Espow HD PET CAMERA User manual

HD PET CAMERA
Before using this product, please be sure to read the manual and retain it. Properly use it on the basis of full
understanding of the content. Below design and specifications subject to change without notice.
I. Introduction
This product is a "lightweight" MP3 music digital camera designed for your pet. Built-in large capacity TF card
(maximum support 32GB). Possesses the characteristics of simple, compact, beautiful and practical, portable.
Give you a new perspective to see the world.
1. Camera 2. Hang rope hole 3.Status indicator light 4. Reset hole 5. Microphone 6.USB

7. Function button. 8. Speaker 9. Dial switch
II. Operating Instructions
1．Function keys for the switch of startup, shutdown, and time interval.
2．Dial switches: above is interval taking pictures, middle is MP3, below is interval shooting
3. Micro SD (TF) card socket (built-in), used to insert standard Micro SD (TF) card; 2.5 'USB socket (shown
above), used to connect a computer or charger, is the interface of data transferring, charging and external
power supply.
4.Startup and shutdown: Shortly press button, red light and green light will alternately, slowly blinking, into the
state of corresponding mode, for instance, long press function key in the state of during boot interval recording,
red light will slowly flash for about 6 seconds before indicator goes out, machine will automatically save the
current video file and shut down. Note: In standby state, machine will automatically shut down if no operation
for 3 minutes.
5. Video recording: In the state of recording, dial switch to video mode, then short press button to start
recording, red light flashing, and then short press the button again, go to next time interval mode, keep the
saved video state and recording, blue light slowly flashes, to next time interval setting; in order to ensure the
shot file’s size and security, system will automatically save a file every three minutes and continue to record.
(According to the indication of status lights of different time intervals, indicator light flashes one time every 10
seconds in time interval mode)
Note: Please ensure that camera in an environment with adequate lighting and not covered, also keep the
vertical and stability of the camera body, and keep at least 50cm distance from camera thing to get an image of
correct direction, natural color, and clear screen. Do not block microphone hole in order to ensure a good
recording.
6. Photographing: dial switch to the mode of interval camera status, short press button to camera status, red
light slowly flashes, shoot according to different time intervals, red light flashes one time, completing
photograph and storing. Go back to standby to wait for the next time interval shooting. (Different lights indicate
statuses of different time intervals, indicator light flashes one time every 10 seconds in time interval mode)
Note: Please ensure that camera in an environment with adequate lighting and not covered, also keep vertical
and stability of the camera body, and keep at least 50cm distance from camera thing to get an image of correct
direction, natural color, and clear picture. Do not block microphone in order to ensure a good recording.
Interval status indicator:
press times
State of working
mode
time interval
Status indication
1
photograph
10 seconds
red light flashes(slow)
recording
0 seconds
2
photograph
30 seconds
blue light flashes(slow)
recording
3 minutes

3
photograph
1 minute
Green light
flashes(slow)
recording
10 minutes
7. MP3 music player: dial switch to MP3 mode, blue and green alternately flashes, and start playing music, click
to go to the next one if switch songs. (Special note: this product is a one-button simple playback device, there is
no volume control and goes to previous one options)
Note: Machine can be used normally in adequate power state.
8. Time setting
Camcorder offers a function of recording time displayed in a video file format:
Year - month - day - hour - minute - second
Set time as follows:
Keep good connection with computer through USB cable in machine’s shutdown state, "Removable hard disk"
appears in My Computer. Open WordPad or Notepad in Windows (*. Txt format), input:
2012-08-10-13-30-30
Name file name: SysTime.txt
Save file in root directory of removable disk, disconnect USB cable, then boot the video, time is displayed by
video and photograph is the one that newly revised.
9. Removable disk: when in shutdown or standby mode, you can connect your computer, computer will bounce
out the logo of ejecting removable disk, the file directory of image file: When camera and computer are
exchanging data, indicator light flashes quickly; To uninstall camera click the lower right corner of the taskbar,
removable device Manager icon, and unload removable storage device when system recognizes it is safe to
unplug hardware, and then disconnect camera connected to computer.
10. PC CAM: in mobile hard disk mode, long press button, U disk symbol disappears, USB video camera
function
Note: Identifying removable disk varies due to different computer or system configuration, so please be patient,
you have better not do any operations during this period, so as not to impact computer’s recognizing hardware.
please try to re-insert it if not recognized for a long time disk, make sure that your operating system,
motherboard drivers, 2.5 'USB interface cable work normally; follow standard process to uninstall hardware, so
as not to cause damage to computer or camera.
11. Charge: Connect computer USB port or charger to camera for charging; Red and blue lights flash
alternately when battery is charging, there is a long red light when battery is fully charged.
Note: Camera builds in high-capacity polymer lithium battery, without memory effect, can be used to charge.

Please fully charges and runs for the first five times to active maximum capacity and get standard working time;
In order to maximize battery storage capacity, charge for more 30 to 60 minutes after light indicates fully
charged.
12. Exception handling: Camera power is low, can’t start up, please check whether camera has power or not. If
there is no enough memory, keep status light to its corresponding standby state and lighting, automatically save
current image file and shut down. If you want to continue to use this machine to back up the desired image file
on your computer, and delete old files in the memory to free up enough storage space; if camera battery is low,
blue light flashes, then exterminate, automatically save current image file and shut down. If you would like to
continue to use camera, please charge.
III.parameters
Item
parameter
video format
AVI
video encoding
M-JPEG
Video Resolution
1280*720P
Video Frame Rate
30fps± 1fps
Playing software
Software built in operating system or Mainstream audio and video
Picture format
JPG
Image pixels
2560*1920
Image ratio
4:3
Support system
Windows me/2000/XP/2003/vista/7；Mac os 10.4；Linux；
Charging voltage
DC-5V
Interface type
2.5’USB
Storage support
built-in MicroSD (TF)
battery type
built-in High-capacity lithium polymer
IV. Note
1. Occasions: Please strictly abide by relevant laws; this product may not be used for any illegal purposes, or
peril.
2. Battery: as time goes on, battery working time will be shortened. A fully charged before use if long unused.
3. File Security: This product is non-professional storage devices, and does not guarantee the integrity and
security of internal storage files; please backup your important files on
computer or other storage device immediately.
4. Video recording quality: This product is non-professional video equipment; effect of recording documents
does not guarantee to meet your expectations.
5 Operating Temperature: -20 ° C-40 ° C.
6. Operating Humidity: 20% -80% do not place it in a wet working environment since it is not waterproof.
7. Shooting illumination: Use in lit environment but not place the camera directly to the sun or other strong light
source to avoid damage to optical devices.
8 Cleaning: Do not use in an environment of large dust density, so as to avoid lens and other
parts

contaminated with dust, affecting camera effects. Can use paper of glass cloth to wipe the lens to keep clean.
V. Other matters: This product is a sophisticated electronic product, do not subject it to strong impact or
vibration; Do not use it in strong magnetic field or under strong electric field.
Additional information: Please contact your local dealer for other unknown issues.
