device. The switch must be in the RUN position to operate with a
PLC configured as a DCE device.
3 Wire Operation
If configuration and hardware flow control is not necessary, the HopNet radio can be
used in 3-wire mode. In this mode, only Ground, Receive Data and Transmit data are
connected. The connector pinout is provided below.


Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
14 of 64
www.murata.com

Remote Pin-Out, RS-232
Pin
Number Signal Type Description
1 DCD Output Data Carrier Detect. For remotes, DCD
indicates that the remote has successfully
acquired the hopping pattern.
2 RXD
(CONFIG) Output Output for Received Serial data.
2 TXD
(RUN) Input Input Serial Data to be transmitted
3 TXD
(CONFIG) Input Input Serial Data to be transmitted
3 RXD
(RUN) Output Output for Received Serial data.
4 DTR Input Data Terminal Ready. Sleep/ wakes radio
transceiver.
5 GND - Signal and Chassis Ground
6 DSR Output Data Set Ready. Response to DTR.
7 RTS Input Request to Send. Gates the flow of receive
data from the radio to the user on or off. In
normal operation signal should be asserted.
8 CTS Output Clear to Send. Used to control transmit flow
from the user to the user to the radio. The
WIT 2410 radio module supports hardware
flow control only and does not support
software flow control (e.g. Xon-Xoff).
9 Not Used - Not Used
NOTE: When the HopNet radios are used as three wire serial devices, DTR and
RTS do not have to be used.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
15 of 64
www.murata.com

Guidelines for Installation
When installing your system, always consider the following points:
Directional antennas are best for remote unit sites. They may increase the
cost, but they confine the transmission path to a narrow lobe and minimize
the interference from nearby stations.
For systems with constant interference present, you may need to change the
polarity of the antenna system and reduce data streams. Groups of short data
streams are more reliable and have a better chance of success in the
presence of interference than do long data streams.
Systems installed in rural areas are least likely to encounter urban
interference.
Multiple HopNet systems can operate in close proximity to each other but
require a unique network address.
Poor quality coaxial cables will seriously degrade system performance. Use
low- loss cable that is suitable for 2.4 GHz operation.
Short cable runs minimize signal loss.
Refer to the section Troubleshooting for additional information on installing a
radio.
Aiming the Antenna and Placing the Remote
Use the following guidelines for aiming the antenna and placing the Remote;
•Do not place anything immediately in front of the antenna that could
obstruct its radiation pattern. Because the antenna in the HopNet
Remote is inside the unit, the antenna must have a clear line of sight.
NOTE: Use the sticker on the HopNet Remote unit to help you locate
and aim the antenna. The sticker indicates which direction the antenna
is pointing.
•Be sure the antenna end of the HopNet radio Remote faces the Base
or Repeater that it is communicating with. Our tests have found that
antenna placement is not critical as long as the patch antenna is facing
in the general direction of the other end of the link.
•If possible, place the Remote unit at a higher elevation than the
structures surrounding it to increase range and link reliability. Since the
Remote will operate with up to 100 feet of interconnect cable between
it and the Host, you can mount the unit on top of a building or other
structure that will provide higher elevation.
Interconnect Cable
The HopNet radios come with 50’ (15 meters) of high quality interconnect
cable. The cable may be lengthened by adding an additional 50’ cable (part
no.: CBLEXT50). The maximum cable length that the HopNet radios will
support is 100’ (30 meters).
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
16 of 64
www.murata.com

Configuring the Network
You can configure the HopNet network using a PC and the HopNet
Configuration Wizard software provided by Cirronet, Inc. The Wizard runs
under Windows 98/NT/2000/XP. This chapter provides the information you
need to configure your network.
HopNet Configuration Wizard (5.0 or later)
If you haven’t already installed the Wizard program, refer to the Getting
Started section of this manual for instructions. Open the Wizard by double-
clicking on the icon on the desktop. When the Wizard boots up, it will
automatically detect the serial port to which the HopNet radio is connected
and its baud rate. This process takes a few seconds to complete. During this
process, the “Please wait” screen is displayed. Once the radio has been
found and the Baudrate determined, the “Finished” screen is displayed. Click
on the Continue button to enter the Wizard.
NOTE: The HopNet configuration Wizard is used with a variety of
Cirronet radios. Not all radios support all the functions and features of
every Cirronet radio. Thus, some selections in the Wizard will be grayed
out if they are not applicable to the radio in use.
After detecting the serial port and baud rate of the HopNet radio, the Wizard
reads the settings of the HopNet radio that is connected to the PC and will
display them in the various parameter windows. In the bottom left corner of
the Wizard window, the Base/Remote status, the serial number and the
communication port are always displayed.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
17 of 64
www.murata.com

NOTE: The S/N displayed in the bottom left corner is the serial number
of the radio inside the unit and is different from the serial number of the
HopNet unit. Both the HopNet unit serial number and the radio serial
number are on the radio unit of the HopNet product. The Wizard will also
prompt to save the configuration settings to a file.
When a parameter value is changed from the value currently in the HopNet
radio, the parameter label and value will turn red and the Apply Settings
button will appear. When the value is changed back to the value that is
currently in the attached HopNet radio, the label and parameter value will
return back to black. When new values are applied to the HopNet radio, the
red values will turn black indicating the updated values in the radio.
NOTE:The changes are not sent to the HopNet radio until the Apply
Settings button is clicked.
Context sensitive help is available through the F1 key or Help menu.
About the INIT.INI File
One of the files unpacked with the program is the INIT.INI file. It contains the entries
below and an explanation has been included on how each parameter may be used.
ErrorLevel=0
Leave this value as is. Only change it at the request of Cirronet Tech Support.
BiDirectionalHigh=55
BiDirectionalMedium=40
ReceiveHigh=55
ReceiveMedium=40
These parameters change the color levels (in percent) on the RF Tools bar
graphs/pie charts.
RFToolsInterval=1000
This parameter sets the how often bar graphs / pie charts will update (in msec)
RSSIMarginal=-60
RSSIPoor=-80
These parameters set the levels (in dBm) of color the bars on the RSSI bar chart will
display. Above the level set by RSSIMarginal, the bars will be green in color.
Between the levels set by RSSIMarginal and RSSIPoor, the bars will be yellow in
color and below the level set by RSSIPoor, the bars will be red in color.
FullShow=0, 1, 2
This changes the number of options that are viewable
0 (default) = Shows minimum amount of options.
1 = Adds all other options.
2 = Adds WinCom.
AutoDetect=1
1 = Auto-detects radio,
0 = User-defined inputs
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
18 of 64
www.murata.com

The parameters below should not be changed as they are specific to different radios.
These parameters will come from the factory set for your radio.
-40dBm=125
-95dBm=55
When the Wizard program is opened, it reads the parameters of the HopNet
radio connected to the PC. These initial parameters are stored by the Wizard
until the program is closed. This function allows the initial parameters to be
loaded into any HopNet radio that is connected to the PC. Clicking on the
Recover button displays the settings stored when the Wizard was first opened
but will not load them in the radio until the Apply Settings is clicked. When the
Apply Settings button is clicked, all the changed values will be loaded into the
radio, even if the changed values are not on the tab currently displayed.
Parameters Tab
The Wizard program opens the main screen with the Parameters Tab
displayed. The parameters screen of the Wizard allows the following variables
to be set;
1. Base or Remote
2. Point-to-Point or Multipoint
3. Baud rate
4. Network number
5. Lockout Key
6. Roaming Mode
7. Protocol Mode
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
19 of 64
www.murata.com

Depending on whether HopNet radio is configured as a Remote or Base
when first connected, the heading on the Parameters page will display either
“Remote Parameters” or “Base Parameters.” If the radio has a Modbus
adapter, Transparent, Modbus and DNP3 selections will appear above the
Point-Point-Multipoint selection as shown below.
Modbus mode is selected to prevent Modbus errors from occurring due to
inter-character gaps that are too long. Refer to the section, Modbus Operation
for details on this mode.
Network Number
This parameter is also known as Set Hopping and is the same command as
wn.(Refer to “Configuration Commands” section for additional information on
commands.) By using different network numbers or “hopping patterns”,
nearby or co-located networks can avoid interfering with each other’s
transmissions.
BaudRate
Also known as Set Data Rate Divisor (command sd) this parameter sets the
serial bit rate between the modem and the host.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2012
HN-210D/X, HN-214D/X Rev. 2.0 01/13/17
20 of 64
www.murata.com
